UDI R/C VOYAGER U845Wifi User manual

U29Plus
User Manual

Catalog
Installing & Removing Component 8
Instruction for Drone and Controller 3
Pre-Flight Checklist 11
Flying Procedure 11
To know your APP 16
Function 14
Using the Flyingsee APP 17
Spare Parts 23
Troubleshooting 26
www.udirc.com
2

Drone
A Propeller
Left Right
Front
Rear
B Propeller
Propeller
Guard
B Propeller
A Propeller
Camera
Switch
Lampshade
Battery
Battery Buckle
Lampshade
Lampshade
Drone Bottom
Housing
Optical Flow Sensor
Lampshade
Drone Cover
Housing
Specifications
Drone Size (Unfolded)
Drone Size （Folded）
Drone Weight
Propeller Diameter
347x366x65mm
204x155x65mm
248g
147mm
Max Streaming Video Range/Radius 20m
100m
150mins
Camera Resolution 1280x720P
Max Flying Time 14mins Frequency
Drone Battery 7.4V 1000mAh Main Motor 1023x4
2.4Ghz
Max Charging Time for Drone Battery
Max Flying Distance/Radius
Instruction for Drone and Controller
www.udirc.com
3

Exploded View
1 2 3 4 5 6 7 8 9
10
11
2 3 5
12
7 8
14 20
18
19
16
15 17
21 22
22 21 24
22 21
23
25
4
29
31
30 27
26 35
36 38
37
1 9 8
20
7
40
5 2
39
9 8
32
7 5 3 2
10
32 33 19
3
33
30
34
9
13
28
28
www.udirc.com
4

21
No. Name No. Name
1
22
2
23
3
24
4
25
5
26
6
27
7
28
8
29
9
30
10
31
11
32
12
33
13
34
14
35
15
36
16
37
17
38
18
39
19
40
Bracket Buckle
Bracket Buckle Spring
Drone Body
Optical Flow Board
Camera Board
Camera Component
Camera Cover
Camera Cushion
Front Bracket Moving Buckle
Camera Lens
Counter-clockwise Motor (Black/White Wire)
Left Rear Bracket Upper Cover
Left Bracket Lower Cover
Left Rear LED Board（Red）
Drone Bottom Housing
Battery Buckle Component
Battery Bracket Spring
Battery Bracket
Left Front Bracket Upper Cover
Left Front LED Board (Green)
20
A Propeller (Clockwise)
Propeller Guard
Transmission Gear
Right Rear Bracket Lower Cover
Motor Holder
Right Rear LED Board (Red)
Transmission Shaft
Lampshade
Cushion
B Propeller (Counter-clockwise)
Right Front Bracket Upper Cover
Right Front LED Board (Green)
Battery
Right Rear Bracket Upper Cover
Drone Cover Housing
Receiver Board
Power Switch
Power Switch Board
Rear Bracket Moving Buckle
Clockwise Motor (Red/Blue Wire)
www.udirc.com
5

Controller Phone Holder
Power Switch
Left Stick
One Button Take Off /
Landing/ Emergency Stop
Button
Heading Hold Mode
Right Stick
No Function No Function
Picture 3 Picture 4
2. Pull out the arm bracket as per the below arrow shown (Picture 3) , it will
make a click sound, then it means fully unfolded (Picture 4). On the contrary,
then it’s folded.
Note: Improperly operation may cause damage to the bracket part.
Picture 1 Picture 2
Unfolding Instruction
1. Pull out the arm bracket as per the below arrow shown (Picture 1) , it will
make a click sound, then it means fully unfolded(Picture 2). On the contrary,
then it’s folded.
www.udirc.com
6

