Trinity EcoStorage TBFZ-1401 User manual

OWNER’S MANUAL
TRINITY ECOSTORAGE® BAMBOO TOP KITCHEN CART
Model # TBFZ-1401
Important / Important / Importante
DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE| DESCARGUE LAAPLICACIÓN GRATUITA
Directives intelligentes
Instrucciones Inteligentes
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D

© 2020 TRINITY - 800.985.5506
Your TRINITY EcoStorage® Bamboo Top Kitchen Cart should include the following parts. Please inspect
box contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via “Contact Us” section at www.trinityii.com.
You will NOT need additional tools for assembly.
1
PARTS LIST
SLIP SLEEVE
(32) + (2) extra
LOCKING
CASTER (2)
BASKET (1)
SIDEBAR
w/4 HOOKS (1)
SHELF –LIP DOWN (1)
BAMBOO
CUTTING BOARD (1)
SHELF –LIP UP (1) CART HANDLE (1)
TOP POLE (4)
End Cap (4) and
Pole Connector (4)
pre-installed
BOTTOM POLE (4)
Threaded Insert (4)
pre-installed
A B C D
E F G H
I J K L
WRENCH (1)NON-LOCKING
CASTER (2)
Note: The black circular plastic spacers in between Shelves are used only for packaging
purposes. They are NOT needed. Please discard.

© 2020 TRINITY - 800.985.5506
ASSEMBLY INSTRUCTIONS
2
A (4) I (8)
STEP 1
STEP 2
Screw each CASTER (J & K) into bottom of each
BOTTOM POLE (A). Turn clockwise to screw in
place. Make sure LOCKING CASTERS are on the
same side.
Use provided caster wrench to tighten
completely. Failure to do as instructed could
result in caster stem breaking.
A (4) K (2)
Note that POLES (A+B) has slight horizontal line
indentations at 1” intervals. Each SLIP SLEEVE (I) has
raised horizontal lines inside designed to lock them in
place on POLES (A+B).
On BOTTOM POLE (A), place 1 pair of SLIP SLEEVES (I) at
desired height no higher than 3rd indentation from the
bottom. Please make sure arrow faces up and word
“TOP” is right-side up. Do this for each BOTTOM POLE (A)
and make sure slip sleeve heights are identical for all
BOTTOM POLES (A).
Slide pair of SLIP SLEEVES (I) until you hear a click to
confirm the pair is locked onto BOTTOM POLE (A). Do
NOT place more than one pair on each BOTTOM POLE (A)
at a time. Do this for each BOTTOM POLE (A) and make
sure height is identical for each BOTTOM POLE (A).
J (2) L (1)
A
J
K
LL
A
II
A
Note: There will be a very small gap in-between two locked SLIP SLEEVES (I)—this is normal.

© 2020 TRINITY - 800.985.5506
ASSEMBLY INSTRUCTIONS
3
STEP 3
STEP 4
Place SHELF –LIP DOWN (E) on its side and slide each BOTTOM
POLE (A) through each corner cylinder on SHELF –LIP DOWN (E).
Make sure SHELF –LIP DOWN (E) corner cylinders are positioned
over SLIP SLEEVES (I).
Stand the unit upright.
Note:
•Level side of SHELF –LIP DOWN (E) is TOP side (TRINITY logo on
corner cylinders should be right-side up.)
•Use a rubber mallet, if needed, to secure SHELF –LIP DOWN (E).
•For convenience, place BOTTOM POLES (A) with Locking Casters
on the same side of shelf.
E (1)
A
AE
Screw TOP POLES (B) into BOTTOM POLES (A). Pole Connectors
are pre-installed in bottom of TOP POLES (B).
Note: The top of each TOP POLE (B) is indicated by a BLACK END
CAP.
B (4)
A
B

