Trox Technik AKK User manual

Shut-off dampers
AKK
Assembly and operating instructions
Read the instructions prior to performing any task!
GB/en

CD10038, 1, GB/en
© TROX GmbH 2023
TROX GmbH
Heinrich-Trox-Platz
47504 Neukirchen-Vluyn
Germany
Telephone: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.troxtechnik.com
12/2023
Shut-off dampers AKK2

1 Safety ................................................................ 4
1.1 Correct use ................................................ 4
1.2 Dangers when handling the unit ................ 4
1.2.1 Electric shock hazards ........................... 4
1.2.2 Dangers due to stored energy ................ 4
1.3 Qualified staff ............................................. 5
1.4 Personal protective equipment .................. 5
1.5 Repair and replacement parts ................... 5
1.6 General safety measures .......................... 5
2............................................................................ 6
2.1 Product overview ....................................... 6
2.2 Functional description ............................... 6
2.3 Display of the damper blade position ........ 6
2.4 Labelling on unit ........................................ 6
2.4.1 Rating plate ............................................ 6
2.4.2 CE marking / declaration of incorpora-
tion .......................................................... 7
3............................................................................ 8
3.1 General installation information ................. 8
3.1.1 Installation of sound attenuators ............ 8
3.2 Fixing/suspension ...................................... 8
3.3 Connecting the air duct ............................. 8
4 Electrical connection .................................... 10
4.1 Safety notes ............................................ 10
4.2 Installation instructions ............................ 10
5 Commissioning and operation ..................... 11
5.1 Requirement for commissioning .............. 11
5.2 Commissioning ........................................ 11
5.2.1 Installation and connection ................... 11
5.2.2 Settings by others ................................. 11
5.2.3 Functional test ...................................... 11
5.3 Operation ................................................. 11
6 Maintenance ................................................... 12
6.1 System owner's responsibility ................. 12
6.2 Maintenance ............................................ 12
6.3 Inspection measures ............................... 12
6.4 Repair ...................................................... 12
6.5 Maintenance service ............................... 12
7 Faults .............................................................. 13
7.1 Troubleshooting ....................................... 13
8 Decommissioning .......................................... 14
8.1 Safety ...................................................... 14
8.2 Disassembly ............................................ 14
8.3 Disposal ................................................... 14
9 Technical data ................................................ 15
9.1 General data ............................................ 15
9.2 Actuators / attachments ........................... 15
10 Index................................................................ 16
Table of contents
Shut-off dampers AKK 3

1 Safety
1.1 Correct use
Type AKK shut-off dampers are used to shut off the
volume flow rate in ventilation systems within closed
rooms.
In kitchen exhaust air systems, the shut-off damper
may only be used if it is ensured that the extract air
is cleaned as well as possible by highly effective aerosol
separators, see VDI 2052.
Type AKK shut-off dampers can especially be used in
ventilation systems with chemical contamination (e.g.
point extraction or extract air from laboratory fume cup-
boards).
Incorrect use
WARNING!
Danger of injury or risk of damage to property
due to incorrect use!
Misuse of the unit can lead to dangerous situations.
Never use the unit:
– in areas with potentially explosive atmospheres
(EX)
– in aircraft
– outdoors without sufficient protection against the
effects of weather
– In wet areas
– for areas of application that are not described in
this manual
Modifying the unit or using replacement parts that have
not been approved by TROX is not permitted.
1.2 Dangers when handling the unit
The unit is a state-of-the-art product and meets current
safety requirements. Residual risks cannot be excluded,
however, and you should proceed with caution. This
section describes the residual risks that have been iden-
tified in a risk assessment.
Always follow the safety notes in this manual to reduce
health hazards and prevent any hazardous situations.
1.2.1 Electric shock hazards
Electric current
DANGER!
Danger of death due to electric current!
Contact with live parts poses an immediate danger
to life due to electric shock. Damaged insulation or
damaged parts are a life threatening hazard.
– Work on the electrical system must only be car-
ried out by skilled qualified electricians.
– If the insulation is damaged, disconnect the
power supply immediately and have the insula-
tion repaired.
– Before you start working on electric systems and
equipment, switch off the supply voltage and
secure it against being switched on accidentally.
Comply with the following safety rules:
– Switch off the supply voltage.
– Secure it against being switched on acciden-
tally.
– Ensure that no voltage is present.
– Connect to the earth; short circuit connection.
– Do not bypass or disable any circuit breakers. Be
sure to maintain the correct current rating when
you replace a circuit breaker.
– Ensure that live parts do not come into contact
with moisture. Moisture can cause a short circuit.
1.2.2 Dangers due to stored energy
DANGER!
Risk of injury due to stored energy.
Pneumatic actuators are pressurised and can cause
the damper to move abruptly:
– Only qualified personnel may work on the pneu-
matic actuator.
– Switch off the compressed-air supply before
working on any pneumatic equipment.
– After switching off the compressed-air supply,
trigger the actuator to discharge the stored
energy.
Safety
Dangers when handling the unit > Dangers due to stored energy
Shut-off dampers AKK4

