Trox Technik EK2-EU User manual

Smoke control damper
Type EK2-EU
Installation and operating manual
Read the instructions prior to performing any task!
according to EN12101-8
Declaration of Performance DoP / EK2-EU / 001
GB/en

A00000085701, 1, GB/en
Translation of the original
Valid from 12/2020
TROX GmbH
Heinrich-Trox-Platz
47504 Neukirchen-Vluyn, Germany
Germany
Phone: [phone]
Telefax: [phone]
E-mail: [email protected]
Internet: http://www.troxtechnik.com
02/2021
Smoke control damper Type EK2-EU
2

General information
About this manual
This operating and installation manual enables oper-
ating or service personnel to correctly install the TROX
product described below and to use it safely and effi-
ciently.
This operating and installation manual is intended for
use by fitting and installation companies, in-house tech-
nicians, technical staff, instructed persons, and qualified
electricians or air conditioning technicians.
It is essential that these individuals read and fully under-
stand this manual before starting any work. The basic
prerequisite for safe working is to comply with the safety
notes and all instructions in this manual.
The local regulations for health and safety at work and
general safety regulations also apply.
This manual must be given to the system owner when
handing over the system. The system owner must
include the manual with the system documentation. The
manual must be kept in a place that is accessible at all
times.
Illustrations in this manual are mainly for information
and may differ from the actual design.
Copyright
This document, including all illustrations, is protected by
copyright and pertains only to the corresponding
product.
Any use without our consent may be an infringement of
copyright, and the violator will be held liable for any
damage.
This applies in particular to:
Publishing content
Copying content
Translating content
Microcopying content
Saving content to electronic systems and editing it
TROX Technical Service
To ensure that your request is processed as quickly as
possible, please keep the following information ready:
Product name
TROX order number
Delivery date
Brief description of the fault
Online www.troxtechnik.com
Phone [phone]
Limitation of liability
The information in this manual has been compiled with
reference to the applicable standards and guidelines,
the state of the art, and our expertise and experience of
many years.
The manufacturer does not accept any liability for dam-
ages resulting from:
Non-compliance with this manual
Incorrect use
Operation or handling by untrained individuals
Unauthorised modifications
Technical changes
Use of non-approved replacement parts
The actual scope of delivery may differ from the infor-
mation in this manual for bespoke constructions, addi-
tional order options or as a result of recent technical
changes.
The obligations agreed in the order, the general terms
and conditions, the manufacturer's terms of delivery,
and the legal regulations in effect at the time the con-
tract is signed shall apply.
We reserve the right to make technical changes.
Warranty claims
The provisions of the respective delivery terms apply to
warranty claims. For purchase orders placed with TROX
GmbH, these are the regulations in section "Vl. War-
ranty claims" of the Delivery and Payment Terms of
TROX GmbH, see www.trox.de/en/ .
General information
Smoke control damper Type EK2-EU 3

Safety notes
Symbols are used in this manual to alert readers to
areas of potential hazard. Signal words express the
degree of the hazard.
Comply with all safety instructions and proceed carefully
to avoid accidents, injuries and damage to property.
DANGER!
Imminently hazardous situation which, if not avoided,
will result in death or serious injury.
WARNING!
Potentially hazardous situation which, if not avoided,
may result in death or serious injury.
CAUTION!
Potentially hazardous situation which, if not avoided,
may result in minor or moderate injury.
NOTICE!
Potentially hazardous situation which, if not avoided,
may result in property damage.
ENVIRONMENT!
Environmental pollution hazard.
Tips and recommendations
Useful tips and recommendations as well as informa-
tion for efficient and fault-free operation.
Safety notes as part of instructions
Safety notes may refer to individual instructions. In this
case, safety notes will be included in the instructions
and hence facilitate following the instructions. The
above listed signal words will be used.
Example:
1. Loosen the screw.
2.
CAUTION!
Danger of finger entrapment when closing
the lid.
Be careful when closing the lid.
3. Tighten the screw.
Specific safety notes
The following symbols are used in safety notes to alert
you to specific hazards:
Warning signs Type of danger
Warning – danger zone.
General information
Smoke control damper Type EK2-EU4

