Tuff stuff AP-5ABS User manual

ASSEMBLY INSTRUCTIONS
America’s Premium Exercise Equipment
AP-5ABS_AP-5ABD Rev0
© 2003 TASK INDUSTRIES, INC.
Ab/Back Option
Includes Assembly for:
AP-5ABS
Ab/Back W/Nylon Pulleys (Standard)
AP-5ABD
Ab/Back W/Aluminum Pulleys (Deluxe)
Revision Date 06-20-03

About the AP-5ABS_AP-5ABD Ab/Back Option
Congratulations on your new purchase of the AP-5ABS_AP-5ABD
Ab/Back Option. We hope you are completely satisfied with this
product and wish you many years of enjoyment.
Tuff Stuff Equipment
This Tuffstuff product has been built to precise quality standards
and has been carefully packaged to ensure that damage will
not occur during shipment. The Limited Warranty and signature
indicating final inspection has been conducted by our line foreman,
is an expression of our confidence in the completeness, the
materials, and workmanship of this product.
Warranty
SEE A COPY OF WARRANTY ON BACK PAGE.
Registration Card
To avoid unnecessary delays in warranty service and to insure that
a permanent record of your purchase is on file with our factory, be
sure to complete the warranty registration card and send it to Task
Industries today.
Prior to the Assembly of the AP-5ABS_AP-5ABD
1. We advise you to consult your local Tuff Stuff retailer if you
should have a question or problem regarding the proper
assembly of this unit.
2. Neatly organize and identify all parts according to the Exploded
View Diagram on Fold-out Pg. 3 and the Parts List on Fold-out
Pg. 4.
Tool Requirements
1. One 7/8” combination wrench
2.One 3/4” combination wrench
3. One 9/16” combination wrench
4.One 1/2” combination wrench
5. One ratchet
6. One 9/16” socket
7. One 1/2” socket
8. One rubber mallet
9. One hammer
10. Windex or household glass cleaner
11. Measuring tape
12. Utility knife
SCREWfiWIDTH
WASHERfiDIAMETER
NUTfiDIAMETER
SCREWfiLENGHT
Hardware Measurement Diagram
Note: Due to continuing product improvements, specifications and designs are subject to change
without notice.
Specifications
1. Maximum Wt. Capacity 200 Lbs. Fixed
2. Total Machine Weight 80 Lbs.
AP-5ABS_AP-5ABD Ab/Back Option
1