ASSEMBLY INSTRUCTIONS
© 2020 TRINITY - 800.985.5506 4
STEP 5
Repeat Step 2 & 3 to assemble BASKET (C), CART HANDLE (G), and
SIDEBAR w/4 HOOKS (H)
Only install ONE item at a time. Make sure to put SLIP SLEEVES (I) at
desired heights for each item.
Note:
•Use a rubber mallet, if needed, to secure BASKET(C), CART
HANDLE (G), and SIDEBAR w/4 HOOKS (H).
G (1) H (1)
C (1)
I (16)
G
H
C
I
I

ASSEMBLY INSTRUCTIONS
STEP 6
Place BAMBOO CUTTING BOARD (D) on top of
SHELF –LIP UP (F). The grooves on the bottom of
BAMBOO CUTTING BOARD (D) will fit exactly on
SHELF –LIP UP (F).
Note:
•Remove BAMBOO CUTTING BOARD (D) to clean
thoroughly.
•Using food safe oil regularly will prevent your
BAMBOO CUTTING BOARD (D) from becoming
dry and brittle.
D (1)
D
STEP 7
Place SLIP SLEEVES (I) at highest position on
TOP POLES (B). Slide SHELF –LIP UP (F) onto
SLIP SLEEVES (I).
Note:
•Use a rubber mallet, if needed, to secure
SHELF –LIP UP (F).
F (1) I (8)
F
I
© 2020 TRINITY - 800.985.5506
5

TRINITY Customer Service provides the following replacement parts:
SERVICE PARTS LIST –TBFZ-1401 Chrome Color
1
8
Part Number Description Part Number Description
1) ONA-20-001-2420 Bamboo Board 8) XXX-97-002-0001 Wrench
2) ZSV-03-008-2216 Shelf (lip up) 9) ZSV-99-008-3010 Locking Caster
3) XBK-01-012-2543 Slip Sleeve 10) ZSV-04-031-1525 Bottom Pole
4) ZSV-02-007-0001 Sidebar w/ 4 Hooks 11) ZSV-01-030-2523 Pole Connector
5) ZSV-21-005-2216 Basket 12) ZSV-04-029-1675 Top Pole
6) ZSV-03-007-2216 Shelf (lip down) 13) ZSV-05-006-1600 Cart Handle
7) ZSV-99-007-3010 Non-locking Caster 14) XBK-23-004-2517 End Cap
2
3
4
5
14
12
6
7
9
10
11
13
© 2020 TRINITY - 800.985.5506 6

WARNINGS
© 2020 TRINITY - 800.985.5506
7
Weight capacity per Shelf (evenly distributed) 200 lb
Weight capacity per Basket (evenly distributed) 65 lb
Total weight capacity of Cart (evenly distributed) 500 lb
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. Use the provided caster wrench to tighten casters completely. Failure to do as
instructed could result in the caster stem breaking thereby causing the product to
collapse.
3. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of the
environment and ensure to use the product in a safe and responsible manner.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product. Any
modifications will void product warranty.
5. Check for damaged parts.Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a
damaged part.
6. Do NOT overload the product.
7. Do NOT allow children to climb or play around the product. Tipping may occur causing
injury.
8. Do NOT stand or lean on the product or use any part of this product as a step ladder.
Tipping may occur causing injury.
9. Do NOT roll the product on an uneven surface. Only move the product on a smooth
surface. Rolling over rough or uneven surface may cause casters to break or items on the
product to fall, resulting in injury and / or damage.
10. Make sure that the wheels are LOCKED when using the bamboo board as a cutting or
work surface.
11. Do NOT leave knifes or sharp objects on the bamboo top unattended.