1 Safety ................................................................ 6
1.1 General safety notes ................................. 6
1.2 Correct use ................................................ 6
1.3 Qualified staff ............................................. 6
2 Technical data .................................................. 7
2.1 General data .............................................. 7
2.2 Dimensions and weight ............................. 8
3 Transport and storage ................................... 11
4 Parts and function ......................................... 12
5 Installation ...................................................... 13
5.1 Installation situations ............................... 13
5.2 Safety notes regarding installation .......... 13
5.3 General installation information ............... 13
5.3.1 Installation position ............................... 14
5.3.2 Adjoined damper installation ................ 14
5.3.3 Installation opening .............................. 16
5.3.4 After installation .................................... 16
5.4 Supporting construction – solid walls ...... 17
5.4.1 Dry mortarless installation .................... 17
5.4.2 Wet-dry mortarless installation ............. 19
5.4.3 Mortar-based installation ...................... 21
5.5 Supporting construction – solid ceiling
slabs ........................................................ 23
5.5.1 Mortar-based installation ...................... 23
5.6 Supporting construction – lightweight par-
tition wall .................................................. 25
5.6.1 Dry mortarless installation .................... 25
5.6.2 Wet-dry mortarless installation ............. 27
5.6.3 Mortar-based installation ...................... 29
5.7 Fire-resistant smoke extract ducts .......... 31
5.7.1 In vertical and horizontal smoke extract
ducts ..................................................... 31
5.7.2 In horizontal smoke extract ducts ......... 33
5.7.3 On horizontal smoke extract ducts ....... 34
5.7.4 On top of horizontal smoke extract ducts
............................................................... 36
5.7.5 At the end of horizontal smoke extract
ducts ..................................................... 38
5.8 Suspending the smoke control damper ... 39
5.8.1 General ................................................. 39
5.8.2 Fixing the unit to the ceiling slab .......... 39
5.8.3 Suspended installation ......................... 39
6 Smoke extract duct and cover grille ............ 40
6.1 Smoke extract ducts ................................ 40
6.2 Cover grilles ............................................. 41
6.3 Inspection access .................................... 41
7 Electrical connection .................................... 42
7.1 General safety notes ............................... 42
7.2 Wiring and connection to the central BMS
.................................................................. 42
7.3 Actuators ................................................. 43
7.3.1 B24 ....................................................... 44
7.3.2 B230 ..................................................... 45
7.3.3 B24-SR ................................................. 46
7.4 Actuator with control module ................... 47
7.4.1 TROXNETCOM B24A, B24AM,
B24AS .................................................. 48
7.4.2 B24BKNE ............................................. 49
7.4.3 SLC technology - B24C ........................ 50
7.4.4 B24D and B230D ................................. 51
8 Commissioning/functional test .................... 53
8.1 Commissioning ........................................ 53
8.2 Functional test ......................................... 53
8.2.1 Manually, on the smoke control damper
............................................................... 53
9 Maintenance ................................................... 54
10 Decommissioning, removal and disposal ... 56
11 Index................................................................ 57
Table of contents
Smoke control damper Type EK2-EU 5

