Trotec BZ25 User manual

TRT-BA-BZ25-TC2019-08-001-EN
BZ25
EN
OPERATING MANUAL
CO₂ AIR QUALITY MONITOR

2 EN
CO₂ air quality monitor BZ25
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................2
Information about the device................................................3
Transport and storage...........................................................5
Operation ...............................................................................5
Maintenance and repair ........................................................6
Disposal .................................................................................6
Notes regarding the operating manual
Symbols
Warning of electrical voltage
This symbol indicates dangers to the life and health of
persons due to electrical voltage.
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information
(e.g. material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
BZ25
https://hub.trotec.com/?id=43283
Safety
Read this manual carefully before starting or using the
device. Always store the manual in the immediate vicinity
of the device or its site of use!
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/ or serious injury.
Save all warnings and instructions for future
reference.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children
without supervision.
• Do not use the device in potentially explosive rooms.
• Do not use the device in aggressive atmosphere.
• Do not immerse the device in water. Do not allow liquids to
penetrate into the device.
• The device may only be used in dry surroundings and must
not be used in the rain or at a relative humidity exceeding
the operating conditions.
• Protect the device from permanent direct sunlight.
• Do not remove any safety signs, stickers or labels from the
device. Keep all safety signs, stickers and labels in legible
condition.
• Do not open the device.
• Observe the storage and operating conditions as given in
the Technical data chapter.

EN 3
CO₂ air quality monitor BZ25
Intended use
Only use the device for air quality (CO2level), indoor
temperature and humidity measurements within the measuring
range specified in the technical data. Observe and comply with
the technical data.
To use the device for its intended use, only use accessories and
spare parts which have been approved by Trotec.
Improper use
Do not use the device in potentially explosive atmospheres, for
measurements in liquids or at live parts. Trotec accepts no
liability for damages resulting from improper use. In such a
case, any warranty claims will be voided. Any unauthorised
modifications, alterations or structural changes to the device are
forbidden.
Personnel qualifications
People who use this device must:
• have read and understood the operating manual, especially
the Safety chapter.
Residual risks
Warning of electrical voltage
There is a risk of a short-circuit due to liquids
penetrating the housing!
Do not immerse the device and the accessories in
water. Make sure that no water or other liquids can
enter the housing.
Warning of electrical voltage
Work on the electrical components must only be
carried out by an authorised specialist company!
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The device is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the device when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
Note
To prevent damages to the device, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
device.
Information about the device
Device description
The CO₂air quality monitor is a mains-powered measuring
device with a comprehensive range of measurement options.
It comes with the following functional properties and equipment
features:
• NDIRmeasurement of carbon dioxide concentrations in the
room air
• Simultaneous indication of CO₂values, room temperature,
humidity level, date and time
• Minimum and maximum value function for CO₂, air
temperature and humidity
• Carbon dioxide alarm function with acoustic alarm for a
freely definable limit value
• Additional CO₂indicator icon (feel-good indication)

4 EN
CO₂ air quality monitor BZ25
Device depiction
1
3
4
6
7
2
8
12
11
9
14
10
15
13
5
DC:6V/1A
No. Designation
1 Main display
2 Date indication
3 Time indication
4 Power adapter input
5ESC button
6MAXMIN button
7 button
8 button
9ALARM button
10 Relative humidity indication
11 Temperature indication
12 button (switch-on/ switch-off)
13 button (hold)
14 °C/°F button
15 Clock button
Main display
22 21 20
19
18
17
26
25
23
24
No. Designation
17 Measured CO2value
18 Unit measured CO2value (parts per million)
19 Alarm activated indication
20 Feel-good indication: poor air quality
21 Feel-good indication: average air quality
22 Feel-good indication: good air quality
23 HOLDindication (freezing displayed values)
24 MINindication (display of minimum values)
25 CO2indication (display of CO2value)
26 MAXindication (display of maximum values)

