PUREIT
Reverse Osmosis Water Purifier
UR5440
Instruction
Manual

CERTIFICATIONS
PUREIT
UR5440
5019012
CAUTION:
FOR INDOOR HOUSEHOLD USE ONLY.
RISK OF ELECTRIC SHOCK.
DISCONNECT POWER ADAPTOR BEFORE SERVICING.
ONLY USE THE POWER ADAPTOR PROVIDED WITH THE
APPLIANCE.
ATTENTION:
POUR USAGE DOMESTIQUE SEULEMENT.
DÉBRANCHER DU CIRCUIT D'ALIMENTATION AVANT D'OUVRIR.
UTILISEZ UNIQUEMENT L’ADAPTATEUR D’ALIMENTATION
FOURNI AVEC L’APPAREIL.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
For any other questions about the product
Our customer excellence team will be happy to assist you
Email: [email protected]
Call: 1-866-4-PUREIT (1-866-478-7348)
M-F 9am-5pm CT
For help with installation
visit https://us.pureitwater.com/how-to-install.html for installation video
and https://us.pureitwater.com/support.html for troubleshooting

INSTALLATION INSTRUCTIONS 02
User Information 02
Preparation 02
Parts List 02
Product Introduction 04
Installation Tips 06
Installation Steps 07
Step 1: Install the RO Filter 07
Step 2: Install the Feed Water Adapter 09
Step 3: Install the Pureit Faucet (Non-Air Gap Faucet) 10
Step 4: Install the Drain Saddle 11
Step 5: Connect the Tubing 12
Step 6: Connect the Power Adapter 14
Step 7: Starting the System for the First Time 14
OPERATION INSTRUCTIONS 15
User Interface Display 15
Filter Life Reminder 16
Filter Replacement Guide 17
Filter Element Reset 20
TECHNICAL PARAMETERS 21
MAINTENANCE 21
TROUBLE SHOOTING 22
LIMITED PRODUCT WARRANTY 22
WARNING 23
CONTENTS

NOTE:
Do not install this device in direct sunlight.
Please install this within 59" of the drain pipe.
Installation of this system must comply with state and local laws and regulations.
Pureit Water Purifier with CTO & PGP pre-installed
PGP CTO
02 03
INSTALLATION INSTRUCTIONS
User Information
Thank you for purchasing Pureit reverse osmosis under-the-sink water purifier. Installation and
operating instructions are included in this manual.
• The applicable water temperature range is: 41°F - 100°F (5°C - 38°C).Do not use with water
beyond this temperature range.
• Please ensure there is a 100-240 V power outlet with type A plug under the sink prior to
installation.
• Never touch the power cord connector when your hands are wet as this may result in electric
shock.
• Only use original Pureit parts and replacement filters.
• All pictures are for reference only.
Preparation
• Check the parts list to confirm all are included in the package. If there are any parts missing,
cracked or broken, please do not proceed with the installation and contact Pureit by phone
1-866-4-PUREIT (1-866-478-7348) Mon-Fri 9:00 AM - 5:00 PM (CT) or by email at
[email protected].com.
• Check and ensure there is sufficient space under the sink to install the Pureit device (product
dimensions: 16.14" x 5.51" x 14.17"). The device should be placed inside the cabinet.
• Please ensure you have a 1" hole drilled in the countertop for the Pureit faucet prior to the
installation of the Pureit system.
Parts List
Pressure Relief
Valve 3/8"
X 1
Right Angle Quick
Connector 3/8"
X 1
Lock Clip 1/4"
X 4
Lock Clip 3/8"
X 4
Teflon Tape
X 1
Feed Water Adapter 3/8"
X 1
Power Adapter
X 1 Set
Pureit Faucet
X 1 Set
White 1/4" PE Tubing
X 118.11"
White 3/8" PE Tubing
X 59.06"
Instruction Manual
X 1
Drain Saddle 1/4"
X 1 Set
Reverse Osmosis Water Purifier
UR5440
Accessories bag
Reverse Osmosis
Membrane Filter
X 1 Set
RO

