Unfinished Furniture of Wilmington C-20 User manual

ITEM
NO
: C
-
20
REVISED AUG 04, 2012
Printed in Vietnam
- 1 -
Description:
Item No.
DOUBLE X BACK CHAIR WITH WOOD EAT
: C-20
ASSEM LY INSTRUCTIONS

ITEM
NO
: C
-
20
REVISED AUG 04, 2012
Printed in Vietnam
- 2 -
EFORE ASSEM LY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
- Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being
scratched.
- Remove all wrapping material, including staples & packing straps before you start to assemble.
- DO NOT tighten all screws and bolts until completely assembled.
- Keep all hardware parts out of reach of children.
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO Description Qty Sketch NO Description Qty Sketch
A Chair back 1 B eat Frame 1
C Chair eat 1 D Front Leg (L-
R) 2
E
ide
tretcher
(L-R)
2 F Middle
stretcher 1
ASSEM LY TOOLS REQUIRED
NOT INCLUDED

ITEM
NO
: C
-
20
REVISED AUG 04, 2012
Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO Description Qty Sketch NO Description Qty Sketch
1
hort bolt
(M6x40mm)
3 2
Medium bolt
(M6x60mm)
4
3
Long bolt
(M6x80mm)
4 4
crew
(M4x35mm)
10
5
Lock Washer
(Φ6.5x 11mm)
11
6
Flat Washer
(Φ6.5x 19mm)
11
7
Allen Key
(4mm)
1
STEP 1
Attach eat Frame (B) to the Back (A) by using bolts (3) and (1), and Washers (5) and (6). Tighten with
Allen Key (7) as shown below.
Note: DO NOT fully tighten any of the bolts, until the chair is assembled, then put on a flat level
surface to make sure the chair is level and then tighten the bolts.

ITEM
NO
: C
-
20
REVISED AUG 04, 2012
Printed in Vietnam
- 4 -
STEP 2
Attach Middle stretcher (F) to ide tretchers (E) with crews (4). Tighten with a screwdriver.
STEP 3
Attach Front Legs (D) to the seat frame.Using bolts (2), and Washers (5) and (6). Tighten with Allen Key
(7).
Place ide tretchers (E) (from step 2) between front and back legs, use the screwdriver to tighten
the screws (4) as shown below.

ITEM
NO
: C
-
20
REVISED AUG 04, 2012
Printed in Vietnam
- 5 -
STEP 4
Attach the eat (C) to top of the seat frame (from tep 3) by using crews (4), tighten with a screw
driver.