1 Safety
1.1 General safety notes
Sharp edges, sharp corners and thin sheet metal
parts
CAUTION!
Danger of injury from sharp edges, sharp cor-
ners and thin sheet metal parts!
Sharp edges, sharp corners and thin sheet metal
parts may cause cuts or grazes.
– Be careful when carrying out any work.
–Wear protective gloves, safety shoes and a hard
hat.
Electrical voltage
DANGER!
Danger of electric shock! Do not touch any live com-
ponents! Electrical equipment carries a dangerous
electrical voltage.
– Only skilled qualified electricians are allowed to
work on the electrical system.
–Switch off the power supply before working on
any electrical equipment.
1.2 Correct use
Type EK2-EU smoke control dampers are used in heat
and exhaust systems to remove smoke or heat and to
supply air in case of an incident.
Daily use for room air change is possible within the
described operating conditions (ambient temperature,
humidity).
Type EK2-EU smoke control dampers may be used
with the following systems:
– mechanical (i.e. powered) smoke exhaust sys-
tems
– pressurisation systems (RDA), e.g. fire brigade
hoists
– heat exhaust systems
– gas fire extinguishing systems
Operation of smoke control dampers is allowed only
in compliance with installation regulations and the
technical data in this installation and operating
manual.
Modifying the smoke control damper or using
replacement parts that have not been approved by
TROX is not permitted.
New provisions regarding use have been added:
Country-specific guidelines, directives and model
regulations must be observed.
Use in accordance with a fire protection concept that
is based on the protection goal can authorise further
installation options in air conditioning and ventilation
systems as well.
Incorrect use
WARNING!
Danger due to incorrect use!
Incorrect use of the smoke control damper can lead
to dangerous situations.
Never use the smoke control damper:
–in areas with potentially explosive atmospheres
– outdoors without sufficient protection against the
effects of weather
– in atmospheres where chemical reactions,
whether planned or unplanned, may cause
damage to the smoke control damper or lead to
corrosion
1.3 Qualified staff
WARNING!
Danger of injury due to insufficiently qualified
individuals!
Incorrect use may cause considerable injury or
damage to property.
– Only specialist personnel must carry out work.
Personnel:
Skilled qualified electrician
Specialist personnel
Skilled qualified electrician
Skilled qualified electricians are individuals who have
sufficient professional or technical training, knowledge
and actual experience to enable them to work on elec-
trical systems, understand any potential hazards related
to the work under consideration, and recognise and
avoid any risks involved.
Specialist personnel
Specialist personnel are individuals who have sufficient
professional or technical training, knowledge and actual
experience to enable them to carry out their assigned
duties, understand any potential hazards related to the
work under consideration, and recognise and avoid any
risks involved.
Safety
Qualified staff
Smoke control damper Type EK2-EU6

2 Technical data
2.1 General data
Nominal sizes 200 × 200 – 1500 × 800 mm
Volume flow rate range up to 12000 l/s
up to 43200 m³/h
Differential pressure range Pressure level 3, –1500 to 500 Pa
Operating temperature -30 °C...50 °C the temperature should not fall below the dew
point
Upstream velocity 1≤ 10 m/s with the maximum size
>10...15 m/s with smaller sizes, up to 43,200 m³/h
Closed blade air leakage EN 1751, at least class 3
Casing air leakage EN 1751, Class C
EC conformity EU Construction Products Regulation no. 305/2011
EN 12101-8 – Smoke and heat control systems –
Smoke control dampers
EN 1366-10 – Fire resistance tests for service installa-
tions – Smoke control dampers
EN 1366-2 – Fire resistance tests for service installa-
tions – Part 2: Fire dampers
EN 13501-4 – Fire classification of construction products
and building elements – Fire resistance tests on compo-
nents of smoke control
EN 1751 – Ventilation for buildings – Air terminal
devices
Declaration of performance DoP/EK2-EU/001
1) If there is a guarantee that actuation does not occur over 10 m/s (change of damper blade position, leaving of end position), the smoke con-
trol damper can be used up to its maximum dimensions with an upstream velocity of 15 m/s.
Rating plate
Fig. 1: Product sticker (example)
1 Type
2 No. of the declaration of performance
3 Number of the European standard and year of its
publication
4 Regulated characteristics; the fire resistance class
depends on the application and may vary
5 Notified body
6 Year of manufacture
7 Manufacturer's address and website from which
the DoP can be downloaded
8 CE mark
9 The last two digits of the year in which the CE
marking was affixed
10 Order code
11 Order number
Technical data
General data
Smoke control damper Type EK2-EU 7

2.2 Dimensions and weight
Fig. 2: EK2-EU size S
Operating side
Installation side
①EK2-EU
②Connecting subframe (optional)
③Fixing screw
④Seal
⑤Keep clear to provide access to the actuator
encasing Fig. 4
⑥Actuator encasing
⑦Module encasing
Dimensions [mm]
Size H L L3L4
S 200...380
650 (only without inspection access
panel)
750 (with inspection access panel)
97
197
208
208
Technical data
Dimensions and weight
Smoke control damper Type EK2-EU8

