U-Reach NVS200 User manual

NVS200
PCIE SSD Duplicator
User Manual
v A.01

1
Index Table
Product Disclaimer.................................................................................................................... 2
Warranty................................................................................................................................... 2
Piracy Statement ...................................................................................................................... 2
Before You Start........................................................................................................................ 3
Notice Symbols ......................................................................................................................... 3
Product Overview..................................................................................................................... 4
Functions Table......................................................................................................................... 6
Functions Description............................................................................................................... 9
1. Copy ............................................................................................................................... 9
2. Compare....................................................................................................................... 10
3. Copy+Compare.............................................................................................................10
4. Erase............................................................................................................................. 10
5. Utility............................................................................................................................ 11
6. Setup............................................................................................................................ 14
Maintenance Guide ................................................................................................................21
v A.01.2

2
Product Disclaimer
U-Reach is not accountable for any incidental or consequential damages, which includes,
but is not constrained to property harm, loss of time or data from use of a U-Reach product,
or any other damages attributable to product malfunction or failure (including without
limitation, those attributable to: (1) reliance of the materials provided, (2) costs of product
replacement, (3) loss of use, data or profits, (4) delays or business interruptions, (5) and any
principle of legal responsibility, arising out of or in reference to the use or overall
performance or from delays in servicing or lack of ability to render service) of any U-Reach
product. U-Reach makes every effort to ensure proper operation of all products. However,
the customer is responsible to affirm that out of the U-Reach product meets the customer’s
quality requirement. The customer further acknowledges that fallacious operation of U-
Reach product and/or software program, or hardware issues, can cause loss of data,
defective formatting, or data loading. U-Reach will make efforts to resolve or repair any
issues recognized by customer either within the warranty period or on a time and materials
basis.
Specifications and features subject to change without notice or obligation.
Warranty
U-Reach provides a basic one-year parts and labor warranty for all its products (excluding
cables, adapters, and other consumable items). An optional extended warranty is also
available for an added cost. Telephone and email support is available for the life of the
product as defined by U-Reach.
All warranties will be restricted and defined by the market region from which customers
purchased.
Piracy Statement
U-Reach accepts no responsibility for copyright infringement or misuse of any U-Reach
equipment. Copying all forms of data: audio, video, or software without the permission of
the copyright holder is illegal. It is the sole responsibility of the user to ensure that the legal
copyrights of the copyright owners are respected.

3
Before You Start
Important Notice
Carefully read the entire manual before operating.
Make sure the source device is correct and functioning.
Equal capacity of source and target is recommended for guaranteed data consistency.
Using the Copy+Compare function provides the most flawless duplication.
Damage incurred due to non-compliance with U-Reach operating instructions will void
the warranty.
Store the equipment safely when not in use and keep out of the reach of children.
Please turn off duplicator before replacing a socket.
Never turn off the power while the firmware is updating.
Use only approved, stable power sources.
The power supply has overload protection. When it is overloaded and shutdown,
please unplug the power cord for 2 minutes for discharge.
Use product only in a clean, dry, dust-free, and ventilated area. Liquids or foreign
debris can severely damage your duplicator.
It is typical for the machine to heat up during operation.
While in use, do not move the duplicator or remove SSDs.
Static electricity may cause duplication error. Please pay attention to the duplicator’s
environment while operating equipment. Purchasing electricity elimination equipment
helps avoid shock.
Devices will operate at high temperatures during selected tasks.
Wear protective gloves to prevent burns when handling devices.
Ensure machine and operator are properly grounded to prevent ESD.
Do not turn off the machine during firmware update.
Notice Symbols
Special items, procedures, or notes to be observed prior to use.
Note
Refers to related duplicator operations, special details, tips, or
suggestions for operational effectiveness.
Caution
Refers to procedures that need to be adhered to or precautions.

