Tronic TRONIC KH 980 User manual

6ALL-PURPOSE BATTERY CHARGER
KOMPERNASS GMBH · BURGSTRASSE 21 · D-44867 BOCHUM
www.kompernass.com
ID-Nr.: KH980-05/09-V2
KH 980
ALL - PURPOSE BATTERY CHARGER
Operating instructions
CV_KH980_E33078_LB6.qxd 28.05.2009 9:24 Uhr Seite 1

KH 980
1
2
31
6
5
432
CV_KH980_E33078_LB6.qxd 28.05.2009 9:24 Uhr Seite 4

- 1 -
CONTENT PAGE
Intended Use 2
Items supplied 2
Description of the appliance 2
Technical data 2
Safety instructions 2
Dealing with rechargable batteries ................................................................................................3
Commissioning 3
Charging batteries 4
Average charging times ..................................................................................................................5
Calculating the charging time .........................................................................................................5
Automatic charging control/Retention charging ...........................................................................5
Troubleshooting 6
Cleaning 6
Disposal 6
Warranty & Service 7
Importer 7
Read these operating instructions carefully before using the appliance for the first time and preserve this
maual for later reference. Pass this manual on to whoever might acquire the appliance at a future date.
IB_KH980_E33078_LB6 28.05.2009 10:36 Uhr Seite 1

- 2 -
ALL -PURPOSE BATTERY
CHARGER KH 980
Intended Use
The Universal Battery Charger is intended
exclusively for:
• the charging of rechargable Ni-Cd and Ni-MH
batteries with the sizes AAA/AA/C/D and 9 V
Block.
• for charging both fast and standard
rechargeable batteries.
• domestic use only, it is not intended for
commercial use.
Items supplied
• Universal Battery Charger KH 980
• Operating manual
Description of the appliance
qCharging slots for 9 V Block batteries
(Charging slots 5 and 6; see fold-out side)
wCharging slots for AAA/AA/C/D batteries
(Charging slots 1 to 4; see fold-out side)
eLEDs
Technical data
Input voltage: AC 100 – 240 V ~50/60 Hz
Power consumption: 25 W
Protection class: II /
Charging currents:
6 x 330 mA (Type AAA)
6 x 1000 mA (Type AA)
4 x 1000 mA (Type C or D )
2 x 60 mA (9 V Block battery)
Safety instructions
Fire hazard!
Do not place the Universal Battery Charger:
• where it would be subject to direct sunlight. It
could happen that the Universal Battery Charger
overheats and becomes irreparably damaged.
• in close adjacency to sources of heat. This inclu-
des for example ovens, fan heaters and similar
appliances, as well as the ventilation openings
of electrical devices. The Universal Battery
Charger could be irreparably damaged.
• in damp environments or in the vicinity of water.
Moisture could permeate into the Universal Bat-
tery Charger. There would then be the danger of
receiving an electric shock and or causing a fire!
• Only charge rechargable batteries of the types
„Ni-Cd“ and „Ni-MH“. NEVER recharge batte-
ries of other types or non-rechargable batteries.
These are not suitable for recharging. Batteries
not suitable for recharging can overheat and ex-
plode. It could irreparably damage the Univer-
sal Battery Charger and the inserted batteries.
There is also a risk of personal injury!
Danger of electrical shock!
Do not place the Universal Battery Charger:
• in the close vicinity of water, e. g. baths and
swimming pools. Should water permeate into the
Universal Battery Charger, the appliance could
be irreparably damaged.
• Remove the power cable from the plug socket
before cleaning the Universal Battery Charger.
You can thus avoid an electric shock. Should
water or moisture permeate the Universal Bat-
tery Charger despite observing all precautions,
immediately remove the power cable from the
plug socket.
IB_KH980_E33078_LB6 28.05.2009 10:37 Uhr Seite 2

