True SPECTRUM ELLIPTICAL XS1000 User manual

* Assembly Guide & Warranty Card Included
SPECTRUM ELLIPTICAL
OWNER’S MANUAL
Model# XS1000 Revision 091418

Truetness.com / 800.426.6570 / 636.272.7100
SPECTRUM ELLIPTICAL OWNERS MANUAL
IMPORTANT:
All products shown are prototype. Actual product delivered may vary.
Product specications, features & soware are subject to change without notice.
For the most up-to-date owner’s manual please visit www.truetness.com.
For documents in additional languages please visit www.truetness.com/resources/document-library/
IMPORTANTE:
Todos los productos mostrados son prototipos. La realidad el producto suministrado puede diferir.
Especicaciones de productos, características y soware están sujetas a cambios sin previo aviso.
Para la más actualizada de este manual del propietario, por favor visite www.truetness.com
Para los documentos en otros idiomas, por favor visite www.truetness.com/resources/document-library/
IMPORTANT: Tous les produits présentés sont prototype. Le produit réel livré peut varier. Spécications du
produit, caractéristiques et logiciels sont sujettes à modication sans préavis. Pour la plus à jour le manuel du
propriétaire s'il vous plaît visitez www.truetness.com. Pour documents dans des langues supplémentaires,
veuillez www.truetness.com/resources/document-library/ de visite
重要提示： 显示所有产品的原型。实际交付的产品可能有所不同产品规格，功能和软件如有更改，恕不另
行通知迄今为止对于大多数的使用说明书，请访问www.true󽗉tness.com 对于其他语言的文档，请访问
www.true󽗉tness.com/resources/document-library/
ھام:
جمیع المنتجات المعروضة ھي النموذج. قد تختلف المنتج الفعلي تسلیمھا.
مواصفات المنتج، والمیزات والبرامج قابلة للتغییر دون إشعار.
لمعظم ما یصل حتى الآن دلیل المالك یرجى زیارة www.truetness.com.
للمستندات في لغات إضافیة، یرجى زیارة www.truetness.com/resources/document-library/
WICHTIG: Alle hier gezeigten Produkte sind Prototypen. Das tatsächliche Produkt ausgeliefert wird, kann
variieren. Produkt-Spezikationen, Funktionen und Soware können sich ohne vorherige Ankündigung
ändern. In den meisten Fällen bis zu Bedienungsanleitung Bisher besuchen Sie bitte www.truetness.com. Für
Dokumente in weiteren Sprachen nden Sie unter www.truetness.com/resources/document-library/
BELANGRIJK: Alle getoonde producten zijn prototype. Daadwerkelijke product geleverd kan verschillen.
Product specicaties, eigenschappen & soware zijn onderhevig aan verandering zonder kennisgeving. Voor
de meest actuele handleiding van de eigenaar kunt u terecht www.truetness.com. Voor documenten in andere
talen kunt u terecht op www.truetness.com/resources/document-library/
ВАЖНО: Все товары указаны прототипа. Фактический продукт, поставляемый могут отличаться.
Технические характеристики, особенности и программного обеспечения могут быть изменены без
предварительного уведомления. Для получения самой последней на сегодняшний день руководство по
эксплуатации пожалуйста, посетите www.truetness.com
.Для документов на другие языки, пожалуйста, посетите www.truetness.com/resources/document-library/

Truetness.com / 800.426.6570 / 636.272.7100
SPECTRUM ELLIPTICAL OWNERS MANUAL
A MESSAGE TO OUR CUSTOMERS
Frank Trulaske began TRUE Fitness® over thirty-ve year ago with the simple philosophy of delivering superior
tness products, service, and support. Today, TRUE is the global leader in premium tness equipment for the
commercial and residential markets. Our goal is to be the leader in technology, innovation, performance, safety
and style. TRUE has received many awards for its product over the years and remains the benchmark for the
industry. Fitness facilities and consumers invest in TRUE products for their durable commercial platforms used
in all its products, both commercial and residential alike.
e proud manufacturing tradition of quality and the culture of innovation at TRUE have given rise to a full line
of extraordinary cardio and strength equipment. As a result, people all over the world are beneting from the
TRUE experience. Innovation across the full product line has made TRUE successful and is a trademark of the
TRUE heritage. TRUE’s patented Heart Rate Control technology is just one of the remarkable ways we deliver
simple and superior performance every user can enjoy, and most importantly, use to achieve personal health and
tness goals.
At the heart of our success is the relentless and systematic life testing of both our products and their components.
We have dedicated employees who understand our philosophy is to deliver the best products in the world.
Our goal is to deliver the world’s best premium equipment for our customers’ health and tness solutions.