1.3 Qualified staff
WARNING!
Danger of injury due to insufficiently qualified
individuals!
Incorrect use may cause considerable injury or
damage to property.
– Only specialist personnel must carry out work.
The following degrees of qualification are required for
the work described in the operating manual:
Skilled qualified electrician
Skilled qualified electricians are individuals who have
sufficient professional or technical training, knowledge
and actual experience to enable them to work on elec-
trical systems, understand any potential hazards related
to the work under consideration, and recognise and
avoid any risks involved.
1.4 Personal protective equipment
Personal protective equipment is equipment that pro-
tects the user against health or safety risks at work.
Personal protective equipment must be worn for var-
ious types of work; the protective equipment required
is listed in this manual together with the description of
each type of work.
Description of personal protective equipment
Safety shoes
Safety shoes protect the feet against crushing, falling
parts, and slipping on slippery ground.
1.5 Repair and replacement parts
The devices must be repaired by qualified personnel
using genuine replacement parts only. This particularly
applies to work on the electrical equipment. For safety
reasons, defective devices should therefore be repaired
by the TROX Technical Service, linktarget [Kundendienst Betrieb]
doesn't exist but @y.link.required='true'.
1.6 General safety measures
Large temperature differences
Be careful when there is a large temperature difference.
If the unit has been kept in an unheated area, wait two
hours before switching on the supply voltage. Conden-
sation may damage the electronic components beyond
repair. Only after about 2 hours will the system have
reached room temperature.
Foreign matter and liquids
Be careful when objects or liquids have got into the
casing, or if the unit emits a smell or smoke. Decommis-
sion the unit and have it checked by the manufacturer.
Safety
General safety measures
Shut-off dampers AKK 5

2.1 Product overview
Fig. 1: AKK product overview
1 Damper blade
2 Plain bearing
3 Flange (optional)
4 Actuator (optional)
2.2 Functional description
Type AKK shut-off dampers are intended to be used for
the low-leakage shut-off of volume flows in ventilation
systems with circular ducts. The damper is used to iso-
late parts of the ventilation system.
A duct section is closed off by means of a damper blade
via manual actuation (standard construction) or optional
actuators with electric or pneumatic signalling. Actua-
tors are available in various constructions with regard
to power supply, safe position (in a de-energised or
depressurised condition) and auxiliary switches for the
electrical monitoring of the damper blade position.
The actuator of a damper blade must be controlled by a
customer-side circuit and then moves the damper blade
to the OPEN or CLOSED position.
2.3 Display of the damper blade posi-
tion
The damper blade position corresponds to the mark on
the shaft and is thus recognisable from the outside.
Clamping device (frictional connection)
Fig. 2: Display with clamping device
1 Shaft with marking for position indication
2 Damper blade
2.4 Labelling on unit
2.4.1 Rating plate
Fig. 3: Type plate (example)
1 Note on observing the operating manual
2 Order data commission number – item number; if
necessary, serial number if there are several pieces
in the item
3 Order code
4 Order code detail of actuator (optional)
5 Information on units that deviate from the standard
6 QR code containing the customer text (10) below in
machine-readable form
7 Barcode with the serial number (for manufacturing
processes at TROX)
8 Manufacturer's address
9 Product and type
10 Customer text for installation/use (tagging text from
the order)
11 QR code with link in myTrox to individual product
documentation matching the serial number
12 Serial number of the complete product including the
installed attachment
Labelling on unit > Rating plate
Shut-off dampers AKK6

