Tyco Illustra Pro series User manual

Illustra Pro Series 5MP, 3MP & 2MP
Mini Dome Series
Quick Start Guide
8200-1135-02 A0

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
2
Copyright
Under copyright laws, the contents of this manual may not be copied, photocopied, reproduced, translated or
reduced to any electronic medium or machine-readableform, in whole or in part, without prior written consent
of Tyco Security Products. © 2015 All Rights Reserved.
Sensormatic Electronics LCC
6600 Congress Avenue
Boca Raton, FL 33487 U.S.A.
Notice of Use
This manual is designed for administrators and users of the network camera. Please read it carefully
before use. All requirements should be followed before using this camera.
We are not responsible for any technical or typographical errors and reserve the right to change the
product and manuals without notice.
Keep this document for future reference.
The camera is intended to be supplied from power source either 24V AC or PoE complying with LPS
requirement. Only connect the camera to this required power system.
The camera must be installed on a solid mounting surface.
Keep the camera and other accessories dry.
We are not responsible for any damage caused by inappropriate use.
All the installation should be performed by qualified personnel.
For outdoor application with a power supply: If the power supply is installed outdoors, it shall be a
listed rainproof/rain tight Class 2/LPS power supply or a listed Class2/LPS power supply
complying with UL 60950-1 Part 1 and Part 22.
For wiring method for the power source: The wiring method should comply with Article 725 and 300 in
National Electrical Code for Class 2 circuits and Wiring in Ducts.

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
3
Contents
1. What’s in the box? ...........................................................................................................................4
Indoor Camera.....................................................................................................................................4
Outdoor Camera..................................................................................................................................4
Indoor and Outdoor Camera Installation .............................................................................................4
2. Preparing the Camera for Installation..............................................................................................5
Remove camera from the box.............................................................................................................5
Use the template to prepare the mounting area..................................................................................6
Flush Mount Using Screws..............................................................................................................6
Flush Mount Using Locking Arms (Indoor) ......................................................................................6
Surface Mount..................................................................................................................................6
Surface Mount Using Junction Box..................................................................................................6
3. Connect the cables and make adjustments.....................................................................................7
4. Mount the Camera Enclosure..........................................................................................................9
Flush Mount Using Screws (Indoor)....................................................................................................9
Flush Mount using Locking Arms (Indoor).........................................................................................10
Surface Mount (Indoor)......................................................................................................................10
Surface Mount (Outdoor)...................................................................................................................11
Mount Using a Junction Box (Indoor)................................................................................................12
Mount Using a Junction Box (Outdoor) .............................................................................................12
Mount using the Pendant Cap (Outdoor) ..........................................................................................13
5. Network Connection.......................................................................................................................15
Default Camera Settings ...................................................................................................................15
Installation Using Illustra Connect.....................................................................................................15
Installation using the Static IP Address.............................................................................................16
Logging in to the Camera..................................................................................................................16
Enable correct Video Orientation for a Wall Mounted Camera.........................................................16

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
4
1.What’s in the box?
Indoor Camera
1400-0149-01
Torx Key
1
2412-0463-01
Indoor Recessed Template
1
2412-0463-02
Indoor Base Template
1
5810-4091-120
Self-tapping screw
4
2880-0073-01
Anchor
4
0710-3822-0100
CD
1
8200-1135-02
Quick Start Guide
1
0505-2025-01
Illustra 4” Indoor Screw Cap - Black
3
0505-2025-02
Illustra 4” Indoor Screw Cap - White
3
0505-1979-01
Illustra Plenum Cap
1
0652-0758-06
*Illustra Rear Video Cable
1
Outdoor Camera
1400-0149-01
Torx Key
1
2412-0463-03
Outdoor Base Template
1
5810-4091-120
Self-tapping screw
4
2880-0073-01
Anchor
4
0710-3822-0100
CD
1
8200-1135-02
Quick Start Guide
1
0505-2026-01
Illustra 4” Outdoor Screw Cap - Black
3
0505-2026-02
Illustra 4” Outdoor Screw Cap - White
3
0652-0758-06
Illustra Rear Video Cable
1
*Not supplied with LT camera models.
Indoor and Outdoor Camera Installation
This installation guide includes information for installing both the indoor and outdoor variants of the
Illustra Pro Series Mini Dome camera. Refer to the procedure relevant to your installation.

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
5
2.Preparing the Camera for Installation
Figure 1
Remove camera from the box
Take care when removing the camera from the box.
1. Remove the camera from the box.
2. Using the supplied security torx key, loosen (but do not remove) the three cover screws from
the bubble assembly.
3. Remove the camera liner.
4. Loosen the three screws marked with a triangle on the camera assembly as seen in Figure 2.
Figure 2
5. Remove from the Enclosure Base Assembly.
Enclosure Base Assembly
Camera Assembly
Camera Liner
Bubble Assembly

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
6
Use the template to prepare the mounting area
Select the type of mounting required from the procedures below.
Flush Mount Using Screws
1. Create a circular opening in the mounting surface with a diameter of 120 mm (4.7”) with
tolerances of -0/+5 mm (-0/.0.2”).
2. Create three 6 mm (0.2”) holes at the T3 template positions. Then insert the screw anchors
into the holes.
NOTE:
Not intended for drop ceiling installation without appropriate lanyard.
Not intended for installation in ceilings used for environmental air return.
Flush Mount Using Locking Arms (Indoor)
1. Create a circular opening in the mounting surface with a diameter of 110 mm (4.3”) with
tolerances of - 0/+5 mm (-0”/.0.2”).
Surface Mount
1. According to your needs, create 6mm (0.2”) holes at the T1/T2 template positions. Then insert
the screw anchors into the holes.
2. If you want to feed wiring from the hole on the top of the enclosure base assembly, create a
circular opening (bottom conduit hole) in the mounting surface.
3. Feed the wires through appropriate hole on the enclosure base assembly.
NOTE:
Ensure that the plug is secured in the other hole on the enclosure base assembly.
Surface Mount Using Junction Box
Refer to either Mount Using a Junction Box (Outdoor) or Mount Using a Junction Box (Indoor).

