Unfinished Furniture of Wilmington CHARLESTON R-93015 User manual

ITEM NO : R-93015
REVISED AUG 24, 2016
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
: CHARLESTON PORCH ROCKER
: R-93015

ITEM NO : R-93015
REVISED AUG 24, 2016
Printed in Vietnam
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO : R-93015
REVISED AUG 24, 2016
Printed in Vietnam
- 3 -
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Seat
1
B
Front leg
frame
1
C
Back
1
D
Long
stretcher
2
E
Short
stretcher
2
F
Left arm
1
G
Right arm
1
H
Runner
2
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Short Bolt
(M8x35mm)
1
2
Long Bolt
(M8x70mm)
8
3
Flat Washer
(8.5x19mm)
9
4
Lock Washer
(8.5x14mm)
9
5
Long screw
(M4x45mm)
16
6
Allen key
(M4x30mmx120mm)
1

ITEM NO : R-93015
REVISED AUG 24, 2016
Printed in Vietnam
- 4 -
STEP 1
Attach seat (A) to back (C) with bolts (1) and (2), and washers (3) and (4) as shown below. Tighten
with Allen key (6).
STEP 2
Attach front leg frame (B) to seat (A) with bolts (2), and washers (3) and (4) as shown below. Tighten
with Allen key (6).

ITEM NO : R-93015
REVISED AUG 24, 2016
Printed in Vietnam
- 5 -
STEP 3
Attach stretchers (D) and (E) to front and back legs with screws (5) as shown below. Tighten with a
screwdriver.
NOTE: PLACE THE STRETCHERS AS SHOWN BELOW BEFORE ATTACHING THEM TO THE LEGS.
STEP 4
Insert front and back legs into runners (H) as shown below.
STEP 4.2
STEP 4.1

ITEM NO : R-93015
REVISED AUG 24, 2016
Printed in Vietnam
- 6 -
STEP 5
Attach runners (H) to bottom of front and back legs with screws (5) as shown below. Tighten with a
screwdriver.
STEP 6
Attach arms (F) and (G) to front and back legs with screws (5) as shown below. Tighten with a
screwdriver.
