Tunturi Pure Run 6.1 User manual

!
!
WWW.TUNTURI.COM
PURE RUN 6.1
USERMANUAL
 
(QJOLVK 
'HXWVFK 
1HGHUODQGV 
)UDQ©DLV 

 


5811
 

(QJOLVK 

'HXWVFK 

1HGHUODQGV 

)UDQ©DLV 

 


5811
!
!
PURE RUN 4.1
USERMANUAL
WWW.TUNTURI.COM
English 10
Deutsch 26
Nederlands 44
Français 61
Español 96
Svenska 113
Suomi 129

Illustrations
EN
2 RUN 6.1

1
14
15
10
10
11
11
13
7
8
2
5
3
9
12
6
3
2
4
A
EN
RUN 6.13

C
B
M8*60LM8*15L
17 (4x)16 (4x)
EN
4 RUN 6.1

100 CM
100 CM
200 CM
100 CM
D1
D0
16
16
EN
RUN 6.15

D3
D2
17
17
EN
6 RUN 6.1

100 CM
100 CM
200 CM
100 CM
D4
EN
RUN 6.17

F
E
EN
8 RUN 6.1

G
EN
RUN 6.19

Content
TREADMILL
Welcome to the world of Tunturi New Fitness!
Thank you for purchasing this piece of Tunturi equipment. Tunturi offers a wide range
of professional fitness equipment, including crosstrainers, treadmills, exercise bikes
and rowers. The Tunturi equipment is suitable for the entire family, no matter what
fitness level. For more information, please visit our website www.tunturi.com
Safety warnings
WARNING
– Read the safety warnings and the instructions. Failure to follow the
safety warnings and the instructions can cause personal injury or
damage to the equipment. Keep the safety warnings and the
instructions for future reference.
WARNING
– Heart-rate monitoring systems may be inaccurate. Over-exercise
may result in serious injury or death. If you feel faint, stop exercising
immediately. For the correct position on the running belt see
illustration D4.
▪ The equipment is suitable for domestic and professional use only (e.g. hospitals,
fire stations, hotels, schools etc.). Max. usage is limited to 6 hrs a day. The
equipment is not suitable for full commercial use (e.g. large gyms).
▪ The use of this equipment by children or persons with a physical, sensory,
mental or motorial disability, or lack of experience and knowledge can give cause
to hazards. Persons responsible for their safety must give explicit instructions or
supervise the use of the equipment.
▪ Before starting your workout, consult a physician to check your health.
▪ If you experience nausea, dizziness or other abnormal symptoms, immediately
stop your workout and consult a physician.
▪ To avoid muscular pain and strain, start each workout by warming up and finish
each workout by cooling down. Remember to stretch at the end of the workout.
EN
10 RUN 6.1

▪ The equipment is suitable for indoor use only. The equipment is not suitable for
outdoor use.
▪ Only use the equipment in environments with adequate ventilation. Do not use
the equipment in draughty environments in order not to catch a cold.
▪ Only use the equipment in environments with ambient temperatures between 10
°C and 35 °C. Only store the equipment in environments with ambient
temperatures between 5 °C and 45 °C.
▪ Do not use or store the equipment in humid surroundings. The air humidity must
never be more than 80%.
▪Only use the equipment for its intended purpose. Do not use the equipment for
other purposes than described in the manual.
▪ Do not use the equipment if any part is damaged or defective. If a part is
damaged or defective, contact your dealer.
▪ Keep your hands, feet and other body parts away from the moving parts.
▪ Keep your hair away from the moving parts.
▪ Wear appropriate clothing and shoes.
▪ Keep clothing, jewelry and other objects away from the moving parts.
▪ Make sure that only one person uses the equipment at a time. The equipment
must not be used by persons weighing more than 150 kg (330 lbs).
▪ Do not open equipment without consulting your dealer.
Electrical safety
Description (fig.A)
Your treadmill is a piece of stationary fitness equipment used to simulate walking or
running without causing excessive pressure to the joints.
1 Running belt 8 Safety key clip
2 Side handlebar 9 Support foot
3 Hand pulse sensor 10 Transport wheel
4 SPEED +/- button 11 Console
5 INCLINE +/- button 12 Master power switch
6 Safety key slot 13 Circuit breaker
7 Safety key 14 Mains cable connection
EN
RUN 6.111