Product Introduction
The device interface and component parts are listed below. Please familiarize with each
parts for a smooth installation.
INSTALLATION INSTRUCTIONS
04 05
Wrench Drill Utility Knife Screw Driver Towel
Required tools (not provided):
Reverse Osmosis
Membrane Filter (RO)
Carbon Block
Filter (CTO)
Composite
Filter (PGP)
Left Side View (With the RO filter
installed and left panel open)
ROCTOPGP
Filter Life
Indicators
Front View
Reset Button
Select Button
Power Port
Filtered Water Port
Waste Water Port
Input Water Port
Back View
RO
PGP
CTO
Example of connection
Filtered Water Tubing
1/4" PE Tube
Input Water Tubing
3/8" PE Tube
Feed Water Washer
Adapter
Power Adapter
Cold Water Supply Valve
Cold Water Pipe
Drain Saddle
Waste Water Tubing
1/4" PE Tube
Pressure Relief Valve

06 07
Installation Tips
How to use the quick-connect fittings
To connect to tubing
1. Push the tubing into the fitting around 4/5" until the tubing is fully inserted.
2. When the tubing is fully inserted, put the blue lock clip on the fitting. It will lock the tubing
in place and prevent it from falling off.
INSTALLATION INSTRUCTIONS
How to drill a hole in your sink or countertop
1. Select the desired location for the drinking faucet on the counter top near the sink.
2. Use a power drill to drill a 1" diameter hole for installation.
To disconnect from tubing or plugs
1. Remove the blue block clip from the fitting. Please skip this for plugs.
2. Use your thumb and index finger to press down the lock sleeve. Use your other hand to
pull out the tubing or plugs from the fitting.
NOTE:
If the tubing is not fully inserted, leakage will occur due to a lack of seal created.
NOTE:
Check and cut the tubing end squarely and cleanly with utility knife to the desired
length.
NOTE:
Please do not pull out the tubing or plugs directly. This will damage the fitting and
cause leakage.
Depending on the countertop material and sink type, a professional installer is
recommended to drill a hole for the drinking water Pureit faucet installation.
NOTE:
Correct Cutting
Incorrect Cutting
Installation Steps
Step 1: Install the RO Filter
1. Locate the recessed handle at the bottom left side of the panel.
2. Pull outward to open the side panel.
3. Take the RO Filter from the package and remove the packaging of the filter.
NOTE:
The RO Filter is provided in separate within the same package.

4. Lift the hoop of the new filter to the full extent and keep it in this position.
5.
Position the bottom of the filter to match a recess in the filter device, then plug the filter tightly
in place.
6. Press down the hoop to the position shown by the dotted line. Tug the filter outward to see
whether it is installed correctly.
7. Install back the left panel.
Step 2: Install the Feed Water Adapter
1. Shut off the cold water supply. Turn on the kitchen faucet to release water pressure.
2. Connect the input water tubing (3/8" PE tubing) to the feed water adapter.
3. Disconnect the cold water pipe from the cold water supply valve.
4. Connect the feed water adapter onto the cold water supply valve (with its washer) and
tighten it with a wrench.
Thread the PE tube through the
nut and cover closely at the
adapter bulge.
Unscrew the nut on feed water
adapter, and slide the nut onto
the 3/8" PE tube.
Use a wrench to tighten the nut,
make sure it doesn't leak.
NOTE:
If you find the tubing difficult to connect, please put one end into warm water for 5
seconds to allow it to soften. Then try again.
5. Re-connect the cold water pipe onto the feed water adapter and tighten with a wrench.
Cold Water Pipe
Feed Water
Adapter Washer
Cold Water Supply Valve
08 09
INSTALLATION INSTRUCTIONS