4
Product Overview
Front View
Back View
Source Port
Control Buttons
LCD Display
Power Supply
12V 5A Adapter
Power Switch
SD Slot
For Firmware Update

5
Package
Optional
Duplicator
1 pcs
Power Adapter
1 pcs
Power Cord
1 pcs
SATA Cable
22pin (6cm)
1 pcs
User Manual
1 pcs
M.2 Socket
Module
Gloves
1 pair
Pad
2 pcs
mSATA Adapter
2 pcs
IDE to SATA
Adapter 2 pcs

6
Functions Table
Functions
Descriptions
1. Copy
Copies data from source device to targets. (There are four copy
modes in function "6.1 Copy Area")
2. Compare
Compares the source and targets to ensure copy accuracy.
3. Copy + Compare
Automatically launches compare function after copy is completed.
4. Erase
4.1 Quick Erase
Erases device(s)’ index table.
4.2 Full Erase
Erases entire device(s), complying with NIST 800-88 Standards.
4.3 DoD Pass
Erases device(s), complying with DoD 5220.22-M Standards.
4.4 DoD3 Pass+Compare
Erases device(s), complying with DoD 5220.22-M Standards and
verifies complete erasure.
4.5 7-Pass Erase
Erases device(s) 7 times complying with DoD 5220.22-M(ECE)
Standards.
4.6 Secure Erase
Erases the non-loadable areas complying with NIST 800-88 Standards.
4.7 Enhanced Secure Erase
Erases devices that support this feature.
5. Utility
5.1 Device Info
Displays basic information such as device model, name, capacity, etc.
5.2 System
Update
5.2.1 Update BIOS
Updates system firmware through the rear SD port
or the source port.
5.2.2 Create BIOS Format
Prepares by formatting the device to a 2GB FAT
partition to accept firmware file.
5.3 System Info
Displays system information such as controller, model number,
software version, etc.
5.4 Read Speed
Calculate the device’s read speed by reading.
5.5 Write Speed
Calculate the device’s write speed by reading. This function will
change the device’s content and format.

7
5.6 Calc. CRC64
Calculate the CRC64 value of the source device.
6. Setup
6.1 Copy Mode
6.1.1 System and Files
Copies data and skips empty space. Only supports
standard formats.
6.1.2 All Partitions
Copies all partitions and data, unallocated partitions
not included.
6.1.3 Whole Device
Copies all source data, bit-by-bit.
6.1.4 Percentage (%)
Sets percentage of source capacity to copy.
6.2 Copy GPT Backup Area
Disable this function to copy the GPT backup area.
6.3 HPA Copy
Mode
Do Not
Copy HPA
Keep Target HPA
Does not copy HPA data but keeps
target device’s original HPA setting.
Clear Target HPA
Does not copy HPA data and clears
target device’s HPA setting.
Setting Target HPA
Copies HPA setting from source device to target.
Copy and Setting
Copies HPA setting and data from source device to
target.
6.4 Skip Bad Sectors
Skips source bad sectors.
6.5 Erase Source Port
Allows user to erase the source port or not.
6.6 Unknown Format
Allows user to copy or skip unknown format(s).
6.7 Erase Pattern
Sets whether to overwrite data in one-byte or Big random data.
6.8 Clear HPA
at ERASE
Clear HPA Setting
Clears HPA setting during erase.
Keep HPA Setting
Keeps original HPA setting during erase.
6.9 Language
Sets preferred language: English or Japanese.

8
6.10 Target Tolerance
Sets the capacity tolerance range between the source and target. The
default setting is “No limit”.
6.11 Clean SSD Before Copy
No
The default setting is “No”.
Yes
6.12 Restore Defaults
Reinstates manufacturer settings.

9
Functions Description
1. Copy
Step 1: Prepare source and target devices.
Step 2: Connect source and target devices.
Step 3: Proceed to copy.
Scroll to select "1. Copy", then press "OK" to start the duplication process.
The following information below states what is displayed on the LCD during duplication.
Step 4: Copy Completed!
The quantity of passed or failed target device(s), the copied duration, and CRC64 will be
displayed on the LCD after duplication completes.
Note
1. Recommendation: Target device(s)’ capacity must be equal to or larger
than the source device capacity.
2. The system accepts only one source and one target for each operation. If
both M.2 and SATA port have device, it will detect SATA port first.
Note
The number of working/connected targets will be displayed on LCD. Press
"OK" to start.
Caution
Press “ESC” for 5 seconds to stop the copy job.
It is recommended to reboot the machine after manually stopping the
copy.
Copy 40.0G
3ready
Copy x3 40G
1:38 25% (4) 10.3G
Function
Total Data
Copied
Time & %
Slowest
Port
Copied
Data
Pass:3 Fail:0 8:00
CRC:7073923CEBDF7B58

