Tyco RM-2 User manual

Model RM-2
Riser Manifold
Page 1 of 6 SEPTEMBER 2021 TFP964
Worldwide
Contacts
www.tyco-fire.com
IMPORTANT
Refer to Technical Data Sheet
TFP2300 for warnings pertaining to
regulatory and health information.
General
Description
The TYCO Model RM-2 Riser Mani-
fold features the necessary water-
flow alarm, pressure gauge, alarm test
orifice, drain, sight glass and check
valve equipment in a single assembly
for use in National Fire Protection Asso-
ciation (NFPA) standard NFPA 13*com-
pliant commercial sprinkler systems.
The riser manifold is available in a
2 in. to 6 in. range of sizes, and pro-
vides a cost effective and easy transi-
tion arrangement to control valves and
system piping. The riser manifold may
be installed in either a horizontal or ver-
tical orientation, for both single sprin-
kler rises and floor control in high-rises.
A TYCO Model TD-2 Test and Drain
Valve installed on the riser manifold as
shown in Figure 2 provides a simplified
means for testing of waterflow alarm
devices and draining for feed mains.
The pressure relief valve, integrated in
the TYCO Model TD-2 Test and Drain
Valve, has an adjustable range of
100 psi (6,9 bar) to 310 psi (21,4 bar).
Excess system pressure is exhausted
internally through the TD-2 valve’s drain
outlet. For more information about the
Model TD-2 Test and Drain Valve, refer
to Technical Data Sheet TFP965.
* Although the Riser Manifold described in this techni-
cal data sheet is intended for the NFPA 13 sprinkler
systems, it may be used for NFPA 13D or 13R residen-
tial sprinkler systems, where a test orice of 2.8K or
4.2K is acceptable.
NOTICE
The TYCO Model RM-2 Riser Manifold
described herein must be installed and
maintained in compliance with this
document, as well as with the applica-
ble standards of the NATIONAL FIRE
PROTECTION ASSOCIATION (NFPA),
in addition to the standards of any other
authorities having jurisdiction. Failure
to do so may impair the performance
of these devices.
The owner is responsible for main-
taining their fire protection system
and devices in proper operating con-
dition. Contact the installing contrac-
tor or product manufacturer with any
questions.
Technical
Data
Approvals
UL and C-UL Listed
FM Approved Components
Listed by California State Fire Marshall
Note: Any alteration to the assembly
voids UL approval and the product
warranty.
Maximum Working Pressure
300 psi (20,7 bar)
Friction Loss
See Table A
Available Sizes
2 in. (DN50)
2-1/2 in. (DN65)
3 in. (DN80)
4 in. (DN100)
6 in. (DN150)
Test Orifice
2 to 3 in. (DN50 to DN80) Manifolds: 2.8K
4 to 6 in. (DN100 to DN150) Manifolds: 4.2K

TFP964
Page 2 of 6
No Qty Part Description CH Part Number or Specification
2 (DN50) 2-1/2 (DN65) 3 (DN80) 4 (DN100) 6 (DN150)
1 1 Model BFV-300 Buttery Valve, G x G 59300G025WS 59300G025WS 59300G030WS 59300G040WS 59300G060WS
22Figure 716 Reducing Grooved Coupling 7162520ES — — — —
1Figure 577 Rigid Grooved Coupling —57725ACP 57730ACP 57740ACP 57760ACP
3 2 Figure 577 Rigid Grooved Coupling 57720ACP 57725ACP 57730ACP 57740ACP 57760ACP
4 1 Groove x Groove Nipple, Flow Switch 5940020 5940025 5940030 5940040 5940060
5 1 Waterow Alarm Switch,
Potter VSR 24110 24111 24112 24114 24116
6 1 Model CV-1FR Riser Check Valve 595901020RM 595901025 595901030 595901040 595901060
7 1 Groove x Groove x Thread Tee, TD-2 5940021 5940026 5940031 5940041 5940061
8 1 Model TD-2 Test
and Drain Valve
