DazeTechnology DazeBox User manual







DazeBox (V5.1)
Installation, use and maintenance manual


1
ENG - June 2020 - Rev. 1

Summary

1. Introduction 3
1.1. Warning on information properties 3
1.2. Declaration of conformity 3
1.3. Safety information 3
1.4. Warranty 4
2. Description 5
2.1. Description of the machine 5
2.2. Structure 5
2.3. Technical features 5
3. Use 8
3.1. Intended use 8
3.2. Unintended use 8
4. Installation 9
4.1. Supply 9
4.2. Transport and storage 9
4.3. Preliminary checks 10
4.4. General Criteria for selecting the place of installation 10
4.5. Assembly 11
4.6. Electrical connection 12
4.7. Commissioning 15
5. Maintenance 16
5.1. Differential protection test 16
5.2. Assistance 17
6. Visual signs and alarms 18
7. Disposal 19
Contact 20

 
2
ENG - June 2020 - Rev. 1

1. Introduction


1.1. Warning on the properties of the information
The information contained in this manual belongs to DazeTechnology srl and may not be reproduced in               
whole or in part.
This manual is supplied with the machine to the Customer.
The Customer must follow the instructions for use and maintenance indicated in this manual; otherwise              
Daze Technology srl declines all responsibility. It is understood that the Customer is also required to use                
the machine operating in the "intended use" conditions indicated in this manual in order to avoid damage to                 
persons or property.


1.2. Declaration of conformity
DazeTechnology srl declares that the DazeBox device complies with the requirements for the release of the               
EC declaration of conformity, according to the Directive 2006/42 / EC Machinery and the Directive              
2004/108 / CE emc.


1.3. Safety information
The device has been developed, constructed and checked in compliance with current safety regulations.             
Therefore, the product does not normally entail any danger to people or things. The machine and its                
components are designed in such a way that they cannot be used abnormally if this could lead to additional                  
risks for the user.
Daze Technology does not assume any responsibility for any damage to persons or things deriving from               
not complying with safety regulations and these recommendations.
All machine installation, use and maintenance operations must be performed only by qualified and             
authorized personnel. Daze Technology srl does not assume any responsibility for damage to persons or              
things deriving from the use of unqualified operators.



Warnings!
▪Read these instructions carefully before using the device.
▪The device must be installed by qualified personnel.
▪Before working on the machine for maintenance or cleaning operations, disconnect the machine from             
the power supply line by disconnecting the main plug. All machine installation, use and maintenance              
operations must be performed only by qualified and authorized personnel.
3
ENG - June 2020 - Rev. 1

▪The owner of the machine (customer) must ensure that it is always used in perfect condition. In this                 
regard, always keep the device clean and periodically perform visual checks on the outside of the               
device, on the power cord and on the charging plug, looking for any damage or residual dirt.
▪If the column is damaged ,it must be immediately disconnected and replaced.
▪The charging station should only be used to charge electric vehicles and plug-in hybrids. Do not               
connect with other electrical devices.
▪The product does not have its own grid switch. The disconnection from the electric grid takes place                
through the device connector and the magnetothermal switch of the building system.
▪Do not use extension cords to connect the device to the electric grid.
▪Make sure that the power supply cable of the wallbox is not damaged mechanically (by bending or                
crushing it with the vehicle). After use, place the plug in the connector holder.
▪Be careful not to damage the charging station.
▪Daze Technology srl assumes no responsibility for any damage to the body of the product due to                
accidents.
▪The use of the machine in an explosive atmosphere is not permitted.
▪The modification of parts of the components or the addition of optional equipment to the device is not                 
permitted.
▪Do not remove any labels such as safety symbols, cable codes or nameplates.
▪During operation, the device cannot be exposed to direct radiation such as sunlight, as these can               
produce overheating of the internal environment, where the electrical equipment is located, degrading            
the insulating materials.
▪The degree of protection of the machine is IP54; that is, the environment of use must be clean, in the                   
absence of dust or vapors.


