Smoke control damper EK-JS
2

General information
About this manual
This operating and installation manual enables oper-
ating or service personnel to correctly install the TROX
product described below and to use it safely and effi-
ciently.
This operating and installation manual is intended for
use by fitting and installation companies, in-house tech-
nicians, technical staff, instructed persons, and qualified
electricians or air conditioning technicians.
It is essential that these individuals read and fully under-
stand this manual before starting any work. The basic
prerequisite for safe working is to comply with the safety
notes and all instructions in this manual.
The local regulations for health and safety at work and
general safety regulations also apply.
This manual must be given to the system owner when
handing over the system. The system owner must
include the manual with the system documentation. The
manual must be kept in a place that is accessible at all
times.
Illustrations in this manual are mainly for information
and may differ from the actual design.
Copyright
This document, including all illustrations, is protected by
copyright and pertains only to the corresponding
product.
Any use without our consent may be an infringement of
copyright, and the violator will be held liable for any
damage.
This applies in particular to:
Publishing content
Copying content
Translating content
Microcopying content
Saving content to electronic systems and editing it
TROX Technical Service
To ensure that your request is processed as quickly as
possible, please keep the following information ready:
Product name
TROX order number
Delivery date
Brief description of the fault
Online www.troxtechnik.com
Phone [phone]
Limitation of liability
The information in this manual has been compiled with
reference to the applicable standards and guidelines,
the state of the art, and our expertise and experience of
many years.
The manufacturer does not accept any liability for dam-
ages resulting from:
Non-compliance with this manual
Incorrect use
Operation or handling by untrained individuals
Unauthorised modifications
Technical changes
Use of non-approved replacement parts
The actual scope of delivery may differ from the infor-
mation in this manual for bespoke constructions, addi-
tional order options or as a result of recent technical
changes.
The obligations agreed in the order, the general terms
and conditions, the manufacturer's terms of delivery,
and the legal regulations in effect at the time the con-
tract is signed shall apply.
We reserve the right to make technical changes.
Warranty claims
The provisions of the respective general delivery terms
apply to warranty claims. For purchase orders placed
with TROX GmbH, these are the regulations in section
"Vl. Warranty claims" of the Delivery Terms of TROX
GmbH, see www.trox.de/en/ .
General information
Smoke control damper EK-JS 3

Safety notes
Symbols are used in this manual to alert readers to
areas of potential hazard. Signal words express the
degree of the hazard.
Comply with all safety instructions and proceed carefully
to avoid accidents, injuries and damage to property.
DANGER!
Imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING!
Potentially hazardous situation which, if not avoided,
may result in death or serious injury.
CAUTION!
Potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE!
Potentially hazardous situation which, if not avoided,
may result in property damage.
ENVIRONMENT!
Environmental pollution hazard.
Tips and recommendations
Useful tips and recommendations as well as informa-
tion for efficient and fault-free operation.
Safety notes as part of instructions
Safety notes may refer to individual instructions. In this
case, safety notes will be included in the instructions
and hence facilitate following the instructions. The
above listed signal words will be used.
Example:
1. Loosen the screw.
2.
CAUTION!
Danger of finger entrapment when closing
the lid.
Be careful when closing the lid.
3. Tighten the screw.
Specific safety notes
The following symbols are used in safety notes to alert
you to specific hazards:
Warning signs Type of danger
Warning – danger zone.
General information
Smoke control damper EK-JS4

