TRENDnet TV-IP422WN User manual

-1-
PREFACE
ThankyouforpurchasingtheSecurViewWirelessNDay/NightPan/Tilt
InternetCamera,apowerfuldual‐codecwirelessnetworkcamerawiththe
2‐wayaudiofunctionthatprovidesthehigh‐qualityimageandon‐the‐spot
audioviatheInternetconnection.TheInfraredLEDsandlightsensor
enablethecameratocaptureimageseveninthedarkenvironment.The
camera’span/tiltfunctionsallowyoutocontrolthecameratomonitor
everywhereremotely.ThroughtheGPIOconnectors,thecameracan
attachavarietyofexternaldevicesforyourspecificpurposes.Thecamera
canbeinstalledasastandalonesystemwithinyourapplication
environmenteasilyandquickly,andsupportsremotemanagement
functionsothatyoucanaccessandcontrolitusingaWebbrowseronyour
PC.
ThisAdvancedInstallationGuideprovidesyouwiththeinstructionsand
illustrationsonhowtouseyourcamera,whichincludes:
Chapter1IntroductiontoYourCameradescribesthefeaturesofthe
camera.Youwillalsoknowthecomponentsandfunctionsof
thecamera.
Chapter2HardwareInstallationhelpsyouinstallthecameraaccording
toyourapplicationenvironment.Youcanusethiscameraat
home,atwork,atanywhereyouwant.
Chapter3AccessingtheCameraletsyoustartusingyourcamera
withoutproblem.Thecameracanbesetupeasilyandwork
withinyournetworkenvironmentinstantly.
Chapter4ConfiguringtheCameraguidesyouthroughtheconfiguration
ofthecamerausingtheWebbrowseronyourPC.
Chapter5Appendixprovidesthespecificationofthecameraandsome
usefulinformationforusingyourcamera.

-2-
Contents
PREFACE..................................................................1
INTRODUCTIONTOYOURCAMERA....................................4
1.1CHECKINGTHEPACKAGECONTENTS..............................................4
1.2GETTINGTOKNOWYOURCAMERA...............................................5
1.3FEATURESANDBENEFITS............................................................7
1.4SYSTEMREQUIREMENT...............................................................9
CHAPTER2.............................................................10
HARDWAREINSTALLATION...........................................10
2.1INSTALLINGTHEWALLMOUNTKIT.............................................10
2.2CONNECTINGTHECAMERATOLAN/WLAN................................11
2.3APPLICATIONSOFTHECAMERA..................................................12
CHAPTER3.............................................................13
ACCESSINGTHECAMERA.............................................13
3.1USINGIPSETUP.......................................................................13
3.2ACCESSINGTOTHECAMERA......................................................14
3.3CONFIGURINGTHEIPADDRESSOFTHEPC...................................18
CHAPTER4.............................................................19
CONFIGURINGTHECAMERA..........................................19
4.1USINGTHEWEBCONFIGURATION..............................................19
4.2USINGSMARTWIZARD.............................................................20
4.3BASICSETUP...........................................................................23
4.4NETWORKSETTINGS................................................................28
4.5PAN/TILTSETTINGS.................................................................37
4.6SETTINGUPVIDEO&AUDIO.....................................................38
4.7EVENTSERVERCONFIGURATION.................................................43
4.8MOTIONDETECT.....................................................................47
4.9EVENTCONFIG........................................................................48
4.10TOOLS...................................................................................53
4.11USB......................................................................................55
4.12DEVICEINFO...........................................................................57

-3-
CHAPTER5.............................................................58
SECURVIEW™PROSOFTWARE.......................................58
5.1INSTALLATION.........................................................................59
5.2USINGSECURVIEW™PRO.........................................................62
CHAPTER6.............................................................93
HOWTOACCESSTHECAMERABEHINDAROUTER..................93
APPENDIX..............................................................99
A.1SPECIFICATION..................................................................................99
A.2GPIOTERMINALAPPLICATION...........................................................102
A.3GLOSSARYOFTERMS........................................................................103


