Trotec TTK 67 E User manual

TRT-BA-TTK67E-TTK68E-TTK73E-TC2021-16-003-EN
TTK 67 E / TTK 68 E / TTK 73 E
EN
OPERATING MANUAL
DEHUMIDIFIER

2 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................3
Information about the device................................................6
Transport and storage...........................................................7
Assembly and installation.....................................................7
Operation ...............................................................................9
Errors and faults..................................................................13
Maintenance ........................................................................14
Technical annex...................................................................18
Disposal ...............................................................................27
Notes regarding the operating manual
Symbols
Danger
This symbol indicates dangers to the life and health of
persons due to extremely flammable gas.
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
TTK 67 E
https://hub.trotec.com/?id=45050
TTK 68 E
https://hub.trotec.com/?id=41545
TTK 73 E
https://hub.trotec.com/?id=45051

EN 3
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use.
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• Do not use the device in potentially explosive rooms or
areas and do not install it there.
• Do not use the device in aggressive atmosphere.
• Only put up the device in an upright, stable position on firm
ground.
• Let the device dry out after a wet clean. Do not operate it
when wet.
• Do not use the device with wet or damp hands.
• Do not expose the device to directly squirting water.
• Never insert any objects or limbs into the device.
• Do not cover or transport the device during operation.
• Do not sit on the device.
• This appliance is not a toy! Keep away from children and
animals. Do not leave the device unattended during
operation.
• Check accessories and connection parts for possible
damage prior to every use of the device. Do not use any
defective devices or device parts.
• Ensure that all electric cables outside of the device are
protected from damage (e.g. caused by animals). Never
use the device if electric cables or the power connection
are damaged!
• The mains connection must correspond to the
specifications in the Technical annex.
• Insert the mains plug into a properly secured mains
socket.
• Observe the device's power input, cable length and
intended use when selecting extensions to the power
cable. Completely unroll extension cables. Avoid electrical
overload.
• Before carrying out maintenance, care or repair work on
the device, remove the mains plug from the mains socket.
Hold onto the mains plug while doing so.
• Switch the device off and disconnect the power cable from
the mains socket when the device is not in use.
• Do not under any circumstances use the device if you
detect damages on the mains plug or power cable.
If the power cable is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Defective power cables pose a serious health risk!
• When positioning the device, observe the minimum
distances from walls and other objects as well as the
storage and operating conditions specified in the Technical
annex.
• Make sure that the air inlet and outlet are not obstructed.
• Make sure that the suction side is kept free of dirt and
loose objects.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Only transport the device in an upright position with an
emptied condensation tank or drain hose.
• Discharge the collected condensate before transport and
storage. Do not drink it. Health hazard!