10 11
INSTALLATION INSTRUCTIONS
Step 3: Install the Pureit Faucet (Non-Air Gap Faucet)
1. Please check if your kitchen sink or countertop has an existing hole. If not, you will need
to drill one. Please refer to “How to drill a hole in your sink or countertop” on page 7.
2. Insert the soft rubber pad into the screw of the Pureit faucet.
3. Place the Pureit faucet into the countertop hole. Under the sink, put the plastic washer
and fixing nut on the screw and tighten the fixing nut to fasten the Pureit faucet.
4. Connect the 1/4" tubing to the quick connection fitting on the bottom of the Pureit faucet
and put the 1/4" lock clip on the fitting.
Step 4: Install the Drain Saddle
1. Choose a place on the drainage pipe that is convenient for installing the drain saddle and tubing.
2. Select the location of the hole and drill a 1/4’’ inch hole through one side of the drain pipe.
Make sure not to penetrate the opposite side of the pipe.
3. Cut the 1/4" tubing into two. The length should be determined base on how far you plan to
place the device from the filtered water tube and waste water tube. Please refer to the tubing
cut note on page 6.
4. Insert the other 1/4’’ PE tubing as the waste water tubing into the drain saddle. Please push
through 3/5" of the PE tubing into the black sticky pad.
5. Place the extruded portion of the waste water tube from the drain saddle into the hole on the
drainage pipe. Then secure the drain saddle by tightening the two screws and hex nuts.
6. Tug on the 1/4" tube to check and ensure it is properly secured.
Hex Nuts
Black Sticky Pad
1/4" White Tube
Soft Rubber Pad
Plastic Washer
Fixing Nut
Countertop
Faucet Body
Faucet Stem
Faucet Spout

3. Install the filtered water tubing:
Connect the filtered 1/4" water tubing from the Pureit faucet to the filtered water port.
4. Install the waste water tubing:
Connect the waste 1/4" water tubing from the drain saddle to the waste water port.
5. To ensure all the tubing connections are secured, please check all lock sleeves have the
blue lock clips in place.
12 13
INSTALLATION INSTRUCTIONS
Filtered Water Tubing
1/4" PE Tube
Drain Saddle
Waste Water Tubing
1/4" PE Tube
Feed Water
Adapter
Pressure Relief Valve
Input Water Tubing
3/8" PE Tube
Step 5: Connect the Tubing
These are the steps to connect the tubing to the Pureit device.
1. Remove the plugs that are on the Pureit water port at the back of the device:
Please press down the lock sleeves and pull out plugs from the device, which were used to
protect the device from dust and insects, etc. Please refer to “How to use the quick-connect
fittings” on page 6.
2. Install the input water tubing:
Cut the 3/8" tubing into two. The length should be determined base on how far you plan to
place the device from the pressure relief valve connection. Please refer to the tubing cut note
on page 6. Connect the 3/8" tubing from the feed water adapter to the pressure relief valve
(Please note the arrow direction on the valve to ensure the direction of water flow is correct.),
then use the other piece of 3/8" tubing to connect the pressure relief valve to the input water
port.
NOTE:
Ensure the tubing is 4/5" inserted into the fitting. Place the blue lock clip into the lock
sleeves to secure the connection.
You can use the 3/8" right angle quick connector to adjust the direction of the tubing.
NOTE:
To disconnect please remove the lock clip, press down the lock sleeve and pull out the plugs
or inserted tubing.
NOTE:
To enable waster water drain freely, make sure that the drain saddle is positioned at least
4 inches below the wasted water port in vertical.