1.4. Warranty
Daze Technology srl guarantees the regular operation of the machine (as long as it is used in the conditions                  
of intended use) for the period established in agreement with the DazeTechnology srl Sales Office and               
regularly registered in the sales contract.
Daze Technology srl guarantees all its machines from factory defects for a period of 24 months starting                
from the delivery date. This guarantee consists in restoring efficiency, through free replacement or repair,              
of items that are unusable or inefficient due to factory defects and / or assembly errors. This warranty is                  
void if the defect can be connected with:
●Failure to perform the minimum maintenance interventions prescribed in the manuals.
●Carelessness.
●Accidents.
●Late complaint of the defect.
●Improper use.
●Unauthorized modification.
●Repair with non-original spare parts.
For each component sent to Daze Technology srl for inspection, repair or replacement, whether to be               
performed free of charge or against payment if the warranty period has expired, the Customer must               
compulsorily complete a document with the identification data of the machine and the largest number of               
information relating to the fault. This will improve the "Customer Service" and minimize the costs and time                
required for the revision or replacement of defective parts.
We emphasize that if we do not receive the defective part, no later than 30 days from the shipping date of                    
the new spare part, we will automatically proceed with billing. 
4
ENG - June 2020 - Rev. 1

2. Description

2.1. Description of the machine
DazeBox is a device for recharging electric vehicles or plug-in hybrids.
The charging is carried out in mode 3, in compliance with the IEC / EN 61851-1 standard, which consists in                   
connecting the electric or rechargeable hybrid vehicle to the AC mains supply using specific connectors, in               
compliance with IEC 62196-1 and 2, and in the presence of a pilot control circuit inside the station for                  
checking the continuity of the protective conductor between the vehicle and the network during charging.              
This check is necessary to ensure that no dangerous voltage can be discharged through the accidental               
contact of unaware persons. Mode 3 is therefore recommended for its maximum degree of safety and also                
for its ability to deliver high currents.
The control circuit also provides for the communication between the charging station and the vehicle              
through the PWM (Pulse Width Modulation) described in attached A of the IEC / EN 61851-1 standard: the                 
station communicates to the vehicle the availability of the grid through a frequency modulated signal, the               
vehicle adapts the load by returning its state through a voltage value (for mode 3 the function is performed                  
by means of a "typical" pilot control circuit).

2.2. Structure
The frame of DazeBox is made of aluminum, to ensure high stability and rigidity. The body and body parts                  
are in plastic.
Each design element is the result of in-depth studies aimed at providing an ergonomic, agile and intelligent                
work tool.


2.3. Technical characteristics
Overall body dimensions: Length: 335 mm; Width: 277 mm; Height 95mm (plug not included).
Weight: about 4 kg.


5
ENG - June 2020 - Rev. 1


Figure 1. DazeBox charging station and its external components.



Figure 2. Dimensions of the DazeBox charging station.


6
ENG - June 2020 - Rev. 1


Body colors: Glossy white RAL9010; Dark gray textured RAL9005
Cable routing: open. Connection with wall socket.
Grid configuration: TT / TN / IT.
Environmental storage conditions: -30 ° C to + 80 ° C.
Operating temperature range at 32 A: from -25 ° C to +45° C (without direct exposure to sunlight).
Protection degree: IP54

There are three types of DazeBox for three different recharging powers, in accordance with customer              
needs.

Model
DazeBox 22
DazeBox 7
Max.
22 kW
7.4 kW
Power supply
400 V three-phase (3P +
N + T);
50/60 Hz
230 V single-phase (1P + N
+ T);
50/60 Hz
Rated current
32 A
32 A
Power
management
No
Optional

 
7
ENG - June 2020 - Rev. 1

3. Use

3.1. Intended use
DazeBox, for indoor and outdoor applications, is suitable for recharging in commercial or private parking of               
Plug-in electric and hybrid vehicles. The charging station is designed to be installed on a wall or column.
DazeBox has been designed, built, tested and documented in accordance with current regulations and             
safety standards.
The instructions in this manual must be followed carefully. Otherwise dangerous situations could arise. In              
addition to these instructions, the general safety regulations for risk prevention must be followed.
This device must be grounded. In the event of damage, grounding reduces the risk of electric shock.