4 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Safety warnings for devices containing flammable
refrigerants
• Only position the device in rooms where potentially leaking
refrigerant cannot accumulate.
• Only position the device in rooms where there is no source
of ignition (e.g. open flames, an active gas appliance or an
electric heater).
• Please note that the refrigerant is odourless.
• Only install the device in compliance with the national
installation regulations.
• Observe the national gas regulations.
• Only install, operate and store the device TTK 67 E/
TTK 68 E / TTK 73 E in a room measuring more than 4m2.
• Store the device in a way that no mechanical damage can
occur.
• Please note that the connected pipelines must not contain
any sources of ignition.
• R290 is a refrigerant that complies with European
environmental regulations. No part of the cooling circuit
may be perforated.
• Observe the maximum refrigerant capacity in the technical
data.
• Do not drill through or burn.
• Do not use any means other than those recommended by
the manufacturer for accelerating the defrosting process.
• Every person working with or at the refrigerant circuit must
be able to provide a certificate of qualification issued by a
body accredited by the industry, demonstrating their
competence in the safe use of refrigerants based on a
procedure well-known in the industry.
• Service work may only be carried out in accordance with
the manufacturer's specifications. If maintenance and
repair work require the support of additional persons, the
person trained in handling flammable refrigerants shall
continuously supervise the work carried out.
• Unventilated rooms, in which the device is installed,
operated or stored, must be built in a way to ensure that
potentially leaking refrigerant cannot accumulate. This
serves to avoid fire or explosion hazards resulting from an
ignition of the refrigerant by an electric furnace, cooking
stove or another ignition source.
• The entire refrigerant circuit is a maintenance-free,
hermetically sealed system and may only be maintained or
repaired by specialist companies for cooling and air-
conditioning or by Trotec.
Intended use
Only use the device for drying and dehumidifying room air, while
adhering to and following the technical data.
In addition, the device may also be used as a kind of clothes
dryer to dry wet laundry.
Intended use comprises:
• dehumidifying and drying:
– living rooms, bedrooms, bathrooms and basements
– laundries, holiday homes, camper vans, boats
• maintaining the dryness of:
– storage spaces, archives, laboratories, garages
– bathrooms, wash rooms, changing rooms etc.
Foreseeable misuse
The device is not intended for industrial use.
• Do not place the device on wet or flooded ground.
• Do not place any objects, e.g. clothing, on the device.
• Do not use the device outdoors.
• Do not make any unauthorised modifications, alterations or
structural changes to the device.
• Any use other than the intended use is regarded as a
reasonably foreseeable misuse.
Personnel qualifications
People who use this device must:
• be aware of the dangers that occur when working with
electric devices in damp areas.
• have read and understood the operating manual, especially
the Safety chapter.
Maintenance tasks which require the housing to be opened
must only be carried out by specialist companies for cooling and
air-conditioning or by Trotec.

EN 5
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Safety signs and labels on the device
Note
Do not remove any safety signs, stickers or labels from
the device. Keep all safety signs, stickers and labels in
legible condition.
The following safety signs and labels are attached to the device:
TTK 67 E / TTK 68 E / TTK 73 E
Follow the manual
This symbol indicates that the operating manual must
be observed.
Follow the repair manual
Disposal, maintenance and repair work of the
refrigerant circuit may only be carried out in
accordance with the manufacturer's specifications and
by persons having a certificate of qualification.
A corresponding repair manual is available from the
manufacturer upon request.
Residual risks
Danger
Natural refrigerant propane (R290)!
H220 – Extremely flammable gas.
H280 – Contains gas under pressure; may explode if
heated.
P210 – Keep away from heat, sparks, open flames and
other ignition sources. No smoking.
P377 – Leaking gas fire: Do not extinguish, unless leak
can be stopped safely.
P410+P403 – Protect from sunlight. Store in a well-
ventilated place.
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning of electrical voltage
Before any work on the device, remove the mains plug
from the mains socket!
Do not touch the mains plug with wet or damp hands.
Hold onto the mains plug while pulling the power cable
out of the mains socket.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Note
Do not operate the device without an air filter inserted
into the air inlet!
Without the air filter, the inside of the device will be
heavily contaminated. This could reduce the
performance and result in damage to the device.
Behaviour in the event of an emergency
1. Switch off the device.
2. In an emergency, disconnect the device from the mains
feed-in: Hold onto the mains plug while pulling the power
cable out of the mains socket.
3. Do not reconnect a defective device to the mains.