2.4.2 CE marking / declaration of incorpo-
ration
The AKK unit complies with the Machinery Directive
2006/42/EC as partly completed machinery, as it does
not fulfil an independent function on its own. A CE mark
and a Declaration of Conformity are therefore not per-
mitted in accordance with the Machinery Directive.
In accordance with the Machinery Directive, partly com-
pleted machinery obtains a Declaration of Incorporation.
This Declaration of Incorporation confirms that the basic
safety aspects of the Machinery Directive and any other
directives are observed.
The Declaration of Incorporation can be accessed via
the QR code on the rating plate. You can download the
document on the Internet at www.troxtechnik.com .
Labelling on unit > CE marking / declaration of incorporation
Shut-off dampers AKK 7

3.1 General installation information
Select the installation location such that the unit,
inspection accesses and the actuator remain acces-
sible for the following work:
– Wiring
– Adjustment work (service socket if necessary)
– Inspection and maintenance, e.g. for replacing
the actuator.
For information on space requirements, see product
data sheets.
Installation in extract air systems in commercial
kitchens is only permitted if the extract air has
already been cleaned with aerosol separators, see
VDI 2052.
3.1.1 Installation of sound attenuators
Circular silencers are usually installed between the
shut-off damper and the room. The circular silencer, e.g.
CAK (same nominal size) can be installed adjacent to or
behind a shut-off damper.
3.2 Fixing/suspension
General installation information
When designing and constructing ventilation and air
conditioning systems, take into account the require-
ments of VDI 6022, in particular:
– Hygienic, clean installation of all components
and their air distribution surfaces.
– Planning inspection/cleaning openings in the
ducting system.
– Avoidance of leaks.
Affix the unit proficiently and only to load-bearing
components.
Load suspension systems only with the weight of
the unit. Adjacent components and connecting ducts
must be supported separately.
Only use approved and sufficiently dimensioned
suspensions for fixing. Secure screw connections
against self-loosening, e.g., by locking them. Fixing
material is not included in the supply package.
Only use the shortest possible drilling screws for
fixing into place; these screws must not be screwed
into the movement and sealing area of the damper
blade.
Fig. 4: Installation example of AK-* shut-off damper
1 Shut-off damper, e.g. AK
2 Drilling screw for fixing to the ducting
3 Pipe clamp
4 Suspension, e.g., with threaded rod
Fig. 5: Examples of fixings for circular units
1 Fixing to pipe clamps
2 Fixing to suspension element
3.3 Connecting the air duct
When connecting the ducting, the customer must
ensure that the connection points are installed as air-
tight as possible in order to avoid negative influences
from leakages such as air volume deviations, power
consumption, etc. Unless otherwise stated, the con-
necting material is not included in the supply package.
In the case of one-sided connection of the ductwork,
intervention in the damper blade is to be prevented by
suitable measures (for example, grilles).
Before connecting the ducting:
Check the inside of the unit for damage and loose
parts.
Remove any contamination from the ducting.
Connecting the air duct
Shut-off dampers AKK8

Fig. 6: Plastic flanges
Matching flanges, including seal available as acces-
sories
Screw connection M8 (to be provided by others)
Dimensions and number of holes in accordance with
EN 12220.
Position the ducting exactly. Do not pull the dis-
tances together via the flange connection.
Fig. 7: Plastic spigot
Installation on ducting in accordance with DIN 8077
– with clamp connectors
– by plastic welding
Connecting the air duct
Shut-off dampers AKK 9

