ttec PowerTouch User manual

www.hellottec.com

3
Table of Contents
Thank You........................................................................................................
Overview...........................................................................................................
Operation..........................................................................................................
Switching On and Off.......................................................................................
How to charge the PowerTouch.........................................................................
Charging your device with the PowerTouch.......................................................
Checking the remaining power capacity of the PowerTouch..............................
Important safety instructions.............................................................................
Maintenance.....................................................................................................
4
5
6
7
8
10
11
12
16

4
Thank you
Thank you for purchasing PowerTouch Universal Mobile Charger. For optimum
performance and safety, please read these instructions carefully before operating the
product. Please keep your user manual for future reference.
Specications
• Capacity: 10.000mAh
• Battery Type: Li-Polymer
• Input: 1 x Micro USB Port
• Output: 2 x USB Outputs
• Input: DC5V 2A (maximum)
• Output: DC5V2.1A (2.4 maximum)
• Charging Time: 7 hours

5
Micro USB Port
Power Soft Key USB Outputs
USB Output LED Power
Indicator
Overview
What’s in the box:
• 1 x PowerTouch Universal Mobile Charger
• 1 x Micro USB Cable
• 1 x User Manual
PowerTouch Universal Mobile Charger includes the parts shown in the following gure:

6
Operation
• iPhone/iPod/iPad
• Samsung, LG, Sony, HTC, Nokia, Huawei, Motorola, BlackBerry, etc...
• Smart watches
• Digital cameras
• Portable Bluetooth devices such as earphones, car kits, and speakers
• Portable game consoles
iPad PSPiPhone MP3/MP4Phone

7
Switching On and Off
Switching PowerTouch On and Off
1. Switching the PowerTouch on:
Touch the power button once. LED power indicator will illuminate, showing that the
device is on.
2. Switching the PowerTouch off:
If PowerTouch is not connected to any device, the LED indicator will go off in 32 seconds
and PowerTouch will be switched off.
If no device is connected, the LED indicators will go off after 32 seconds and the
mobile power unit will automatically switch off after 120 seconds.

8
How to charge PowerTouch
Charging PowerTouch
Please connect your cable to the PowerTouch Micro USB port. Charging will begin when
you connect the USB connector to a USB-compatible charger or your computer.
• The LED power indicator will ash to indicate the charge status during charging process.
• When charging is complete, all LED power indicators will remain illuminated.

9
When PowerTouch is locked or enters into short-circuit protection mode due to
misuse, please charge and restart it.
*A charger and computer are not supplied with the product. The charging time
depends on the output power of the charger.
How to charge PowerTouch

10
Charging your device with the PowerTouch
Suitable for the following devices:
1. You can use the original USB data cable or Micro USB cable supplied with your
product in order to connect your device.
2. Connect your device to PowerTouch USB output with the cable.
3. Touch the power button.
4. The LED power indicator will remain illuminated while your device is being charged.
5. Disconnect your device when it is fully charged.
iPad PSPiPhone MP3/MP4Phone

11
Checking the remaining power capacity of PowerTouch
•After touching the Power button, the LED power indicator will show the remaining
capacity.
•The LED power indicator will go off automatically after approximately 32 seconds.
Between 25% and 50%
Between 50% and 75%
Between 75% and 99%
100%
On Off Flashing Remaining Capacity
Less than 25%

12
Important safety instructions
•In order to maximize battery life, please fully charge PowerTouch before rst use.
•Please keep PowerTouch in a dry and cool place.
•Please do not leave PowerTouch in hot and humid environments.
•Operating temperature should be between -10°C and 45°C.
•If PowerTouch is not being used for a long time, you should charge and discharge it
every three months.
•PowerTouch may get hot when charging a device. This is normal and there is no
need for concern.
•Battery performance will reduce in a few years under normal conditions.
•Please do not put PowerTouch in extremely hot environments or into re.
•Please do not use hazardous chemicals or detergents to clean PowerTouch.
•Misuse, dropping or excessive force may damage the device.