1 Safety ................................................................ 6
1.1 General safety notes ................................. 6
1.2 Correct use ................................................ 6
1.3 Qualified staff ............................................. 6
2 Technical data .................................................. 7
2.1 General data .............................................. 7
2.2 Dimensions and weight ............................ 11
3 Transport and storage ................................... 13
4Parts and function ......................................... 14
4.1 Overview .................................................. 14
4.2 Functional description ............................. 14
5 Installation ...................................................... 16
5.1 Installation situations ............................... 16
5.2 Safety notes regarding installation .......... 16
5.3 General installation information ............... 16
5.3.1 High-temperature sealing tape ............. 17
5.4 Sheet steel smoke extract duct ............... 18
5.4.1 On a horizontal duct ............................. 18
5.4.2 In a horizontal duct ............................... 20
5.4.3 At the end of a horizontal duct .............. 22
5.4.4 On a horizontal duct ............................. 24
5.4.5 On a vertical duct ................................. 28
5.4.6 In a vertical duct ................................... 30
5.4.7 At the end of a vertical duct .................. 32
5.5 Solid smoke extract duct ......................... 34
5.5.1 On a vertical solid duct ......................... 34
5.6 Suspending the smoke control damper ... 36
5.6.1 General ................................................. 36
5.6.2 Fixing the unit to the ceiling slab .......... 36
5.6.3 Suspended installation ......................... 36
6 Smoke extract duct and cover grille ............ 37
6.1 Smoke extract ducts ................................ 37
6.2 Cover grilles ............................................. 38
7 Electrical connection .................................... 39
7.1 General safety notes ............................... 39
7.2 Wiring and connection to the central BMS
.................................................................. 39
7.3 Actuators ................................................. 40
7.3.1 B24 ....................................................... 40
7.3.2 B230 ..................................................... 41
7.3.3 B24-SR ................................................. 42
7.4 Actuator with control module ................... 43
7.4.1 TROXNETCOM B24A, B24AM,
B24AS .................................................. 44
7.4.2 B24BKNE ............................................. 45
7.4.3 SLC technology - B24C ........................ 46
7.4.4 B24D and B230D ................................. 47
8 Commissioning/functional test .................... 49
8.1 Commissioning ........................................ 49
8.2 Functional test ......................................... 49
9 Maintenance ................................................... 50
10 Decommissioning, removal and disposal ... 52
11 Flange dimensional drawing ........................ 54
12 Index................................................................ 56
Table of contents
Smoke control damper EK-JS 5

1 Safety
1.1 General safety notes
Sharp edges, sharp corners and thin sheet metal
parts
CAUTION!
Danger of injury from sharp edges, sharp cor-
ners and thin sheet metal parts!
Sharp edges, sharp corners and thin sheet metal
parts may cause cuts or grazes.
– Be careful when carrying out any work.
–Wear protective gloves, safety shoes and a hard
hat.
Electrical voltage
DANGER!
Danger of electric shock! Do not touch any live com-
ponents! Electrical equipment carries a dangerous
electrical voltage.
– Only skilled qualified electricians are allowed to
work on the electrical system.
–Switch off the power supply before working on
any electrical equipment.
1.2 Correct use
Type EK-JS smoke control dampers are used in
smoke and heat exhaust systems to remove smoke
and heat. EK-JZ smoke control dampers may be
used with the following systems:
– in pressure differential systems
– mechanical (i.e. powered) smoke exhaust sys-
tems
– natural smoke and heat exhaust systems
– heat exhaust systems
For use in single sections for increased operating
temperatures up to 600 °C.
Permitted for automatic release.
Suitable for use in combined systems (combination
damper) for ventilation.
Suitable for restricting extract air flow rates.
Operation of the smoke control dampers is only per-
mitted in compliance with the Declaration of Per-
formance (DoP) and these installation and operating
instructions.
Modifying the smoke control damper or using
replacement parts that have not been approved by
TROX is not permitted.
Incorrect use
WARNING!
Danger due to incorrect use!
Incorrect use of the smoke control damper can lead
to dangerous situations.
Never use the smoke control damper:
–in areas with potentially explosive atmospheres
– outdoors without sufficient protection against the
effects of weather and outside of temperature
limits
– in atmospheres where chemical reactions,
whether planned or unplanned, may cause
damage to the smoke control damper or lead to
corrosion
1.3 Qualified staff
WARNING!
Danger of injury due to insufficiently qualified
individuals!
Incorrect use may cause considerable injury or
damage to property.
– Only specialist personnel must carry out work.
The following degrees of qualification are required for
the work described in the operating manual:
Skilled qualified electrician
Skilled qualified electricians are individuals who have
sufficient professional or technical training, knowledge
and actual experience to enable them to work on elec-
trical systems, understand any potential hazards related
to the work under consideration, and recognise and
avoid any risks involved.
Specialist personnel
Specialist personnel are individuals who have sufficient
professional or technical training, knowledge and actual
experience to enable them to carry out their assigned
duties, understand any potential hazards related to the
work under consideration, and recognise and avoid any
risks involved.
Safety
Qualified staff
Smoke control damper EK-JS6

