Tuttnauer EZ10 Manual

OPERATION
&
MAINTENANCE
MANUAL
Electronic Tabletop Autoclaves
Models EZ9, EZ10, EZ10K
Cat. No. MAN205-0263001EN Rev. K
Tuttnauer Ltd., Har Tuv B Industrial zone P.O.Box 170, 9910101, Beit Shemesh IsraelTel: [phone],
Fax: [phone]
Tuttnauer U.S.A. Co Ltd., Ltd. 25 Power Drive Hauppauge, NY, 11788, USA. Tel [phone],
Fax: [phone]

1
Web site: http//www.tuttnauerUSA.com

2
TABLE OF CONTENTS
Paragraph Page No.
1. GENERAL......................................................................................................................................4
1.1 Manufacturer and US Official Correspondence Information........................................4
1.2 Intended Use.....................................................................................................................4
1.3 Intended Users..................................................................................................................4
1.4 Incoming Inspection.........................................................................................................4
1.5 Warranty...........................................................................................................................4
1.6 Warranty Statement..........................................................................................................5
2. SAFETY INSTRUCTIONS ...........................................................................................................6
3. TECHNICAL DATA......................................................................................................................8
3.1 Introduction......................................................................................................................8
3.2 Standby Heating Mode.....................................................................................................8
3.3 Environmental Emission Information.............................................................................8
3.4 Operating Conditions .......................................................................................................9
3.5 Utilities..............................................................................................................................9
3.6 Construction .....................................................................................................................9
3.7 Symbol Description.........................................................................................................10
3.8 Electrical Data................................................................................................................11
3.9 Maximum Solid Load Sizes............................................................................................12
3.10 Specifications..................................................................................................................12
3.11 Technical Specifications ................................................................................................13
3.12 Directives and Standards................................................................................................14
3.13 Water Quality..................................................................................................................15
4. KEYBOARD (Keys and Display).................................................................................................18
4.1 Indicator Light Description............................................................................................19
4.2 Description and Functions of the Control Panel Keyboard..........................................20
4.3 Description of the Display Panel....................................................................................22
4.4 Description of Displayed Messages and Safety Measures ............................................22
5. STERILIZATION PROGRAMS .................................................................................................25
5.1 PROGRAM 1. Unwrapped Instruments ........................................................................25
5.2 PROGRAM 2. Wrapped Instruments and Porous Loads..............................................26
5.3 PROGRAM 3. Glassware...............................................................................................27
5.4 PROGRAM 4. Accessory (Dry Only).............................................................................27
6. PRINTER (Optional) ...................................................................................................................28
6.1 Printer Operation ...........................................................................................................28
6.2 Printer Handling ............................................................................................................30
7. INSTALLATION INSTRUCTIONS ...........................................................................................31
7.1 Electrical.........................................................................................................................31
7.2 Water Filling ..................................................................................................................32
7.3 Lifting and Carrying ......................................................................................................33
7.4 Loading and Unloading the Device ...............................................................................33
7.5 Filling the Water Reservoir............................................................................................34
8. PREPARATION BEFORE STERILIZATION ..........................................................................35
9. OPERATING INSTRUCTIONS .................................................................................................38

3
10. MAINTENANCE INSTRUCTIONS...........................................................................................40
10.1 Preventive and Scheduled Maintenance........................................................................40
10.2 Replacing the Air Filter .................................................................................................42
10.3 Draining the Reservoir...................................................................................................43
10.4 Cleaning the Air Jet .......................................................................................................44
10.5 Replacing the Door Gasket ............................................................................................45
10.6 Checking the Safety Valve..............................................................................................46
10.7 Replacing the Fuse.........................................................................................................47
10.8 Cleaning Water Outlet Strainer.....................................................................................48
10.9 Cleaning Tabletop Autoclaves with Chamber Brite ™ .................................................50
10.10 Water Sensor Cleaning ..................................................................................................51
11. TROUBLESHOOTING FOR THE OPERATOR.......................................................................52
TABLE OF CONTENTS (Cont.)
Drawings Page No.
FRONT VIEW.......................................................................................................................................16
REAR VIEW..........................................................................................................................................17
FRONT PANEL KEYBOARD..............................................................................................................18

