TRENDnet TEW-450APB - Wireless Super G Access Point User manual

The TRENDnet TEW-450APB 108Mbps High Speed 802.11g
Wireless Access Point with XR support, which achieves “wired”
speeds wirelessly with the latest technology. Using frame bursts,
frame compression, fast frames and dynamic turbo, the TEW-
450APB can have speeds up to 108Mbps. The TEW-450APB is also
compatible with standard 802.11b/g and has WPA-PSK, 64/128-bit
WEP security.
TEW-450APB
108Mbps 802.11g Wireless Access Point
TEW-450APB
rev:01.24.2007
• Wi-Fi Compliant with IEEE 802.11g / 802.11b Wireless Devices
• High-Speed Wireless Access Point with up to 108Mbps Connection
• Supports Access Point, AP Client, Repeater and Bridge (PTP & PTMP) Modes
• Support WDS Enable/Disable Function for AP Client & Repeater Modes
• Supports Super G and XR (eXtended Range) Technology Data Rate up to 108Mbps (In AP Mode only)
• Dynamic Data Rate Scaling at 54, 48, 36, 24, 18, 12, 9 and 6Mbps for 802.11g
• Dynamic Data Rate Scaling at 11, 5.5, 2 and 1Mbps for 802.11b
• Supports ESSID Enable/Disable to Increase Security
• Supports 64/128-bit WEP (Hex & ASCII), WPA and WPA-PSK
• Allows 802.1x and Non-802.1x Clients Running Simultaneously
• Adjust Transmit Power (Full / Half (-3dB)/ Quarter(-6dB)/ Eighth(-9dB)/ Min)
• Easy Configuration with Web Browser and Built-in Flash Memory for Firmware Upgrade
• Range for Indoor of 30 ~ 50 meters (depends on the environment)
• Range for Outdoor of 50 ~ 200 meters (without XR), 400 ~ 450 meters (with XR) (depends on the
environment)
• 3-Year Warranty
FEATURES
BENEFITS
Easy Integration:
Setup your own Wireless Hot Spot fast and easy.
Cost-Effectiveness:
Saves on network cable installation fee and on-line charges.
Security:
64/128-bit WEP and WPA protects Access Point from unwanted wireless clients.
Traffic Control:
Controls traffic with MAC Address Filter feature
Note: Coverage and Speed performance might vary depending on the network environment.

• 802.11b: CCK, DQPSK, DBPSK • 802.11g: OFDM
• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
• 2.4 ~ 2.484 GHz
• Direct Sequence Spread Spectrum (DSSS) • Orthogonal Frequency Division Multiplexing (OFDM)
• 802.11b/g: 15±2dBm
• 1~11 Channel (US) , 1~13 Channel (EU)
• Windows Based Utility or Web Browser (HTTP)
• 64/128-bit (WEP), WPA, WPA-PSK, ESSID Control, MAC Address Filter
• 11Mbps 8% PER @ -85 dBm (typical) • 54Mbps 10% PER @ -70 dBm (typical)
• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps • Super G: 108Mbps
•Wired: IEEE 802.3 (10Base-T), IEEE 802.3/802.3u (100Base-TX) , ANSI/IEEE 802.3 Auto Negotiation
• Wireless: IEEE 802.11b (11Mbps), IEEE 802.11g (54Mbps)
• Operating: 0°~ 55°C (32°F~ 131°F) • Storage: -10°~ 70°C (14°F~ 158°F)
• Max. 95% (non-condensing)
• Power, LAN, WLAN
• TCP/IP
• LAN : 1 x 10/100Mbps Auto-MDIX Port
• 1 x 2dBi External Detachable Dipole Antenna (Female Reverse SMA Connector)
• 802.3u : 10/100Mbps Fast Ethernet, IP v4, UDP, ICMP, TCP, DHCP
• FCC, CE
• 5V DC, 2A External Power Adapter
• 146 x 113 x 41 mm (5.7 x 4.4 x 1.6 inches) (without antenna)
• 226g. (8 oz.)
Redio Technology
Temperature
LED Indicator
Protocols
Interface
Antenna
Network Protocols
Power Source
Humidity
Certification
Frequency Range
Data Rate (auto fallback)
Channels
Management
Security
Receiving Sensitivity
Module Technique
Transmit Power
Dimensions (LxWxH)
Weight
Wireless
Standards
Hardware
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet
products and is subject to change at any time, without notice. For the most recent product information please visit
http://www.trendnet.com.
©
Copyright TRENDnet. All Rights Reserved.
108Mbps 802.11g Wireless Access Point
TEW-450APB
RELATED PRODUCTS
PACKAGE CONTENTS
TEW-443PI
TEW-444UB
TEW-441PC 108Mbps 802.11g Wireless PC Card
• CD-ROM (User's Guide)
• Power Adapter (5V, 2A)
108Mbps 802.11g Wireless PCI Adapter
• TEW-450APB
108Mbps 802.11g Wireless USB 2.0 Adapter
• Multi-Language Quick Installation Guide
ORDERING INFORMATION
To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
SPECIFICATIONS
Notebook with
Wireless PC Card
(TEW-441PC)
Workstation with
Wireless PCI Adapter
(TEW-443PI)
Cable/DSL 4-Port
Broadband Router
(TW100-S4W1CA)
Notebook with
Wireless USB 2.0 Adapter
(TEW-444UB)
108Mbps 802.11g
Wireless Access Point
(TEW-450 )APB
108Mbps Wireless 802.11g
Cable/DSL
Modem
Internet