2 Technical data
2.1 General data
Nominal sizes B Ï H 100 × 100 – 1250 × 2560 mm
Casing length 200 mm
Flow rate range at maximum face velocity 10 m/s from 360 m³/h to 115,200 m³/h
from 100 l/s to 32,000 l/s
Differential pressure range Pressure level 3, –1500 to 500 Pa
Operating temperature -30 °C...50 °C the temperature should not fall below the dew
point
Upstream velocity
with uniform upstream and downstream flow
≤ 12 m/s, dimensional range
Ä table on page 9
≤ 20 m/s, dimensional range
Ä table on page 10
Note: Technical clarification with TROX required for some
sizes.
Closed damper leakage EN 1751, Class 2
Nominal size B Ï H ≥ 840 x 480: Class 3
Casing leakage EN 1751, Class B
Nominal size B Ï H ≥ 840 x 480: Class C
EC conformity EU Construction Products Regulation no. 305/2011
EN 12101-8 – Smoke and heat control systems –
Smoke control dampers
EN 1366-10 – Fire resistance tests for service installa-
tions – Smoke control dampers
EN 13501-4 – Fire classification of construction products
and building elements – Fire resistance tests on compo-
nents of smoke control
EN 1751 – Ventilation for buildings – Air terminal
devices
Declaration of performance DoP / EK-JS / 001
Technical data
General data
Smoke control damper EK-JS 7

Rating plate
Fig. 1: Smoke control damper rating plate (example)
1 Note regarding the observance of the operating
manual
2 Order number
3 Order code
4 Website from which the verification documents can
be downloaded
5 CE mark
6 The last two digits of the year in which the CE
marking was affixed
7 Year of manufacture
8 Manufacturer's address
9 Notified body
10 Regulated characteristics; the fire resistance class
depends on the application and may vary
Ä 5.1
‘Installation situations’ on page 16
11 Type
12 No. of the declaration of performance
13 Number of the European standard and year of its
publication
14 QR code to call the documentation
15 Product identification number
Technical data
General data
Smoke control damper EK-JS8

Actuator depending on the size of the smoke control damper at 12 m/s
H
B
100
150
200
250
300
360
400
450
520
550
600
680
700
750
840
850
900
950
1000
1050
1100
1150
1200
1250
100
125
150
165
320
480
640
800
960
1120
1280
1440
1600
1760
1920
2080
2240
2400
2560
= 15 Nm BEN, = 25 Nm BEE, = 40 Nm BE, = technical clarification with TROX required
Technical data
General data
Smoke control damper EK-JS 9

Actuator depending on the size of the smoke control damper at 20 m/s
H
B
100
150
200
250
300
360
400
450
520
550
600
680
700
750
840
850
900
950
1000
1050
1100
1150
1200
1250
100
125
150
165
320
480
640
800
960
1120
1280
1440
1600
1760
1920
2080
2240
2400
2560
= 15 Nm BEN, = 25 Nm BEE, = 40 Nm BE, = technical clarification with TROX required
Technical data
General data
Smoke control damper EK-JS10