4
1. GENERAL
Read the Operating Instructions carefully, before beginning any operation
on the autoclave!
1.1 Manufacturer and US Official Correspondence Information
The Autoclave is manufactured by Tuttnauer Ltd., Located Har –
Tuv B Industrial Zone, P.O. Box 170, Beit Shemesh 9910101, Israel.
Tel: [phone]
The US Official Correspondence is:
Tuttnauer U.S.A. Co., Ltd., 25 Power Drive Hauppauge, NY 11788,
USA Tel: [phone], Fax: [phone]
1.2 Intended Use
The autoclave is designed for the sterilization of medical and surgical
goods such as wrapped and unwrapped solid, hollow, and porous loads
used in healthcare facilities (e.g., hospitals, nursing homes, extended
care facilities, freestanding surgical centers, clinics, and medical &
dental clinics).
1.3 Intended Users
The autoclave is intended for use by hospital personnel and other
medical personnel.
All autoclave users must receive training in proper usage from an
experienced employee. Every new employee must undergo a training
period from an experienced employee.
1.4 Incoming Inspection
Upon receiving your Tuttnauer Autoclave, carefully inspect the outside
of the shipping carton for signs of damage. If any damage to the carton
is found, note the location with respect to the autoclave and check that
area of the autoclave carefully once it is fully unpacked. Observe
packing method and retain packing materials until the unit has been
inspected. Mechanical inspection involves checking for signs of physical
damage such as: scratched panel surfaces, broken knobs, etc.
If any damage is found, contact your dealer as soon as possible so
that they can file a claim with the shipping carrier and notify
Tuttnauer.
All Tuttnauer products are carefully inspected prior to shipment and all
reasonable precautions are taken in preparing them for shipment to
assure safe arrival at their destination.
Note: Lifting and carrying should always be done by two people.
1.5 Warranty
We certify that this instrument is guaranteed to be free from defects in
material and workmanship for two years against faulty components and
assembly.
This warranty does not include routine cleaning and preventive
maintenance, to be performed according to instructions in
section 10.1 (Preventive and Scheduled Maintenance).

5
Tuttnauer warranties all new autoclaves for a period of two full years,
covering both parts and labor. This two-year warranty covers defects in
materials and workmanship on every part in the autoclave except door
gaskets and HEPA filters (they are wear items).
Tuttnauer warranties all chambers for a period of ten (10) years against
defects in materials and workmanship. This chamber warranty went
into effect January 1997.
This warranty does not apply to any instrument that has been subjected
to misuse, neglect, accident or improper installation or application, nor
shall it extend to autoclaves that have been repaired or altered outside
the factory without prior authorization from Tuttnauer.
Tuttnauer’s obligation is limited to the repair or replacement of parts
for the autoclave. This warranty will be void if the unit is not purchased
from an authorized Tuttnauer dealer. No other warranties or obligations
are expressed or implied.
The Autoclave should only be used in a manner described in this
manual!
1.6 Warranty Statement
To activate the warranty, the registration card must be completed and
returned to Tuttnauer within fourteen (14) days of purchase, or you
may call our customer service department at the number listed below.
No product will be received or accepted for repair without prior return
authorization from Tuttnauer. All transportation charges to and from
Tuttnauer must be paid by the owner of the autoclave. During the first
90 days after purchase of an autoclave, Tuttnauer will pay shipping
costs on an individually evaluated basis and ONLY with pre-approval.
Note:
If you have any questions or there are any difficulties with this instrument
and the solution is not covered in this manual, please contact your dealer or
Tuttnauer USA Co. Do not attempt to service this instrument yourself.
Tuttnauer USA Co., Ltd., 25 Power Drive Hauppauge, NY 11788, USA
: [phone], [phone], Fax : [phone]
e-mail: [email protected].

