  9. Unex Spannfeder-Set Flat User manual

Unex Spannfeder-Set Flat User manual

BETRIEBSANLEITUNG FÜR
Deckeneinbauleuchte
Spannfeder-Set Flat
OPERATING MANUAL FOR
Recessed ceiling luminaire
Spannfeder-Set Flat
MODE D’EMPLOI POUR
Plafonnier encastré
Spannfeder-Set Flat
ISTRUZIONI DI FUNZIONAMENTO PER
Apparecchio da incasso a soffitto
Spannfeder-Set Flat
160-013-95
Technische Änderungen vorbehalten / Les détails techniques sont sujet à des changements.
Modifiche tecniche riservate / Technical Details are subject to change.
25.07.2022 © unex lighting AG / Flüelastrasse 12 / 8048 Zürich
DEUDie Montage und Inbetriebnahme darf nur von autorisiertem Fachpersonaldurchgeführt werden (Elektroinstallateur).
Die Leuchte dient ausschliesslich der Beleuchtung und ist entsprechend den Errichtungsbestimmungen zu installieren. Eine
andere Nutzung oder ein anderer Einbau gilt als nicht „bestimmungsgemäss“.
Achtung! Während der Verdrahtung und Installation der Leuchten und Versorgungsgeräte immer spannungslos arbeiten.
Nichtbeachten kann zur Zerstörung der LED-Module führen. Bei Defekt zurück an Hersteller. Montageanleitung muss
aufbewahrt werden. Technische Änderungen vorbehalten.
FRA Le montage et la mise en service ne peuvent être effectués que par du personnel spécialisé autorisé (installateur
électrique). Le luminaire sert uniquement à éclairer et doit être installé conformément aux dispositions d‘édification. Une
autre utilisation ou intégration est considérée comme «non conforme aux dispositions».
Attention! Toujours travailler hors tension lors du câblage et de l’installation des luminaires et unités d'alimentation. Le non-
respect de cette consigne peut entraîner la destruction des modules à LED. Retourner au fabricant en cas de défaut.
L‘instruction de montage doit être conservée. Sous réserve de modifications.
ITA Montaggio e messa in funzione possono essere effettuati solo da personale specializzato autorizzato
(elettroinstallatori). Il proiettore serve esclusivamente a scopo di illuminazione e deve essere installato secondo le
disposizioni di montaggio. Un altro utilizzo o un’altra modalità di incasso sonoconsiderati “non conformi”.
Attenzione! Lavorare sempre in assenza di tensione mentre si cablano e si installano gli apparecchi e le unità di
alimentazione. In caso contrario i moduli LED possono andare distrutti! In caso di guasto rispedire il proiettore al
produttore. Le istruzioni di montaggio devono essere conservate. I dati tecnici possono subire modifiche senza preavviso.
ENG Installation and commissioning may only be carried out by authorised technical personnel (electrical fitters). The
luminaire is designed solely for lighting and is to be installed according to the installation instructions. Any other use or any
other installation is considered to be improper.
Caution! Make sure that the luminaires and power supply units are always disconnected from the main supply during wiring
and installation work. Otherwise, the LED modules may be destroyed. Return to manufacturer if defects are found.
Assembly instructions must be kept. Subject to technical change without notice.
DE | Reinigung und Pflege
Reinigung nur mit trockenem oder feuchtem Mikrofasertuch.
FR | Nettoyage et entretien
Nettoyage seulement avec chiffon microfibre sec ou humide.
IT | Cura e pulizia
Pulire solo con un panno in microfibra asciutto o umido.
EN| Cleaning and care
Only use dry or moist microfiber cloth for cleaning.
5.
4.
Flat Long LED
Flat Short LED
6.
1.
2.
1.
3.
Flat LED Modul 300
Flat LED Modul 600
Flat LED Modul 625
2.
Flat LED Modul 300
: 275-280 x 275-280 mm
Flat LED Modul 600
: 570-580 x 570-580 mm
Flat LED Modul 625:
590-605 x 590-605 mm
Flat Short LED: 270-280 x 570-580 mm
Flat Long LED: 270-280 x 1170-1180 mm
Technische Änderungen vorbehalten / Les détails techniques sont sujet à des changements.
Modifiche tecniche riservate / Technical Details are subject to change.
25.07.2022 © unex lighting AG / Flüelastrasse 12 / 8048 Zürich
3 - 16 mm
8.
10.
9.
7.
Technische Änderungen vorbehalten / Les détails techniques sont sujet à des changements.
Modifiche tecniche riservate / Technical Details are subject to change.
25.07.2022 © unex lighting AG / Flüelastrasse 12 / 8048 Zürich