10
2. Compare
Scroll to select "2. Compare", then press "OK" to start the verification process.
3. Copy+Compare
Sequentially automates from Function 1, Copy to Function 2, Compare.
Scroll to select "3. Copy+Compare", then press "OK" to start the automated duplication and
verification process.
4. Erase
There are 2 submenu modes.
Step 1: Connect device(s) for sanitizing.
Step 2: Enter function "4. Erase"
Scroll to select "4. Erase”, then press "OK" to view the 7 submenus.
Caution
User is responsible for verification of targets’ quality. Testing a few completed
targets in a mass production environment for quality control is recommended.
4.1 Quick Erase
This function will erase the index table from the connected device(s).
Scroll to select "4.1. Quick Erase”, then press "OK" to start the erasing process.
4.2 Full Erase
This function will erase all data per NIST 800-88 Standards on the connected device(s).
Scroll to select "4.2 Full Erase”, then press "OK" to start the erasing process.
Note
The number of working/connected targets will be displayed on the LCD. Press
"OK" to start.
Caution
Please back up all important data before using this function.

11
4.3 DoD Pass
This function will erase all data per DoD 5220.22-M Standards on the connected device(s).
Scroll to select "4.3 DoD Pass", then press "OK" to start the erasing process.
4.4 DoD3 Pass+Compare
This function will erase all data per DoD 5220.22-M Standards, then verifies erasure of the
connected device(s).
Scroll to select "4.4 DoD3 Pass+Compare", then press "OK" to start the erasing and
verification process.
4.5 7-Pass Erase
This function will erase device(s) 7 times complying with DoD 5220.22-M(ECE) Standards.
Scroll to select "4.5 7-Pass Erase", then press "OK" to start the erasing process.
4.6 Secure Erase
This function erases the non-loadable areas complying with NIST 800-88 Standards.
Scroll to select "4.6 Secure Erase ", then press "OK" to start the erasing process.
4.7 Enhanced Secure Erase
This function erases devices that supports this feature.
Scroll to select "4.7 Enhanced Secure Erase", then press "OK" to start the erasing process.
5. Utility
This menu will reveal submenus related to device information, system information and
updates.
Scroll to "5. Utility”, then press "OK" to view the submenus.
5.1 Device Info
This function will display basic information such as device model, name, capacity, etc.
Note
Although Secure Erase/ Enhanced Secure Erase is a command of the SATA-
specification, not all SATA devices can support it. When a device that cannot
be supported is encountered, the LCD will display Not Support!

12
Scroll to select "5.1 Device Info”, then press "OK" to view the connected device(s). Then
through to view connected device(s) by port number order.
5.2 System Update
There are 2 system update methods.
❶Through SD Slot
Step 1: Prepare a SD card for update.
Connect a SD card to a PC. Download the latest firmware provided from the supplier’s
technical support, unzip the BIOS firmware, and save it to the root directory in the device.
Step 2: Proceed to update firmware
Connect the SD card to the back of the duplicator. Scroll to select "Update BIOS", then press
"OK" to start the firmware update process.
❷Through Source Port
Step 1: Prepare a device for update.
Connect a device to the source port. Scroll to select "Create BIOS Format”, then press "OK"
to start the format process. This will format the device to a 2GB FAT32 Partition.
Step2: Download Firmware.
Connect this device to PC. Download the latest firmware provided by U-Reach technical
support, unzip the BIOS firmware, then save it to the root directory in the device.
Note
The device’s format must be: FAT16 or FAT32.
Note
Ensure that the SD card does not have any bad sectors.
Caution
The firmware update process may take longer than 5 minutes. Please do not
disrupt power or process during BIOS update. If interrupted, the system will
become useless. U-Reach will not be held responsible for any damages.
[System Update]
1.Update BIOS