Fig. 3: EK2-EU size M and L
Operating side
Installation side
* For size L, the actuator/module encasing is sup-
plied in two versions, depending on the drive
required. For 15 Nm and 25 Nm (small), for 40 Nm
(large).
①EK2-EU
②Connecting subframe (optional)
③Fixing screw
④Seal
⑤Keep clear to provide access to the actuator
encasing Fig. 4
⑥Actuator encasing
⑦Module encasing
Dimensions [mm]
Size H L L3L4
M 385...545 600 210 210
L 550...800 800 310 310
Technical data
Dimensions and weight
Smoke control damper Type EK2-EU 9

Weights [kg] (standard lengths)
Size H
[mm]
L
[mm]
B [mm]
200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500
S
200
650
31 36 41 46 51 55 60 65 70 75 80 84 89 94
250 33 39 44 49 54 59 64 69 74 79 84 89 94 99
300 36 41 47 52 57 62 67 72 77 83 88 93 98 103
380 38 44 49 55 60 65 71 76 81 86 92 97 102 108
M
400
600
39 44 49 55 60 65 70 75 81 86 91 96 101 107
450 41 47 52 57 63 68 73 79 84 90 95 100 106 111
500 44 49 55 60 66 71 77 82 88 93 99 104 110 116
545 46 51 57 63 69 74 80 86 91 97 103 108 114 120
L
600
800
60 67 74 81 88 96 103 110 117 124 131 138 146 153
650 63 70 77 85 92 99 107 114 121 129 136 143 150 158
700 66 73 81 88 96 103 110 118 125 133 140 148 155 163
750 69 76 84 91 99 107 114 122 130 137 145 153 160 168
800 72 79 87 95 103 110 118 126 134 142 150 157 165 173
Technical data
Dimensions and weight
Smoke control damper Type EK2-EU10

3 Transport and storage
Delivery check
Check delivered items immediately after arrival for
transport damage and completeness. In case of any
damage or an incomplete shipment, contact the ship-
ping company and your supplier immediately.
A complete shipment includes:
Smoke control damper(s)
– Attachments/accessories, if any
Installation and operating manual (one per ship-
ment)
Fixing and installation material
Fixing and installation material is not part of the
supply package (unless stated otherwise), but has to
be provided by others; it has to be suitable for the
installation situation.
Transport on site
If possible, take the product in its transport packaging
up to the installation location.
Transport protection devices
The EK2-EU is delivered with cardboard transport pro-
tection that stabilises the casing during transport and
installation. Only remove the transport protection after
the installation work has been completed or, in the case
of mortar-based installation, only after the mortar has
cured.
Bearing
For temporary storage please note:
Remove any plastic wrapping.
Protect the product from dust and contamination.
Store the product in a dry place and away from
direct sunlight.
Do not expose the unit to the effects of weather (not
even in its packaging).
Storage temperature: -30 °C to 50 °C, no condensa-
tion.
Packaging
Properly dispose of packaging material.
Transport and storage
Smoke control damper Type EK2-EU 11