Truetness.com / 800.426.6570 / 636.272.7100
TABLE OF CONTENTS:
SPECTRUM ELLIPTICAL OWNERS MANUAL
Chapter 1: Safety Instructions
Safety Instructions..................................................................................................................................................................5
Space Requirements ...............................................................................................................................................................8
Elliptical Entry and Exit Safety.............................................................................................................................................8
Grounding Instructions.........................................................................................................................................................9
Power Requirements ............................................................................................................................................................10
Warning Decals.....................................................................................................................................................................11
Compliances..........................................................................................................................................................................11
Proper Training Position.....................................................................................................................................................11
Chapter 2: Assembly Instructions
Pre Assembly Checklist .......................................................................................................................................................13
Assembly Steps......................................................................................................................................................................14
Wiring Diagram....................................................................................................................................................................23
Exploded Diagram ...............................................................................................................................................................24
Chapter 3: Product Overview
Product Overview ................................................................................................................................................................25
Chapter 4: Care & Maintenance
Care & Maintenance ............................................................................................................................................................27
Cleaning the Equipment......................................................................................................................................................27
Other Scheduled Preventive Maintenance........................................................................................................................28
Long Term Storage ...............................................................................................................................................................28
Chapter 5: Customer Service
Contacting Service ...............................................................................................................................................................29
Contacting Sales ...................................................................................................................................................................29
Reporting Freight or Parts Damage ...................................................................................................................................30
Chapter 6: Additional Information
Troubleshooting Guide........................................................................................................................................................31
Chapter 7: Warranty Information
Warranty Registration..........................................................................................................................................................34

Truetness.com / 800.426.6570 / 636.272.7100 5 of 36
CHAPTER 1: SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE SAFETY INSTRUCTIONS
is equipment is intended for a commercial or institutional setting. is owner’s manual should be accessible to all
personal trainers, faculty, and members.
WARNING: ALL EXERCISERS MUST READ ALL INSTRUCTIONS BEFORE USING THE
EQUIPMENT.
WARNING:Heart rate monitoring systems may be inaccurate for some individuals. Over-exercising
may result in serious injury or death. If you feel faint, stop exercising immediately.
WARNING:Equipment should be immediately taken out of use if it fails to work properly or when a
warning is presented electronically.
TRUE STRONGLY recommends seeing a physician for a complete medical exam before undertaking an exercise program,
particularly if the user has a family history of high blood pressure or heart disease, is over the age of 45, smokes, has high
cholesterol, is obese or has not exercised regularly in the past year. Additionally, TRUE recommends consulting a tness
professional on the correct use of this product. If at any time while exercising the user experiences faintness, dizziness,
pain or shortness of breath, he or she must stop immediately.
WARNING:To reduce the risk of electrical shock, always unplug this TRUE product before cleaning
or attempting any maintenance activity. Do not handle the plug with wet hands.
WARNING:To reduce the risk of burns, re, electric shock, or injury, it is imperative to connect
each product to a properly grounded 110V electrical outlet. A risk of electrical shock may result from improper
connection of the equipment’s grounding conductor. Check with a qualied electrician if you are unsure about
proper ground techniques. Do not modify the plug provided wiht this product. If it will not t an electrical outlet,
have a proper outlet installed by a qualied electrician. Your TRUE Fitness product must be properly grounded
to reduce risk of shock if the equipment malfunctions. Your equipment is equipped with an electrical cord, which
includes an equipment grounding conductor and a grounding plug. e plug must be inserted into an outlet that
has been properly installed and grounded in accordance with all local codes and ordinances. A temporary adapter
cannot be used to connect this plug to a two-pole receptacle in North America. If a properly grounded 15 amp
outlet is not available, a qualied electrician must install one.
WARNING:Do not move the equipment by liing the console. Do not use the console as a handlebar
during a workout.
WARNING:is product contains chemicals known to the state of California to cause cancer and birth
defects or other reproductive harm.
WARNING:Keep equipment stable on at ground.