- 3 -
Injury hazard!
• Always store batteries out of the reach of
children! There is a danger that children could
swallow batteries! Due to the poisonous content
of batteries there is a danger to life!
• When charging batteries never leave the
Universal Battery Charger unsupervised.
• The batteries could become hot during charging.
NEVER touch hot batteries! There is a risk of
being burnt! After charging batteries, first of all
remove the power cable of the Universal Battery
Charger from the plug socket. Then allow the
batteries to cool down before removing them
from the Universal Battery Charger.
• Should the power cable be defective, immedia-
tely arrange for it to be replaced by a service
partner to avoid the risk of injury.
• The Universal Battery Charger does not contain
any user-serviceable components. Should you
open the housing of the Universal Battery Char-
ger, the warranty expires! Should repairs be
needed, contact one of our service partners in
your area.
• No liability or warranty will be accepted for
damage caused by opening the appliance
housing, repairs attempted by non-qualified
persons or improper use of the Universal Battery
Charger!
• Leakage of battery acids can occur, especially
with old batteries. You should remove all batte-
ries from the Universal Battery if you do not in-
tend to use it for an extended period. You can
thus protect the Universal Battery Charger from
leaking battery acids.
• This appliance is not intended for use by persons
(including children) with reduced physical, sen-
sorial or mental cabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their
safety.
• Children should be supervised to ensure that
they do not play with the appliance.
Dealing with rechargable batteries
• Do not use damaged (corroded) batteries.
• Should batteries leak, avoid skin contact with
them. This leads to skin irritation.
• Should a battery leak into the Universal Battery
Charger, clean it with a dry cloth. Wear
protective gloves!
Commissioning
• Before taking the Universal Battery Charger into
use, check that all items are complete/available
and free of visible damage.
• Place the Universal Battery Charger on a
straight, level, scratch and slip resistant surface.
Notice:
This appliance is equipped with non-slip rubber feet.
As furniture surfaces may be made of a variety of
materials and are treated with many different types
of cleaning agents, it cannot be completely ruled
out that some substances contain ingredients which
may corrode the rubber feet and soften them. If
possible, place an anti-slip material under the
• Compare the technical details with those of
your power supplier. If they match, insert the
power plug into a power socket. The LEDs blink
in orange three times. The Universal Battery
Charger is now ready for use.
IB_KH980_E33078_LB6 28.05.2009 10:37 Uhr Seite 3

- 4 -
Charging batteries
Danger!
Charge exclusively rechargable batteries of the
types „Ni-Cd“ and „Ni-MH“.
NEVER recharge batteries of other types or non-
rechargable batteries. These are not suitable for re-
charging. They could irreparably damage the Uni-
versal Battery Charger and the inserted batteries.
There is also the danger of a fire as well as an
explosion!
Notice:
Ensure that the batteries are inserted into the
charging slots in accordance with their polarities.
Otherwise, the batteries will not be charged.
• Insert the batteries into the charging slots.
• Press the 9 V Block batteries into the charging
slot until they audibly engage.
1 to 8 batteries can be individually charged:
• 4 x Type C or Type D batteries in the charging
slots 1 to 4, with additionally
2 x Type 9 Volt Block batteries in the charging
slots 5 and 6,
or
• 6 x Type AA or AAA in the charging slots 1 to 4,
with additionally
2 x Type 9 Volt Block batteries in the charging
slots 5 and 6.
• The charging process now begins.
The Universal Battery Charger has an LED for
each cell in the charging slot. The LEDs of the
respective charging slots show the charge
condition of the individual batteries.
• In the first 5 seconds the Universal Battery
Charger carries out a capacity test:
- The LED of the charging slot glows orange:
Capacity between 20%–80%.
- The LED of the charging slot glows red:
Capacity under 20%.
- The LED of the charging slot glows green:
Capacity over 80%.
When the battery capacity has been determined,
the charging process begins.
The various displays have the following meanings:
The LED blinks alternatively red and green:
The batteries are being discharged for
max.10 minutes (Refresh-Function).
The LED blinks green:
The batteries are being charged by means of
impulse-charging, for ca. 3 minutes with a
reduced charging current.
The LED continuously glows red:
The batteries are being charged.
The LED continuously glows green:
The batteries are fully charged.
The LED blinks red:
The inserted batteries are not positioned
correctly in the charging slot or are defective.
Note:
Should type C or D batteries be charged in the
outer charging slots, the operating condition is
displayed by the inner LEDs.
Warning!
The batteries could become hot during charging.
NEVER touch hot batteries! There is a danger of
being burnt!
• Remove the power cable of the Universal Battery
Charger from the plug socket and allow the
batteries to cool down.
Afterwards you can remove the charged batteries
from the Universal Battery Charger.
IB_KH980_E33078_LB6 28.05.2009 10:37 Uhr Seite 4

