Trinity TBFZ-0902 User manual

ITM. / ART. 403516
OWNER’S MANUAL
TRINITY ECOSTORAGE™ NSF 3-TIER CART
Model # TBFZ-0902 / CTBFZ-0902
Important / Important / Importante
DOWNLOAD THE FREE APP | TÉLÉCHARGER L’APPLICATION GRATUITE| DESCARGUE LAAPLICACIÓN GRATUITA
Directives intelligentes
Instrucciones Inteligentes
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D

PARTS LIST
431
A B C
D
28 + 4 2
E F
G
2
1
Your TRINITY EcoStorage™NSF 3-Tier Cart should include the following parts. Please inspect box
contents to ensure you have received all components.
If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY
Customer Service: 800.985.5506 or [e-mail]. Parts can also be requested online
via “Contact Us” section at www.trinityii.com.
You will NOT need additional tools for assembly.
Note: The black circular plastic spacers in between Shelves are used only for packaging
purposes. They are NOT needed. Please discard.
© 2020 TRINITY - 800.985.5506 1

ASSEMBLY INSTRUCTIONS
Warning: Tighten CASTERS (E & F) to POLES (A)
completely. Failure to do as instructed could
result in the caster stem breaking.
A (4) E (2)
STEP 1
F (2) D (8)
STEP 2
Note: For stability, the lowest SLIP SLEEVES (D)
should be installed no higher than the 3rd
indentation from the caster end of the POLES
(A).
G (1)
DD
A
EF
AA
© 2020 TRINITY - 800.985.5506
2

ASSEMBLY INSTRUCTIONS
STEP 3
Note: The level side of the SHELF (B) is the TOP
side (the TRINITY logo on the corner cylinders
should be right-side up).
D (8)
STEP 5
B (2)
D (16)
STEP 4
D
B
D (4) C (1)
C
B (1)
B
D
© 2020 TRINITY - 800.985.5506 3

SERVICE PARTS LIST –TBFZ-0902 / CTBFZ-0902 Chrome Color
© 2020 TRINITY - 800.985.5506
4
TRINITY Customer Service provides the following replacement parts:
Part Number Description Part Number Description
1) XBK-01-011-2543 Slip Sleeve 5) ZSV-99-008-4010 Locking Caster
2) ZSV-04-009-3100 Pole 6) ZSV-05-006-1800 Cart Handle
3) ZSV-99-007-4010 Non-locking Caster 7) XBK-23-004-2517 Endcap
4) XXX-97-002-0001 Wrench 8) ZSV-03-007-3618 Shelf
1
2
3
4
5
6
7
8

WARNINGS
CARE AND MAINTENANCE
1. Read and understand all instructions. Failure to follow all instructions may result in injury
and / or damage.
2. Tighten all casters completely by using the wrench. Failure to do as instructed could result
in the caster stem breaking, thereby causing the product to collapse.
3. The warnings, cautions, and instructions discussed in this manual cannot cover all
possible conditions or situations that may occur. The user must always be aware of the
environment and ensure to use the product in a safe and responsible manner.
4. Do NOT modify the product in any way. Unauthorized modification may impair the
function and / or safety of the product, and may affect the life of the product. Any
modifications will void product warranty.
5. Check for damaged parts.Before using this product, carefully check that all parts are in
good condition, and that the product will operate properly and perform its intended
function. Check for damaged parts and any other conditions that may affect the operation
of this product. Replace damaged or worn parts, and never use this product with a damaged
part.
6. Do NOT overload the product.
7. Do NOT allow children to climb or play around the product. Tipping may occur causing
injury.
8. Do NOT roll the product on an uneven surface. Only move the product on a smooth
surface. Rolling over rough or uneven surface may cause casters to break or items on the
product to fall, resulting in injury and / or damage.
9. Lock all locking casters when leaving the product in stationary position.
10. Load the product evenly and place the heaviest items on the lower shelves.
Weight capacity per Shelf (evenly distributed) 120.3 kg / 265 lb
Total weight capacity of Cart (evenly distributed) 363 kg / 800 lb
•Avoid harsh, abrasive cleaners, and other corrosive chemicals.
•This product is not recommended for outdoor use.
© 2020 TRINITY - 800.985.5506 5