Truetness.com / 800.426.6570 / 636.272.7100 6 of 36
CHAPTER 1: SAFETY INSTRUCTIONS
WARNING: Replace warning labels that may be worn, damaged, or missing.
WARNING:Replace any non-working or damaged components, remove the unit from service until
repair is performed.
WARNING:To reduce the risk of burns, re, and electric shock or injury to persons, follow these
instructions:
• is appliance should never be le unattended when plugged in.
• Do not use any type of extension cord with this product.
• Unplug it from the outlet when not in use and before any servicing.
• Do not operate the equipment while being covered with a blanket, plastic, or anything that insulates or stops airow.
WARNING:Risk of personal injury-crushing hazard when equipment is in operation - Keep feet,
hands, and ngers away from moving parts.
CAUTION:
• Health related injuries may result from incorrect or excessive use of exercise equipment.
• Do not use typing or web surng features at excessive speeds. Always stabilize yourself by holding a stationary handle
when using typing or web surng features. (Varies by console option)
• Do not use the contact heart rate grips as a handlebar during a workout.
• Any changes or modications to this equipment could void the product warranty.
• To disconnect, turn power OFF at the ON/OFF switch if applicable, then remove plug from electrical outlet.
• Never operate a TRUE product if it has a damaged power cord or electrical plug, or if it has been dropped, damaged,
or even partially immersed in water. Contact TRUE Customer Service for a replacement.
• Use a TRUE AC power cord or AC/DC adapter only.
* Note the plug conguration for the power adapter may vary by country.
• Position this product so the power cord plug is accessible to the user.
• Keep the power cord away from heated surfaces. Do not pull the equipment by the power cord or use the cord as a
handle. Do not run the power cord along the side or under the equipment.
• If the electrical supply cord is damaged it must be replaced by the manufacturer, an authorized service agent, or a
similarly qualied person to avoid a hazard.
• Do not use this product in areas where aerosol spray products are being used or where oxygen is being administered.
Such substances create the danger of combustion and explosion.
• Always follow the console instructions for proper operation.
• Close supervision is necessary when used near children under the age of 15, or disabled persons.
• Do not use this product outdoors, near water, while wet, or in areas of high humidity including extreme temperature
changes.
• Never operate a TRUE product with the air openings blocked. Keep air openings free of lint, hair or any obstructing
material.

Truetness.com / 800.426.6570 / 636.272.7100 7 of 36
CHAPTER 1: SAFETY INSTRUCTIONS
CAUTION:
• Health related injuries may result from incorrect or excessive use of exercise equipment.
• Never insert objects into any openings in this product. If an object should drop inside, turn o the power, unplug the
power cord from the outlet and carefully retrieve it. If the item cannot be reached, contact TRUE Customer Service.
• Never place liquids of any type directly on the unit except in the accessory tray or bottle holders. Containers with lids
are recommended.
• Wear shoes with rubber or high traction soles. Do not use shoes with heels, leather soles, cleats or spikes. Make sure
no stones are embedded in the soles. Do not use this product in bare feet. Keep all loose clothing, shoelaces and towels
away from moving parts.
• Do not reach into or underneath the unit, or tip it on its side during operation.
• Use correct ergonomic positioning while running on equipment.
• Do not allow animals on or near the equipment while in operation.
• Use the side handrails whenever additional stability is required. In case of emergency, such as tripping, the side
handrails should be grabbed and the user should place his/her feet on the side platforms. e front handlebars should
be used to grasp the heart rate sensors or to rest the hand on while operating the activity zone keys, but not for
stability, emergency, or continuous use.
• Do not exceed maximum user weight of 400 lbs (181 kg).
• Do not use if you have a cold or fever.
• When using this exercise machine, basic precautions should always be followed.
• Use this equipment only for its intended use as described in this manual.
• Do not use attachments not recommended by the manufacturer.
• Allow only trained personnel to service this equipment.
• Avoid the possibility of bystanders being struck or caught between moving parts by making sure that they are out of
reach of the equipment while it is in motion.
• is appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without supervision.
• Allow only one person at a time on the equipment while it’s operating.
• It is the sole responsibility of the owner/operator to ensure regular and scheduled maintenance is performed.
• To avoid injury stand on the side rails before starting the equipment.
• Avoid exiting equipment while leaving the tread belt in motion.
• Never walk or jog backwards on the equipment.
• Do not change the incline of the equipment by placing objects under it.
• To avoid serious injury, do not touch the incline rack while the equipment is in use.
• To avoid serious injury, do not touch the belt while the equipment is in use.
• Do not operate under blanket or pillow. Excessive heating can occur and cause re, electric shock, or injury to persons.
• See Grounding Instructions.
• On the machine power switch, the “1” means that the machine power is switched “ON” and the “0” means the
machine power is switched “OFF”.
• Before servicing the motor area or removing the motor cover, please contact TRUE service.
• Do not place hand near the running belt when the unit is in operation.
• To avoid serious injury, remove and store the power cord when the machine is not in use.
• Noise emission under load is higher than without load.
• A-weighted emission sound pressure level at the trainer’s ear: 67dBA.