The illustrations and explanations in this manual refer to a typical version of the device. The version to                 
which this manual is linked may be slightly different.

In normal operating conditions (once installed and connected to the network), DazeBox is in stand-by,              
awaiting charging. The status of the LEDs is pulsed green.

To charge the vehicle, pull out the charging cable by always holding it by the plug and never by the cable                    
itself and connect it to the vehicle socket. The status of the LEDs will turn into a green and blue, as it is                      
being verified.

Once the machine is connected and accepts the cable, the vehicle is charging and the status of the LEDs                  
will turn to pulsed blue.

The charging cycle ends by disconnecting the charging cable. Other details are described in the manual               
provided by the vehicle manufacturer. At the end, the plug must be placed neatly in the connector holder in                  
the center of the DazeBox.

3.2. Unintended use
It is to be considered unintended use any condition of use in which one or more of the conditions expressed                   
in "Intended use" are not observed.
Daze Technology srl does not assume any responsibility for damage to persons or things deriving from               
unintended use of the machine.

Do not try to open the device manually.
Do not charge any other electric instruments except for electric and plug-in hybrid cars. 
8
ENG - June 2020 - Rev. 1

4. Installation
The installation must be performed by qualified personnel and equipped with protective clothing. Daze             
Technology srl assumes no responsibility for any damage to the device resulting from failure to comply               
with the instructions provided.
If the installation is not explicitly covered by the DazeTechnology srl sales contract, we will be pleased to                 
assist you in finding a qualified installer.
Do not make arbitrary changes to the device. Repairs may only be carried out by the manufacturer or by                  
specialized personnel.
Do not remove safety symbols, danger warnings, cable labels or tags.


Warning!
If it is raining or snowing and DazeBox is located outdoors, do not open the device. Wait for the charging                   
cycle to be completed and for the vehicle to be disconnected before opening the device.


4.1. Supply
Inside the packaging is supplied:
●DazeBox with Type 2 cable of 3 or 5 meters. The 5 version is equipped with a cable holder.
●Installation, use and maintenance manual (this document).
●Resistance kit
●Screws and dowels


4.2. Transport and storage
The machine parts are protected with a bubble wrap and sealed with adhesive tape. The whole is placed in a                   
cardboard box.
Do not place loads on the box. On the box there are clearly visible signs with indications of the type in figure                     
3.

Figure 3. Pictograms on the packaging. From the left: Do not place loads on the box; Do not overturn; Tall.

After storage and transport to the place of installation and immediately before installation, prepare the              
machine by removing it from the box and removing the packaging sheet.


9
ENG - June 2020 - Rev. 1

4.3. Preliminary checks
Check that the various parts of the machine do not exhibit physical damage due to bumps, tears or                 
abrasions.
In the event that damage is found, interrupt the installation procedure and report the nature of the damage                 
to the person in charge of the machine. If necessary, contact the DazeTechnology srl sales office.
Clean the machine, removing dust and residues of bubble wrap and adhesive tapes.

Transport the charging station manually in order to install it on the wall suitable for installation.
 Warning
During handling by hand there is a risk of tripping on the vehicle power cable.


4.4. General criteria for choosing the place of installation
Before starting to transport the machine parts from the storage area to the place of installation, check the                 
feasibility of the place of installation. The place of installation must be suitable and free of materials and                 
equipment on the entire surface required for handling, between the place of storage and the place of                
installation (included).
▪The position chosen for installing the machine must allow easy connection to the power supply line.
▪Respect the local regulations in force for electrical installations, fire prevention measures and rescue             
ways at the place of installation.
▪Do not install the device in places:
- at risk of explosion (EX environment).
- used as escape routes.
- where objects can fall (eg hanging stairs or car tires).
- in which it is possible that it is hit by jets of water under pressure (eg due to washing                  
systems, high pressure cleaners, garden hoses).
▪If possible, install the device so that it is protected from direct exposure to rain, to avoid for example                  
deterioration due to inclement weather, freezing, damage due to hail or similar.
▪If possible, install the device so that it is protected from direct sunlight.
▪Respect the allowed environmental conditions (from -10 ° C to + 55 ° C).
▪The surface on which the device is placed must be flat.
▪Comply with the national and international regulations in force concerning construction and the            
directives, for example IEC 60364-1 and IEC 60364-5-52.