6 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Information about the device
Description of the device
The device uses the principle of condensation to automatically
dehumidify rooms.
The fan sucks damp room air through the air inlet, the air filter,
the evaporator and to the condenser located behind it. The air is
cooled at the cold evaporator until it is below the dew point.
Water vapour contained in the room air precipitates on the
evaporator fins as condensation or rime. The dehumidified,
cooled air is slightly warmed at the condenser and blown out
again. The drier air thus conditioned mixes with the air in the
room. The humidity in the room where the device is positioned
is reduced as air constantly circulates through the device.
Depending on the air temperature and the relative humidity, the
condensed water either drops continuously or only during the
defrost phase through the integrated drain nozzle into the
condensation tank below. It is fitted with a float to measure the
filling level.
The device has a control panel for operating and controlling the
functions.
Once the maximum fill level of the condensation tank is
reached, the condensation tank indicator light (see chapter
Operation) on the control panel is illuminated. The device
switches off. The condensation tank indicator light only goes out
again once the emptied condensation tank is reinserted. On the
TTK67E and TTK73E, the indicator lights also light up if the
condensate tanks are not inserted correctly.
Optionally, the condensed water can be drained by attaching a
hose (Ø = 14mm) at the condensation connection.
The device can reduce the relative humidity of a room to approx.
30 %.
In addition, the device may also be used as a kind of clothes
dryer to dry wet laundry in living or working spaces.
Because of the heat radiation generated during operation, the
room temperature may rise slightly.
The devices TTK67E, TTK68E and TTK73E differ in their
appearance and design. They are similar in operation.
Device depiction
TTK67E/ TTK68E/ TTK73E
The device depiction of the TTK67E is shown as an example.
1
2
3
4
5
6
8
3
7
No. Designation
1Control panel
2Air inlet
3Cover of condensation drain hose connection
4Wheels
5Transport handle
6Condensation tank
7Air outlet
8Front cover with air filter

EN 7
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
Please note that additional transport regulations might apply to
devices containing flammable refrigerants. The equipment's
arrangement and the maximum number of components to be
transported together can be gathered from the applicable
transport regulations.
To make the device easier to transport, it is fitted with a carry
handle.
To make the device easier to transport, it is fitted with wheels.
Before transporting the device, observe the following:
• Switch off the device.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Drain the remaining condensate from the device and the
condensation drain hose (see chapter Maintenance).
• Do not use the power cable to drag the device.
• Only wheel the device on a level and smooth surface.
After transporting the device, proceed as follows:
• Set up the device in an upright position after transport.
• Leave the device to rest for 12to24hours, so the
refrigerant can accumulate within the compressor.
Wait 12to24hours before switching the device back on!
Acting contrary might lead to compressor damage and a
malfunctioning device. If so, any warranty claims will be
voided.
Storage
Before storing the device, proceed as follows:
• Drain the remaining condensate from the device and the
condensation drain hose (see chapter Maintenance).
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
When the device is not being used, observe the following
storage conditions:
• Only store the device in a room measuring more than 4m2.
• dry and protected from frost and heat
• in an upright position where it is protected from dust and
direct sunlight
• with a cover to protect it from invasive dust, if necessary
• Place no further devices or objects on top of the device to
prevent it from being damaged.
Assembly and installation
Scope of delivery
• 1x Device
• 1x Air filter
• 1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.
Start-up
When positioning the device, observe the minimum distance
from walls or other objects as described in the chapter
Technical annex.
A
B
C
C
D
• Before restarting the device, check the condition of the
power cable. If there are doubts as to the sound condition,
contact the customer service.
• Only position the device in rooms where potentially leaking
refrigerant cannot accumulate.
• Only position the device in rooms where there is no source
of ignition (e.g. open flames, an active gas appliance or an
electric heater).
• Only put up the device in an upright, stable position on firm
ground.

8 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
• Do not create tripping hazards when laying the power
cable or other electric cables, especially when positioning
the device in the middle of the room. Use cable bridges.
• Make sure that extension cables are completely unrolled.
• When positioning the device, keep a sufficient distance to
heat sources.
• Make sure that no curtains or other objects interfere with
the air flow.
• When positioning the device, particularly in wet areas,
secure it locally with an RCD (residual current device)
which complies with the respective regulations.
Inserting the air filter
Note
Do not operate the device without an air filter inserted
into the air inlet!
Without the air filter, the inside of the device will be
heavily contaminated. This could reduce the
performance and result in damage to the device.
• Make sure that the air filter is installed before switching
the device on.
TTK 67E
TTK 68E
TTK 73E
Inserting the condensation tank
• Ensure that the float inside the condensation tank is
inserted correctly.
TTK 68 E
• Ensure that the condensation tank is empty and inserted
correctly.