Truetness.com / 800.426.6570 / 636.272.7100 8 of 36
CHAPTER 1: SAFETY INSTRUCTIONS
SPACE REQUIREMENTS:
TRUE’s recommendation is to leave a 39” (0.9m) safety zone at rear of elliptical. e sides of the unit should be at least 24”
(0.6m) away from the wall or obstructions. (See Fig 1)
ELLIPTICAL ENTRY AND EXIT SAFETY:
Elliptical Entry: Elliptical Exit:
• Step up onto the rear step.
• Step up onto the side
platforms.
• Grip the heartrate handlebars
for stability while
stepping onto the lowest
pedal.
• Place opposite foot onto the
other pedal.
Note: e elliptical trainer is not equipped with a free wheel, therefore the moving parts are
unable to stop immediately.
• Stop pedaling by slowing leg motion and
applying slight resistance to the upper
exercise arms.
• While gripping the heartrate handlebars for
stability, step from the highest pedal onto
the side platform.
• Place the opposite foot on the other side
platform.
• Step down to the rear step.

Truetness.com / 800.426.6570 / 636.272.7100 9 of 36
CHAPTER 1: SAFETY INSTRUCTIONS
GROUNDING INSTRUCTIONS:
is product must be grounded, if it should malfunction or breakdown, grounding provides a path of least resistance for
electric current to reduce the risk of electric shock. is product is equipped with a cord having an equipment-grounding
conductor and a grounding plug. e plug must be plugged into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
DANGER:
• Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
• Check with a qualied electrician or serviceman if you are in doubt as to whether the product is properly
grounded. Do not modify the plug provided with the product. If it will not t the outlet, have a proper outlet
installed by a qualied electrician.
• Do not remove the motor cover or you may risk injury due to electric shock.
• 120-Volt: is model is for use on a nominal 120-V circuit and has a grounding plug that looks like the plug
illustrated in gure A. Make sure the product is connected to an outlet having the same conguration as the
plug. No adaptor should be used with this product.
• 230-Volt: is model is for use on a circuit having a nominal rating more than 120-V and is factory-equipped
with a specic electric cord and has a grounding plug that looks like the plug illustrated in gure B. Make sure
that the product is connected to an outlet having the same conguration as the plug in Figure B. No adapter
should be used with this product. If the product must be reconnected for use on a dierent type of electric
circuit, the reconnection should be made by qualied service personnel.

Truetness.com / 800.426.6570 / 636.272.7100 10 of 36
CHAPTER 1: SAFETY INSTRUCTIONS

Truetness.com / 800.426.6570 / 636.272.7100 11 of 36
CHAPTER 1: SAFETY INSTRUCTIONS
WARNING DECALS:
WARNING: Replace warning labels that may be worn, damaged, or missing.
To replace any worn or missing decals contact TRUE FITNESS by visiting www.truetness.com or contact customer
service at 800-883-8783.
COMPLIANCES:
is equipment complies with all applicable codes and regulations. For a complete list of compliances, please visit
www.truetness.com.
PROPER TRAINING POSITION:
• Users should keep both feet on the pedals (A) during the
workout.
• During a workout the user’s hand should grasp the upper
exercise arms (B).
• Users should remain standing throughout their workout.
SAMPLE
B
A