The correct positioning of the charging station is very important for the operation of the equipment.
When choosing the mounting position, take into account the position of the charging connection on your               
vehicle and the usual parking direction: especially for Dazebox equipped with a 3 meter long charging cable,                
it is important to position the charging station near the position of the socket of the parked vehicle.



Around the charging station it is necessary to leave the space free to ensure ease of use. If several                  
DazeBoxes are installed close to each other, a distance of at least 200 mm must be left between the                  
DazeBoxes.


10
ENG - June 2020 - Rev. 1

For Dazebox equipped with a 3-meter cable refer to figure 4.



Figure 4. Depiction of mounting on the wall with relative dimensions of the DazeBox with 3-meter cable.


For Dazebox with 5-meter cable and cable holder refer to figure 5.


Figure 5 . Depiction of mounting on the wall with relative dimensions of the DazeBox with 5 meter cable and cable holder.
11
ENG - June 2020 - Rev. 1

4.5. Mounting
The electrical connection (power supply line) must have been prepared.

To install the charging station it is necessary to open the cover by unscrewing 3 Allen screws. Remove the                  
black plate. Remove the white and black plastic body that is interlocking.
For wall mounting it is necessary to use 3 plugs 8 mm diameter and screw the aluminum back plate of the                    
device.

The installation height must be respected: 1400-1500 mm with respect to the lower edge of the plate (figure                 
4) for the 3-meter cable version; 1200-1500 mm with respect to the lower edge of the plate (figure 5) for the                    
5 meter cable version.
Mark the three holes using a drilling template and a spirit level. Then drill the fixing holes and insert the                   
plugs (figure 6).
Screw the plate to the wall with the screws suitable for the dowels.


Figure 6. Holes for the screws with which the DazeBox is fixed to the wall.

4.6. Electrical connection

Selection of the differential switch
The power supply line must be installed and permanently wired in the already existing domestic system to                
comply with the national laws in force.
12
ENG - June 2020 - Rev. 1

▪The DazeBox device must be permanently connected to the electrical system through its own             
differential switch. No other electrical circuits must be connected to this differential switch.
▪The differential switch must be at least type A (30 mA tripping current) for installation in Italy. For                 
installation in another country of the European Community, a type B differential is required.
▪In addition, the differential switch can be of type A for single-phase installations, while it must               
necessarily be type B for three-phase installations (CEI 64-8-7 -722).
▪The nominal current chosen must be suitable for the circuit breaker and the fuse.

The earth connection is ensured by the user's system.
The device does not have its own electric grid switch. The differential switch and / or the magnetothermal                 
switch of the power supply line act as a grid separation device.
The electrical connection (power supply line) must have been prepared.


Current setting for Dazeboxes without power management.
The current is regulated by means of the selector on the board (figure 7). Each combination of the dip                  
switches corresponds to a specific current of use. The relative power at which the Wallbox operates is                
shown in table 6.1 for both the single-phase (1F) and the three-phase (3F) wallbox.


Figure 7. Selector to adjust the current.














13
ENG - June 2020 - Rev. 1

Dip switch
Power
management
Corrente max
Potenza max 1F
Potenza max 3F
1
2
3
4
A
kW
kW
0
0
0
0
PM OFF
6,500
1,5
4,5
0
0
0
1
PM OFF
8,000
1,8
5,5
0
0
1
0
PM OFF
13,000
3,0
9,0
0
0
1
1
PM OFF
16,000
3,7
11,1
0
1
0
0
PM OFF
19,000
4,4
13,2
0
1
0
1
PM OFF
22,000
5,1
15,2
0
1
1
0
PM OFF
26,000
6,0
18,0
0
1
1
1
PM OFF
32,000
7,4
22,2

Table 6.1. Table for selecting the power of the Wallbox.