4 Electrical connection
4.1 Safety notes
DANGER!
Danger of electric shock! Do not touch any live com-
ponents. Electrical equipment carries a dangerous
electrical voltage.
– Only skilled qualified electricians are allowed to
work on the electrical system.
– Switch off the supply voltage before working on
any electrical equipment.
DANGER!
Risk of injury due to stored energy.
Pneumatic actuators are pressurised and can cause
the damper to move abruptly:
– Only qualified personnel may work on the pneu-
matic actuator.
– Switch off the compressed-air supply before
working on any pneumatic equipment.
– After switching off the compressed-air supply,
trigger the actuator to discharge the stored
energy.
4.2 Installation instructions
The shut-off damper was manufactured and configured
on a project-specific basis. If an electric actuator has
been ordered, it is assembled at the factory. For units
with an electric actuator, the supply voltage and the
signal line must be connected. For devices with a pneu-
matic actuator, the compressed-air supply and the com-
pressed-air control line must be connected.
The connection is made in accordance with the infor-
mation on the actuator or connection diagrams in the
product data sheet or commissioning instructions for the
respective actuator, www.troxtechnik.com . The voltage
ranges and the terminal connections specified on the
actuator must be observed!
Personnel:
Skilled qualified electrician
Observe the following during installation:
Legal and official regulations, in particular VDE
guidelines.
Observe the technical connection rules (TCR) of the
local grid operator.
Wiring work for supply voltage and signal lines on
site.
The rating and manufacturing of customer-side con-
nections and wiring must be carried out in accord-
ance with the recognised rules of electrical engi-
neering.
The responsibility for design, dimensioning and
sizing of the electrical and network installations
as well as their execution by others lies with the
specialist consultant, HVAC contractor and commis-
sioning engineer appointed by the system owner.
This includes, in particular, the dimensioning of the
power supplies as well as cable types and cross
sections.
Observe wiring guidelines and project-specific circuit
diagrams.
The electrical connection may only be made after
complete installation of the unit.
For units with a 24 V supply voltage, observe the
following:
– Electrical connection only with safety trans-
former
– Make sure that all connected units have the
same GND reference point for the supply
voltage.
Suitable wire clamping brackets must be provided
for all connecting cables.
Electronic components contain no parts that can be
replaced or repaired by the user and may only be
opened by the manufacturer!
Electrical connection
Installation instructions
Shut-off dampers AKK10

5 Commissioning and opera-
tion
5.1 Requirement for commissioning
Contamination, e.g. dust, can adversely affect the func-
tionality of the shut-off damper.
Therefore, the ventilation and air conditioning system
and its components may not be put into operation for
the first time until the rooms connected to the ventila-
tion system have been cleaned of any contamination
resulting from construction work. Contamination of the
ventilation system by construction dust and sucked-in
dirt particles must be eliminated. In the case of systems
that are heavily contaminated due to construction activ-
ities, the system may need to be cleaned before com-
missioning.
5.2 Commissioning
Code of good practice for commissioning
Commissioning is governed by the standard "DIN
EN 12599 Testing and measuring procedures for the
transfer of installed ventilation and air conditioning
systems", and, if applicable, contractually agreed
services between HVAC contractors, system owners
and installation engineers. The standard describes
the essential commissioning steps of the complete-
ness check, function check, function measurement
as well as report generation and handover.
5.2.1 Installation and connection
Once the electrical connections have been correctly
installed and made, the shut-off damper is ready for
operation.
5.2.2 Settings by others
Setting of the auxiliary switch
For actuators with auxiliary switches, set the switching
points.
Special version
Bus-compatible actuators may require integration into
the building's network infrastructure to be performed
by others (network commissioning, e.g. setting the sub-
scriber address and communication parameters). Man-
ufacturer-specific tools such as adjustment devices or
software packages and associated interface adapters
may be required for this.
5.2.3 Functional test
Prerequisites for the functional test
Electrical or pneumatic connections have been cor-
rectly installed and tested.
Ventilation and air conditioning system is in opera-
tion (fans running).
Supply voltage or the compressed air supply is
switched on.
1. Check damper blade positions:
Door open
Door closed
Intermediate position (only for variable actua-
tors)
2. Check the auxiliary switch positions.
5.3 Operation
Once commissioning has been completed, the shut-off
damper will operate in a self-powered manner and
require no intervention from the system owner.
In case of a malfunction, decommission the shut-off
damper and have it repaired before commissioning it
again.
Commissioning and operation
Operation
Shut-off dampers AKK 11