Fasteners (fig. C)
16 Screw (M8*60L) 17 Screw (M8*15L)
Package contents (fig. B & C)
▪ The package contains the parts as shown in fig. B.
▪ The package contains the fasteners as shown in fig. C. Refer to the section
“Description”.
NOTE
– If a part is missing, contact your dealer.
Assembly (fig. D)
WARNING
– Assemble the equipment in the given order.
– Carry and move the equipment with at least two persons.
CAUTION
– Place the equipment on a firm, level surface.
–Place the equipment on a protective base to prevent damage to the
floor surface.
– Allow at least 200 cm of clearance behind the equipment, 100 cm in
front of the equipment and 100 cm on the sides of the equipment.
▪ Refer to the illustrations for the correct assembly of the equipment.
EN
12 RUN 6.1

Workouts
The workout must be suitably light, but of long duration. Aerobic exercise is based on
improving the body’s maximum oxygen uptake, which in turn improves endurance
and fitness. You should perspire, but you should not get out of breath during the
workout.
To reach and maintain a basic fitness level, exercise at least three times a week, 30
minutes at a time. Increase the number of exercise sessions to improve your fitness
level. It is worthwhile to combine regular exercise with a healthy diet. A person
committed to dieting should exercise daily, at first 30 minutes or less at a time,
gradually increasing the daily workout time to one hour. Start your workout at low
speed and low resistance to prevent the cardiovascular system from being subjected
to excessive strain. As the fitness level improves, speed and resistance can be
increased gradually. The efficiency of your exercise can be measured by monitoring
your heart rate and your pulse rate.
Pulse rate measurement (hand pulse sensors)
The pulse rate is measured by sensors in the handlebars when the user is touching
both sensors at the same time.
WARNING
– Heart rate monitoring systems may be inaccurate. Over exercise
may result in serious injury or death. If you feel faint stop exercising
immediately.
Most accurate pulse measurement is achieved when the skin is slightly moist and
constantly touching the hand pulse sensors. If the skin is too dry or too moist, the
pulse rate measurement might become less accurate.
NOTE
– Do not use the hand pulse sensors in combination with a heart rate
chest belt.
– If you set a heart rate limit for your workout, an alarm will sound
when it is exceeded.
EN
RUN 6.113

Heart rate measurement (heart rate chest belt)
The most accurate heart rate measurement is achieved with a heart rate chest belt.
The heart rate is measured by a heart rate receiver in combination with a heart rate
transmitter belt. Accurate heart measurement requires that the electrodes on the
transmitter belt are slight moist and constantly touching the skin. If the electrodes are
too dry or too moist, the heart rate measurement might become less accurate.
WARNING
– If you have a pacemaker, consult a physician before using a heart
rate chest belt.
CAUTION
– If there are several heart rate measurement devices next to each
other, make sure that the distance between them is at least 2 meter.
–If there is only one heart rate receiver and several heart rate
transmitters, make sure that only one person with a transmitter is
within transmission range.
NOTE
– Do not use a heart rate chest belt in combination with the hand
pulse sensors.
– Always wear the heart rate chest belt under your clothes directly in
contact with your skin. Do not wear the heart rate chest belt above
your clothes. If you wear the heart rate chest belt above your
clothes, there will be no signal.
– If you set a heart rate limit for your workout, an alarm will sound
when it is exceeded.
– The transmitter transmits the heart rate to the console up to a
distance of 1,5 meter. If the electrodes are not moist, the heart rate
will not appear on the display.
– Some fibers in clothes (e.g. polyester, polyamide) create static
electricity which can prevent accurate heart rate measurement.
– Mobile phones, televisions and other electrical appliances create an
electromagnetic field which can prevent accurate heart rate
measurement.
EN
14 RUN 6.1

Maximum heart rate (during training)
The maximum heart rate is the highest heart rate a person can safely achieve
through exercise stress. The following formula is used to calculate the average
maximum heart rate: 220 - AGE. The maximum heart rate varies from person to
person.
WARNING
– Make sure that you do not exceed your maximum heart rate during
your workout. If you belong to a risk group, consult a physician.
Category Heart rate zone Explanation
Beginner 50-60% of maximum heart
rate
Suitable for beginners, weight-watchers,
convalescents and persons who have
not exercised for a long time. Exercise at
least three times a week, 30 minutes at a
time.
Advanced 60-70% of maximum heart
rate
Suitable for persons who want to
improve and maintain fitness. Exercise
at least three times a week, 30 minutes
at a time.
Expert 70-80% of maximum heart
rate
Suitable for the fittest of persons who are
used to long-endurance workouts.
Use
Master power switch
The equipment is equipped with a master power switch to shut down the equipment
completely.
To start the equipment:
1. Insert the mains plug into the equipment.
2. Insert the mains plug into the wall socket.
3. Set the master power switch to the on position.
EN
RUN 6.1