1-1/4” x 2.8K Orice 598321 —
2” x 4.2K Orice — 598322
9 1 Model RM-2 Identication Tag 5941020 5941025 5941030 5941040 5941060
10 1Water Pressure Gauge,
300 psi/2000 kPa 923431005 923431005 923431005 923431005 923431005
11 1 1/4" Gauge Test Valve 460051003 460051003 460051003 460051003 460051003
12 1 Pipe Nipple, Galvanized ✓1/4” x 3” 1/4” x 3-1/2”
13 2Pipe Plug, Galvanized ✓1/4”
14 1Pipe Plug, Galvanized ✓1-1/4” 2”
NOTES
1. CH = Common Hardware
2. Refer to Technical Data Sheet TFP950 for information on Model CV-1FR Riser Check Valve replacement parts
Nominal Valve Size, in. (DN) Nominal Dimensions, in. (mm)
A B C D E F G H
2 (DN50)
1-1/4 NPT
23.5 (597) 2.6 (66) 9.4 (239) 8.4 (213)
4.7 (119)
5.1 (130 )
2-1/2 (DN65) 24.8 (630) 3.5 (89) 10.0 (254) 8.4 (213) 5.7 (145)
3 (DN80) 25.2 (640) 3.7 (94) 10.2 (259) 8.6 (218) 5.9 (150)
4 (DN100) 2 NPT 28.2 (716) 4.6 (117) 11.1 (282) 9.6 (244) 5.0 (127) 6.6 (168)
6 (DN150) 31.3 (795) 5.9 (150) 12.0 (305) 11.4 (290) 7.5 (191)
WATERFLOW
ALARM
SWITCH
SYSTEM
SUPPLY
SHUT-OFF
VALVE
FACTORY
ASSEMBLY SHOWN,
ROTATE COMPONENTS
AT COUPLING JOINTS
AS NECESSARY TO
SUIT INSTALLATION
SYSTEM
WATER
PRESSURE
GAUGE
TEST AND
DRAIN VALVE
RISER
CHECK VALVE
DRAIN
CONNECTION
(REF.)
1" (25 mm)
MINIMUM
CLEARANCE
FLOW
10
11
13
9
5
4
3
6
3
2
1
7
14
8
12
A
13
AGFED
C
H
B
2
*
*2" (DN50) ONLY
FIGURE 1
MODEL RM-2 RISER MANIFOLD
STANDARD ASSEMBLY AND DIMENSIONS

TFP964
Page 3 of 6
Installation
The TYCO Model RM-2 Riser Manifold
must be installed in accordance with
this section.
The Model RM-2 Riser Manifold may be
installed either horizontally or vertically.
Note: Where applicable pipe thread
sealant must be applied sparingly. Use
of a non-hardening pipe thread sealant
is recommended.
Never remove any piping component
nor correct or modify any piping defi-
ciencies without first depressurizing
and draining the system.
Installing the Riser Manifold
Step 1. Install the manifold assembly
with the flow arrow embossed on the
riser check valve oriented downstream
from the water supply, and secure
the end-connections with mechanical
grooved couplings listed for fire protec-
tion service.
Note: For horizontal installation, ensure
the TYCO Model CV-1FR Riser Check
Valve is installed with the valve cover
up. For more information, refer to Tech-
nical Data Sheet TFP950.
Step 2. Connect the drain line and set
the Model TD-2 Test and Drain Valve to
the CLOSED position.
Step 3. Wire the riser manifold in
accordance with the wiring guidance in
Figure 3. All wiring must be performed
in accordance with the authority having
jurisdiction and/or the National Electri-
cal Code.
Step 4. Place the system in service
by filling the system with water. When
filling the system, partially open the
control valve to fill the system slowly.
Filling the system slowly helps to avoid
damaging the waterflow alarm switch.
After the system is fully pressurized,
completely open the control valve.
Step 5. Secure all supply valves open.
Setting the Pressure Relief Valve
Step 1. Review the pressure relief valve
assembly on the test and drain valve as
shown in Figure 3.
Step 2. Rotate the pressure relief cap
and align the set pressure marks to the
the set pressure indicating surface plus
(+) or minus (-) a quarter turn.
Nominal
Valve Size
ANSI in. (DN)
Equivalent
Length of
Schedule 40 Pipe
ft (m)
2 (DN50) 32 (9,7)
2-1/2 (DN65) 31 (9,4)
3 (DN80) 31 (9,4)
4 (DN100) 36 (10,9)
6 (DN150) 55 (16,7)
Dim.