The number zero "0" refers to a dip switch positioned downwards (referring to figure 7), while the number                 
one "1" refers to a dip switch positioned upwards.

Power management system setting.

The installation of power management involves connecting the current transformer to the electric meter. In              
order to complete the installation, a 0.5 mm shielded bipolar cable must be procured. It has to be long                  
enough to to connect the current transformer from the electric meter to the DazeBox. The amperometric               
ring must be inserted on the line cable at the output of the general meter before each branch as shown in                    
figure 8.


Figure 8. Amperometric ring positioned under the meter.

The amperometric ring, already equipped with a 30 cm cable, must be connected to the shielded bipolar                
cable.
Once the shielded bipolar cable has been brought to the DazeBox, pass it through the specific PG shown in                  
figure 9.

14
ENG - June 2020 - Rev. 1


Figure 9. PG cable type 2 (SX), PG power management (in the center), PG power supply (DX).


The shielded bipolar cable must be connected to the terminal blocks circled in red in figure 10. The two                  
cables are interchangeable. Before reaching the two terminal blocks, the bipolar cable must be unsheathed              
and positioned in the earth terminal circled in yellow. It is important that the cable is properly stripped and                  
that the shielding is well in contact with the earth terminal.



 Figure 10. Power management wiring


Once the electrical connection is complete, the current can be adjusted. Using the current selector indicated               
in figure 7, select the charging power available at the meter to which the DazeBox has been connected. The                  
number zero "0" refers to a dip switch positioned downwards (referring to figure 7), while the number one                 
"1" refers to a dip switch positioned upwards. The possible combinations and the relative reference powers               
are indicated in table 6.2


15
ENG - June 2020 - Rev. 1


Dip switch
Power
management
Corrente max
Potenza max
1
2
3
4
A
kW
1
0
0
0
PM ON
13,043
3
1
0
0
1
PM ON
15,217
3,5
1
0
1
0
PM ON
17,391
4
1
0
1
1
PM ON
19,565
4,5
1
1
0
0
PM ON
21,739
5
1
1
0
1
PM ON
23,913
5,5
1
1
1
0
PM ON
26,087
6
1
1
1
1
PM ON
30,435
7

Table 6.2. Table for selecting the maximum power available in the house.

Connecting the power supply line
1. Shorten the connection wires to the appropriate length. The wires must be as short as possible.
2. Remove approximately 12 mm of insulation from the connection wires. For thin connection wires it              
is recommended to use end sleeves.
3. Connect the power supply line L1, L2, L3, N and PE (figures 8).
4. Unscrew the terminal screws with a star screwdriver.
5. Push each connection wire with the insulation removed into the power supply terminal.
6. Retighten the screws to close the contacts and check the correct connection of the connection              
cables.



Figure 11. Power supply line wiring.
.


16
ENG - June 2020 - Rev. 1

4.7. Commissioning
●Clean the connection area (remove material residues and dirt).
●Before commissioning, check that all screw are correctly fastened.
●Switch on the supply voltage. After the self-test the status LED of the Viridian must light up after                 
15-20 seconds in blue and the general status LEDs light up green.
●Perform the initial checks required by local directives and laws in force.
●Close the DazeBox connection panel cover.
●Fit the housing cover.
Before starting up the system for the first time, check the effectiveness of the relative safety measure(s)                
according to the national regulations in force.
Electrical systems or devices must be checked by the manufacturer of the system or device before being                
put into operation for the first time. The same also applies to the expansion or modification of existing                 
electrical systems or devices. However, we expressly draw your attention to the need to comply with all the                 
safety measures.
The points to be considered include the following:
1. Checks: continuity of the protection conductor connections, insulation resistance, residual current          
of the differential switch, intervention time must be checked on the extended and / or modified part.
2. The measuring instruments used must comply with national regulations, eg DIN EN 60557 (VDE             
0413) "Electrical safety in low-voltage grids up to AC 1000V and DC 1500V".
3. Measurement results must be documented. On the basis of the check, a test report must be               
compiled to be kept.
5. Maintenance

Before intervening on the machine for any maintenance operation, wait for the machine to stop completely               
and switch it off by activating the main stop switch. Disconnect the machine from the power supply line by                  
operating the main switch on the electrical cabinet.