6
2. SAFETY INSTRUCTIONS
The autoclave has unique characteristics. Please read and understand the
operation instructions before first operation of the autoclave. This manual
includes instructions and guidance provided by the manufacturer: how to
operate the autoclave, the door safety mechanism, and the dangers involved in
circumventing safety means, how to ensure that the door is closed, and how to
select a correct sterilization program.
Make sure that you know where the main power switch is located.
Warning!
Mind the Power Socket. Keep it and its vicinity dry. Danger of
electrocution.
Autoclave maintenance is crucial for the correct and efficient function of the
device.
Never use the autoclave to sterilize corrosive products, such as: acids, bases
and phenols, volatile compounds, or solutions such as ethanol, methanol,
chloroform or radioactive substances. Below are the operating instructions –
safety instructions:
1. All autoclave users must receive training in proper usage from an
experienced employee. Every new employee must undergo a training
period under an experienced employee.
2. When sterilizing plastic materials, refer to the item manufacture
information and make sure that the item can withstand the sterilization
temperature. Plastic that melts in the chamber is liable to cause a great
deal of damage.
3. On closing the device door, make sure it is properly locked before
activating. Verify that the DOOR OPEN symbol is replaced by
“System Ready”.
4. Do not place your hand or head, etc. above the door while opening, as hot
steam is escaping the chamber.
5. Do not stand near the back panel of the autoclave while operating, as the
pressure safety valve may release steam.
6. Do not touch hot surfaces, such as the top enclosure and area adjacent to
the chamber opening!
7. When withdrawing trays, use the enclosed tray handle or wear heat
resistant gloves.
8. To assure proper operation of the autoclave, avoid placing in the vicinity
of electrical equipment which is not certified for Electromagnetic
Compatibility according to IEC/EN 61326-1.
9. The door is electronically locked and will not open unless the pressure in
the chamber equals the atmospheric pressure (chamber pressure is
displayed on the screen).
10. The door also remains locked if there is a cycle failure or the unit has no
power.
11. Open the door slowly to allow steam to escape.
12. Once a year, or more frequently, effectiveness tests must be performed,
i.e., calibration and validation.
13. Once a month, ensure that the safety valve is operating, and once every 5
years a certified inspector must perform a chamber pressure safety test.

7
14. Make sure there are no leaks, breaks, blockages, whistles, or strange
noises.
15. Perform maintenance operations as instructed. The owner of the
autoclave is responsible to perform the maintenance operations.
16. Notify the person in charge immediately of any deviation from the proper
function of the device.
17. Protective equipment and clothes and other safety instructions should be
implemented in accordance with local and national regulations and/or
rules!

8
3. TECHNICAL DATA
3.1 Introduction
This autoclave is an electrically heated sterilizer using steam as the
sterilizing agent. Acomputerized control unit ensuring a fully
automatic sterilization cycle, control and monitoring of physical
parameters and a clear documentation of the sterilization cycle controls
the autoclave.
The autoclave has three automatic programs, according to the material
to be sterilized, and one auxiliary drying program. The autoclave is
equipped with an air compressor that, during the drying stage draws air
through a HEPA filter (0.2
µ
m). It pushes the air through the heated
chamber to remove moisture and facilitate the drying operation. Drying
is performed with the door closed.
On all models, a water pump is installed between the water reservoir
and the chamber. This pump guarantees fast and accurate filling of the
chamber every time. Entry of water may be accompanied by a noise for
approximately 30 seconds. This is normal noise generated by regular
operation of the pump.
The control system provides adequate protection, to ensure the safety
of personnel and reliable operation with a minimum of shutdown time.
On all models, a printer is an optional addition to the autoclave. The
printer prints the preset and actual parameters of the cycle
(temperature, time, and pressure).
This manual is intended for the user and gives the user a general
understanding of the instrument and the best ways to operate and take
care of it, to obtain optimum effective results.
After reading this manual, operating the autoclave will be easy.
However, since this instrument is built with high technology sensitive
components, no attempt should be made by the user or any other
unauthorized person to repair or recalibrate it.
Only technical personnel, having proper qualifications and holding
technical documentation (including a technician manual) and
adequate information, are authorized to service the apparatus.
3.2 Standby Heating Mode
The autoclave provides an option of heating the chamber in standby
mode between cycles, at a very low power level, to reduce total cycle
time (1.6% of the total power only). The autoclave turns off
automatically if the interval between the sterilization cycles is more
than 2 hours. This feature is standard on model EZ10K and optional on
EZ9 and EZ10 models.
3.3 Environmental Emission Information
1. The peak sound level generated by the autoclave is less than 70 dBA
with background noise of 60 dBA.