Controller Button Functions
High / Medium/Low Speed button:
Left Stick:
Right Stick:
Trimmer Mode Button:
Power Switch:
Press to switch to High /Medium/ Low Speed.
Move the Stick to forward / backward / left / right to fly the drone up / down / turn left / turn right.
Move the Stick to forward / backward / left / right to fly the drone forward / backward / left / right.
Press this button and move the right stick to the required trimmer direction, then it
will adjust the direction accordingly. Release the stick to end trimmer mode.
Push up the power switch to turn on the controller, and pull down to turn off.
Heading Hold Mode: Press to enter Heading Hold Mode. Press again to exit Heading Hold Mode.
Take Off / Landing / Emergency Stop Button: Press once and the drone will take off automatically.
Press again and the drone will land automatically. Press and hold the button for more than 1 second for
an emergency landing. The drone propellers will stop and it will land immediately.
Trimmer Mode Button
Battery Cover
High/Medium/Low
Speed Mode
Battery Installation
Open the battery cover on the back side of the controller, insert 4 AA batteries,
following the polarity indicators. ( Picture 5/6, battery is not included)
Picture 6Picture 5
1.Make sure the electrodes are correct. 2.Do not mix new with old batteries.
3.Do not mix different kinds of batteries. 4.Do not charge the non rechargeable battery.
Notice:
Battery Cover
4 x 1.5V
Alkaline Battery
www.udirc.com
7

Drone Battery Li-Po Battery Disposal & Recycling
Wasted Lithium-Polymer batteries must not be placed with household
trash. Please contact local environmental or waste agency or the
supplier of your model or your nearest Li-Po battery recycling center.
Charging Instruction for Drone Battery
Installing & Removing Component
* For faster charging, it is recommended to use an adapter with 5V 2A output current (not included)
to charge the battery
Power BankPhone Charger Computer Charging Car Charger
Drone Battery
1. Connect the drone battery with USB cable first and then choose one of the
method as below picture shown to connect with USB plug.
2. The red USB indicator light keeps bright when charging and the light turns green
when fully charged.
Phone Installation Instruction
1. Pull out the holder until the phone can be hold( Picture 7), then unfold the
lower clamp( Picture 8).
2. Put the phone into the holder, then release the clamp, and the phone will be
fixed on the holder( Picture 9/10).
Picture 7 Picture 8 Picture 9 Picture 10
Notice: Make sure that the button on phone is not clamped.
www.udirc.com
8

Propeller Installation Diagram
Note: Be sure that the A propeller is
on the right arm marked with A letter,
and the B propeller is on the right
arm marked with B letter.
Picture 11
Picture 12 Picture 13
WARNING: The motor’s rotating direction should be the same, or it will not work.
Note: The motor is consumable. If it is damaged, visit the local seller to buy
new motor for replacement.
Motors Replacement
Picture 15Picture 14 Picture 16
1. To remove the propeller, remove the screw from propeller first (Picture 11),
and then pull the propeller out.( Picture 12)
2. To install the propeller , make sure the propeller rotated direction is correct
first, and then mount propeller on transmission shaft of the motor and press
down ( Picture 12), and then fix the screw. ( Picture 11)
1. To remove the motor, remove the screw from the lampshade first(Picture 14)，
then take the lampshade out ( Picture 15) , unplug the motor connector from
LED board and then take the motor out.
2. To install the motor, plug the required motor connector into the LED board
socket,and put the motor into motor holder (Picture 16) . Put on the motor
cover ( Picture 15) and fix it with screw ( Picture 14).
www.udirc.com
9

Picture 21
Prop Guard Assembly Instruction
Installing & Removing Battery
Picture 19 Picture 20
Picture 17 Picture 18
To remove the battery, slide the switch back (Picture 19), and then take the
battery out from compartment.
To install the battery, insert the battery contact chip to drone battery slot first,
and then press the another end down until it makes sound of “ Click”.( Picture 21)
To remove the propeller guard, take out the propeller buckles on both side and
remove the propeller. ( Picture 17)
To install the propeller guard, attach one buckle to the arm and then push another
buckle in until they locks.( Picture 18)
www.udirc.com