EN 9
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Operation
Notes:
• Avoid open doors and windows.
• After being switched on, the device operates fully
automatically.
• The fan permanently runs in dehumidification mode even
after the set nominal value has been reached until the
device is switched off.
Operating elements
Except for the On/OffLED(23), the operating elements of the
TTK67E and TTK73E are identical. The control panel of the
TTK68E is arranged differently and offers fewer functions than
the TTK67E and TTK73E.
TTK67E/ TTK73E
9 10 11 12 14 15 16
171819202122 23
13
TTK 68E
Filter
Clean ON/OFF
ON/OFF
Smart Cont Dry Timer ON/OFF
High Med Low Water
Full
Fan Mode
Humidity
Timer
15 12 13 14 9 22
1618192017
23
No. Designation Meaning
9Water Full LED Condensation tank full
Condensation tank not installed correctly
(TTK67E and TTK73E only)
10 Swing LED Illuminated when swing function is
activated
No. Designation Meaning
11 Fixed LED Illuminated when the automatic
movement of the ventilation flap is
switched off
12 Operating mode
LEDs
Operating mode indication:
Smart = automatic operation
Cont = continuous operation
Quiet = night mode (TTK67E and
TTK73E only)
Dry = dehumidification or laundry drying
function
13 Segment display Indication of the current relative room
humidity level
Indication of the desired room humidity
level
Indication of the number of hours during
timer programming
Indication of a message if child lock is
activated
14 Timer ON/OFF
LED
Illuminated when the timer is activated.
15 Fan speed
LEDs
Fan speed indication:
High
Med(ium)
Low
16 ON/OFF button Switching the device on or off
17 Fan button Setting the fan speed:
High
Med(ium)
Low
18 Timer button Switching the timer function on or off
19 Humidity button Selection button for the desired relative
humidity level
(30% to 80% in increments of 10%)
20 Mode button Selection button for operating mode
Smart= automatic mode
Cont= continuous operation
Quiet= night mode (TTK67E and
TTK73E only)
Dry= dehumidification/laundry drying
function
21 Swing button Switching the swing function on or off
(TTK67E and TTK73E only)
22 Filter Clean LED Filter needs to be cleaned
23 ON/OFF LED Illuminated during operation (TTK68E
and TTK73E only)