© 2020 TRINITY - 800.985.5506 8
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•Bamboo board should be hand washed only and periodically treated with food safe oil.
•The product is designed for indoor use.
CARE AND MAINTENANCE

© 2020 TRINITY - 800.985.5506
9
Thank you for purchasing a TRINITY EcoStorage® Bamboo Top Kitchen Cart. In order to register your
product and receive streamlined customer service, please fill out the following Product Registration
Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at
www.trinityii.com or (3) scan and email the form to [email protected]om. Include a copy of
your original receipt with your submission.
First Name: Last Name:
Address:
City: State: Zip Code:
Email Address: Phone:
Product Model #: TBFZ-1401 Purchase Date: / /
Location of Purchase:
Please rate the importance of each feature (1=least important; 10=most important)
Quality Price Size/Capacity Appearance Other
How did you hear about our product?
Magazine Ad Catalog Salesperson Word of Mouth
Internet Store Display Other
Marital Status: Single Married
Household Income: Below $50,000 $50,000-$150,000 $150,000+
Education: High School College Graduate School
Primary Residence: Own Rent
Comments/Suggestions:
PRODUCT REGISTRATION

1 YEAR LIMITED WARRANTY
TRINITY EcoStorage® Bamboo Top Kitchen Cart
Model # TBFZ-1401
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the
TRINITY EcoStorage® Bamboo Top Kitchen Cart (“Product”) that each Product shall be free from defects in
workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation
under this warranty shall be limited to repair or replacement of, or adequate compensation for the Product
which shall not be greater than the amount of the purchase price of the Product, at the option of Trinity,
during the warranty period. All replaced parts and Products become the property of Trinity and must be
returned to Trinity.
This warranty excludes normal wear and tear of the Product and its parts or components, and damage arising
from any of the following: negligent use or misuse of the Product, use contrary to this User’s Manual, or
alteration by any one other than Trinity. The warranty period of 1 year shall not be extended or renewed by
the repair or replacement of, or compensation for, the Product. Any warranty implied by applicable law is
limited in duration to one year from the date of purchase and is subject to the same conditions and
limitations as is provided for our express warranty.
Except as set forth herein, and to the extent of applicable there are no warranties on this Product either
express or implied, and Trinity disclaims all warranties including, but not limited to, any implied warranties of
merchantability, infringement or fitness for a particular purpose. No warranty or guarantee given by any
person, firm, or corporation with respect to this product shall be binding on Trinity.
If your Product is defective or otherwise requires service or parts, please call TRINITY Customer Service toll-
free at [phone], between 5:00 a.m. and 5:00 p.m., PST. Please tell us which model you purchased,
the date of the purchase, and the problem with your Product. A copy of your original purchase receipt must
accompany your service request.
LIMITATION OF REMEDIES AND LIABILITY
Trinity (and its employees, officers, members, managers, affiliates and assigns) shall not be liable for any
incidental, consequential, special, indirect, remote, special or punitive damages for breach of any warranty,
express or implied, including, but not limited to, lost profits, lost savings, loss of anticipated benefits and
attorneys’ fees, which arise out of the purchase, use or inability to use the Product, whether arising out of
contract, negligence, strict tort, product liability, or any other legal theory on which a claim is based. As
noted above, to the extent damages are allowed by our express warranty or by applicable law, those
damages may not exceed the purchase price paid for the Product. Without limiting the foregoing Purchaser
assumes all risk and liability for loss, damage or injury to Purchaser and Purchaser’s property and to others
and their property arising out of the use, misuse, or inability to use this Product. This limited warranty shall
not extend to anyone other than the original purchaser of this product, is nontransferable and states your
exclusive remedy.
Some states do not allow the exclusion or limitation of incidental, consequential, special, or punitive
damages, so the above limitation or exclusion may not apply to you. The above warranty gives you specific
legal rights, and you may have other rights which vary from state to state.
© 2020 TRINITY - 800.985.5506 10

TRINITY Customer Service
TEL: [phone]
FAX: [phone]
EMAIL: [e-mail]
Monday through Friday
5:00 AM –5:00 PM (PST)
www.trinityii.com
QUESTIONS? NEED PARTS?
WE ARE HERE TO HELP!
Please feel free to contact us. There are no questions too small, or
any problems too big. We’re committed to providing our customers
with the highest level of service.
CONTACT US