13
Step3: Proceed to update firmware.
Connect this device to the source port. Scroll to select "Update BIOS”, then press "OK" to
start the firmware update process.
Caution
The firmware update process may take longer than 5 minutes. Please do not
disrupt power or process during BIOS update. If interrupted, the system will
become useless. U-Reach will not be held responsible for any damages.
5.3 System Info
This function will display basic information such as device model, name, capacity, etc…
Scroll to select "5.3 System Info”, then press "OK" to view the connected device(s). Then
scroll through to view all information.
5.4 Read Speed
This function will calculate the read speed of the selected device. The device’s original data
will not be modified after checking. Scroll to select "5.4 Read Speed”, then press "OK" to
select the device, and then press “OK” to proceed.
5.5 Write Speed
This function will calculate the write speed of the selected device. The device’s original data
will be modified after checking. Scroll to select "5.5 Write Speed”, then press "OK" to select
the device, and then press “OK” to proceed.
5.6 Calc. CRC64
This function will count the CRC64 value for the source port. The CRC64 value is an easy way
to double check the source data is correct. Scroll to select "5.6 Calc. CRC64”, and then press
“OK” to proceed.
Note
Ensure that the device does not have any bad sectors.
Caution
User is responsible for verification of targets’ quality. Testing a few completed
targets in a mass production environment for quality control is recommended.

14
6. Setup
This menu will reveal submenus related to copy area, skip bad sector, and setting language.
Scroll to select "6. Utility”, then press "OK" to view the submenus.
6.1 Copy Mode
There are 4 submenu modes.
Scroll to select "6.1 Copy Mode”, then press "OK.” Then scroll through to select one of the
four copy methods.
Selecting the Proper Copy Modes
Example: There are two defined partitions in a 500GB device. The charts below illustrate
what portion would be duplicated.
6.1.1 System and Files
Copies data and skips empty space. Only supports standard formats.
Scroll to select "6.1.1 System and Files”, then press "OK" to save the copy method.
Allows user to copy source device’s System and Files, instead of the entire device. The
system will analyze the source device and identify the data area to copy. If the source
device’s data is within the target device’s capacity, the copy will be processed. FAT16/32/64,
NTFS, EXT2/EXT3/EXT4/lvm, and HFS/HFS+/HFSX are supported in this copy mode.
100GB
250GB
500GB
60GB Data
150GB
Unallocated
30GB Data
System and Files
100GB
250GB
500GB
60GB Data
150GB
Unallocated
All Partitions
70GB
190GB
30GB Data
100GB
250GB
500GB
60GB Data
150GB
Unallocated
Whole Device
70GB
190GB
30GB Data
This function will analyze and
copy only data and skip empty
spaces.
This function will copy the
entire device.
This function will copy all data
within the defined partitions.

15
6.1.2 All Partitions
Copy or skip HPA, DCO, unknown partitions, modified formats, etc. defined by settings.
Scroll to select "6.1.2 All Partitions”, then press "OK" to save the copy method.
The target device’s capacity must be equal to or larger than the source device’s capacity.
6.1.3 Whole Device
Copies all source data, bit-by-bit.
Scroll to select "6.1.3 Whole Device”, then press "OK" to save the copy method.

16
Copies the whole source device, irrespective of content, format, partition, or empty space.
This mode does not analyze the data.
6.1.4 Percentage (%)
Select percentage of source capacity to copy.
Scroll to select "6.1.4 Percentage”, set the upper and lower %, then press "OK" to save the
copy method.
6.2 Copy GPT Backup Area
Disabling this function makes the duplicator ignore the GPT backup area, and thus allows
the duplicator to copy from a big capacity device to a small capacity device(s).