-4-
CHAPTER1
INTRODUCTION TO YOUR
CAMERA
1.1 Checking the Package Contents
Checktheitemscontainedinthepackagecarefully.Youshouldhavethe
following:
5OneTV‐IP422WN
5OnePowerAdapter
5OneExternalAntenna
5OneCameraStand/MountingKit
5OneGPIOConnector
5OneNetworkCable
5OneCD‐ROM(Utility&User’sGuide)
5OneMulti‐LanguageQuickInstallationGuide

NOTEOnceanyitemcontainedisdamagedormissing,contactthe
authorizeddealerofyourlocale.

-5-
1.2 Getting to Know Your Camera
Front View

Power LED
indicates the camera
is powered on with
the steady amber
light.
Light Sensor
is used to trigger on and off the
Infrared LEDs according the
environmental light level.
USB Port*
allows you to connect an
external USB device. It
provides the power
distribution up to 500mA.
Infrared LEDs (x7)
allow your camera to
capture clear image in
a dark environment.
Internal Microphone
allows the camera to
receive sound and voice.
Link LED
indicates the camera’s
network connectivity
with the flashing green
light.

-6-
Rear View
WPS button
Used to connect to your
encrypted Wireless
network
External Antenna
Connector connects the
external antenna.
GPIO Connectors
is used to connect the
external devices.
Audio-out Connector
connects an external
active speaker.
Reset Button
will restart the camera when it is
pressed quickly; when it is
pressed and held for five
seconds, the camera will resume
the factory default settings.
DC Power Connector
connects the AC power
adapter, in order to
supply power to the
camera.
Ethernet Cable Connector
connects the network cable.

-7-
1.3 FeaturesandBenefits
MPEG4/MJPEGDual‐codecSupported
ThecameraprovidesyouwithexcellentimagesbytheMPEG4/MJPEG
dual‐codecselectabletechnology,allowingyoutoadjustimagesizeand
quality,andbitrateaccordingtothenetworkingenvironment.
2‐wayAudioCapability
Thebuilt‐inmicrophoneofthecameraprovideson‐the‐spotaudioviathe
Internet,allowingyoutomonitortheon‐sitevoice.Inaddition,youcan
connectanexternalspeakertothecameratospeakthroughthecamera.
Day&NightSurveillanceSupported
ThesevenInfraredLEDsaroundthestandardlensassemblyenablethe
cameratocapturecrystalclearimagesinthedarkenvironmentoratnight.
WhentheLightSensordetectstheenvironmentallightlevelbecomeslow,
thecameracapturestheimagesinblack&whitemodeusingthese
infraredLEDs.
OptimalViewing
Withthepan/tilefunctions,youcaneasilymonitoreverywhereviathe
camerabymovingthecameralenstotheleft/right(165/165degrees)or
up/down(90/15degrees).Inaddition,youcanassignuptoeightpositions
forthecamera,enablingyoutomovethecameralenstothedesired
positionquickly.
SupportsRTSP
ThecamerasupportsRTSP(RealTimeStreamingProtocol),whichisa
technologythatallowsyoutoviewstreamingmediaviathenetwork.You
canviewthereal‐timevideowiththeQuickTimeplayerorRealPlayer.To
viewthereal‐timestreamingimageonyourcomputer,opentheWeb
browserandentertheRTSPlink:rtsp://(IPaddressofthecamera)/3gp