To stop the equipment:
1. Set the mains power switch to the off position.
2. Remove the mains plug from the wall socket.
3. Remove the mains plug from the equipment.
Safety key (fig. E)
The equipment is equipped with a safety key that must be properly inserted into the
console to start the equipment. If you remove the safety key from the console, the
equipment will stop immediately.
1. Insert the safety key into the slot in the console.
2. Make sure that the clip of the safety key is properly attached to your clothing.
Make sure that the clip is not removed from your clothing before the safety key is
removed from the console.
Circuit breaker
The equipment is equipped with a circuit breaker that interrupts the circuit when the
electricity load is above the maximum capacity. When this occurs, the circuit breaker
must be pressed.
WARNING
– Before pressing the circuit breaker, remove the mains plug from the
equipment.
If the equipment shuts down, proceed as follows to restart the equipment:
1. Remove the mains plug from the equipment.
2. Press the circuit breaker to restart the equipment.
3. Insert the mains plug into the equipment.
Adjusting the support feet
The equipment is equipped with 4 support feet. If the equipment is not stable, the
support feet can be adjusted.
1. Turn the support feet as required to put the equipment in a stable position.
2. Tighten the locknuts to lock the support feet.
EN
16 RUN 6.1

Console
START
STOP
energy
PACE
KM/H
MPH
MILES
KM
1
8
9
34 675
17
12
10
11
2
1416 15 13
11
EN
RUN 6.117

1 ELEVATION display 10 SET button
2 KCAL display 11 Training profile indicator
3 HEART RATE display 12 MEM button
4 Main display 13 SPEED + button
5 TIME display 14 SPEED - button
6 DISTANCE display 15 START/STOP button
7 SPEED display 16 INCLINE - button
8 Distance unit indicator 17 INCLINE + button
9 Speed unit indicator
EN
18 RUN 6.1

Explanation of buttons and display
Button Explanation
SET Touch the button to select a workout program (P1-
P11).
MEM Touch the button to select a workout from the memory
(01-05).
INCLINE + Touch the button to increase the incline (0%-12%) by
1% at a time. The ELEVATION display shows the
incline. Touch and hold the button to accelerate the
process.
INCLINE - Touch the button to decrease the incline (0%-12%) by
1% at a time. The ELEVATION display shows the
incline. Touch and hold the button to accelerate the
process.
START/STOP Touch the button to start or stop the workout.
SPEED + Touch the button to increase the speed (0.8-20 km/h
(0.5-12.4 mph)) by 0.1 km/h (0.1 mph) at a time. The
SPEED display shows the speed. Touch and hold the
button to accelerate the process.
SPEED - Touch the button to decrease the speed (0.8-20 km/h
(0.5-12.4 mph)) by 0.1 km/h (0.1 mph) at a time. The
SPEED display shows the speed. Touch and hold the
button to accelerate the process.
EN
RUN 6.119

Display Explanation
Main display Workout profile.
TIME Duration (mm:ss) for the workout.
DISTANCE Distance (km or ml) for the workout.
SPEED Speed (km/h or mph) for the workout.
ELEVATION Incline (%) for the workout.
HEART RATE Heart rate limit (bpm) during the workout.
KCAL Energy consumption (kcal) for the workout.
Training menu
The program contains 11 preset training profiles.
1. Touch the SET button to select a training profile.
2. Touch and hold the SET button until the correct training profile indicator comes
on.
3. Manually change the speed and the incline during the workout:
–Touch the SPEED +/- buttons to increase or decrease the speed (0.8-20 km/
h (0.5-12.4 mph)) by 0.1 km/h (0.1 mph) at a time. The SPEED display
shows the speed. Touch and hold the button to accelerate the process.
– Touch the INCLINE +/- buttons to increase or decrease the incline (0%-12%)
by 1% at a time. The ELEVATION display shows the incline. Touch and hold
the button to accelerate the process.
4. Touch the START/STOP button to pause or stop the workout.
Cleaning and maintenance
WARNING
– Before cleaning and maintenance, remove the mains plug from the
wall socket.
– Do not use solvents to clean the equipment.
▪ Do not block the ventilation openings. Keep the ventilation openings clear from
dust, dirt and other obstructions.
▪ Clean the equipment with a soft, absorbent cloth after each use.
EN
20 RUN 6.1