6 Maintenance
6.1 System owner's responsibility
WARNING!
Only authorised specialist personnel are allowed
to perform the described maintenance measures.
The system owner is responsible for maintenance. The
system owner is responsible for creating a maintenance
plan, for defining the maintenance goals, and for the
functional reliability of the equipment.
The legal regulations must be observed during mainte-
nance, e.g. the system owner is responsible for hygienic
operation in accordance with VDI 6022.
6.2 Maintenance
The shut-off damper and the actuator are maintenance-
free with regard to wear, but the damper must still
be included in the regular cleaning of the ventilation
system. Regular care and maintenance ensure opera-
tional readiness, functional reliability, and long service
life of the shut-off damper.
6.3 Inspection measures
DANGER!
Danger of electric shock! Do not touch any live com-
ponents. Electrical equipment carries a dangerous
electrical voltage.
– Only skilled qualified electricians are allowed to
work on the electrical system.
– Switch off the supply voltage before working on
any electrical equipment.
CAUTION!
Crushing hazard.
The shut-off damper may suddenly open or close.
Switch off the voltage supply before you start
working on the unit.
DANGER!
Risk of injury due to stored energy.
Pneumatic actuators are pressurised and can cause
the damper to move abruptly:
– Only qualified personnel may work on the pneu-
matic actuator.
– Switch off the compressed-air supply before
working on any pneumatic equipment.
– After switching off the compressed-air supply,
trigger the actuator to discharge the stored
energy.
Personnel:
Skilled qualified electrician
Protective equipment:
Safety shoes
1. Remove contamination on the shut-off damper
that affects its function.
2. Check all screws for firm seating and retighten
them, if necessary.
3. Depending on the construction:
– Check electrical feeder cables for damage
and firm seating in the terminals.
– Check pneumatic lines for damage and a
tight fit.
4. Functional check of the damper blade position
OPEN/CLOSED
5. Document maintenance measures and measure-
ment results.
6.4 Repair
Repair work is only allowed to be carried out by spe-
cialist personnel or by the manufacturer. Only genuine
replacement parts must be used.
6.5 Maintenance service
Regular maintenance by the TROX Technical Service is
recommended in order to ensure operational readiness,
functional reliability, and long service life of the unit.
Maintenance
Maintenance service
Shut-off dampers AKK12

7 Faults
7.1 Troubleshooting
To troubleshoot the problem, check and log the following points. Take appropriate action if necessary. In case of
inquiries to TROX Service, please send the fault log.
System/area:
TROX shut-off damper type (see rating plate):
Actuator (see rating plate):
Complete order code (see rating plate):
Description Yes No Not
applicable
Installation situation
Are the shut-off damper and actuator easily accessible? ☐ ☐ ☐
System readiness
Fan switched on? ☐ ☐ ☐
Actuator
Error-free wiring and supply voltage within tolerance zone? ☐ ☐ ☐
Faults
Troubleshooting
Shut-off dampers AKK 13

8 Decommissioning
If the unit is no longer used, it has to be removed and
disposed of in an environmentally friendly manner.
8.1 Safety
Personnel
Disassembly must only be carried out by specialist
personnel.
Only skilled qualified electricians must work on the
electrical system.
Electrical system
DANGER!
Danger of death due to electric current!
Danger of electric shock! Do not touch any live com-
ponents! Live electrical components may suddenly
move uncontrollably and seriously injure people.
Therefore:
– Switch off the power supply and disconnect the
product permanently before you begin to disas-
semble it.
DANGER!
Risk of injury due to stored energy.
Pneumatic actuators are pressurised and can cause
the damper to move abruptly:
– Only qualified personnel may work on the pneu-
matic actuator.
– Switch off the compressed-air supply before
working on any pneumatic equipment.
– After switching off the compressed-air supply,
trigger the actuator to discharge the stored
energy.
WARNING!
Risk of injury due to incorrect disassembly
Stored residual energy, pointed parts and parts with
sharp edges or corners on the unit or on tools can
cause injuries. Therefore:
Therefore:
– Before you start, make sure that there is suffi-
cient clearance for the work you have to com-
plete.
– Be careful when you touch parts that have sharp
edges or corners.
– Disassemble components professionally. Be
aware that some components are very heavy.
Use lifting gear if necessary.
– Secure components to prevent them from falling
or toppling.
– When in doubt, contact the manufacturer.
8.2 Disassembly
Before you start disassembly:
Switch off the unit and secure it against being
switched on accidentally.
Physically disconnect the unit from the power supply
and discharge any residual energy.
Remove and dispose of any operating fluids, auxil-
iary materials and leftover processing materials in
an environmentally sound manner.
Then professionally clean subassemblies and compo-
nents and disassemble them in compliance with local
occupational safety and environmental protection regu-
lations.
8.3 Disposal
If no take back (disposal) agreement is in place, the
various parts should be recycled:
Scrap the metals.
Take plastic parts to be recycled.
Dispose of other components in a suitable manner,
i.e. depending on their material properties.
ENVIRONMENT!
Risk of harm to the environment due to improper
disposal!
Electronic waste, electronic components, lubricating
and other auxiliary materials are hazardous waste
and must be disposed of by a specialist company.
If you are not sure how to dispose of anything in
an environmentally friendly manner, contact your local
authorities or a specialist disposal company.
Decommissioning
Disposal
Shut-off dampers AKK14