-8-
SupportsMultipleProfiles
Thecamerasupportsmultipleprofilessimultaneously,sothatyoucan
separatelysetupdifferentimagesettings(suchasimagequalityand
framerate)forthethreevideotypesofthecamera:MPEG4,MJPEG,and
3GPP.
I/OConnectorsProvided
ThecameraprovidestheI/Oconnectorsontherearpanel(IN/OUT),
whichprovidethephysicalinterfacetosendandreceivedigitalsignalsto
avarietyofexternalalarmdevices.Youcanconnectaspecialfeatured
device,andthenconfigurethesettingsandcontrolthedevicefromthe
GPIOTriggerwindowofWebConfiguration.
RemoteControlSupported
ByusingastandardWebbrowserorthebundledSecurViewProsoftware
application,theadministratorcaneasilychangetheconfigurationofthe
cameraviaIntranetorInternet.Inaddition,thecameracanbeupgraded
remotelywhenanewfirmwareisavailable.Theusersarealsoallowedto
monitortheimageandtakesnapshotsviathenetwork.
SupportsConnectiontotheExternalDevices
WiththeauxiliaryInput/Outputconnectors,youcanconnectthecamera
toavarietyofexternaldevices,suchastheexternalspeakerandtheUSB
device.
MultiplePlatformsSupported
Thecamerasupportsmultiplenetworkprotocols,includingTCP/IP,SMTP
e‐mail,HTTP,andotherInternetrelatedprotocols.Therefore,youcanuse
thecamerainamixedoperatingsystemenvironment,suchasWindows
VistaandWindows7.
MultipleApplicationsSupported
Throughtheremoteaccesstechnology,youcanusethecamerasto
monitorvariousobjectsandplacesforyourownpurposes.
Forexample,babiesathome,patientsinthehospital,officesandbanks,
andmore.Thecameracancapturebothstillimagesandvideoclips,so
thatyoucankeepthearchivesandrestorethematanytime.

-9-
1.4SystemRequirement
Networking
LAN:10Base‐TEthernetor100Base‐TXFastEthernet.
WLAN:IEEE802.11b/g,BasedonIEEE802.11nTechnology
AccessingtheCamerausingWebBrowser
Platform:Microsoft®Windows®2000/XP/Vista/Win7
CPU:IntelPentiumIII800MHzorabove
RAM:512MB
Resolution:800x600orabove
UserInterface:Microsoft®InternetExplorer6.0orabove
AccessingtheCamerausingSecurViewPro
Platform:Microsoft®Windows®XP/Vista/Win7
Resolution:1024x768orabove
HardwareRequirement:
1~8cameras:IntelCore2Duo2GBRAM
9~32cameras:IntelCore2Quad4GBRAM

NOTEIfyouconnectmultiplecamerastomonitorvariousplaces
simultaneously,youarerecommendedtouseacomputerwith
higherperformance.



-10-
CHAPTER2
HARDWAREINSTALLATION
2.1InstallingtheWallMountKit
ThecameracomeswithaWallMountKit,whichallowsyoutoplaceyour
cameraanywherebymountingthecamerathroughthethreescrewholes
locatedinthebaseoftheWallMountKit.



Wall Mount Kit
Screw
Screw
Screw

-11-
2.2ConnectingtheCameratoLAN/WLAN
UsetheprovidedEthernetcableto
connectthecameratoyourlocalarea
network(LAN).
WhenyouconnecttheACpower
adapter,thecameraispoweredon
automatically.Youcanverifythe
powerstatusfromthePowerLEDon
thefrontpanelofthecamera.
Onceconnected,theLinkLEDstarts
flashinggreenlightandthecamerais
onstandbyandreadyforusenow.



Ifyouuseawirelessnetworkinyour
applicationenvironment,youneedto
attachtheincludedexternalantenna
tothecamera.
Whenthecameraispoweredon,the
camerawillautomaticallysearchany
accesspointwith“default”SSID.




NOTEIfthecameracannottoyourwirelessnetwork,youneedtoinstall
thecamerainLANandproceedwithWLANsettings.
Connecting the Ethernet Cable
Connecting the External Antenna

-12-
2.3ApplicationsoftheCamera
Thecameracanbeappliedinmultipleapplications,including:
MonitorlocalandremoteplacesandobjectsviaInternetorIntranet.
Capturestillimagesandvideoclipsremotely.
Uploadimagesorsendemailmessageswiththestillimagesattached.
Thefollowingdiagramexplainsoneofthetypicalapplicationsforyour
cameraandprovidesabasicexampleforinstallingthecamera.