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
7
*Alarm in-2
*Alarm Out
*Audio IN
3.Connect the cables and make adjustments
*Not available on LT camera models
AC Power: Connects to AC 24V power adapter. If you are to use power from Ethernet connection,
this connector is not used when the power is provided by PoE.
PoE Network Port: Connects to the LAN port of a standard 10Base/100Base-TX device, e.g.,
hub, switch or router.
Audio In: Connects to an external microphone. This feature is not available on the LT camera
model.
Audio Out: Connects to speaker. This feature is not available on the LT camera model.
Alarm In 1 & 2: Connects to devices that trigger alarm signals. Up to two 2 input devices can be
connected. This feature is not available on the LT camera model.
Alarm Out: Connects to device that responds to alarm signals, such as buzzers or lights. This
feature is not available on the LT camera model.
GND: Ground
NOTE:
To connect the Audio In/Out, Alarm In/Out or GND wires, press the relevant spring terminal tab inward
using an appropriate small tool and insert the wire into the opening. Then release the tab to secure the
wire.
AC Power
PoE Network
Port
*Alarm in-1
*Audio Out
GND
Figure 3

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
8
DIP Switches:
oPAL/NTSC system switch, default is NTSC.
oFuture Enhancement.
oIR On/Off, default is on.
Use a suitable small tool to operate the switch.
NOTE:
After switching the video system mode from NTSC to PAL or vice versa, you have to reboot the
camera for the change to take effect.
Micro SD Card: Micro SDHC card slot.
NOTE:
micro SD Card is not available on LT camera models.
Defaults:
oReboot Request: Press and hold for between 5 to 14 seconds to restart the camera.
oHardware Factory Default: Press and hold for more than 14 seconds to restart and restore
the camera to factory defaults.
Video Out: Analog video output to the video input of a monitor. The Illustra video cable should
be fed through from the rear of the camera assembly. Ensure that the cable is kept taut.
Analog Video Out
Phone Home
(Future Enhancement)
Reset/Defaults
PAL
IR (On/Off)
Future
Enhancement
micro SD Card slot
(not visible in this image)
Note: micro SD Card is
not available on LT
camera models
NTSC
Figure 4

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
9
4.Mount the Camera Enclosure
Select the type of mounting required and refer to the relevant procedure:
Flush Mount Using Screws (Indoor)
Surface Mount (Indoor)
Surface Mount (Outdoor)
Mount Using a Junction Box (Indoor)
Mount Using a Junction Box (Outdoor)
NOTE:
If the camera is being wall mounted, after hardware installation ensure that the mirror and flip option is
enabled using the camera GUI. Refer to Enable correct Video Orientation for a Wall Mounted
Camera.
Flush Mount Using Screws (Indoor)
1. For a plenum rated ceiling, feed the leads through the plenum cover, then connect the wiring
and assemble the plenum cover. Secure with two M3 screws to the camera assembly.
2. Insert the camera assembly into the ceiling; fasten the two TP4 screws to the inserted
anchors to secure the camera assembly in place.
3. Aim the camera to the area of interest by rotating and panning the camera base. When
rotating the camera base, do not rotate it past the stop point. When desired orientation is
achieved tighten the two pivot screws to secure.
4. Fit the camera liner over the camera assembly so that it snaps into place.
5. Use the supplied security torx key to tighten the three cover screws to secure the bubble
assembly.
6. Finally, insert the screw hole covers to cover three screws in the bubble assembly.

Illustra Pro Series 5MP, 3MP & 2MP Mini Dome Series
10
Flush Mount using Locking Arms (Indoor)
1. Turn the screws clockwise to extend the locking arms as seen in Figure 5.
2. Tighten the screws sufficiently to compress the arms to adjust to the mounting surface.
3. Aim the camera to the area of interest by rotating and panning the camera base. When
rotating the camera base, do not rotate it past the stop point. When desired orientation is
achieved tighten the two pivot screws to secure.
4. Fit the camera liner over the camera assembly so that it snaps into place.
5. Use the supplied security torx key to tighten the three cover screws to secure the bubble
assembly.
6. Finally, insert the screw hole covers to cover three screws in the bubble assembly.
Surface Mount (Indoor)
1. According to your needs, use the top or side conduit hole on the enclosure base assembly
for cable entry and connect the wiring.
NOTE:
Ensure that the plug is secured in the other conduit hole on the enclosure base assembly.
2. Mount the enclosure base assembly on a surface with two screws.
3. Align the camera assembly with the enclosure base assembly using the green dot as a
guide. Insert the camera assembly and then fasten the TP4 screws into the inserted anchors.
4. Aim the camera to the area of interest by rotating and panning the camera base. When
rotating the camera base, do not rotate it past the stop point. When desired orientation is
achieved tighten the two pivot screws to secure.
5. Fit the camera liner over the camera assembly so that it snaps into place.
6. Use the supplied security torx key to tighten the three cover screws to secure the bubble
assembly.
Figure 5