10 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Switching the device on
Once you have completely installed the device as described in
the chapter Assembly and start-up, you can switch it on.
1. Press the ON/OFF button(16).
ðThe unit starts to dehumidify.
Setting the operating mode
• automatic operation
• continuous operation
• night mode (TTK67E and TTK73E only)
• dehumidification/laundry drying function
Automatic operation
The humidity level is regulated automatically depending on the
room temperature. The device detect the temperature
automatically. It only switches off automatically when
necessary.
1. Press the Modebutton(20) until the operating modeLED
Smart(12) is illuminated.
ðAutomatic mode is selected.
Continuous operation
The device dehumidifies the air constantly and regardless of the
relative room humidity. The desired relative room humidity
cannot be adjusted in this operating mode. The fan speed can
be freely selected.
1. Press the Modebutton(20) until the operating modeLED
Cont(12) is illuminated.
ðContinuous operation is selected.
Info
For continuous operation a condensation drain hose
can be connected in order to continuously drain the
accumulating condensate.
Night mode (TTK67E and TTK73E only)
In night mode, the device operates at the lowest fan speed. The
room humidity is automatically adjusted depending on the room
temperature.
1. Press the Mode button(20) until the Quiet LED(12) for
night mode is illuminated.
ðNight mode is selected.
Dehumidification/laundry drying function
The device keeps running until the laundry is dry. After that, the
device keeps the humidity at a low level to prevent mould
growth. In this operating mode, the fan speed and room
humidity level cannot be set.
1. Press the Mode button(20) until the Dry LED(12) for
dehumidification mode is illuminated.
ðThe dehumidification mode/laundry drying function is
selected.
Setting the desired relative room humidity
Please proceed as follows to adjust the humidity value:
1. Press and hold the Humidity button(19) in order to set the
desired value (in increments of 10% ranging from 30% to
80%).
2. Release the Humidity button(19) when the desired value is
reached.
ðThe value for desired relative humidity level in the room
is indicated on the segment display(13) for approx.5s.
ðThe desired relative room humidity is set.
ðThen the currently measured humidity level reappears
on the segment display(13).
Setting the fan speed
You can choose between low, medium and high fan speed.
1. Press the Fan button(17) to select the desired fan speed.
ðThe corresponding fan speedLED(15) will be
illuminated.
Setting the timer
For the device to switch on or off automatically after a
predefined number of hours (max. 24hrs) you can programme
the timer.
The timer can be set in all operating modes.
You can activate automatic switch-on when the device is in
standby mode.
Note
The device must not be left unattended in a freely
accessible room with an activated timer.
Automatic switch-on
üThe device is now in standby mode.
1. Press the Timerbutton(18) to programme automatic
switch-on.
2. Repeatedly press the Timer button(18) until the desired
number of hours until automatic switch-on is indicated on
the segment display(13).
ðThe number of hours is indicated on the segment
display(13) for approx.5s.
ðThe timer is now set to the desired number of hours.
ðAfter the predefined time, the device switches itself on.

EN 11
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Automatic switch-off
üThe device is switched on.
1. Press the Timerbutton(18) to programme automatic
switch-off.
2. Repeatedly press the Timer button(18) until the desired
number of hours until automatic switch-off is indicated on
the segment display(13).
ðThe number of hours is indicated on the segment
display(13) for approx.5s.
ðThe timer is now set to the desired number of hours.
ðAfter the predefined time, the device switches itself off.
Notes regarding automatic switch-on and switch-off:
• Manually switching the device on disables the automatic
switch-on function.
• If the power supply is interrupted, the timer will be
deactivated.
• Pressing the ON/OFF button(16)deactivates the automatic
switch-on and switch-off function.
Swing function (TTK67E and TTK73E only)
The swing function can be switched on in any operating mode if
required. By means of the swing function, the air outlet(7) is
moved automatically and thus ensures continuous air
circulation.
1. Press the Swing button(21).
ðThe SwingLED(10) is illuminated.
ðThe ventilation flap moves up and down continuously.
2. Press the Swing button(21) again to stop the ventilation
flap in a certain position and to switch off the swing
function.
ðThe FixedLED(11) is illuminated.
Child lock
Please proceed as follows to enable child lock:
1. Simultaneously press and hold the buttons Mode(20) and
Timer(18) for approx. 1s.
ðThe child lock is activated.
ðThe messageLC will be indicated on the segment
display when a button is pressed.
2. Again press and hold the buttons Mode(20) and Timer(18)
simultaneously for approx. 1s to disable the child lock.
ðNow all buttons can be actuated as usual.
Auto stop function
If the water tank is full, not inserted correctly or the humidity
level in the room is 5% lower than the set room humidity, the
device will stop automatically.
Operation with hose attached to the condensation
connection
For continuous operation or unattended dehumidification, please
connect a suitable condensation drain hose to the device.
The action of connecting the condensation drain hose is
explained by means of the deviceTTK68E, which serves as an
example.
üA suitable hose (Ø= 14mm) is ready for use.
üA suitable hose adapter is ready for use.
üThe device is switched off.
1. Open the cover(3) of the condensation drain hose
connection.
2. Unscrew the sealing cap by turning it counter-clockwise.