Truetness.com / 800.426.6570 / 636.272.7100 12 of 36
WARNING!
CHAPTER 2: ASSEMBLY GUIDE
IMPORTANT SAFETY INSTRUCTIONS
• Read and understand all instructions and warnings prior to use.
• Obtain a medical exam before beginning any exercise program. If at any time during exercise you
feel faint, dizzy, or experience pain, stop and consult your physician.
• Obtain proper instruction prior to use.
• is unit is intended for commercial use only.
• Inspect the unit for incorrect, worn, or loose components and do not use until corrected,
replaced,or tightened prior to use.
• Do not wear loose or dangling clothing while using the unit.
• Care should be used when mounting or dismounting the unit.
• Read, understand, and test the emergency stop procedures before use.
• Disconnect all power before servicing the unit.
• Do not exceed maximum user weight of 400 lbs.
• Keep the top side of the moving surface clean and dry.
• Keep children and animals away.
• Use caution when moving and assembling unit.
• All exercise equipment is potentially hazardous. If attention is not paid to the conditions
ofequipment usage, death, or serious injury could occur.
• Save these instructions.
If you are connecting this machine to a power source other than 110V, you must install the required transformer
before powering on the machine. e transformer installation instructions are included with the transformer.
Step-Down Transformer
Voltage Range: 180-260V
Hertz: 50/60 Hz
Amperage: 3A max
Step-Up Transformer
Voltage Range: 75-100V
Hertz: 50/60 Hz
Amperage: 8A max

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 13 of 36
CAUTION:
• It is recommended that two people unpack and assemble elliptical.
• Remove bands from packaging and pull top from pallet.
• Remove all parts from packaging. Leave machine on pallet.
• For each step use hardware in the corresponding bag.
WARNING:
DO NOT use an impact drill when assembling plastic components!
Parts Identication:
Use this page to identify the parts used in each step.
PRE-ASSEMBLY CHECK LIST:
Tools Required (not included):
• Phillips screwdriver
• M6 Hex Key
• M8 Hex Key
• M10 Hex Key
• 17mm wrench
Exercise Arms
Steps 6 & 7
Console
Step 14
Console Mast
Step 4
Draw Bars
Step 10
Chin Bar
Steps 8 & 9
Base
Step 1
Heart Rate Handlebars
Step 5
Pedestal
Step 1
Footskates & Pedal Tubes
Steps 11, 12, & 13
Step Up Tube
Step 2

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 14 of 36
ASSEMBLY STEPS:
Measure Doorways:
Measure all doorways, hallways and stairwells to make sure that the 34.5” frame can t through them. If it will not t,
move all parts to the nal location and assemble machine in that location. If the machine needs to be placed on its
side, separate the upper pedestal from the base and keep the le side foam packaging attached to the base to help avoid
damaging the plastic covers as shown.
a) Disconnect the cables from the lower
board.
b) Separate the Network cable and
COAX cable at the base of the right
pedestal.
c) Disconnect the Ground cable on the
right pedestal hinge.
d) Remove the shoulder bolts on each
pedestal hinge and carefully remove the
pedestal from the elliptical base.
NOTE: e elliptical base can be set
on its LEFT side, but ONLY with the
attached foam packaging underneath it.
Lower Board Ground Cable Coax Cable
Network Cable
Shoulder Bolts

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 15 of 36
ASSEMBLY STEPS:
STEP 1 Fold Up and Install Pedestal:
a) Remove the container lid and top layer of parts
and packaging.
b) Remove all loose parts and packaging materials.
c) Leave the machine base on the shipping container
until Step 3.
d) Li the Pedestal into an upright position.
STEP 2 Install Step Up Tube and Cover:
a) Attach the step tube to the rear of
the machine using the
2 M10 1.5 x 75mm bolts and
a 13mm socket.
b) Attach the plastic step using the
4 M5 0.8 x 12mm screws.
Hardware Required :
e) Secure each Pedestal to the Base
using 6 M10 1.5 x 20mm bolts and
an 8mm allen wrench.
Hardware Required:
12 M10 1.5 x 20mm Bolts
4 M5 0.8 x 25 mm Bolts
2 M8 1.25 x 70mm Bolts M10 1.25 x 70mm bolts M5 0.8 x 25 bolts

