ACL875SU –Surface Mount Standalone Keypad
Reader - Installation Manual
Description / Operation
ACL875SU is a standalone digital keypad for access control
applications with backlit keys, 99 user codes, 2 outputs (relay
and transistor) and 1 push button input. These keypads are
available in three different color finishes. Authorized users can
be assigned specific codes for use in access control
applications, electrical switching and arming/disarming alarm
systems. The users can be assigned to activate the first, the
second or both outputs. There is a 30 seconds lockout after 8
successive invalid PIN codes.
The tamper switch output can trigger the alarm system, if an
attempt is made to open or remove the unit from the wall.
Specifications
Operating voltage
12 to 24 VDC; 15 to 24 VAC
Current consumption
60 mA at 12 VDC
PIN Code capacity
99 (1 to 8 digits)
Outputs
1 Relay (2 A at 24 VDC, 2 A at 120 VAC),
1 transistor (100 mA)
Buzzer
Yes
LED
Green - Output 1 status (Relay)
Red - Output 2 status (Transistor)
Orange - Key press and Menu
LED control
No
Tamper
Yes
Backlight ON/OFF
Yes, by DIP switch
Panel connection
Cable,1 m
Material of design
housing
Molded Aluminum or ABS (black)
Dimensions of housing
(W x H x D)
51 x 92 x 25 mm; 51 x 92 x 27 mm (ABS);
Operating environment
Temperature
Relative humidity
-20 to +50°C
0 to 95% noncondensing
IP rating
IP65
Color
-S = Silver, -C = Grey, -B = Black
Weight
Shipping weight: 305 g
Product weight: 173 g
Mounting
Figure 1: Mounting instructions
Wiring
Figure 2: Wiring
1
12/24V
12 to 24 VDC;
2
AC/DC
15 to 24 VAC
3
Tamp
Tamper
4
Tamp
Tamper
5
GND
Ground (PB)
6
PB
Push Button Input
7
Transistor
Transistor Output
8
NC
Normally closed
9
COM
Common
1 0
NO
Normally open
Red
Black
Pink
Violet
Blue
Green
Orange
Gray
Yellow
White

2 / 4 P/N 1073523A• REV 00.00 • ISS 4JUL18
Application diagram
Figure 3: Application diagram
12 to 24 VDC
Note: Exit button (NO) automatically activates relay output1.
15 to 24 VAC
NOTE: The PIN code is typed with A for confirmation.
Example:
123 + A
Transistor
DIP switch and Status LED’s
Default: 1 –OFF; 2 - ON
1 :Redefine Master Code
2: Backlight in Idle Mode ON/OFF
Orange LED - Key press and Menu
Red LED - Output 2 Status
Green LED - Output 1 Status
Redefine Master Code
It is possible to redefine and restore the default setting if the
Master code is forgotten.
1. Disconnect power and put the DIP switch1 to ON
2. Reconnect power (beep beep ... + orange LED blinks)
3. Put back the DIP switch1 to OFF (Orange LED ON + Long
beep)
4. Press 000
5. Press the new Master Code
6. Press A (beep, beep)
7. Press B (Orange LED OFF)
.
12 to 24
VDC
Diode 1N4001

P/N 1073523A• REV 00.00 • ISS 4JUL18 3 / 4
Programming flowchart
Assign a User Code
Press (0)
+
Memory position from
01 to 99
Change
Master code
Press (0)
+
Memory
position (00)
Set Output Timer
Pulsed Mode (01 to 99 sec):
Relay1:
Press (1) + (from 01 to 99
)
Relay2:
Press (2) + (from 01 to 99
)
OR
Latch Mode (ON/OFF):
Press (1) or (2) + (00)
Enter
NEW PIN Code
(1 to 8 digits)
Press “A” to validate
Validation OK?
1 small beep + 1 long beep + Yellow LED is ‘on’
Validate by pressing (B)
Multiple small beeps
+
Orange LED blinks rapidly
Yes
No
Enter “Master Code” OR “000” (if first time use)
Assign Output
Press
(3)
+
Memory position
from
(01 to 99)
+
Press (
1
) for Relay1
OR
Press (
2
) for Relay2
OR
Press (12) for
both outputs
Delete Single
Code
Press (9)
+
Memory
position from
(01 to 99)
Delete ALL
codes
Press (8)
+
(99)
Validation OK?
Press “B” (Orange LED is OFF)
Ex.: To assign User Code “6789” at Memory
Position “6” and Relay that activates for 5
seconds assuming Master Code = 000
000B + 0 + 06 + 6789 + A + 1 + 05 + A + B.
Yes
No

4 / 4 P/N 1073523A• REV 00.00 • ISS 4JUL18
Regulatory information
Trademarks and
patents
The trade names used in this document may be
trademarks or registered trademarks of the
manufacturers or vendors of the respective
products.
Manufacturer
Interlogix.
2955 Red Hill Avenue, Costa Mesa, CA 92626
5923, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, The Netherlands
Certification
European Union
directives
This product and - if applicable - the supplied
accessories too are marked with "CE" and
comply therefore with the applicable harmonized
European standards listed under the EMC
Directive 2014/30/EU, the RoHS Directive
2011/65/EU.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.recyclethis.info.
2013/56/EU & 2006/66/EC (battery directive):
This product contains a battery that cannot be
disposed of as unsorted municipal waste in the
European Union. See the product documentation
for specific battery information. The battery is
marked with this symbol, which may include
lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the
battery to your supplier or to a designated
collection point. For more information see:
www.recyclethis.info.