EN 5
CO₂ air quality monitor BZ25
Technical data
Parameter Value
Model BZ25
Article number 3.510.205.014
Weight (packaging
excluded)
190 g
Dimensions
(lengthx widthx
height)
90 mmx 110mmx 98mm
Display LCD (monochrome)
Carbon dioxide (ppm)
Carbon dioxide
sensor
NDIRsensor (non-dispersive infrared)
Measuring range 0 to 9999ppm
Accuracy ±5% or ±75ppm
Resolution 1ppm
Relative humidity
Measuring range 0.0%RH to 99.9%RH
Accuracy ±5%RH
Resolution 0.1%
Air temperature
Measuring range -5°C to 50°C or 23°F to 122°F
Accuracy ±1°C or ±1.8°F
Measuring range
resolution
0.1°C/°F
Ambient conditions
Operation -5°C to 50°C or 23°F to 122°F
and 90%RH (non-condensing)
Storage -5°C to 50°C or 23°F to 122°F
and 90%RH (non-condensing)
Power supply External (power adapter)
Scope of delivery
• 1 x Measuring device BZ25
• 1 x Power adapter
• 1x Operating manual
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
The manufacturer packed the device to the best of his abilities
to protect it against transport damage.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• protected from dust and direct sunlight
• The storage temperature is the same as the range given in
the Technical data chapter.
Operation
Connecting the power adapter
Prior to use, connect the device to the mains using the supplied
power adapter.
DC:6V/1A
Start-up
Press the button at the rear of the device for approx. 1second
to switch the device on. The device will then start a warm-up
phase lasting 120seconds.
Setting date and time
Press and hold the Clockbutton for approx. 4seconds to set
time and date. The day indication starts flashing. Press the
button again to switch between year, month, day, hours and
minutes. Press one of the buttons or to increase or
decrease the number flashing on the display. To exit the setting
mode and to save the entered value press the ESCbutton once
you have set the correct date and time.
Hold function
Press the button(hold) to permanently indicate or "freeze"
the displayed values.

6 EN
CO₂ air quality monitor BZ25
Alarm function
The device features an alarm function that indicates when a
previously set CO2threshold is exceeded.
Please proceed as follows to enable the alarm function:
1. Press the ALARMbutton.
ðThe alarm function is enabled and the alarm symbol
appears on the display. As soon as the measured value
exceeds the previously set limit value, an acoustic alarm
signal will be emitted and the buttons below the display
start to flash in red.
2. Press the button again to exit or disable the alarm mode.
Setting the limit value for the alarm function
Please proceed as follows to set a new limit value:
1. Press and hold the ALARMbutton for approx. 5seconds.
ðThe previously set limit value appears on the display
and the displayed alarm symbol flashes.
2. Press or to increase or reduce the decrease the
displayed number.
3. Then you can press the ESCbutton to exit the mode and to
adopt the set value or to change the limit values for the
feel-good indication .
Adjusting the limit values for the feel-good indication
Note:
This setting can only be adjusted in the setting mode for the
alarm threshold! After having set an alarm threshold, do not
press the ESCbutton but rather the ALARMbutton again for a
brief moment. The lower limit value for the feel-good indication
will be displayed and the icons of the feel-good
indication   start to flash.
1. Press or to increase or reduce the lower limit value for
the feel-good indication.
2. Press the ALARMbutton to switch over to setting the upper
limit value.
3. Press or to increase or reduce the upper limit value for
the feel-good indication.
4. Press the ESCbutton to exit the mode and to adopt the set
value.
Displaying the minimum/ maximum value
The device saves the highest and lowest display values. To call
up these values, please proceed as follows:
1. Press the MAXMINbutton.
ðMAX appears on the display and the highest measured
values for carbon dioxide, temperature and relative
humidity will be displayed as well.
2. Press the button again to view the minimum values (MIN).
3. Press the ESCbutton to exit this mode.
Background illumination
The background illumination will be switched on in addition by
pressing either ALARM, MAXMIN, or . The background
illumination goes out after approx. 20seconds of non-use.
Press the ESCbutton to exit this mode.
Setting the °C/°Findication
Press the °C/°Fbutton at the rear of the device to switch
between an indication in degrees Celsius and degrees
Fahrenheit.
Maintenance and repair
Cleaning
Clean the device with a soft, damp and lint-free cloth. Make
sure that no moisture enters the housing. Do not use any
sprays, solvents, alcohol-based cleaning agents or abrasive
cleaners, but only clean water to moisten the cloth.
Repair
Do not modify the device or install any spare parts. For repairs
or device testing, contact the manufacturer.
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. For further return options provided by us please
refer to our website www.trotec24.com.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.

Trotec GmbH
Grebbener Str. 7
D-52525 Heinsberg
[phone]
[phone]
[email protected]
www.trotec.com