HomeApplications


-13-
CHAPTER3
ACCESSINGTHECAMERA
3.1UsingIPSetup
Thecameracomeswithaconvenientlyutility,IPSetup,whichisincludedin
theInstallationCD‐ROM,allowingyoutosearchthecameraonyour
networkeasily.
1. InserttheInstallationCD‐ROMintoyourcomputer’sCD‐ROMdriveto
initiatetheAuto‐Runprogram.
2. ClicktheIPSetupitemtolaunchtheutility.Thecontrolpanelwill
appearasbelow.




3. OnceyougettheIPaddressofthecamera,launchtheWebbrowser
orSecurViewProtoaccessyourcamera.
ClickAbouttogettheVersioninformationofIPSetup.
ClickLinktoconnecttheselectedcamera.
ClickChangeIPtomodifytheIPaddressoftheselectedcamera.
ClickSearchtofindtheIPaddressoftheconnectedcamera(s).
ClickExittoclosetheutility.
Displaytheconnected
camera(s).
Doubleclicktolinkthe
Camera.

-14-
3.2AccessingtotheCamera
Wheneveryouwanttoaccessthecamera:
1. SincethedefaultconfigurationofthecameraisDHCPmodeenabled,
youarerecommendedtolaunchIPSetuptosearchtheIPaddressthat
isassignedtothecamerabytheDHCPserver,andthenclickLinkto
accessthecameraviatheWebbrowser.
2. IfNetworkCameracan'tgetIPAddressunderDHCPmode,thedefault
IPAddresswillbe192.168.10.30.
3. Whentheloginwindowappears,enterthedefaultUsername(admin)
andpassword(admin)andpressOKtoaccesstothemainscreenof
thecamera’sWebConfiguration.

NOTEIfyouareinitiallyaccesstothecamera,youwillbeasktoinstalla
newplug‐inforthecamera.Permissionrequestdependsonthe
Internetsecuritysettingsofyourcomputer.ClickYestoproceed.

EntertheUsername
andPassword.

-15-
AfteryouloginintotheWebConfigurationofthecamera,themainpage
willappearasbelow:


ThemainpageoftheWebConfigurationprovidesyouwithmanyuseful
informationandfunctions,including:
CameraInformation–Displaysthecamera’slocationandthecurrent
date&time.TheinformationcanbemodifiedintheWeb
Configuration.
Pan/Tilt Buttons
Compression Buttons
Live View/Setup Switch
Camera Information
Live View Ima
g
e
Zoom In Buttons
Ni
g
htmode Button
Function Buttons

-16-
LiveViewImage–Displaysthereal‐timeimageoftheconnected
camera.
zMoveyourmousetotheLiveViewareaandclickonanywhere,
thecameralenswillthenmovetothepositionwhereyouclicked
todisplayitinthecentralpartofLiveViewarea.
zWhenyouenlargetheLiveViewbyclickingtheZoomInbuttons
(2xor3x),youcanmovethedisplayedimagebyright‐clicking
yourmouseontheLiveViewarea.Thepositionwhereyouright‐
clickedwillbedisplayedinthecentralpartofLiveViewarea.
ZoomInButtons–Clickthebuttonstozoomintheliveviewimageby
1x,2x,and3x.
NightmodeButton–Clickthebuttontoenablethe“nightshotmode”
todeliverclearerimagesinthedarkenvironment.However,thiswill
reducetheframerateofvideosetting.
LiveView/SetupSwitch–ClickSetuptoconfigurethecamera.For
details,seeChapter4andClicktheLiveViewbuttontoreturntothe
Mainscreentoviewtheliveviewimage.
CompressionButtons–Selecttotransmitandrecordthevideousing
MPEG4orMJPEGcompression.
Pan/TiltButtons–Providesthebuttonstocontrolthecameralens:

zLeft/Right/Up/Down/Homebuttonsallowyoutomovethe
cameralensposition.ClickingtheHomebuttonwillmovethe
cameralenstotheassignedhomeposition.
zAutoPatrolbuttoncontrolsthecameratoautomaticallyscanthe
presetpositionsonce.ClickStoptostoppatrolling.
zClicktheNumberbutton(1~8)tomovethecameralenstothe
presetpositionimmediately.
Tosetupthepresetpositions,movethecameralensbyclicking
theLeft/Right/Up/Downbuttonstothedesiredpositionfirst,then

-17-
selectthenumber(1~8)fromthepull‐downlistandclickthe
Applybutton.Youcanenteradescriptivenamefortheassigned
positioninthetextboxtoidentifyiteasily.

FunctionButtons–Usethesebuttonstocontroltheaudio,video,and
triggerfunctions.
zManualRecordallowsyoutorecordandsaveavideoclip.
zSnapshotallowsyoutocaptureandsaveastillimage.
zBrowseallowsyoutoassignthedestinationfoldertostorethe
videoclipsandstillimages.
zTalkallowsyoutospeakoutthroughthecamera.Pleasenote
onlyoneuserisallowedtousethisfunctionatatime.
zListenallowsyoutoreceivetheon‐sitesoundandvoicefromthe
camera.
zTriggerOutallowsyoutotriggeron/offtheGPIOoutputmanually.


NOTEIfyourPCuseMicrosoftVistaplatform.Maybeyoucan’tfindthese
recordedfileswhatstoredbySnapshotorManualRecord.That
youneedtodisabletheprotectedmodeofSecurityintheIE
Browser.PleasefollowasbelowSteps:
1.OpenIEBrowser
2.SelectToolsÆInternetOptions
3.SelectSecurity
4.Disablethe”EnableProtectedMode”thenpressOK



-18-
3.3ConfiguringtheIPAddressofthePC
Ifyouarefailedtoaccesstothecamera,pleasechecktheIPaddressof
yourcomputer.Whenyouconnectthecameratoyourcomputerdirectly
toproceedwithconfigurationofthecamera,youneedtosetuptheIP
addressestobeinthesamesegmentforthetwodevicestocommunicate.
1. Onyourcomputer,clickStart>ControlPaneltoopentheControl
Panelwindow.
2. Double‐clickNetworkConnectiontoopentheNetworkConnection
window.
3. Right‐clickLocalAreaConnectionandthenclickPropertiesfromthe
shortcutmenu.
4. WhentheLocalAreaConnectionPropertieswindowappears,select
theGeneraltab.
5. SelectInternetProtocol[TCP/IP]andthenclickPropertiestobringup
theInternetProtocol[TCP/IP]Propertieswindow.
6. ToconfigureafixedIPaddressthatiswithinthesegmentofthe
camera,selecttheUsethefollowingIPaddressoption.Then,enteran
IPaddressintotheemptyfield.ThesuggestedIPaddressis
192.168.10.x(xis1~254except30),andthesuggestedSubnetmaskis
255.255.255.0.
7. Whenyouarefinished,clickOK.


-19-
CHAPTER4
CONFIGURINGTHECAMERA
4.1UsingtheWebConfiguration
YoucanaccessandmanagethecamerathroughtheWebbrowserandthe
providedsoftwareapplicationSecurViewPro.Thischapterdescribesthe
WebConfiguration,andguidesyouthroughtheconfigurationofthe
camerabyusingtheWebbrowser.
Toconfigurethecamera,clickSetuponthemainpageofWeb
Configuration.TheWebConfigurationwillstartfromtheBasicpage.

TheWebConfigurationcontainsthe
settingsthatarerequiredforthecamerain
theleftmenubar,includingSmartWizard,
Basic,Network,Video/Audio,Event
Server,Motiondetect,EventConfig,
Tools,USB,andInformation.