12 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
3. Remove the plug.
4. Screw the hose adapter onto the connection in a clockwise
motion.
5. Push one end of the hose onto the hose adapter.
6. Guide the other hose end to a suitable drain or sufficiently
dimensioned collection container. Please note that the
hose must not be kinked.
Automatic defrost
At low ambient temperatures, ice may form at the evaporator
during dehumidification. The device will then carry out an
automatic defrost.
Dehumidification is briefly interrupted during defrosting. The fan
keeps running.
The duration of the defrost process can vary. Do not switch off
the device during automatic defrost. Do not remove the mains
plug from the mains socket.
Drying laundry
In addition, the device may also be used as a kind of clothes
dryer to dry wet laundry in living or working spaces.
When positioning the device or a clothes horse, please observe
the minimum distances specified in the technical data.
The following humidity values are suitable for drying laundry:
• cupboard dry= 46% relative humidity
• iron dry= 58% relative humidity
• slightly dried= 65% relative humidity
If the Dry LED(12) is illuminated, the device automatically
switches to laundry drying mode. After drying the laundry, the
room humidity level is maintained.
When the laundry drying function is activated, the fan speed and
room humidity level cannot be set manually.
Adjust the settings for the relative humidity level to the device
(e.g. 60% relative humidity for iron dry laundry). If necessary,
use a measuring device to determine the humidity level.
Please proceed as follows to adjust the laundry drying function
manually:
1. Repeatedly press the Modebutton(20) until the operating
modeLED Dry(12) is illuminated.
ðThe function for drying laundry is activated.
Shutdown
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch off the device.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• If necessary, remove the condensation drain hose and any
residual fluid from it.
• Empty the condensation tank, if need be.
• Clean the device according to the Maintenance chapter.
• Store the device according to the Transport and storage
chapter.

EN 13
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Errors and faults
The device has been checked for proper functioning several
times during production. If malfunctions occur nonetheless,
check the device according to the following list.
The device does not start:
• Check the power connection.
• Check the power cable and mains plug for damage.
• Check the on-site fusing.
• Check the condensation tank for correct seating.
• Check the filling level of the condensation tank, and empty
it if necessary. The Water Full LED(9) must not light up.
• Check the room temperature. Observe the device's
permissible operating range according to the technical
data.
• Wait for 10minutes before restarting the device. If the
device is not starting, have the electrics checked by a
specialist company or by Trotec.
The device is running, but there is no formation of
condensate:
• Check the float in the condensation tank for dirt. If
necessary, clean the condensation tank. The float must be
able to move freely.
• Check the room temperature. Observe the device's
permissible operating range according to the technical
data.
• Ensure that the relative room humidity complies with the
technical data.
• Check the preselected desired room humidity level. The
relative humidity in the room must be above the selected
range. If necessary, reduce the preselected desired room
humidity.
• Check the air filter for dirt. If necessary, clean or replace
the air filter.
• From the outside, check the condenser for dirt (see
chapter Maintenance). If the condenser is dirty, have it
cleaned by a specialist company or by Trotec.
• The device might carry out an automatic defrost. During
automatic defrost, the device does not dehumidify.
The device is loud or vibrates:
• Check whether the device is set up in a stable and upright
position.
Condensate is leaking:
• Check the device for leaks.
The compressor does not start:
• Check the room temperature. Observe the device's
permissible operating range according to the technical
data.
• Ensure that the relative room humidity complies with the
technical data.
• Check the preselected desired room humidity level. The
relative humidity in the room must be above the selected
range. If necessary, reduce the preselected desired room
humidity.
• Check whether the overheating protection of the
compressor has tripped. Disconnect the device from the
mains and let it cool down for approx. 10minutes before
reconnecting it.
• The device might carry out an automatic defrost. During
automatic defrost, the device does not dehumidify.
The device gets very warm, is loud or is losing
performance:
• Check the air inlets and air filters for dirt. Remove external
dirt.
• From the outside, check the device for dirt (see chapter
Maintenance). If the inside of the device is dirty, have it
cleaned by a specialist company for cooling and
air-conditioning or by Trotec.
Note
Wait for at least 3 minutes after maintenance and
repair work. Only then switch the device back on.
The device still does not operate correctly after these
checks:
Please contact the customer service. If necessary, bring the
device to a specialist company for cooling and air-conditioning
or to Trotec for repair.