Nominal Dimension
in. (mm)
2 (DN50) 2-1/2 (DN65) 3 (DN80) 4 (DN100) 6 (DN150)
D2.6 (66) 3.5 (89) 3.7 (94) 4.6 (117) 5.9 (150)
J12.2 (310) 12.8 (325) 12.7 (323) 12.0 (305) 13.0 (330)
K7.8 (19 8) 8.4 (213) 8.3 (211) 7. 2 (18 3 ) 8.2 (208)
L3.9 (99) 5.0 (127)
No Qty Part Description CH Part Specification
2 (DN50) 2-1/2 (DN65) 3 (DN80) 4 (DN100) 6 (DN150)
15 1 Pipe Nipple, Galvanized ✓1-1/4” x 5” 2” x 3-1/2”
16 1Elbow, Galvanized ✓1-1/4” x 90° 2” x 90°
NOTES
1. CH = Common Hardware
TEST AND DRAIN VALVE
(SHOWN TO ILLUSTRATE
ALTERNATE INSTALLATION
LOCATION ONLY,
NOT INCLUDED IN KIT)
RISER
MANIFOLD
SYSTEM
DRAIN
CONNECTION
DRAIN
OUTLET
J
15 16
D
K
L
FIGURE 2
MODEL TD-2 TEST AND DRAIN VALVE
ALTERNATE INSTALLATION KIT ARRANGEMENT
TABLE A
FRICTION LOSS EXPRESSED
AS FLOW THROUGH
EQUIVALENT LENGTH OF
SCHEDULE 40 PIPE

TFP964
Page 4 of 6
For supervised circuits, see "Switch Terminal Connections" above. The Waterow Alarm
Switch has two switches, one can be used to operate a central station, proprietary or remote
signaling unit, while the other contact is used to operate a local audible or visual annunciator.
When connecting to a
UL Listed control panel,
use panel resistor rating
for circuit supervision
Two sets of SPDT (Form C)
10.0 Amps at 125/250VAC
2.0 Amps at 30VDC Resistive
10 mAmps min. at 24VDC
An uninsulated section of a
single conductor is not
permitted to be looped around
the terminal and serve as two
separate connections. The
wire must be severed to serve
as two separate connections,
thereby providing supervision
of the connection in the event
that the wire becomes
dislodged from the terminal.
CAUTION:
NOTE:
NOTE:
CONTACT RATINGS:
SWITCH TERMINAL CONNECTIONS
IMPROPER CONNECTION METHOD PROPER CONNECTION METHOD
FIRE PANEL OR
ADDRESSABLE
MODULE
LOCAL
AUDIBLE/VISUAL
ANNUNCIATOR
NEUTRAL
WHITE
BLACK
(LINE/HOT)
CIRCUIT
BREAKER
LOAD OUT TO
AUDIBLE/VISUAL
ANNUNCIATOR
SINGLE
CONDUCTOR
UNINSULATED
LOOPED SECTION
CLAMPING
PLATE
TERMINAL
SEPARATE
CONDUCTORS
CLAMPING
PLATE
TERMINAL
SEVERED
STRIPPED
ENDS
INCOMING
OUTGOING
NO NC COM COM NONC
WIRE NUTWIRE NUT
BLACKWHITE
FIGURE 3
MODEL RM-2 RISER MANIFOLD
WIRING GUIDANCE

TFP964
Page 5 of 6
Nominal
Valve Size
Range
ANSI in.
(DN)
Flexible Drain Hose
End Connections Length
in.
(mm)
Part
Number
NPT
in.
Groove
in.
(DN)
2 to 3
(DN50 to DN80) 1-1/4 1-1/4 (DN32)
24
(610) 5940124
36
(915) 5940136
4 to 6
(DN100 to DN150) 22 (DN50)
24
(610) 5940224
36
(915) 5940236
Notes:
1. Drain pipe and ttings not included
ROTATE TEST
VALVE HOUSING AS
NECESSARY FOR
UNOBSTRUCTED
FULL RANGE
OF HANDLE
OPERABILITY
DRAIN
CONNECTION
SIGHT GLASS
EACH SIDE
TEST
VALVE
(NORMALLY
CLOSED)
PRESSURE
RELIEF
VALVE
DRAIN VALVE
(NORMALLY
CLOSED)
ROTATE
HANDLE 180°
TO TEST
FLOW
PRESSURE
RELIEF
CAP
SET
PRESSURE
MARKS
SET
PRESSURE
INDICATING
SURFACE
TEST VALVE
HOUSING
(FACTORY
ORIENTATION)
CLOSED
POSITION
OPEN
POSITION
DO NOT ROTATE
TEST VALVE
HOUSING WHEN IN
CLOSED POSITION
DRAIN VALVE
HANDWHEEL
*
*
DRAIN PIPE
AND FITTINGS
FLEXIBLE
DRAIN
HOSE
MODEL
RM-2
RISER
MANIFOLD
FIGURE 4
MODEL TD-2 TEST AND DRAIN VALVE
FEATURES AND FUNCTION
FIGURE 5
MODEL RM-2 RISER MANIFOLD
OPTIONAL FLEXIBLE DRAIN HOSE

TFP964
Page 6 of 6
NATIONAL FIRE PROTECTION ASSOCIATION and NFPA are registered trademarks of National Fire Protection Association;
TEFLON is a trademark of The Chemours Company FC, LLC
1400 Pennbrook Parkway, Lansdale, PA 19446 | Telephone [phone]
© 2021 Johnson Controls. All rights reserved. All specifications and other information shown were current as of document revision date and are subject to change without notice.
