Ublox EVK-M10QSAM User manual

1. Overview 2. Setup
1. Download and install the EVK-M10QSAM / EVK-M8QSAM
/ EVKM8xCAM software (and documentation) from
www.u-blox.com/evk-search.
See installation notes on the back of this card.
2. Connect the unit to a PC. Options:
• USB: Connect via USB port (A). Set switch (B) to
USB. The USB driver installs automatically when
the device is connected to a PC; this requires an
internet connection.
• UART: Connect via RS232 (C). Set switch (B) to
RS232.
NOTE: Press RST (D) after setting switch (B).
3. Provide power to the device at all times, either via USB on
the back or the V5 IN pin on the front (F).
4. EVK-M10QSAM / EVK-M8QSAM: Place the EVK with
an unobstructed view of the sky, no external antenna
connectivity at (E).
5. EVK-M8QCAM / EVK-M8CCAM: Place the EVK with an
unobstructed view of the sky or connect antenna signal
to (E).
6. Start the u-center GNSS evaluation software and select
the corresponding COM port and baud rate.
Quick Start EVK-M10QSAM / M8QSAM / M8xCAM
Copyright © 2022, u-blox AG
A (USB) C (RS232)
UBX-16024579 - R04
D (RST) B (USB/RS232 switch)
E (RF IN)
EVK-M8xCAM only
F (14-pin connector)
G (Boot)

3. Kit includes
• EVK-M10QSAM, EVK-M8QSAM, EVK-M8QCAM, or
EVK-M8CCAM unit
• USB cable
• Active GPS / Galileo / GLONASS / BeiDou antenna with a
3 m cable (only for EVK-M8xCAM)
5. Interfaces
All the kits provide a USB connector for communication
and powering the device, as well as a UART connector for
connecting to the COM port of your PC.
The DDC interface (I2C compliant) is also available for all
the kits.
Additionally, the EVK-M8xCAM kits support optional SPI
bus connectivity (requires a jumper resistor) to enable com-
munications with a host CPU.
7. More information
NOTE: Refer to recommendations in the EVK user guide
when using the evaluation kit with a GNSS simulator.
For more information about the evaluation kit, contact your
nearest u-blox support:
www.u-blox.com/contact-technical-support
UBX-16024579 - R04
4. Installation
Notes for downloading the EVK software package and
running the installation:
• An Internet connection is required
• Supported Windows operating systems: Windows 7
onwards (x86 and x64 versions)
• For EVK-M8QSAM, EVK-M8QCAM, or EVK-M8CCAM
download the u-center evaluation software
• For EVK-M10QSAM download the u-center 2 evaluation
software
• Run the u-center or u-center 2 installer executable le
and follow the installer instructions
• When the installation is complete, you will nd a u-center
or u-center 2 menu under the Windows Start button:
All Programs > u-center
All Programs > u-center 2
6. u-center
The u-center GNSS evaluation software provides a powerful
tool for evaluation, performance analysis and conguration
of u-blox positioning products.