2.2 Dimensions and weight
Fig. 2: EK-JS dimensional drawing
Installation side
Operating side
B Width
H Height
B x H = nominal size = area exposed to the airflow
①Keep area free for accessibility of the actuator
➁Fixing option for control module,
Fixing with self-tapping screws Æ 4.2 x 9.5 mm
(to be provided by others)
Technical data
Dimensions and weight
Smoke control damper EK-JS 11

Dimensions [mm] and total weight incl. actuator [kg]
H
B
100
150
200
250
300
350
400
450
500
550
600
650
700
750
800
850
900
950
1000
1050
1100
1150
1200
1250
100 7 8 8 8 9 9 9 10 10 10 11 11 11 11 12 12 12 13 13 13 14 14 14 15
125 8 8 8 9 9 9 10 10 10 11 11 11 11 12 12 12 13 13 13 14 14 14 15 15
150 8 8 9 9 9 9 10 10 10 11 11 11 12 12 12 13 13 13 14 14 14 15 15 15
165 8 8 9 9 9 10 10 10 11 11 11 12 12 12 13 13 13 14 14 14 15 15 15 16
320 11 12 13 13 14 15 15 16 17 17 18 19 19 20 21 21 22 23 23 24 25 25
480 13 14 15 16 16 17 18 19 19 20 21 22 22 23 24 25 26 26 27 28 29 29
640 16 16 17 18 19 20 21 21 22 23 24 25 26 27 27 28 29 30 31 32 32 33
800 18 19 20 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 35 36 37
960 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 42
1120 22 23 24 25 27 28 29 30 31 32 33 34 36 37 38 39 40 42 43 44 45 46
1280 24 25 27 28 29 30 32 33 34 35 37 38 39 41 42 43 44 46 47 48 49 51
1440 26 28 29 30 32 33 34 36 37 39 40 41 43 44 45 47 48 50 51 52 54 55
1600 28 30 31 33 34 36 37 39 40 42 43 45 46 48 49 51 52 54 55 57 58 59
1760 31 32 34 35 37 39 40 42 43 45 47 48 50 51 53 54 56 58 59 62 64 66
1920 33 35 36 38 40 41 43 45 47 48 50 52 53 55 57 58 62 63 65 67 68 70
2080 35 37 39 41 42 44 46 48 50 51 53 55 57 58 62 64 65 67 69 71 73 74
2240 37 39 41 43 45 47 49 51 53 54 56 60 62 64 66 67 69 71 73 75 77 79
2400 40 42 44 46 48 50 52 54 56 59 61 63 65 67 69 71 73 75 77 79 81 83
2560 42 44 46 48 50 52 54 57 60 62 65 67 69 71 73 75 77 79 81 84 86 88
Technical data
Dimensions and weight
Smoke control damper EK-JS12

3 Transport and storage
Delivery check
Check delivered items immediately after arrival for
transport damage and completeness. In case of any
damage or an incomplete shipment, contact the ship-
ping company and your supplier immediately.
A complete shipment includes:
Smoke control damper(s)
– Attachments/accessories, if any
Installation and operating manual (one per ship-
ment)
Fixing and installation material
Fixing and installation material is not part of the
supply package (unless stated otherwise), but has to
be provided by others; it has to be suitable for the
installation situation.
Transport on site
If possible, take the product in its transport packaging
up to the installation location.
Bearing
For temporary storage please note:
Remove any plastic wrapping.
Protect the product from dust and contamination.
Store the product in a dry place and away from
direct sunlight.
Do not expose the unit to the effects of weather (not
even in its packaging).
Storage temperature: -30 °C to 50 °C, no condensa-
tion.
Packaging
Properly dispose of packaging material.
Transport and storage
Smoke control damper EK-JS 13