17
Note
The partition size of the source HDD should be smaller than target capacity.
Otherwise, it is recommended to leave the GPT backup area intact.
Caution
GPT backup areas will be rebuilt automatically the next time Windows
reboots. For Linux, tools such as gdisk can rebuild these backups.
6.3 HPA Copy Mode
This menu contains submenus related to HPA Copy Modes
Scroll to select "6.3 HPA Copy Mode”, then press "OK" to view the submenus.
6.3.1 Do Not Copy HPA
This menu contains submenu settings from which users can select.
Scroll to select "6.3 Copy HPA Area >> Do Not Copy HPA”, then press "OK" view submenu
settings.
Keep Target HPA
Does not copy HPA data but keeps target device ‘s original HPA setting.
Scroll to select "Keep Target HPA”, then press "OK" to save this setting.
Clear Target HPA
Does not copy HPA data and clears target device’s HPA setting.
Scroll to select "Clear Target HPA”, then press "OK" to save this setting.
6.3.2 Setting Target HPA
Copies HPA setting from source device to target.
Scroll to select "6.3 HPA Copy Modes >> Copy HPA Settings”, then press "OK" to save this
setting.
GPT Index
Partition
GPT Backup Area
Disabling function “6.2 Copy GPT Backup Area” will
force the duplicator to ignore this area.

18
6.3.3 Copy and Setting
Copies HPA setting and data from source device to target.
Scroll to select "6.3 HPA Copy Modes >> Copy All HPA”, then press "OK" to save this setting.
6.4 Skip Bad Sectors
Scroll to select "6.4 Skip Bad Sectors”, then press "OK" to scroll through the available values
for skipping bad sectors. If the device data is critical and needs to be a full clone, it is
recommended to set “Skip Bad Sectors” at "0.” Bad sectors can be set as unlimited or at a
value from 0 to 65,535.
6.5 Erase Source Port
This function allows user to enable or disable the source port for sanitization.
Scroll to select "6.5 Erase Source Port”, then press "OK.” Then scroll through to select one of
two settings.
❶ Disabled
Source port will be unable to erase.
Scroll to select "6.5 Erase Source Port >> Disabled”, then press "OK" to save this setting.
❷ Enabled
Source port will be able to erase.
Scroll to select "6.5 Erase Source Port >> Enabled”, then press "OK" to save this setting.
6.6 Unknown Format
This function only works with “6.1 Copy Mode >> System and Files.”
Scroll to select "6.6 Unknown”, then press "OK”. Then scroll through to select one of two
settings.
Unknown format includes all forms of modified and proprietary data and partitions.
❶ Copy Unknown
Caution
HPA function “Copy and Setting” may change the original parameter of target
devices. To reset it, user must set “6.8 Clear HPA at Erase >> Clear HPA Setting”
and then execute “4. Erase.”
Caution
The “Copy+Compare” function is advised for enhanced copy accuracy.

19
Copy unknown format(s).
Scroll to select "6.6 Unknown Format >> Copy Unknown”, then press "OK" to save this
setting.
❷ Skip Unknown
Skip unknown format(s).
Scroll to select "6.6 Unknown Format >> Skip Unknown”, then press "OK" to save this
setting.
6.7 Erase Pattern
Scroll to select "6.7 Erase Pattern”, then press "OK”. Then scroll through to select one of two
settings.
❶ One Byte
Random character written per byte.
Scroll to select "6.7 Erase Pattern >> One Byte”, then press "OK” to save this setting.
❷ Big Random Data
Random character written in a set of area.
Scroll to select "6.7 Erase Pattern >> Big Random Data”, then press "OK" to save this setting.
6.8 Clear HPA at Erase
Sets to clear HPA setting during erase.
Scroll to select "6.8 Clear HPA at Erase”, then press "OK" to save this setting.
❶ Clear HPA Setting
Clears HPA setting and data during erase.
Scroll to select "6.8 Clear HPA at Erase >> Clear HPA Setting”, then press "OK" to save this
setting.
❷ Keep HPA Setting
Keeps original HPA setting and data during erase.
Scroll to select "6.8 Clear HPA at Erase >> Keep HPA Setting”, then press "OK" to save this
setting.
6.9 Language
Select English or Japanese.
Scroll to select "6.9 Language”, then press "OK.” Then scroll through select the desired
language.