- 5 -
Average charging times
Depending on the type, age and remaining charge
in the batteries, the charging process can take va-
rious lengths of time. The average charging time
can be taken from the following table. Take note ho-
wever that the times given are only guiding values.
9V Block batteries
Capacity Ni-MH Ni-Cd
200 mAh 280 Min. ---
100 mAh --- 140 Min.
Type D batteries
Capacity Ni-MH Ni-Cd
4500 mAh 400 Min. ---
1800 mAh --- 160 Min.
Type C batteries
Capacity Ni-MH Ni-Cd
4000 mAh 360 Min. ---
1800 mAh --- 160 Min.
Type AA batteries
Capacity Ni-MH Ni-Cd
2500 mAh 225 Min. ---
800 mAh --- 70 Min.
Type AAA batteries
Capacity Ni-MH Ni-Cd
900 mAh 245 Min. ---
300 mAh --- 80 Min.
Calculating the charging time
Current time (Min.) =
Capacity of the battery (mAh) x 1,5 x 60
Charging current of the appliance (mA)
Automatic charging control/
Retention charging
This Universal Battery Charger controls the charging
time for rechargable batteries of the types Ni-Cd
and Ni-MH separately. This control is based on
the –Δ U („minus Delta U“) calculation.
In mathematics, with Delta Δ differences are
described.
„Minus Delta U“ in this case means a negative
voltage difference.
This charge identification makes itself useful in the
following effects:
Should a battery be charged with a constant cur-
rent, its voltage rises continuously. When the battery
is full, its voltage reaches a maximum and falls light-
ly with further current flow. This light fall in voltage is
recognised by the charging electronics and the
charge process is terminated. The Universal Battery
Charger automatically switches to „Retention
charging“. This means that the batteries are no lon-
ger being charged with continuous power, but with
short power impulses instead. This counteracts the
process of self-discharge, thus retaining the batteries
in a fully charged condition.
IB_KH980_E33078_LB6 28.05.2009 10:37 Uhr Seite 5

- 6 -
Troubleshooting
The Universal Battery Charger displays no
functions
• Check to see if the power cable is correctly
inserted into the power socket.
• Check to see if the power socket is „live“. To do
this, connect a different, functioning electrical
appliance to the socket.
The inserted batteries are not being charged
• Check that the batteries are being inserted in
accord with their polarity.
• Check that batteries suitable for charging have
been inserted into the Universal Battery Charger.
Suitable for charging are exclusively recharga-
ble Ni-Cd and Ni-MH batteries of the types
AAA/AA/C/D and 9 V Block batteries.
• Remove the power cable from the power socket
and allow the appliance to cool down, as the
temperature monitoring has possibly activated
itself. Temperature monitoring ensures that the
charging process is broken off as soon as a bat-
tery reaches an excessively high temperature.
Other malfunctions
Make contact with one of our service partners close
to you if:
• the malfunction cannot be corrected as
described above,
• or, when operating the Universal Battery
Charger, other malfunctions occur.
Cleaning
Clean the housing of the Universal Battery Charger
only with a dry cloth. For stubborn soiling use a
lightly moistened cloth. When cleaning ensure that
no moisture can permeate into the Universal Battery
Charger! Never clean the insides of the charging
slots with moist cloths. Instead, use a clean soft
brush to clean them. Under no circumstances should
you use abrasive or chemical cleaners.
Disposal
Do not dispose of the appliance in your
normal domestic waste. This product is
subject to the European guideline
2002/96/EC.
Dispose of the appliance through an approved dis-
posal centre or at your community waste facility.
Observe the currently applicable regulations.
In case of doubt, please contact your waste disposal
centre.
Battery disposal!
Batteries may not be disposed of with normal
domestic waste. All consumers are statutorily obli-
ged to dispose of batteries at the collection point in
their community/district or with the original supplier.
The purpose of this obligation is to ensure that
batteries can be disposed of in an environmentally
friendly manner. Only dispose of batteries when
they are fully discharged.
Dispose of all packaging materials in an
environmentally responsible manner.
IB_KH980_E33078_LB6 28.05.2009 10:37 Uhr Seite 6

- 7 -
Warranty & Service
The warranty for this appliance is for 3 years from
the date of purchase. The appliance has been
manu-factured with care and meticulously examined
before delivery. Please retain your receipt as proof
of purchase. In the case of a warranty claim, please
make contact by telephone with our service depart-
ment. Only in this way can a post-free despatch for
your goods be assured.
The warranty covers only claims for material and
maufacturing defects, not for wearing parts or for da-
mage to fragile components. This product is for priva-
te use only and is not intended for commercial use.
The warranty is void in the case of abusive and
improper handling, use of force and internal tampe-
ring not carried out by our authorized service
branch. Your statutory rights are not restricted in
any way by this warranty.
DES Ltd
Tel.: [phone]
Fax: [phone]
e-mail: [e-mail]
Kompernass Service Ireland
Tel: [phone] (0,082 EUR/Min.)
Standard call rates apply. Mobile operators may vary.
e-mail: [e-mail]
Importer
KOMPERNASS GMBH
BURGSTRASSE 21
44867 BOCHUM, GERMANY
www.kompernass.com
IB_KH980_E33078_LB6 28.05.2009 10:37 Uhr Seite 7

- 8 -
IB_KH980_E33078_LB6 28.05.2009 10:37 Uhr Seite 8