4 Parts and function
4.1 Overview
Fig. 3: Smoke control damper EK-JS
1 Enclosure
2 Linkage cover (cut open)
3 Linkage
4 Actuator
5 Rating plate
6 Side seal
7 Damper blades
8 Damper blade profiled seal
4.2 Functional description
Smoke control dampers of the EK-JS series are used in
smoke control systems and serve, on the one hand, to
remove smoke gases and thermal energy and, on the
other hand, to allow fresh air to flow into the area to be
kept smoke-free.
The EK-JS is used in pressurised ventilation systems to
keep smoke out of
safety stairwells and their vestibules
Fire brigade lift shafts
Escape tunnels
The EK-JS is intended for use in single sections.
It is allowed to be used in combined ventilation/smoke
extract systems as a combination damper for smoke
extraction as well as for restricting extract air flow rates.
Regular maintenance of the smoke control damper is
required to ensure its functional reliability
Ä 9 ‘Mainte-
nance’ on page 50 .
Smoke extract
Fig. 4: Smoke extract system
①EK-JZ or EK2-EU in solid shaft wall
②EK-JZ or EK2-EU in solid wall or duct
③EK-JZ or EK2-EU on solid shaft wall
④EK-JZ or EK2-EU on a vertical smoke extract duct
(shaft)
⑤EK-JZ or EK2-EU on a horizontal smoke extract
duct
⑥EK-JS in a horizontal smoke extract duct
⑦EK-JS at the end of a horizontal smoke extract duct
⑧EK-JS, EK-JZ or EK2-EU as additional supply air
inlet
⑨Cover grilles
Smoke control dampers are completely closed during
normal operation. In smoke extraction mode, the smoke
control dampers in the affected fire compartment are
opened to extract smoke from it. All other smoke control
dampers remain closed.
In the event of a fire, smoke control dampers that are
used as additional supply air inlets in the affected fire
compartment also open so that smoke can be extracted.
To ensure the creation of a layer that is nearly free from
smoke, smoke control dampers used as additional
supply air inlets should be installed near the ground.
The control input signal for the actuator may come from
a duct smoke detector or from the central fire alarm
system. Using cables with specific circuit integrity for the
supply voltage ensures that the actuator is supplied with
voltage even in the event of a fire and hence that its
function and the communication are maintained.
Parts and function
Functional description
Smoke control damper EK-JS14

Supply air and smoke extraction in ventilation sys-
tems
When authorised by building authorities or authorised
bodies, smoke extract and supply air applications as
well as ventilation can be enabled in combined systems
with smoke control dampers. Depending on the system
layout, the damper blade can be fully opened, fully
closed or in the intermediate position. Depending on
where the dampers are installed, country-specific regu-
lations may apply to ventilation applications.
Parts and function
Functional description
Smoke control damper EK-JS 15

5 Installation
5.1 Installation situations
The table lists the various installation types of EK-JZ smoke control dampers; for details on the performance level
see the declaration of performance.
Installation locations described here may be combined with other installation location characteristics. For example, a
smoke control damper may be installed on a vertical smoke extract duct where a horizontal smoke extract duct
branches off.
Supporting con-
struction
Construction Installation loca-
tion
Installa-
tion type
Performance
level
Installa-
tion
informa-
tion
Horizontal sheet
steel smoke extract
duct
Sheet steel smoke extract
duct tested according to
EN 1366-9
Operating temperature up to
600 °C
on a horizontal
duct
LE
E600 120
(ved, i↔o) S
Ä 18
in a horizontal
duct
Ä 20
at the end of a
horizontal duct
Ä 22
on top of a hori-
zontal duct
E600 120
(hod, i↔o) S
Ä 24
Vertical sheet steel
smoke extract duct
(horizontal sheet
steel smoke extract
duct with height
offset)
on a vertical duct E600 120
(ved, i↔o) S
Ä 28
in a vertical duct E600 120
(hod, i↔o) S
Ä 30
at the end of a
vertical duct
Ä 32
Vertical solid
smoke extract
ducts
Operating temperature up to
600 °C on a vertical duct E600 120
(ved, i↔o) S
Ä 34
LE = As specified for the duct
5.2 Safety notes regarding installation
Sharp edges, sharp corners and thin sheet metal
parts
CAUTION!
Danger of injury from sharp edges, sharp cor-
ners and thin sheet metal parts!
Sharp edges, sharp corners and thin sheet metal
parts may cause cuts or grazes.
– Be careful when carrying out any work.
– Wear protective gloves, safety shoes and a hard
hat.
5.3 General installation information
NOTICE!
Be careful to not damage the smoke control
damper
– Protect the smoke control damper from contami-
nation and damage.
– Cover the flange openings and the actuator (e.g.
with plastic) to protect them from mortar and
dripping water.
Please note:
Install the smoke control damper without torsion
(horizontal/vertical).
Make sure that no loads are imposed on the casing
as this may impair the function of the smoke control
damper.
Smoke control damper and electric actuator must
remain accessible for maintenance.
Installation
General installation information
Smoke control damper EK-JS16