4 Parts and function
Smoke control dampers are used in mechanical smoke
extract systems. They are used for extracting smoke
gases and for providing additional supply air to one or
more fire compartments.
Smoke control dampers are made from calcium silicate
boards, and the electric actuator and the optional con-
trol module are encased so that the functional reliability
is ensured even in the event of a fire.
Regular maintenance of the smoke control damper is
required to ensure its functional reliability
Ä 9 ‘Mainte-
nance’ on page 54 .
Fig. 4: Smoke control damper EK2-EU
①Casing
②Damper blade
③Travel stop
④Inspection access (optional)
⑤Actuator encasing
⑥Actuator
⑦Cover of the actuator encasing (open)
⑧Rating plate
Smoke extract
Fig. 5: Smoke extract system
①EK2-EU in a solid shaft wall
②EK2-EU in a solid wall and a duct
③EK-JZ on a vertical solid shaft wall
④On a vertical smoke extract duct (shaft)
⑤On a horizontal smoke extract duct
⑥In a horizontal smoke extract duct
⑦At the end of a horizontal smoke extract duct
⑧EK2-EU as additional supply air inlet
⑨Cover grilles
During normal operation, Type EK2-EU smoke control
dampers remain closed. For smoke extract, the smoke
control dampers in the affected fire compartment open
so that smoke can be extracted. All other smoke control
dampers remain closed.
In the event of a fire, smoke control dampers that are
used as additional supply air inlets in the affected fire
compartment also open so that smoke can be extracted.
To ensure the creation of a layer that is nearly free from
smoke, smoke control dampers used as additional
supply air inlets should be installed near the ground.
The control input signal for the actuator may come from
a duct smoke detector or from the central fire alarm
system. Using cables with specific circuit integrity for the
supply voltage ensures that the actuator is supplied with
voltage even in the event of a fire and hence that its
function and the communication are maintained.
Supply air and smoke extraction in ventilation sys-
tems
When authorised by building authorities or authorised
bodies, smoke extract and supply air applications as
well as ventilation can be enabled in combined systems
with smoke control dampers. Depending on the system
layout, the damper blade can be fully opened, fully
closed or in the intermediate position. Depending on
where the dampers are installed, country-specific regu-
lations may apply to ventilation applications.
Parts and function
Smoke control damper Type EK2-EU12

5 Installation
5.1 Installation situations
The overview of all possible installation types of the
smoke control damper EK2-EU are listed in the declara-
tion of performance; they can be downloaded from the
TROX homepage.
5.2 Safety notes regarding installation
Sharp edges, sharp corners and thin sheet metal
parts
CAUTION!
Danger of injury from sharp edges, sharp cor-
ners and thin sheet metal parts!
Sharp edges, sharp corners and thin sheet metal
parts may cause cuts or grazes.
– Be careful when carrying out any work.
–Wear protective gloves, safety shoes and a hard
hat.
5.3 General installation information
NOTICE!
Be careful to not damage the smoke control
damper
– Protect the smoke control damper from contami-
nation and damage.
–Cover the flange openings and the actuator (e.g.
with plastic) to protect them from mortar and
dripping water.
Please note:
Smoke control damper and electric actuator
(encasing) must remain accessible for maintenance.
Make sure that no loads are imposed on the casing
as this may impair the function of the smoke control
damper.
Install the smoke control damper without torsion
(horizontal/vertical).
Mortar-based installation: The perimeter
gap »s« must be large enough so that mortar can be
filled in even in case of thicker walls.
Requirements for wall and ceiling systems
EK2-EU smoke control dampers may be installed in wall
and ceiling systems if these walls and ceilings have
been erected in compliance with the relevant regula-
tions and according to the manufacturers' instructions,
and if the information on the respective installation sit-
uation applies and the following requirements are met.
Provide any installation openings according to the
installation details in this manual.
Solid walls or solid shaft walls
Solid walls or solid shaft walls made of, for example,
concrete, aerated concrete or bricks, gross density
≥ 500 kg/m³.
Wall thickness W ≥ 100 mm.
Provide each installation opening according to the
local and structural conditions and with regard to the
dimensions of the smoke control damper.
Solid ceiling slabs
Solid ceiling slabs without open spaces, made of
concrete or aerated concrete, gross density
≥ 500 kg/m³.
Ceiling thickness D ≥ 150 mm.
Provide each installation opening according to the
local and structural conditions and with regard to the
dimensions of the smoke control damper.
Lightweight partition walls with metal support struc-
ture
Lightweight partition wall with metal support or steel
support structure, with European classification to
EN 13501-2 or equivalent national classification.
Cladding on both ends made from plasterboard fire
barriers.
Wall thickness W ≥ 100 mm.
≤ 625 mm distance between metal studs.
Create an installation opening with studs.
If necessary, provide trim panels and screw-fix them
to the support structure.
Additional layers of cladding (if stated in the usability
certificate for the wall) and double stud construc-
tions are approved.
Connect the metal sections near the installation
opening according to the installation details in this
manual.
Acceptable mortars for mortar-based installation
In case of mortar-based installation, the open spaces
between the fire damper casing and the wall or ceiling
slab must be closed off with mortar. Entrapped air is to
be avoided. The mortar bed depth should be equal to
the thickness of the wall but must be at least 100 mm.
The following mortars are acceptable:
DIN 1053: Groups II, IIa, III, IIIa; fire protection
mortar of groups II, III
EN 998-2: Classes M 2.5 to M 10 or fire protection
mortar of classes M 2.5 to M 10
Equivalent mortars that meet the requirements of
the above standards, gypsum mortar or concrete
Installation
General installation information
Smoke control damper Type EK2-EU 13