Step 6: Connect the Power Adapter
Connect the power adapter into the power port before connecting to the power outlet.
14 15
RO
PGP
CTO
Filter life indicator light
• When functioning normally, the filter life indicator light will be blue.
• When the filter life is about to expire, the filter life indicator light will flash red
every 2 seconds.
• When a filter has expired, the filter life will flash red quickly every second.
• When the blue lights are flashing in sequence, it indicates that the device is
in flushing mode.
• When the red lights are flashing in sequence, it indicates that the device is
in protection mode. Please turn off the device and restart it, the system will
resume normally.
Reset button
To reset the selected filter, press and hold the reset button for 3 seconds.
Select button
After replacing the filter, press the select button to reset the new filter. The
corresponding light indicator will be lit next to the filter name.
PGP = composite filter
RO = reverse osmosis membrane filter
CTO = carbon block filter
User Interface Display
INSTALLATION INSTRUCTIONS OPERATION INSTRUCTIONS
Step 7: Starting the System for the First Time
1. Plug in the power adapter into a power outlet. Turn on the cold water supply valve, feed
water adapter and the Pureit faucet. Check for leaks.
NOTE:
Filter life indicators should turn blue at this point. Slight vibrations can be expected as
the pump starts.
Inspect the system for any water leakage especially at the joints, fittings, valves and
tubing connections. If any water leakage is found, turn off the cold water supply
immediately and reinforce all tubing connections. If the issue persists please contact
Pureit customer service.
2. Turn on the Pureit faucet and run the purifier device for 2 hours to flush the system. This
should be done each time when the reverse osmosis filter is changed.
3. Then turn off the Pureit faucet to let the purifier stand for 24 hours.
4. Turn on the Pureit faucet and flush the device for 2 hours again. The system is now ready
for use and filtered water can be consumed directly.
NOTE:
Please do not consume water during the flushing process. The water can be reused
and conserved for other purposes such as watering plants.
When the device is running for 30 minutes continuously, a protection mode will kick in
to stop the device from over-working. A red indicator light will flash repeatedly. Please
turn off the device and then restart it to resume operation.
Power Adapter

16 17
Purchase of replacement filters
Please visit https://us.pureitwater.com for purchase of replacement filters.
OPERATION INSTRUCTIONS
Filter Life Reminder
A device sensor monitors and indicates when it is time to replace the filter.
1. When the filter is about to expire: There will be a beeping sound and the filter's
corresponding indicator light will flash in red every 2 seconds on the interface.
2. When it is time to replace the filter: The filter's corresponding indicator light will flash in
red every second on the interface. Please replace the filter when you see the reminder
notification.
Filter Replacement Guide
NOTE:
Always disconnect the appliance from the power outlet and shut off water before
replacing filters.
1. Find the correct filter to replace according to the corresponding filter life indicators on the user
interface display in front of the device.
Reverse Osmosis
Membrane Filter (RO)
Carbon Block
Filter (CTO)
Composite
Filter (PGP)
ROCTOPGP
2. How to open the device for filter change:
2.1 Locate the recessed handle at the bottom left side of the panel.
2.2 Pull outward to open the side panel.
Filter Life
Indicators
RO
PGP
CTO
Reverse Osmosis
Membrane Filter
FUR54RO
Filter Life: 2 - 3 Years
RO
Carbon Block Filter
FUR54CTO
Filter Life: 6 - 12 Months
CTO
Composite Filter
FUR54PGP
Filter Life: 6 - 12 Months
PGP
NOTE:
The recommended filter lifetime is for reference only, the specific replacement cycle
depends on the water source and frequency of use. This reverse osmosis water purifier
contains a replaceable treatment component, critical for the effective reduction of total
dissolved solids and the product water should be tested periodically to verify that the
system is performing properly.

3. How to remove the filter:
3.1 Please turn off the inlet valve on feed water adapter or shut off cold water supply valve
before replacing the filters.
3.2 After turning off the inlet valve, lift the hoop of the expired filter to the full extent and keep
it in this position.
3.3 Pull the hoop outwards and take out the filter, and wipe off the remaining water with a
towel.
4. How to replace the filter:
4.1 Remove the packaging of the new filter.
4.2 Lift the hoop of the new filter to the full extent and keep it in this position.
4.3
Position the bottom of the filter to match a recess in the filter device, then plug the filter
tightly in place.
4.4 Press down the hoop to the position shown by the dotted line. Tug the filter outward to see
whether it is installed correctly.
4.5 After replacement, please flush the filter according to the system starting method,
normal operation cannot be carried out until the flushing is completed.
18 19
OPERATION INSTRUCTIONS OPERATION INSTRUCTIONS