Installation position
Fig. 5: EK-JS installation position
1 Horizontal smoke extract duct
2 Vertical smoke extract duct (horizontal)
3 Solid smoke extract duct
The EK-JS smoke control damper is only allowed to be
installed with the installation position horizontal or lying
down.
The position of the actuator is not critical but it must
remain accessible for maintenance.
5.3.1 High-temperature sealing tape
High-temperature sealing tape is used to seal between
the flange of the smoke control damper and the flange
of the sheet steel smoke extract duct and is available as
an accessory (accessories 17 and 19)
Installation
General installation information > High-temperature sealing tape
Smoke control damper EK-JS 17

5.4 Sheet steel smoke extract duct
5.4.1 On a horizontal duct
Fig. 6: Installation on a horizontal smoke extract duct
①EK-JS
②Suspension system
Ä 5.6 ‘Suspending the
smoke control damper’ on page 36
③Sheet steel duct for increased operating tempera-
tures
④Hexagon bolts M8 with 2 washers and nuts (to be
provided by others)
⑤Duct clips or self-tapping screws Æ 5.5 x 22 mm (to
be provided by others)
⑥HT sealing tape (accessories or to be provided by
others)
* Duct clips not shown
** Hexagon bolts M8 with 2 washers and nut not
shown
Classification:
E600120 (ved- i <-> o) S1500 Cmod AA single
Installation
Sheet steel smoke extract duct > On a horizontal duct
Smoke control damper EK-JS18

Personnel:
Specialist personnel
Requirements:
Sheet steel duct for increased operating tempera-
tures
The actuator must remain accessible for mainte-
nance work after installation
1. Manufacture sheet steel duct ➂ and cut to length
according to manufacturer's instructions.
2. Apply HT sealing tape ➅ to the flange of the
smoke control damper ➀ for sealing.
3. Manufacture suspension ➁ for smoke control
damper
Ä 5.6 ‘Suspending the smoke control
damper’ on page 36 .
4. Screw smoke control damper to the sheet steel
duct with hexagon bolts, washers and nuts ➃.
5. In addition, connect the smoke control damper
with duct clips ➄ or alternatively self-tapping
screws
Ä Chapter 6.1 ‘Smoke extract ducts’
on page 37 .
Installation
Sheet steel smoke extract duct > On a horizontal duct
Smoke control damper EK-JS 19

5.4.2 In a horizontal duct
Fig. 7: Installation in a horizontal smoke extract duct
①EK-JS
②Suspension system
Ä 5.6 ‘Suspending the
smoke control damper’ on page 36
③Sheet steel duct for increased operating tempera-
tures
④Hexagon bolts M8 with 2 washers and nuts (to be
provided by others)
⑤Duct clips or self-tapping screws Æ 5.5 x 22 mm (to
be provided by others)
⑥HT sealing tape (accessories or to be provided by
others)
* Duct clips not shown
** Hexagon bolts M8 with 2 washers and nut not
shown
Classification:
E600120 (ved- i <-> o) S1500 Cmod AA single
Installation
Sheet steel smoke extract duct > In a horizontal duct
Smoke control damper EK-JS20