14 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Maintenance Maintenance intervals
Maintenance and care interval before every
start-up
as needed at least every
2weeks
at least every
4weeks
at least every
6months
at least
annually
Check air inlets and outlets for dirt
and foreign objects and clean
ifnecessary
X X
Clean the exterior X X
Visually check the inside of the
device for dirt
X X
Check the air filter for dirt and
foreign objects and clean or
replace if necessary
X X
Replace the air filter X
Check for damage X
Check attachment screws X X
Test run X
Empty the condensation tank and/
or drain hose
X
Maintenance and care log
Device type: ............................................. Device number: ....................................
Maintenance and care interval 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Check air inlets and outlets for dirt
and foreign objects and clean
ifnecessary
Clean the exterior
Visually check the inside of the
device for dirt
Check the air filter for dirt and
foreign objects and clean or
replace if necessary
Replace the air filter
Check for damage
Check attachment screws
Test run
Empty the condensation tank and/
or drain hose
Comments
1. Date: ...................................
Signature: ................................
2. Date: ....................................
Signature: .................................
3. Date: ....................................
Signature: .................................
4. Date: ....................................
Signature: .................................
5. Date: ...................................
Signature: ................................
6. Date: ....................................
Signature: .................................
7. Date: ....................................
Signature: .................................
8. Date: ....................................
Signature: .................................
9. Date: ...................................
Signature: ................................
10. Date: ..................................
Signature: .................................
11. Date: ..................................
Signature: .................................
12. Date: ..................................
Signature: .................................
13. Date: .................................
Signature: ................................
14. Date: ..................................
Signature: .................................
15. Date: ..................................
Signature: .................................
16. Date: ..................................
Signature: .................................

EN 15
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
Warning of electrical voltage
Tasks which require the device to be opened must
only be carried out by authorised specialist
companies or by Trotec.
Refrigerant circuit
Danger
Natural refrigerant propane (R290)!
H220 – Extremely flammable gas.
H280 – Contains gas under pressure; may explode if
heated.
P210 – Keep away from heat, sparks, open flames and
other ignition sources. No smoking.
P377 – Leaking gas fire: Do not extinguish, unless leak
can be stopped safely.
P410+P403 – Protect from sunlight. Store in a well-
ventilated place.
• The entire refrigerant circuit is a maintenance-free,
hermetically sealed system and may only be maintained or
repaired by specialist companies for cooling and air-
conditioning or by Trotec.
Safety signs and labels on the device
Check the safety signs and labels attached to the device at
regular intervals. Replace illegible safety signs!
Cleaning the housing
Clean the housing with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Visual inspection of the inside of the device for dirt
1. Remove the air filter.
2. Use a torch to illuminate the openings of the device.
3. Check the inside of the device for dirt.
4. If you see a thick layer of dust, have the inside of the
device cleaned by a specialist company for cooling and air-
conditioning or by Trotec.
5. Put the air filter back in.
Cleaning the air filter
Note
Ensure that the air filters are neither worn nor
damaged. The corners and edges of the air filters must
not be deformed or rounded. Before reinserting the air
filters, make sure that they are undamaged and dry!
The air filter must be cleaned when dirt is visible or the Filter
Clean indication(22) is illuminated. This is brought to light e.g.
by a reduced capacity (see chapter Errors and faults).
üThe device is switched off and disconnected from the
mains.
1. Remove the front cover as shown below. On the TTK67E,
also press the side buttons at the bottom to release the
front cover.
2. Remove the filter.
TTK 67 E

16 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
TTK 68 E
TTK 73 E
3. Clean the filter using a slightly damp, soft, lint-free cloth. If
the filter is heavily contaminated, clean it with warm water
mixed with a neutral cleaning agent.
4. Allow the filter to dry completely. Do not insert a wet filter
into the device.
5. Reinsert the filter and push the air filter down until it clicks
into place.
6. Reattach the front cover.
TTK 67 E
TTK 68 E
TTK 73 E
7. To carry out a filter reset, press the buttons Fan(17) and
Humidity(19) at the same time.
ðThe Filter Clean indication(22) disappears.