9
2. The total heat per hour transmitted by the autoclave is < 100 Wh for
all models.
3.4 Operating Conditions
This device is to be used for indoor use.
This autoclave is intended for NORMAL environment conditions as
follows:
Altitude up to 2000m.
Room temperature range 5ºC to 40ºC.
Installation Category II.
Pollution Degree 2.
Maximum relative humidity 80% for temperature up to 31ºC
decreasing linearly to 50% relative humidity at 40ºC.
Mains supply voltage fluctuations up to +/-10% of the nominal voltage.
The sterilizer should be loaded only with autoclavable material.
Caution!
Waste water should be brought into the public net in accordance with
the local rules or requirements, i.e.
ONLY NON-HAZARDOUS LIQUIDS SHALL BE DISPOSED IN
PUBLIC SEWAGE!
3.5 Utilities
Utilities
Unit
Value
Power supply (as appropriate)
V-A
1ph, 120V –16A,50/60 Hz
V-A
1ph, 230V –16A,50/60 Hz
Attention:
The electrical net must be protected with a current leakage safety relay.
The electrical network must comply with local rules or regulations.
3.6 Construction
The main parts of the autoclave are made of materials as indicated
below:
Chamber is electro-polish and built of stainless steel 316 L.
Door is made of stainless steel CF8.
Trays are made of stainless steel 304.
Water reservoir is made of hard plastic material.
Door handle is made of hard plastic material, which is safe to touch
and thermo-insulated.
Covers are made of aluminum sheet, coated with Epoxy paint.

10
3.7 Symbol Description
Manufacturer
Year of Manufacturing
Medical Device
Model Number
Serial Number
Consult the Operation and Maintenance Manual (User Manual) before
use
Keep away from sunlight and protect from heat.
For Indoor Use Only
Keep dry
Disposal according to electronic scrap ordinance
This side up (during transport and shipment)
Fragile (during transport and shipment)
OR
A warning or precaution as detailed in the Operation and Maintenance
Manual (User Manual)
OR
Caution! Hot surface.
Caution! Hot steam.
Protective earth (Ground)

11
3.8 Electrical Data
EZ9
EZ10
EZ10K
Ampere (A) at 230/240V
6
6
9.6
Ampere (A) at 120V
11.7
11.7
⎯
Watts (W)
1400
1400
2200
Frequency
50 / 60 Hz
Protection against electrical shock
IEC 61010-1
DESCRIPTION
AUTOCLAVE TYPE
EZ9, EZ10
EZ10K
120V
230V
230V
Circuit breaker (A)
15
10
15
Air pump fuse (A)
2.0
1.25
1.25
Water pump fuse (A)
1.25
1.25
1.25

12
3.9 Maximum Solid Load Sizes
(Textile load = 1/3 of solid load)
Models
Loads
lbs
kg
1730
6.0
2.7
2340 (EZ9)
7.0
3.2
2540 (EZ10)
8.8
4.0
3140
11.0
5.0
3850
13.6
6.0
3870
14.0
6.4
3.10 Specifications Overall Dimensions

13
Model
Dimensions
EZ9
EZ10, EZ10K
mm
in
mm
in
Overall Dimensions
A
510
20.0
510
20.0
B
365
14.4
365
14.4
C
540
21.5
545
21.5
Maximum
Dimensions (door
open)
D
910
35.8
910
35.8
E
630
24.8
655
25.8
Distance Between
Supporting Legs
F
299
11.8
299
11.8
F1
422
16.6
422
16.6
G
50
2.0
50
2.0
H
400
15.8
400
15.8
Reservoir Volume
3 lit.
0.8 gal.
3 lit.
0.8 gal.
Minimum Water Volume in
Reservoir
0.8 lit.
0.21 gal.
0.8 lit.
0.21 gal.
Max. Allowable Working
Pressure (MAWP)
2.76 bar (40 psi)
Load No. Counter
Counting from 0 to 250 and nullifies.
3.11 Technical Specifications
Models
EZ9
EZ10, EZ10K
Shipping Volume
9.4 cu.ft.
(0.27m3)
9.4 cu. ft.
(0.27m3)
Shipping Weight
79 lbs.
(36 kg)
106 lbs.
(48 kg)
Printer
Yes
Yes
No. of IMS Cassettes
(Optional)
Half
2
3
Full
2
3
No. of Trays
3
4
Tray Dimensions W X D X H
6.7" x 16.3" x 0.8"
(17 x 41.5 x 2cm)
6.7" x 16.3" x 0.8"
(17 x 41.5 x 2cm)
Volume of Mineral Free
Water Reservoir
0.66 US gal.
(3.0 liters.)
0.66 US gal.
(3.0 liters.)
Volume of Chamber
5 US gal.
(19 liters)
6 US gal.
(23 liters)
Chamber Dimensions DIA x D
9" x 18"
(23 x 47 cm)
10" x 19"
(25.4 x 47.5cm)