AP-5ABS_AP-5ABD Ab/Back Option 4
Item No. Description Part No. Qty Item No. Description Part No. Qty
17 INSERT TUBE 1 X 16 UP0053 1 142 PLASTIC INSERT CAP 2" SQ. 10-14 GA. BNH0012 2
23 FOOT ROLL 1 X 5 1/2 X 7 1/4 UP0350 2 144 PLASTIC TUBE GUIDE W/LIP-TEETH 2 1/4" SQ. BNH0059 2
36 ACTUATOR ARM UP0344 1 148 PUSH PULL PIN 1/2 X 3 1/2 BNH0520 1
40 SWIVEL FOAM ROLL TUBE UP2026 1 149 PVC 1 X 7 1/4 BNH1023 2
43 FOAM ROLL 2 X 5 1/2 X 18 UP2031 1 151 ROLL PIN Z/P 3/8 X 1 1/2 BNH0483 1
45 ADJUSTABLE PULLEY BRACKET UP0127 1 166 SHOULDER BOLT ALLOY 3/8 X 3/4 BNH0718 1
75 ABS PIPE 2 X 18 BNH1245 1 170 SOCKET SET SCREW ALLOY 3/8-16 X 1/2 BNH0474 1
78 ALUMINUM PULLEY 3/8" X 4 1/2" BHN0069 5 172 SPLIT HEX TAP BOLT GR-5 B/O 1/2-13 X 3 1/2 BNH1131 1
79 BALL BEARING #W 516 BNH0628 2 174 SPLIT LOCK WASHER B/O 3/8" BNH0658 1
81 BRONZE BUSHING 1 X 1 1/4 X 3/4 X 1 1/2 X 1/8 BNH0527 2 176 SPLIT LOCK WASHER Z/P 1/2" BNH0572 3
83 BUTTON HEAD SOCKET CAP SCREW B/O 3/8-16 X 1 BNH0115 1 179 TURN/PULL PIN W/KNOB AND LOCK BNH0989 1
84 CHROME CAP 2" RD BNH1137 1 180 URETHANE BUMPER 1 3/4 BNH0229 3
89 FINISHED HEX NUT B/O 1/2-13 BNH0201 2 184 DECAL-DANGER TIGHTEN THIS RET..., 3/4 X 1-1/2 BNH0142 1
90 FINISHED HEX JAM NUT B/O 1/2-13 BNH0655 1 191 DECAL-WARNING KEEP HANDS AND FINGERS... BNH0620 1
92 FLAT PHILLIPS MACHINE SCREW 8-24 X 1/4 BNH0408 1 197 HEX KEY 3/16" BNH0371 1
94 FLAT WASHER SAE 3/8" BNH0239 28 198 HEX KEY 7/32" BNH0575 1
99 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/4 BNH0273 4 235 MAIN FRAME UP2119 1
100 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 1/2 BNH0303 3 236 SIDE FRAME UP2120 1
101 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 1 3/4 BNH0274 5 237 PLATE 1/4 X 2 X 6 UP1758 1
102 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 2 BNH0279 2 238 PLATE 1/4 X 2 X 5 UP1759 1
105 HEX HEAD CAP SCREW GR-5 B/O 3/8-16 X 3 1/4 BNH0312 6 239 PIVOT ARM UP0336 1
122 NYLON FLAT WASHER 1 X 1 1/4 X 1/16 BNH0393 2 240 PULLEY COVER UP0337 1
123 NYLON INSERT JAM LOCK NUT B/O 3/8-16 BNH0365 5 241 CIRCULAR PLATE W/AXLE UP0340 1
125 NYLON INSERT LOCK NUT B/O 3/8-16 BNH0214 6 242 ADJUSTABLE FOOT PIECE UP0338 1
126 NYLON INSERT LOCK NUT B/O 5/16-18 BNH0215 1 243 FOOT ROLL TUBE 1 X 18 1/4 UP0943 1
127 NYLON INSERT JAM LOCK NUT B/O 1/2-13 BNH0366 2 244 SEAT PAD UP2111 1
133 PLASTIC INSERT CAP "A" 1 RD. BNH0812 2 245 MAIN CABLE UP2122 1
134 PLASTIC INSERT CAP "B" 1 RD. BNH0813 2 246 SEAT BELT BRACKET UP2110 2
135 PLASTIC INSERT CAP "C" 2 RD. BNH0814 1 247 HEX HEAD CAP SCREW GR-5 B/O 1/2-13 X 1 BNH0259 2
136 PLASTIC INSERT CAP "D" 2 RD. BNH0815 1 248 PLASTIC INSERT CAP 1 1/4" RD. 11 GA. BNH0573 2
137 PLASTIC INSERT CAP 1" X 2"_ 10-14 GA. BNH0005 3 249 RUBBER GRIP 1 ID X .125 X 7 1/4 BNH0963 2
138 PLASTIC INSERT CAP 1" RD. 10-12 GA. BNH0002 2 250 BLACK SEAT BELT TYPE 1 BUCKLE BNH1217 1
139 CHROME WASHER 3/8 X 1 1/2 BNH1015 1 251 BLACK SEAT BELT TYPE 1 ALR RETRACTOR BNH1218 1
140 PLASTIC INSERT CAP 1 3/4" SQ. 10-14 GA. BNH0053 3
Item No. Description Part No. Qty
78 NYLON PULLEY 4 1/2 RD. WHITE BNH0556 5
AP-5ABD
All parts same as AP-5ABD, except for the part listed below
Parts List
AP-5ABS
Parts List
COLOR CHART
GRAY= SUB-ASSEMBLY PARTS
BLACK= HARDWARE

DO NOT DISCARD THIS MANUAL
TASK INDUSTRIES, INC.
1325 E. Franklin Ave., Pomona, CA 91766
Ph: 909-629-1600 Fax: [phone]
E-mail: [email protected] Net: www.tuffstuff.net