9 Technical data
9.1 General data
Nominal sizes 125 – 400 mm
Permissible static differential pressure 1500 Pa
Operating temperature 10 – 50 °C
9.2 Actuators / attachments
The following actuators are available for the AKK shut-off damper:
Electric actuators
Attachment Actuator Supply voltage Auxiliary switch
Open/Close actuators
B30 Actuator with mechanical stops
TROX/Belimo
24 V AC/DC –
B32 2
B40 100 – 240 V AC –
B42 2
BP0 Spring return actuator with mechanical stops
TROX/Belimo
24 V AC/DC –
BP2 2
BR0 24 – 240 V AC,
24 to 125 V DC
–
BR2 2
Modulating actuators
B20 Continuous actuator 0 - 10 V
with mechanical stops
TROX/Belimo
24 V AC/DC –
B22 2
Pneumatic actuators
Attachment Actuator Control pressure Auxiliary switch
Pneumatic actuators
TN0 Pneumatic actuator with safe position
Manufacturer: TROX
0.2 – 1.0 bar –
Technical data
Actuators / attachments
Shut-off dampers AKK 15

10 Index
A
Actuator..................................................................... 15
Application................................................................... 4
Area of application...................................................... 4
Attachments.............................................................. 15
C
CE marking................................................................. 7
Circular silencers......................................................... 8
Commissioning.......................................................... 11
Connecting the air duct............................................... 8
Correct use.................................................................. 4
D
Dangers....................................................................... 4
Declaration of Conformity............................................ 7
Declaration of Incorporation........................................ 7
Decommissioning...................................................... 14
Disassembly.............................................................. 14
Disposal.................................................................... 14
Duct connection.......................................................... 8
E
Electrical connection
Installation instructions......................................... 10
Electric current............................................................ 4
F
Faults........................................................................ 13
Fixing........................................................................... 8
Flange connection....................................................... 9
Functional description................................................. 6
Functional test........................................................... 11
I
Incorrect use............................................................... 4
Inspection.................................................................. 12
Installation location...................................................... 8
M
Maintenance.............................................................. 12
Misuse......................................................................... 4
O
Operating temperature.............................................. 15
Operation................................................................... 11
Order code.................................................................. 6
P
Personnel
Removal............................................................... 14
Pneumatic................................................................... 4
Product overview......................................................... 6
Protective equipment.................................................. 5
Q
QR code...................................................................... 6
R
Rating plate................................................................. 6
Repair.................................................................. 5 , 12
Replacement parts...................................................... 5
Residual risks.............................................................. 4
S
Serial number.............................................................. 6
Service...................................................................... 12
Sound attenuators....................................................... 8
Staff............................................................................. 5
Suspending................................................................. 8
T
Technical data........................................................... 15
Troubleshooting......................................................... 13
TROX Technical Service........................................... 12
U
Unauthorised use........................................................ 4
Usage.......................................................................... 4
W
Wiring
Installation instructions......................................... 10
Index
Shut-off dampers AKK16

© TROX GmbH 2023
TROX GmbH
Heinrich-Trox-Platz
47504 Neukirchen-Vluyn
Germany
[phone]
[phone]
E-mail: [email protected]
www.troxtechnik.com
