TRENDnet TPL-310AP User manual

Features
• Powerline
• 1 x 10/100Mbps Auto-MDIX RJ-45 Ethernet port
• Connect one 200Mbps** Powerline AV Adapter to the Internet and then plug in up to 15* additional Powerline AV adapters for instant building
connectivity
• One-touch Sync button networks adapters quickly
• Share data intensive files, play games, download music, and more at ultra fast data transfer rates
• Advanced 128-bit encryption (AES) ensure total network security
• Neighbor network support for up to 4 overlapping networks
• Tri-color LED indicator
• Network signal transmitted up to 300 meters (984ft.)
• Auto QoS support through traffic classification and multiple priority queuing
• Windows-based Powerline configuration utility: compatible with Windows 7 (32/64-bit), Vista (32/64-bit), and XP (32/64-bit) operating systems
• Wireless
• Integrated high performance wireless n access point
• Based on IEEE 802.11n technology and compliant with IEEE 802.11b/g standards
• High-speed data rates of up to 300Mbps*** with IEEE 802.11n
• One-touch Wi-Fi Protected Setup (WPS) button connects wireless clients quickly
• Supports Access Point or Access Point (AP) Client (wireless adapter) mode
• In Access Point mode: expand a wireless network using Repeater mode (listed as AP Mode Support), Wireless Distribution System (WDS), or
Mesh mode (bridging)
• MAC filter feature for added security (AP mode only)
• Wireless security up to WPA/WPA2-RADIUS
• Create a weekly schedule to enable or disable wireless network
• Wi-Fi Multimedia (WMM) Quality of Service (QoS) support
• Broadcast up to 4 SSIDs with different wireless encryption
• Web graphical user interface provides backup, configuration, and firmware management
• Wireless indoor coverage up to 100 m (328 ft.)***
• 3-year limited warranty
* Maximum of 16 adapters (nodes) recommended for streaming video across your network. Additional adapters may decrease performance.
** 200Mbps is the maximum theoretical data rate. Actual throughput will vary depending on environment.
*** Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending
on interference, network traffic, building materials and other conditions.
**** Networked Powerline devices need to be plugged into power outlets that are on the same electrical system.
***** It is not recommended to use this product on electrical systems that use AFCI circuit breakers or plugged into GFI protected outlets as this may
cause performance degradation or loss in connectivity.
PoEpowerline
TPL-310AP
rev:12.20.2010
The 200Mbps Powerline AV Wireless N Access Point, model TPL-310AP, allows
users to create a wireless network from any outlet on their electrical system.
Connect one adapter to your network and plug in up to 15* other adapters for
high speed network access. Connect adapters quickly using the convenient one-
touch 'sync' button. Advanced AES encryption provides optimum Powerline
security, LED displays convey device status for easy troubleshooting, and Quality
of Service technology prioritizes video, audio, and online gaming.
The built in 300Mbps*** wireless n access point offers Access Point, Client,
WDS, and Mesh mode functionality. One-touch Wi-Fi Protected Setup (WPS)
connects wireless clients quickly. Advanced features include 4 SSIDs, different
encryption for each SSID, WMM Quality of Service data prioritization, WPA2-
RADIUS encryption, MAC Access Control, and Spanning Tree support.
TPL-310AP (V1.0R)
200Mbps Powerline AV Wireless N Access Point

SPECIFICATIONS
Interface
Standards
Powerline Frequency
Modulation
Protocol
Wired Speed
• IEEE 802.3, IEEE 802.3x, IEEE 802.3u, IEEE 802.11n, IEEE 802.11b, IEEE 802.11g, IEEE 802.11s, IEEE 802.1d, HomePlug AV
• 10/100Mbps Auto-MDIX RJ-45 Port, Power Prongs
• 2 ~ 28 MHZ
• OFDM Symbol Modulation on link synchronization, 1024/256/64/8 - QAM, QPSK, BPSK, ROBO Carrier
• TDMA, and CSMA/CA
• Windows 7 (32/64-bit), Vista (32/64-bit), XP(32/64-bit)
Hardware
Wireless
Powerline Security
Power Switch
Buttons
Dimension (L x W X H)
• Up to 64 (max.) • Recommended: Up to 16* per powerline network
Utility OS Compatibility
Nodes
• Up to 4 (per electrical system)
Overlapping Powerline
Networks
• 128-bit AES (Advanced Encryption Standard)
• On/Off power switch
• Sync, WPS, Reset
• A: 103 x 81 x 66 mm (4.1 x 3.2 x 2.6 in.)
Powerline Coverage
• Powerline: Up to 200Mbps • Ethernet: Up to 200Mbps ( Full Duplex mode)
• Up to 300m (984ft.)
TPL-310AP (V1.0R)
200Mbps Powerline AV Wireless N Access Point
• Power (PWR), Ethernet Link/Act (ETH) Wireless (WLAN)
• Powerline (PL) w/Connection Quality Indication: • Best (Green)
• Better (Amber) • Good (Red)
LED
• EU: 103 x 81 x 81 mm (4.1 x 3.2 x 3.2 in.)
• A: 100~230V AC, 50~60Hz
Weight
Power Source
Consumption
Temperature
Humidity
Certifications
Modulation
Access Point Modes
Frequency Band
Data Rate***
Security
Antenna
Channel
Output Power
Receiver Sensitivity
• EU: 220~240V/ 5A AC, 50Hz
• 8.4 Watts (max.)
• Operating: 0° ~ 40° C (32° ~ 104° F) • Storage: -10° ~ 70° C (14° ~ 158° F)
• Max. 90% (non-condensing)
• OFDM with BPSK, QPSK, 16QAM, and 64QAM
• 2.412GHz ~ 2.472GHz
• 64/128-Bit WEP (HEX & ASCII), WPA/WPA2 RADIUS, WPA/WPA2-PSK
• 2.4GHz: 1~11 (FCC), 1~13 (ETSI)
• 802.11n Typical -68 dBm
• CE, FCC
• Access Point (AP) • Access Point (AP) Client (wireless adapter) • Wireless Distribution System (WDS)
• Wireless Distribution System (WDS) with Access Point (AP)
• Mesh
• Mesh with Access Point (AP) • Repeater (using AP mode only)
• 802.11b: 1,2,5.5, and 11Mbps • 802.11g: 6,9,12,18,24,36,48 and 54Mbps • 802.11n: up to 300 Mbps
• 1 x 2dBi internal printing dipole antenna
• 16dBm typically @ 802.11b • 14dBm typically @ 802.11g • 13dBm typically @ 802.11n
• 802.11g Typical -73 dBm • 802.11b Typical -84 dBm
• A: 266 g (9.4 oz) • EU: 272 g (9.6 oz)
TPL-310AP
rev:12.20.2010

• Multi-Language Quick Installation Guide