Care and
Maintenance
The TYCO Model RM-2 Riser Manifold
must be serviced and maintained in
accordance with this section.
Before closing a fire protection system
control valve for inspection or main-
tenance work on the fire protection
system that it controls, obtain per-
mission to shut down the effected fire
protection system from the proper
authorities and notify all personnel who
may be affected by this action.
After placing a fire protection system
in service, notify the proper authorities
and advise those responsible for moni-
toring proprietary and/or central station
alarms.
The owner is responsible for the inspec-
tion, testing, and maintenance of their
fire protection system and devices in
compliance with this document, as well
as with the applicable standards of the
NATIONAL FIRE PROTECTION ASSO-
CIATION such as NFPA 25, in addition
to the standards of any authority having
jurisdiction. Contact the installing con-
tractor or product manufacturer with
any questions.
It is recommended that automatic
sprinkler systems be inspected, tested,
and maintained by a qualified Inspec-
tion Service in accordance with local
requirements and/or national codes.
Note: With the exception of the Model
TD-2 Test and Drain Valve and the
Model CV-1FR Riser Check Valve, do
not attempt to repair any component of
the Model RM-2 Riser Manifold in the
field. The Drain Valve Handwheel of the
Model TD-2 Test and Drain Valve may
be replaced in the field. Refer to Tech-
nical Data Sheet TFP950 for CV-1FR
repair information. Replace other com-
ponents as whole assemblies only. See
Figure 1 for component descriptions
and part numbers.
The alarm/flow test procedure results
in operation of the associated alarms.
Notify the owner and the fire depart-
ment, central station, or other signal
station to which the alarms are con-
nected, and the building occupants.
The following inspection procedure
must be performed as indicated, in
addition to any specific requirements
of the NFPA, and any impairment must
be immediately corrected:
Alarm/Flow Test Procedure
Step 1. Rotate the test valve handle
180 degrees to the OPEN position as
shown in Figure 4.
Note: This action permits water to flow
through the orifice of the test valve sim-
ulating flow from an individual sprinkler
located downstream of the waterflow
alarm switch as shown in Figure 1.
Note: The test valve housing can be
rotated 360 degrees to eliminate equip-
ment interference with the test valve
handle as shown in Figure 4.
Do not rotate the test valve housing in
the closed position.
Step 2. Confirm water flow through the
test port by observing flow at the drain
port sight glass.
Step 3. Verify proper operation of the
waterflow alarm switch at the fire panel,
the addressable module, and the local
audible/visual annunciator if installed
as shown in Figure 3.
Step 4. Rotate the test valve handle 180
degrees back to the CLOSED position.
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
Contact your local distributor for avail-
ability. When placing an order, indi-
cate the full product name, including
description and part number (P/N).
Riser Manifolds
Model RM-2 Riser Manifold
Specify: Model RM-2 Riser Manifold,
Size (specify), P/N (specify)
2 in. (DN50) . . . . . . . . . . . . . . . . . . . . . . 5940601
2-1/2 in. (DN65) . . . . . . . . . . . . . . . . . . . 5940 611
3 in. (DN80) . . . . . . . . . . . . . . . . . . . . . . 5940621
4 in. (DN100). . . . . . . . . . . . . . . . . . . . . . 5940651
6 in. (DN150). . . . . . . . . . . . . . . . . . . . . . 5940661
Accessories
Optional Flexible Drain Hose
See Figure 5 for part descriptions and
part numbers.
Specify: Flexible Drain Hose, P/N
(specify)
Optional Test and Drain Valve
Alternate Installation Kit
Specify: Size Range (specify) Model
RM-2 Riser Manifold, Test and
Drain Valve Alternate Installation Kit,
P/N (specify)
2 to 3 in. (DN50 to DN80). . . . . . . . . . . 59352691
4 to 6 in. (DN100 to DN150) . . . . . . . . . 59352692
Replacement Parts
See Figure 1 for part descriptions and
part numbers.
Specify: Model RM-2 Riser Manifold,
Replacement (specify part description),
P/N (specify)
Note: Refer to TFP965 for Model TD-2
Test and Drain Valve replacement parts.