EN 17
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Emptying the condensation tank
Once the condensation tank is full, the device stops
dehumidification operation and switches itself off. The Water
Full LED(9) is illuminated.
On the TTK67E and TTK73E, the Water FullLED(9) also lights
up if the condensate tank is not inserted correctly.
The action of emptying the condensation tank is explained by
means of the deviceTTK68E, which serves as an example.
1. Take the condensation tank out of the device.
2. Empty the condensation tank over a drain or sink.
3. Rinse the tank with clear water. Clean the tank regularly
using a mild cleaning agent (no detergent!).
4. Refit the condensation tank into the device.
Make sure not to damage the float when inserting or
removing the condensation tank.
ðIn doing so, make sure that the float is positioned
correctly.
TTK 68 E
ðIn doing so, make sure that the condensation tank is
inserted correctly, for otherwise the device cannot be
switched back on.
Activities required after maintenance
If you want to continue using the device:
• Leave the device to rest for 12to24hours, so the
refrigerant can accumulate within the compressor.
Wait 12to24hours before switching the device back on!
Acting contrary might lead to compressor damage and a
malfunctioning device. If so, any warranty claims will be
voided.
• Reconnect the device to the mains.
If you do not intend to use the device for a considerable time:
• Store the device according to the Transport and storage
chapter.

18 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Technical annex Technical data
Parameter Value
Model TTK67E TTK68E TTK73E
Dehumidifying capacity, max. 20 l/ 24h 20 l / 24 h 20 l / 24 h
Air flow rate
Stage1 (Low):
Stage2 (Med):
Stage3 (High):
105m3/h
115m3/h
130m3/h
105m3/h
115m3/h
130m3/h
105m3/h
115m3/h
130m3/h
Operating range (temperature) 5°C to 32°C 5°C to 32°C 5°C to 32°C
Operating range (relative
humidity)
30% to 90%RH 30% to 80%RH 30% to 90%RH
Pressure suction side 1.5MPa 1.5MPa 1.5MPa
Pressure outlet side 3.0MPa 3.0MPa 3.0MPa
Max. permissible pressure 3.0MPa 3.0MPa 3.0MPa
Mains connection 220 – 240 V / 50 Hz 220 – 240 V / 50 Hz 220 – 240 V / 50 Hz
Power consumption, max. 450 W 450 W 450 W
Nominal current 2 A 1.9 A 2 A
Refrigerant R-290 R-290 R-290
Amount of refrigerant 110 g 110 g 110 g
GWP factor 3 3 3
CO2 equivalent 0.00033 t 0.00033 t 0.00033 t
Water tank 3.5 l 4 l 3.5 l
Sound pressure level 43 dB(A) 43 dB(A) 43 dB(A)
Dimensions
(lengthx widthx height)
210 x 325 x 580 mm 246 x 367 x 582 mm 220 x 365 x 590 mm
Minimum distance to walls and
other objects
A: top:
B: rear:
C: side:
D: bottom:
50 cm
20 cm
20 cm
20 cm
50 cm
20 cm
20 cm
20 cm
50 cm
20 cm
20 cm
20 cm
Weight 15.5 kg 15 kg 15.5 kg

EN 19
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Circuit diagram TTK67E

20 EN
dehumidifier TTK 67 E / TTK 68 E / TTK 73 E
Circuit diagram TTK68E