Mineral wool as filling material
Unless otherwise stated in the installation details, min-
eral wool with a gross density of ≥ 80 kg/m³ and a
melting point of ≥ 1000 °C must be used.
High-temperature sealing tape
Fig. 6: Affixing the sealing tape
Affix the high-temperature sealing tape ( Fig. 6 /1) with
trim panel thickness (flush at front and rear) to the
damper frame (if necessary, mark the trim panel thick-
ness beforehand).
Permitted use (depending on installation situation)
Lower installation gap
Side installation gap
The high temperature sealing tape (melting point
1200 °C) can be ordered as an accessory.
5.3.1 Installation position
The smoke control damper can be installed so that the
damper blade shaft is horizontal or vertical. The position
of the actuator is not critical but it must remain acces-
sible for maintenance.
Fig. 7: Blade shaft horizontal or vertical
5.3.2 Adjoined damper installation
Side by side
The casings are screwed in to the vertical H parts
(opposite the actuator encasing) on both sides of the
damper (installation and operating side).
Fig. 8: EK2-EU side by side
1 m× dry wall screw 6 × 80 mm (by others)
n H - 100 / 200 (round up if necessary)
P1 H - 100 / n (≤200 mm)
P2 P1 + 50
P3 P1 × 2
m n + 1 (number of screws)
Calculation example:
H = 800 mm
n = 800 - 100 / 200 = 3.5 -> 4
P1 = 800 - 100 / 4 = 175 mm
P2 = 175 + 50 = 225
P3 = 175 × 2 = 350
m = 4 + 1 = 5
Installation
General installation information > Adjoined damper installation
Smoke control damper Type EK2-EU14

On top of each other
The casings are screwed in to the horizontal B parts on
both sides of the damper (installation and operating
side.
Insert screws both from the top damper and from the
bottom damper; do not insert all screws in one line, but
pre-drill in an offset pattern.
Fig. 9: EK2-EU on top of each other
1 m × dry wall screw 6 × 80 mm (by others)
n B- 100 / 200 (round up if necessary)
P1 B - 100 / n (≤200 mm)
P2 P1 + 50
P3 P1 × 2
m n + 1 (number of screws)
Calculation example:
B = 1500 mm
n = 1500 - 100 / 200 = 7
P1 = 1500 - 100 / 7 = 200 mm
P2 = 200 + 50 = 250
P3 = 200 × 2 = 400
m = 7 + 1 = 8
Installation
General installation information > Adjoined damper installation
Smoke control damper Type EK2-EU 15

5.3.3 Installation opening
Fig. 10: Ideal installation opening
B Rated dimension, width EK2-EU
b Width of installation opening
H Rated dimension, height EK2-EU
h Height of installation opening
Calculation of installation opening
b = (B + 100 mm) + S1+ S2
h = (H + 100 mm) + S3 + S4
The dimensions for the installation gaps S1 – S4 can be found in the respective installation descriptions.
Adapting the installation opening in solid walls and
shaft walls
Fig. 11: Installation opening with concrete or calcium sili-
cate boards for height adjustment
t = W (100 mm min., 250 mm max.)
h1 See Table
To adapt the height of the installation opening you can
fill in concrete ( Fig. 11 /1) or calcium silicate boards
( Fig. 11 /2) at the bottom.
Be sure to attach the boards to each other and also to
attach them to the brick structure. To do so, use glue or
screws ( Fig. 11 /3); screws should be at ≤200 mm from
each other.
Boards Thickness [mm] h1 [mm]
Promatect MT 40 40 - 200
Boards Thickness [mm] h1 [mm]
Promatect LS 35 35 - 210
Promatect H 25 25 - 200
Promatect H 10 - 20 10 - 100
Glue: Promat K84
Additional information upon request.
5.3.4 After installation
Remove the transport protection device (in case of
mortar-based installation, do this after the mortar
has cured)
Clean the smoke control damper.
Carry out functional test.
Ä 53
Connect the smoke extract duct.
Make electrical connections.
Installation
General installation information > After installation
Smoke control damper Type EK2-EU16