20 21
Product Name Reverse Osmosis Water Purifier
___________________________________________________________________
Model UR5440
___________________________________________________________________
Applicable Water Source Municipal Tap Water
___________________________________________________________________
Feed Water Pressure 15 PSI ~ 60 PSI
___________________________________________________________________
Max Working Pressure 100 PSI
___________________________________________________________________
Ambient Temperature 39
°F - 100 °F (4 °C - 38 °C )
___________________________________________________________________
Ambient Humidity ≤ 90%
___________________________________________________________________
Applicable Water Temperature 41
°F - 100 °F (5 °C - 38 °C )
___________________________________________________________________
Rated Voltage 24 VDC
___________________________________________________________________
Rated Power 88 W
___________________________________________________________________
Filtered Water Flow Rate 0.28 Gal/min*
MAINTENANCE
OPERATION INSTRUCTIONS
* 1. The recommended maximum filtered water volume for the Pureit UR5440 is approximately
4800 litres and the flow rate is approximately 0.28 Gal/min of municipal tap water.
The appliance has been tested with tap water with below water supply conditions:
• Feed Water Pressure between 15 PSI - 60 PSI
• Water temperature between 72
°F - 82 °F (22 °C - 28 °C )
• Total dissolved solids between 0 - 500 ppm
• Water pH 6.5 - 8
• SDI15 < 5
2. All parameters related to the performance of the product are obtained under the above
testing condition and may vary depending on the condition of your tap water supply and
usage environment.
If the system will not be used for more than a week, please shut off the cold water supply valve,
drain the system and disconnect the power.
Please replace filters regularly based on the filter life indicators. The actual filter life depends on
the water source quality and frequency of use.
Filter Element Reset
1. Press the button to select the corresponding filter life indicator light of the replaced
filter, until the indicator flashes.
2.
Press the button and hold for 3 seconds until the indicator light turns a steady blue
accompanied by the buzzers. The filter element reset is now completed.
Press Press And Hold
RO
PGP
CTO
Filter Life Indicators
TECHNICAL PARAMETERS

22
WARNING
Having trouble getting your Pureit device to work?
Please visit https://us.pureitwater.com/support.html for trouble shooting instructions.
Should you still have questions, please contact the Pureit Customer Service hotline:
1-866-4-PUREIT (1-866-478-7348) or e-mail us at [email protected].com for additional
support. Our operating hours are Mon-Fri 9:00 AM - 5:00 PM (CT).
TROUBLE SHOOTING
Warranty information
The Pureit “LIMITED PRODUCT WARRANTY” applies only if the water purifier is installed,
used, and maintained according to the instructions in this manual. For warranty conditions visit
https://us.pureitwater.com/warranty.html.
Warranty and returns
If you purchased the water purifier at one of our authorized retailers, please contact the
same store to request assistance.
23
LIMITED PRODUCT WARRANTY
• The device is appropriate for municipal tap water only, and not intended for use of water
that is microbiologically unsafe or of unknown quality.
• Please do not remove or damage the connector of each parts in the Pureit purification
system.
•
Unauthorized modification and disassembly are strictly prohibited and will void the warranty.
• When the device has not been used or left unattended for more than one week, the water
and power supply shall be cut off to better protect the device. It is recommended to drain
the direct drinking water in the first few minutes when reusing, otherwise it may affect the
taste.
• This device is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do not play with the device.
• The feed water pressure is neither lower than 15 PSI nor higher than 60 PSI.
• The reverse osmosis water purifier can operate without air gap faucet. If your local
plumbing code may require one to be installed, use a dual air gap faucet for dishwasher
and reverse osmosis water purifier if necessary.
• Follow below installation instruction that come with the dual air gap faucet.
Garbage Disposal
Dual Air Gap Faucet
Reverse Osmosis
Water Purifier
Waste Water Tubing

125 S Clark St., Ste. 2000
Chicago, IL 60603 USA
PUREIT
Reverse Osmosis Water Purifier
UR5440
Instruction
Manual