Safety warnings
▪Disconnect the device from the mains
▪Check that there is no voltage
▪Earth the circuit and short-circuit the installation
▪Mark the danger points

Warnings for authorized personnel when opening the device
▪Take care not to damage the device after opening the body
▪Do not open the device in outdoor locations in rainy conditions
▪Danger of breaking the plastic housing:
- Pay attention to the reuse of the same screws for the various fixing points.
- Screw carefully to avoid the risk of stripping the body fixing plate.
- Do not tighten the fixing screws with force
▪Electronic components may be irreparably damaged in the event of contact.
▪Before handling the groups, discharge the electric charges by touching a metal object and grounded.


The charging station does not require specific maintenance.
17
ENG - June 2020 - Rev. 1


During cleaning, avoid possible damage due to aggressive solvents, water jets or abrasive materials. Clean              
with a damp cloth.

Once a year all electrical connections must be checked. The charging station must be opened and checked                
internally only by qualified electrician.

5.1. Differential protection test
To guarantee an adequate service it is recommended to supply the station with a dedicated line as well as                  
each socket equipped inside is individually protected with magnetothermal differential switches. The           
differential devices must be checked periodically according to the regulations in force; in the absence of               
national regulations, manufacturers recommend checking each month.
Acting on the test button the device must intervene immediately. Otherwise contact your trusted technician              
because the safety of the system is no longer guaranteed and people are not protected against direct and                 
indirect contacts.
The presence of such a protection device does not exempt from observing all the precautions connected to                
the use of electric current.

5.2. Assistance
In case of need for assistance, contact the DazeTechnology Srl Service Department or (after the expiry of                
the warranty period) the manufacturer of the relevant part of the machine not built by Daze Technology Srl.

Warning: Access to the inside of the electrical box is allowed only to qualified and authorized service                
personnel.
 
18
ENG - June 2020 - Rev. 1

6. Visual signals and alarms
The LED frame notifies the user of the status of the DazeBox. The colors and statuses are shown in table                   
6.3.

Colore
Stato
Descrizione
Green
Not connected
DazeBox is not connected to the vehicle
Blue
Charging
Vehicle is being charged
Yellow
Waiting PM
There is not enough current available to start charging
the vehicle..
Green + Blue
Connected
DazeBox is connected to the vehicle but not charged
(vehicle fully charged or not available to recharge)
Red
Error
In case of error, refer to table 6.4

Tabella 6.3. Statuses Led.

With flashing red LEDs, DazeBox is in an error state. Each error is associated with a corresponding number                 
of short consecutive flashes. In case of error, contact support.



Numero lampeggi
Errore
2
Temperature to high
5
Error on vehicle side
6
Generic error
8
Overcurrent
 
Table 6.4. Error codes

7. Disposal

This chapter explains how to deactivate and dismantle the machine, indicating the residual risks that occur               
in these situations and the necessary precautions to neutralize these risks.
Once the end of its technical and operational life has been reached, the machine must be deactivated, or                 
taken out of service.


Switching off the electricity power supply
Disconnect cable from the machine side and the fabricated side. Before starting the procedure, check that               
the terminal of the power supply grid is not live.
19
ENG - June 2020 - Rev. 1

After a correct execution of the deactivation procedure just indicated, there are no particular risks and the                
machine can be disposed of and set aside or dismantled.


Disposal of packaging
The materials used for packaging this product are recyclable and must be disposed of in accordance with                
the regulations in force in the country of use.


Decommissioning and disposal of the product
When the equipment is disposed of all components and materials must be identified and separated to allow                
their reuse and / or recycling in an environmentally friendly manner. Waste electrical and electronic              
equipment (WEEE) must be treated and disposed of in compliance with current legislation, separate from              
normal household waste (crossed-out garbage bin symbol).


 
20
ENG - June 2020 - Rev. 1