5.4 Supporting construction – solid walls
5.4.1 Dry mortarless installation
Fig. 12: Dry mortarless installation in solid wall, installation variant b, classification index: vew
①EK2-EU, vertical or horizontal installation position
②Solid wall made of brick, concrete or aerated con-
crete
④High-temperature sealing tape
⑤Fire protection acrylic bead
⑥Annular gap cover, 2 pieces, 12.5 x 45 mm
⑦Steel wire clip
W Wall thickness ≥ 100 mm
Installa-
tion var-
iant
Classifica-
tion*
Installation gap
s1 (left) s2 (right) s3 (top) s4 (bottom)
a EI90...S Annular gap cover Annular gap cover Annular gap cover Annular gap cover
b EI90...S Annular gap cover Annular gap cover Annular gap cover HT sealing tape
c EI90...S HT sealing tape Annular gap cover Annular gap cover HT sealing tape
days EI90...S Annular gap cover HT sealing tape Annular gap cover HT sealing tape
* Part of the classification key
HT sealing tape = high-temperature sealing tape, Þ detail 4
Annular gap cover = annular gap cover on both sides of the wall, Þ detail 5 + 6
Installation
Supporting construction – solid walls > Dry mortarless installation
Smoke control damper Type EK2-EU 17

Personnel:
Specialist personnel
Materials:
High-temperature sealing tape
Ä ‘High-temperature sealing tape’ on page 14
For annular gap cover: PROMATECT®-H fire protection board d = 25 mm or strips of plasterboard 2 x 12.5 mm x
45 mm
Steel staples 63/11.2/1.53 mm
Fire protection acrylic
Requirements:
Solid walls,
Installation alternatives outside the wall
To prevent sleeve joints between the damper and the duct in the wall, the damper can alternatively be placed
outside the wall in the flow of the approved smoke extract duct
Ä 5.7 ‘Fire-resistant smoke extract ducts’
on page 31 .
Create an appropriate opening
1. Create an installation opening according to Fig. 12 .
Installation opening b x h:
b = B + 100 + s1 + s2
h = H + 100 + s3 + s4
Example: B x H = 1200 x 750 mm, s1 = 5 mm, s2 = 5 mm, S3 = 10 mm, s4 = 3 mm
b = 1200 + 100 + (5 + 5 mm) = 1310 mm
h = 750 + 100 + (10 + 3 mm) = 863 mm
2.
In case of installation variant b, c, d
Stick the high-temperature sealing tape on the damper housing in the trim panel thickness on the damper
housing,
Þ detail 4, Ä ‘High-temperature sealing tape’ on page 14
Push the smoke control damper into the installation opening and secure it. Make sure that the actuator
encasing rests on the face of the wall or freely positioned up to a total length L 1/2, centred in the wall.
3. Create the installation gap "s" according to the installation variant; see the table above.
Making the annular gap cover Þ detail 5 + 6
Before fitting the annular gap cover, seal the installation gap with fire protection acrylic on both sides of the
wall. Fix the annular gap cover to the damper casing on both sides of the wall with steel wire clips.
Connecting the smoke extract duct to EK2-EU
4.
Ä 6 ‘Smoke extract duct and cover grille’ on page 40
Follow the manufacturer's instructions of the smoke extract duct here as well.
Installation
Supporting construction – solid walls > Dry mortarless installation
Smoke control damper Type EK2-EU18