13
Safety Information
• Please remove the product carefully from the packaging and store all the accessories
in the box in order to avoid losing them. Please check the product for transportation
damage. Please do not expose the product to any impacts during transport.
• If your product is damaged and not operating, please notify your point of purchase
immediately.
• If your product has been shipped directly to you, please notify the shipper im-
mediately.
• There are no user-serviceable parts inside your product. In the case of faults please
contact an authorized service station (Please see the list of authorized service stations)
or authorized seller that you purchased your product from.

14
Information on misuse
• Errors caused by not using the product as specied in the manual,
• Short circuits that occur when the product is used in hot and extremely humid
environments,
• Using additional connection cables other than those supplied by the manufacturer
inside the product packaging,
• User intervention or adding/removing parts,
• External physical impact on the product and damage such as breaking the product,
• Damaging or removing the product serial number,
• Failure caused by not using the original accessories,
• Damage caused by natural disasters such as re, lightning, oods, and earthquakes.

15
Disclaimer
This battery can only be used with compatible electronic equipment. Please read
the instructions on your equipment’s packaging to make sure this battery is suitable
for your equipment. The manufacturer will not be held responsible for damage to
electronic equipment that occurs during the usage of this product.
The manufacturer will not be held responsible for damage to the battery caused by
misuse or by the intentional or unintentional actions of the buyer or third parties with
regards to equipment and accessories that are not compatible with this battery. As
stated above, the manufacturer will not be held responsible for damage to the battery
due to misuse.

16
Maintenance
Your device is a product of advanced design and workmanship, and must be
maintained properly. The following recommendations will help you preserve
your warranty coverage.
· Please store all accessories and attachments out of children’s reach.
· Please keep the device dry. Rain, moisture, and all kinds of liquids contain minerals
that may be corrosive to electronic circuits. If your device gets wet please dry it
thoroughly.
· Please do not use or store the device in dusty and/or dirty environments. Moving
parts and electronic parts may become damaged.
· Please do not store the device in hot environments. High temperatures may shorten
the life of electronic devices, damage batteries, and cause certain plastic parts to
deform or melt.

17
· Please do not store the device in cold environments. When the device returns to
normal temperature, moisture may build up inside it and electronic circuits may be
damaged.
· Please take care not to drop, bang or shake the device. Rough handling may cause
breaking of internal circuits and sensitive mechanical parts.
· Do not use abrasive chemicals, cleaning solvents or strong detergents to clean the
device.
· Do not paint the device. Paint may restrict the moving parts and prevent them from
functioning properly.
All the recommendations above apply to the device, batteries, charger or all the other
accessories. If the device does not function properly, please take it to the nearest
authorized service center.

18
Technical Assistance for Damages
• Product fails to operate due to not following operating instructions,
•An unexpected change in performance,
• Product is dropped or damaged,
• Problems due to improper use or negligence,
• Damage to power source or connection cable,
• Liquid spillage or insertion of objects into the product,
• Opening or removing any of the labels,
• Any signs of attempts to open and/or tamper with the product.

19
INFORMATION ON MAINTENANCE, REPAIR, AND
PRODUCT CLEANING
Your product does not require maintenance as long as the instructions in the user manual
are followed.
The “LIFETIME” of the device is 3 years in terms of spare parts supply and proper
functioning.
Note: Our company is not responsible for any errors that may occur during writing and
printing.
*** This product complies with the AEEE Directive.
*** This product is marked in accordance with regulations.
***This product complies with the RoHS Directive.

20
RoHS Statement
All our company’s lead-free products comply with the Restriction of the Use of Certain
Hazardous Substances (RoHS) European directive. This means that our production pro-
cesses and products are strictly “lead-free” and do not contain hazardous substances
as dened in the directive.
The crossed-out wheelie bin symbol indicates this product should be collected sepa-
rately within the European Union at the end of its lifetime. This applies to your product
and its attachments that have this symbol. Please do not dispose of these products as
unclassied domestic waste.
