ttec PowerSlim User manual

PowerSlim 5000 Kilavuz EN.indd 1 6.07.2018 09:56

FOR TECHNICAL ASSISTANCE:
Phone: [phone]
E-mail: [email protected]
www.tesan.com.tr
PowerSlim 5000 Kilavuz EN.indd 2 6.07.2018 09:56

3
Table of Contents
Thank You............................................................................................................
Overview..............................................................................................................
Operation............................................................................................................
Switching On and Off...........................................................................................
How to charge the PowerSlim..............................................................................
Charging your device with the PowerSlim............................................................
Checking the remaining power capacity of the PowerSlim...................................
Important safety instructions...............................................................................
Maintenance.......................................................................................................
Service Stations...................................................................................................
4
5
6
7
8
10
11
12
16
22
PowerSlim 5000 Kilavuz EN.indd 3 6.07.2018 09:56

4
Thank You
Thank you for purchasing the PowerSlim. For optimum performance and
safety, please read these instructions carefully before operating the product.
Please keep your user manual for future reference.t
Specications
• Capacity: 5.000mAh
• Battery Type: Li-Polymer
• Input: 1 x Micro USB Port
• Output: 1 x USB Output
• Input: DC5V 1A (maximum)
• Output: DC5V1A (1A maximum)
• Charging Time: 6-7 hours
PowerSlim 5000 Kilavuz EN.indd 4 6.07.2018 09:56

5
Overview
What’s in the box:
• 1 x PowerSlim Mobile Battery
• 1 x Micro USB Cable
• 1 x User Manual
The PowerSlim Mobile Battery includes the parts as shown in the following gure:
LED Power Indicators
Micro USB Port
Power On/Off Button
USB Outputs
PowerSlim 5000 Kilavuz EN.indd 5 6.07.2018 09:56

6
• Phone/iPod/iPad
• Samsung, LG, Sony, HTC, Nokia, Huawei, Motorola, BlackBerry, etc...
• Smart watches
• Digital cameras
• Portable Bluetooth devices such as earphones, car kits and speakers
• Portable game consoles
Operation
iPad PSPiPhone MP3/MP4Phone
PowerSlim 5000 Kilavuz EN.indd 6 6.07.2018 09:56

7
• Phone/iPod/iPad
• Samsung, LG, Sony, HTC, Nokia, Huawei, Motorola, BlackBerry, etc...
• Smart watches
• Digital cameras
• Portable Bluetooth devices such as earphones, car kits and speakers
• Portable game consoles
Switching On and Off
Switching the PowerSlim On and Off
1. Switching the PowerSlim on:
Press the power button once. LED power indicator will illuminate, showing that the
device is on.
2. Switching the PowerSlim off:
If the PowerSlim is not connected to any device, the LED indicator will switch off in 8
seconds and the PowerSlim will switch off.
If no device is connected, the LED indicators will go off after 8 seconds and
the mobile power unit will automatically be switched off after 120 seconds.
PowerSlim 5000 Kilavuz EN.indd 7 6.07.2018 09:56

8
How to charge the PowerSlim
Charging the PowerSlim
Please connect your cable to the PowerSlim Micro USB port, and charging will start
when you connect the USB connector to a USB-compatible charger or your computer.
• The LED indicators will ash to show the charge status during the charging process.
• When charging is nished, all of the 4 LED indicators will illuminate continuously.
PowerSlim 5000 Kilavuz EN.indd 8 6.07.2018 09:56

9
When the PowerSlim is locked or enters into short-circuit protection mode due to
misuse, please charge and restart it.
*A charger and computer are not supplied with the product. The charging time
depends on the output power of the charger.
How to charge the PowerSlim
PowerSlim 5000 Kilavuz EN.indd 9 6.07.2018 09:56

10
Charging your device with the PowerSlim
Suitable for the following devices:
1. You can use the original USB data cable or Micro USB cable supplied with your
product in order to connect your device.
2. Connect your device to the PowerSlim’s USB output with the cable.
3. Press the power button.
4. The LED power indicator will remain illuminated while your device is being charged.
5. Disconnect your device when it is fully charged.
iPad PSPiPhone MP3/MP4Phone
PowerSlim 5000 Kilavuz EN.indd 10 6.07.2018 09:56

11
Charging the remaining power capacity of the PowerSlim
• After pressing the power On/Off button the LED indicators will show the remaining
capacity.
• The LED indicators will switch off automatically after approximately 8 seconds.
Between 25% and 50%
Between 50% and 75%
Between 75% and 99%
100%
On Off Flashing Remaining Capacity
Less than 25%
PowerSlim 5000 Kilavuz EN.indd 11 6.07.2018 09:56