5.4.2 Wet-dry mortarless installation
Fig. 13: Wet-dry mortarless installation in solid wall, installation variant 2a, classification index: vew
①EK2-EU, vertical or horizontal installation position
②Solid wall made of brick, concrete or aerated con-
crete
④High-temperature sealing tape
⑤Fire protection acrylic bead
⑥Annular gap cover, 2 pieces, 12.5 x 45 mm
⑦Steel wire clip
⑧Mortar
W Wall thickness ≥ 100 mm
Installa-
tion var-
iant
Classifica-
tion*
Installation gap
s1 (left) s2 (right) s3 (top) s4 (bottom)
2a EI90...S Mortar Annular gap cover Mortar Annular gap cover
2b EI120...S Mortar HT sealing tape Mortar HT sealing tape
2c EI90...S Mortar HT sealing tape Mortar Annular gap cover
2d EI90...S Mortar Annular gap cover Mortar HT sealing tape
3a EI120...S Mortar Mortar Mortar HT sealing tape
* Part of the classification key
HT sealing tape = high-temperature sealing tape, Þ detail 4
Annular gap cover = annular gap cover on both sides of the wall, Þ detail 5 + 6
Mortar = close off installation gap with mortar, Þ detail 8
Installation
Supporting construction – solid walls > Wet-dry mortarless installation
Smoke control damper Type EK2-EU 19

Installa-
tion var-
iant
Classifica-
tion*
Installation gap
s1 (left) s2 (right) s3 (top) s4 (bottom)
3b EI90...S Mortar Mortar Mortar Annular gap cover
4 EI180...S only possible in connection with an additional housing insulation (doubling) of
t≥20 x H=100 x L). Additional information upon request
* Part of the classification key
HT sealing tape = high-temperature sealing tape, Þ detail 4
Annular gap cover = annular gap cover on both sides of the wall, Þ detail 5 + 6
Mortar = close off installation gap with mortar, Þ detail 8
Personnel:
Specialist personnel
Materials:
High-temperature sealing tape
Ä ‘High-temperature sealing tape’ on page 14
For annular gap cover: PROMATECT®-H fire protection board d = 25 mm or strips of plasterboard 2 x 12.5 mm x
45 mm
Steel staples 63/11.2/1.53 mm
Fire protection acrylic
Mortar
Ä ‘Acceptable mortars for mortar-based installation’ on page 13
Requirements:
Solid walls,
Create an appropriate opening
1. Create an installation opening according to Fig. 13 .
Installation opening b x h:
b = B + 100 + s1 + s2
h = H + 100 + s3 + s4
Example: B x H = 1200 x 750 mm, s1 = 50 mm, s2 = 5 mm, S3 = 100 mm, s4 = 5 mm
b = 1200 + 100 + (50 + 5 mm) = 1355 mm
h = 750 + 100 + (100 + 5 mm) = 955 mm
2.
In case of installation variant 2b, 2c, 2d, 3b
Stick the high-temperature sealing tape on the damper housing in the trim panel thickness on the damper
housing,
Þ detail 4, Ä ‘High-temperature sealing tape’ on page 14
Push the smoke control damper into the installation opening and secure it. Make sure that the actuator
encasing rests on the face of the wall or freely positioned up to a total length L 1/2, centred in the wall.
3. Create the installation gap "s" according to the installation variant; see the table above.
Making the annular gap cover Þ detail 5 + 6
Before fitting the annular gap cover, seal the installation gap with fire protection acrylic on both sides of the
wall. Fix the annular gap cover to the damper casing on both sides of the wall with steel wire clips.
Mortar Þ detail 8
Close off the perimeter gap "s" (2 or 3) completely with mortar depending on the installation variant. The
mortar bed depth must be at least 100 mm.
Connecting the smoke extract duct to EK2-EU
4.
Ä 6 ‘Smoke extract duct and cover grille’ on page 40
Follow the manufacturer's instructions of the smoke extract duct here as well.
Installation
Supporting construction – solid walls > Wet-dry mortarless installation
