Uni-ram UM80W User manual

IDEAL FOR QUICK COLOR CHANGE
S
SPRAY GUN CLEANER
SPRAY GUN CLEANER
UM80W,
UM80W,
WATERBORNE
WATERBORNE
CLEANING BECOMES FAST AND EASY
• Water under hi
g
h
p
ressure flows, at the
p
ress
of a button, to thorou
g
hl
y
clean the paint
passa
g
e in less than 30 seconds.
• Th
e
outside of the
g
un is cleaned wth the
Fl
ow-t
h
rou
gh
B
rus
h
an
d
d
r
i
e
d
w
i
t
h
t
h
e
included Blow
G
un.
• Locatin
g
the compact UM80W inside the
s
pra
y
b
oot
h
saves t
i
me
b
ecause t
h
e
g
un
ca
n r
e
m
ai
n
co
nn
ec
t
ed
t
o
t
he
ai
r
li
n
e
a
n
d
t
he
p
ainter can remain in the booth; the
p
aint
c
hannel is flushed while the paint is still "wet
"
Wall Mount

SPRAY GUN CLEANER
SPRAY GUN CLEANER
1. Connect spray gun to whip air line (or leave
spray gun connected to supply air line.)
2. Position spray gun under nozzle as shown
below, press start button and squeeze
trigger to flush paint passage. Fresh water
pumps from left pail (photo on cover) through
Diaphragm Pump
the nozzle and used water drains to right pail.
3. Clean cap against pad (see below).
4. Clean exterior with flow-through brush (see
below).
5 Dry paint passage and exterior with blow gun.
6. Dry air passage by squeezing trigger of gun.
CLEANING PROCEDURE
TECHNICAL DATA
• Dimensions 13.5" W x 11.5" D x 35.8" H
35 cm W x 29 cm D x 91 cm H
• Weight 17.5 lb (8.0 kg)
• Input Pressure: at least 50 PSI (4 bar)
APPLICATION
• For use with waterborne paints only.
• For use in the spray booth or in the general
shop area.
• For use with water only or with Uni-ram's
effective cleaner, AQUA-KLEEN PGC,
p/n 102-8200, (1 L concentrate)
• Ideal for cleaning PPS and other
disposable cup adapters.
FEATURES
• Cleaning tools - nozzle for cleaning paint
passage, pad to clean cap, flow-through
brush to clean exterior of gun and blow bun
to dry paint passage and exterior.
• Air supply whip line included.
• Wall mount is standard; Part number for unit
with stand is UM80WS.
• Non-corrosive stainless steel cleaning tank.
• Powered by Uni-ram's dual diaphragm pump.
• One year warranty,
2 year replacement
warranty on pump.