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 16 of 36
ASSEMBLY STEPS:
STEP 3 Remove Unit from Pallet:
a) Using the Step up tube, li the unit at the rear.
b) Carefully walk the unit forward to remove it from
the pallet.
STEP 4 Route Cable and Install Console Mast:
a) Slide the USB data cable through the opening in the
Console Mast toward the front of the machine (in the
direction of the arrow shown to the right).
b) Secure the console mast to the unit
using 4 M8 1.25 x 16mm bolts and a
6mm allen wrench.
Hardware Required:
4 M8 1.25x16mm Bolts

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 17 of 36
ASSEMBLY STEPS:
STEP 5 Install Heart Rate Handle Bars:
a) Connect Cardio Arm Heart Rate Cable.
b) CAREFULLY slide the handle bar onto
Pedestal and tuck the Heart Rate Cable into
the metal tube. Make sure to not pinch the
heart rate wires.
c) Use 3 M6 1.0 x 10mm bolts, 3 at
washers, and 3 spacers on each side
to tighten the handle bars onto the
Pedestal.
Hardware Required:
8 Tapered M8 x 16 mm bolts
STEP 6 Install Upper Exercise Arms:
a) Install each upper arm with 4 M8 1.25 x
20mm bolts using a 6mm hex key.
Hardware Required:

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 18 of 36
ASSEMBLY STEPS:
STEP 7 Connect Cables & Install Exercise Arm Covers:
a) Connect remote access key cable at the base of each Upper Exercise
Arm.
STEP 8 Install Chin-Bar Tube:
a) Slide the Chin Bar over the posts on
the front of the unit.
b) Secure using 4 M8 1.25 x 16mm bolts.
Hardware Required:
b) Attach the Exercise Arm Covers
using 2 M5 0.8 x 25mm and 1 M5 0.8
x 12mm screws per side.
Hardware Required:
4 M5 0.8 x 25 mm bolts
2 M5 0.8 x 12 mm bolts
4 M8 1.25 x 16mm bolts
Note: If this unit is being connected to a power souce other than 110v,
install the required power transformer NOW. e transformer
instructions are included in the transformer packaging.
*DO NOT use an impact drill when
assembling plastic components.

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 19 of 36
ASSEMBLY STEPS:
Short Screw
12 M5 0.8 x 12 mm bolts
2 M5 0.8 x 50 mm bolts
8 M8 1.25 x 12 mm bolts
8 Curved Washers
2 Flat Washers
*DO NOT use an impact drill when
assembling plastic components.
Short Screw
Long Screw
& Washer
STEP 9 Install Chin-Bar Covers and Gasket:
a) Attach the inner and outer chin-bar
covers using 6 M5 0.8 x 12 mm screws
and 1 M5 0.8 x 50 mm screw.
*Screw locations shown on the right.
b) Slide the black rubber gaskets down
the pedestal uprights until they are snug
against the newly installed chin bar covers.
Hardware Required:
STEP 10 Install Draw-Bars:
a) Secure the bottom of each drawbar
using 4 M8x 12 bolts and 4 M8 curved
washers, but do not fully tighten.
Hardware Required:

CHAPTER 2: ASSEMBLY GUIDE
Truetness.com / 800.426.6570 / 636.272.7100 20 of 36
ASSEMBLY STEPS:
STEP 10 Install Draw-Bars:
b) Slide each drawbar onto its sha and
install and fully tighten M10 1.5x75mm
bolt, at washer and M10 nut with a 17mm
socket and wrench.
c) Tighten the bottom 8 bolts with 6mm
allen wrench.
Hardware Required:
STEP 11 Install Pedal Tubes:
a) Use 2 M10 x 80 mm bolts and 2 M10 nuts
to attach the Pedal Tubes, but do not fully
tighten.
Hardware Required:
b) Ensure that the Pedal Tubes are centered
on the cranksha rollers.
c) Fully tighten the pedal tube bolts.
2 M10 x 75mm Bolts
2 M10 x 80 mm bolts
2 M10 Nuts
2 M10 Nuts 2 Flat Washers
