Trinity TBFPBR-2103 User manual

OWNER’S MANUAL
TRINITY 3-Bag Laundry Cart
Model # TBFPBR-2103 / TBFPNC-2103
Everything in its place.®

© 2018 TRINITY - 800.985.5506
1

Your TRINITY 3-Bag Laundry Cart should include the following parts. Please inspect box contents to
ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via our “Contact Us” section at www.trinityii.com.
All tools required for assembly are included.
PARTS LIST
© 2018 TRINITY - 800.985.5506 2
SIDE FRAME (2)
A
BOTTOM SHELF (1)
B
POLE (4)
C
SCREW (12)
D
E F
I
LAUNDRY BAG (3)
J
HANDLE (6)
LOCKING CASTER (2)
G
NON-LOCKING
CASTER (2)
H
HEX KEY (1)WRENCH (1)

ASSEMBLY INSTRUCTIONS
© 2018 TRINITY - 800.985.5506
3
A
H
J
B (1) H (6)C (4) J (1)
STEP 1
STEP 2
H (6) J (1)
A (1)
A (1)
H
A
J
Lay the SIDE FRAME (A) on its side with
the TRINITY logo facing out. Attach the
BOTTOM SHELF (B) to the SIDE FRAME (A)
using SCREWS (H) and the HEX KEY (J).
Then attach POLES (C) to the SIDE FRAME
(A), using SCREWS (H) and the HEX KEY (J).
Repeat instructions in Step 1 to attach the second SIDE
FRAME (A) with the TRINITY logo facing out.

ASSEMBLY INSTRUCTIONS
© 2018 TRINITY - 800.985.5506 4
E
F
D
F (2) G (2) I (1)
STEP 3
STEP 4
D (6) E (3)
G
I
Screw CASTERS (F+G) into the nuts at the bottom of the
SIDE FRAMES (A). Turn clockwise to screw in place.
Make sure the LOCKING CASTERS (F) are on the same
side.
Use the provided WRENCH (I) to tighten completely.
Failure to do as instructed could result in the caster
stem breaking.
Stand the unit upright. Insert the HANDLE (D) through the
loops at the top of the LAUNDRY BAG (E). Repeat for
remaining (5) HANDLES (D).
Hang the LAUNDRY BAGS (D+E) on the POLES (C) as shown
in the diagram.

SERVICE PARTS LIST –TBFPBR-2103 / TBFPNC-2103
Part Number Description Part Number Description
1) PBR-05-013-1675 Handle –Bronze 8) XXX-97-002-0001 Wrench
2) PNC-05-013-1675 Handle –Champagne 9) ZSV-99-009-2008 Non-locking Caster
3) XWH-24-002-0814 Laundry Bag 10) PBR-03-017-2617 Shelf –Bronze
4) ZBK-01-002-0618 Screw 11) PNC-03-017-2617 Shelf –Champagne
5) LNA-14-007-1730 Side Frame –Bamboo 12) XXX-97-001-0001 Hex Key
6) LWH-14-007-1730 Side Frame –White 13) PBR-13-007-2600 Pole –Bronze
7) ZSV-99-010-2008 Locking Caster 14) PNC-13-007-2600 Pole –Champagne
TRINITY Customer Service provides the following replacement parts:
5
3
1
4
10
© 2018 TRINITY - 800.985.5506
5
6
7
8
14
2
9
11
12
13

© 2018 TRINITY - 800.985.5506 6
WARNINGS
CARE AND MAINTENANCE
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and/or damage.
2. Use the provided WRENCH to tighten casters completely. Failure to do as instructed could
result in the caster stem breaking thereby causing the laundry cart to collapse.
3. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of their
environment and ensure that they use the product in a safe and responsible manner.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and/or safety of the product, and may affect the life of the product.
5. Check for damaged parts. Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
6. Do NOT overload the product.
7. Do NOT stand on the bottom shelf.
•Laundry Bags are made of 100% cotton, and are fully washable.
•Machine wash warm
•Tumble dry low
•Do not bleach
•Laundry bag handles MUST be removed before washing.
•Bamboo can be maintained with mineral oil for best results.
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
Weight capacity per bag 15 lbs
Total weight capacity of laundry cart 40 lbs