12
Important safety instructions
• In order to maximize battery life, please fully charge the PowerSlim before rst use.
• Please keep the PowerSlim in a cool, dry place.
• Please do not leave the PowerSlim in hot and humid environments.
• Operating temperature should be between -10°C and 45°C.
• If the PowerSlim has not been used for a long time, you should charge and dis-
charge it at every three months.
• The PowerSlim may get hot when charging a device. This is normal and there is no
need for concern.
• Battery performance will reduce in a few years under normal conditions.
• Please do not put the PowerSlim in extremely hot environments or into re.
• Please do not use hazardous chemicals or detergents to clean the PowerSlim.
• Misuse, dropping or excessive force may damage the device.
PowerSlim 5000 Kilavuz EN.indd 12 6.07.2018 09:56

13
Safety Information
• Please remove the product carefully from the packaging and store all the accessories
in the box in order to avoid losing them. Please check the product for transportation
damage. Please do not expose the product to any impacts during transport.
• If your product is damaged and not operating, please notify your point of purchase
immediately.
• If your product has been shipped directly to you, please notify the shipper im-
mediately.
• There are no user-serviceable parts inside your product. In the case of faults please
contact an authorized service station (Please see the list of authorized service stations)
or authorized seller that you purchased your product from.
PowerSlim 5000 Kilavuz EN.indd 13 6.07.2018 09:56

14
Information on misuse
• Errors caused by not using the product as specied in the manual,
• Short circuits that occur when the product is used in hot and extremely humid
environments,
• Using connection cables other than those supplied by the manufacturer in the
product packaging,
• User intervention or adding/removing parts,
• External physical impact on the product and damage such as breaking the product,
• Damaging or removing the product serial number,
• Failure caused by not using the original accessories,
• Damage caused by natural disasters such as re, lightning, oods and earthquakes.
PowerSlim 5000 Kilavuz EN.indd 14 6.07.2018 09:56

15
Disclaimer
This battery can be used only with compatible electronic equipment. Please read the
instructions on your equipment’s packaging to make sure this battery is suitable for
your equipment. Manufacturer will not be held responsible for damage to electronic
equipment that occurs during usage of this product.
Manufacturer will not be held responsible for damage to the battery caused by misuse
or by intentional or unintentional actions of the buyer or third parties with regards to
equipment and accessories that are not compatible with this battery. As stated above,
manufacturer will not be held responsible for damages due to misuse of the battery.
PowerSlim 5000 Kilavuz EN.indd 15 6.07.2018 09:56

16
Maintenance
Your device is the result of sophisticated design and masterful craftsmanship
thus, its maintenance must be carried out with special care. The following
recommendations will help you preserve your warranty coverage.
• Please store all accessories and attachments out of children’s reach.
• Please keep the device dry. Rain, moisture, and all kinds of liquids contain minerals
that may be corrosive to electronic circuits. If your device gets wet, please dry it
thoroughly.
• Please do not use or store the device in dusty and/or dirty environments. Moving
parts and electronic parts may be damaged.
• Please do not store the device in hot environments. High temperatures may shorten
the life of electronic devices, damage batteries, and cause certain plastic parts to
deform or melt.
PowerSlim 5000 Kilavuz EN.indd 16 6.07.2018 09:56

17
• Please do not store the device in cold environments. When the device returns to
normal temperature, moisture may build up inside it and the electronic circuits may
be damaged.
• Please avoid dropping, impacts and shaking. Rough handling may cause breakage of
internal circuits and sensitive mechanical parts.
• Do not use abrasive chemicals, cleaning solvents or strong detergents to clean the
device.
• Do not paint the device. Paint may restrict the moving parts and prevent them from
functioning properly.
All the recommendations above apply to the device, battery, charger and all other
accessories. If any device does not function properly, please take it to the nearest
authorized service center.
PowerSlim 5000 Kilavuz EN.indd 17 6.07.2018 09:56

18
Technical Support for Damages
• Product fails to operate due to not following operating instructions,
• An unexpected change in performance,
• Product is dropped or damaged,
• Problems due to improper use or negligence,
• Damage to power source or connection cable,
• Liquid spillage or insertion of objects inside the product,
• Opening or removing any of the labels,
• Any signs of attempts to open and/or tamper with the product.
PowerSlim 5000 Kilavuz EN.indd 18 6.07.2018 09:56

19
INFORMATION ABOUT MAINTENANCE, REPAIR, AND
PRODUCT CLEANING
IMPORTER - MANUFACTURER
Your product does not require maintenance as long as the instructions in the user
manual are followed.
TESAN İLETİŞİM A.Ş.
ÇOBANÇEŞME MAHALLESİ BİLGE 1 SK.
NO:17 YENİBOSNA / İSTANBUL
Phone: [phone]
Faks: 0212 454 60 20
www.tesan.com.tr
Technical Service: 0212 454 60 70
PowerSlim 5000 Kilavuz EN.indd 19 6.07.2018 09:56

20
The “LIFETIME” of the device is 3 years in terms of spare parts supply and proper
functioning.
Note: Our company is not responsible for any errors that may occur during writing
and printing.
*** This product complies with the WEEE Directive.
*** This product is marked in accordance with norms and
regulations.
***This product complies with the RoHS Directive.