14
3.12 Directives and Standards
Every autoclave meets the provisions of the following Directives and is in compliance
with the following Standards:
Medical Device Directive 93/42/EEC as amended by 2007/47/EC
Medical Device Single Audit Program –(MDSAP)
ISO 9001:
Quality Management System
EN ISO 13485:
Quality Management System –Medical Devices
ISO 14001:
Environmental management system
ISO 17025:
General requirements for the competence of testing and calibration
laboratories
EN ISO 14971:
Medical devices –Application of risk management for medical
devices
ASME Code
Section I and Section VIII. Div. I
PED
2014/68/EU
Chinese Regulations
Special Equipment Licensing Office
EN 13060:
Small Steam Sterilizers
ANSI/AAMI/ST55:
Table Top Steam Sterilizer
ISO 17665:
Sterilization of health care products –Moist heat
ANSI/AAMI/ST79:
Comprehensive guide to steam sterilization and sterility assurance
in health care facilities
IEC 61010-1 / UL 61010-1:
Safety requirements for electrical equipment for measurement,
control, and laboratory use –Part 1: General requirements
IEC 61010-2-040:
Safety requirements for electrical equipment for measurement,
control, and laboratory use –Part 2-040: Requirements for
sterilizers and washer-disinfectors used to treat medical materials
EN 613261-1:
EMC Requirements for Electrical Equipment
IEC 62304:
Medical Device Software –Software life cycle processes

15
3.13 Water Quality
The distilled or mineral-free water supply shall be according to the table
below:
Suggested maximum limits of contaminants in water for steam sterilization
per EN13060
Substance
Feed Water
Condensate
Evaporate residue
≤ 10 mg/l
≤ 1.0 mg/l
Silicate (SiO2)
≤ 1 mg/l
≤ 0.1 mg/l
Iron
≤0.2mg/l
≤ 0.1mg/l
Cadmium
≤ 0.005 mg/l
≤ 0.005 mg/l
Lead
≤ 0.05 mg/l
≤ 0.05 mg/l
Rest of heavy metals
except iron, cadmium,
lead
≤ 0.1 mg/l
≤ 0.1 mg/l
Chloride (Cl)
≤ 2 mg/l
≤ 0.1 mg/l
Phosphate
≤ 0.5 mg/l
≤ 0.1 mg/l
Conductivity (at 20°C)
15 µs/cm
≤ 3 µs/cm
pH value
5 to 7.5
5 to 7
Hardness
≤ 0.02 mmol/l
≤ 0.02 mmol/l
Appearance
Colorless, clean, without sediments
Note: The condensate is produced from steam taken from the empty sterilizer chamber.
Compliance with the above data should be tested in accordance
with acknowledged analytical methods, by an authorized
laboratory.
Attention:
The use of water for autoclaves that does not comply with the table
above may have severe impact on the working life of the sterilizer and
can invalidate the manufacturer’s warranty.

16
FRONT VIEW
No.
Description
No.
Description
1
Reservoir water drain valve
9
Air relief valve
2
Ring for drain valve
10
Panel base
3
Door closing device
11
Front panel key board
4
Door switch (under door)
12
Printer
5
Autoclave cover
13
Main switch
6
Water reservoir cover
14
RS232 port cover
7
Water reservoir –assembly
15
Completion to panel
8
Safety valve

17
REAR VIEW

18
4. KEYBOARD (Keys and Display)
FRONT PANEL KEYBOARD
Note: See section 4.2 for a description of the Keyboard buttons

19
4.1 Indicator Light Description
Programs
Indicators
Shows the selected program
START
Shows the system is running a program.
HEAT
The system is currently in the Heating stage.
STE
The system is currently in the Sterilization stage.
EXH
The system is in the Exhaust stage.
DRY
The system is in the Dry stage.
FAIL
Shows the system has failed as a result of either a
malfunction, or the STOP key was pressed. A
message is displayed on the screen; the reason for
failure.
ADD WATER
This indicator lights if there is a lack of water in the
reservoir.
DOOR
CLOSED
This indicator lights showing the door is in the
closed position.
