US Steam BlueEvolution S+ User manual

1
US STEAM®
2440 Chambers Street, Ste A Venus, Texas 76084
[phone] / ussteam.net

POWER SUPPLY
120 V. 60Hz
READY TIME
10 MINUTES
BOILER REFILL SYSTEM
AUTOMATIC REFILL
STEAM FLOW ADJUSTMENT
3 LEVELS / ADJUSTED ON CONSOLE
PRESSURE
8 BAR / 145 PSI
MAX TEMPERATURE
336
°F
BOILER VOLUME
1/2 GALLON
BOILER MATERIAL
AISI 304
WATER TANK CAPACITY
1/2 GALLON
–INTERNAL TANK
DETERGENT/ TANK CAPACITY
1/2 GALLON
–INTERNAL TANK
VACUUM RECOVERY CAPACITY
2.2 GALLON / WATER FILTRATION SYSTEM
VACUUM POWER ADJUSTMENT
YES, 3 LEVELS
BOILER POWER
1700 W
VACUUM POWER
1200 W
AIR FLOW
95 m3/h
-56 CFM
MAX DEPRESSION
2.100 mm H2O
-82.6 in H2O
DIMENSIONS L x W x H
23
“ x15 “ x37 “
HOSE LENGTH
10 FT
NET WEIGHT
58 lbs
2
32
Pos.(3)
Entkalkungsanleitung B
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functionality of the
appliance. Te connections on the extension pipes and the safety handle can be sprayed with a
suitable lubricant or silicone spray as required. This will make it easier to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the extension
pipes must be checked regularly for damage. The O-rings will last longer if they are coated regularly
with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for damage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for damage:
Pos(3): 2 O-rings on the brass spout
Checking O-rings on the extension pipes
Check the O-rings on all extension pipes for damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Cleaning, care and maintenance of accessories
Pos.(1) Pos.(2)
Pos.(4) Pos.(5)
You can order a suitable set of O-rings from our online shop at
www.beam.de or by telephone on [phone].
Item no.: 96300
Pos.(3)
Entkalkungsanleitung B
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functionality of the
appliance. Te connections on the extension pipes and the safety handle can be sprayed with a
suitable lubricant or silicone spray as required. This will make it easier to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the extension
pipes must be checked regularly for damage. The O-rings will last longer if they are coated regularly
with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for damage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for damage:
Pos(3): 2 O-rings on the brass spout
Checking O-rings on the extension pipes
Check the O-rings on all extension pipes for damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Cleaning, care and maintenance of accessories
Pos.(1) Pos.(2)
Pos.(4) Pos.(5)
You can order a suitable set of O-rings from our online shop at
www.beam.de or by telephone on [phone].
Item no.: 96300
Check the O-rings on the safety handle for da-
mage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for da-
mage:
Pos(3): 2 O-rings on the brass spout
Check the O-rings on all extension pipes for
damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functio-
nality of the appliance. Te connections on the extension pipes and the safety handle can
be sprayed with a suitable lubricant or silicone spray as required. This will make it easier
to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the
extension pipes must be checked regularly for damage. The O-rings will last longer if they
are coated regularly with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Checking O-rings on the extension pipes
Pos. (1) Pos. (2)
Pos. (3)
Pos. (4) Pos. (5)
Specifications

3
Assembly (Collection Tank, Handle, and Toolbox) ________________________________________ 7
Quick Start
Steam _______________________________________________________________________ 9
Extraction ____________________________________________________________________ 10
Vacuum ______________________________________________________________________ 10
Extraction ______________________________________________________________________ 13
Accessories ____________________________________________________________________ 14
Troubleshooting / Error Codes _______________________________________________________ 15
Maintenance -Descaling ___________________________________________________________ 16
Maintenance – O-Rings _____________________________________________________________ 26
Notices _________________________________________________________________________ 27
Warranty & Repair ________________________________________________________________ 28
ØD0 NOT leave the steam cleaner unattended while plugged in
ØTurn off all controls and unplug the electrical cord when not in use
ØDO NOT use with a damaged cord or plug
ØIf the steam cleaner is not working as it should, has been dropped, damaged, left outdoors or
dropped into water, call for service before using
ØNEVER attempt to disassemble this steamer
ØDO NOT handle the electrical plug with wet hands
ØDO NOT use near children
ØDO NOT pull or carry by power cord
ØKeep cord away from heated surfaces
ØALWAYS set safety switch on hose handle into the locked position when not in use
ØNot setting safety switch to locked position could result in an injury
ØKeep body, hands, and feet away from accessories or nozzle when steam is in active use
ØALWAYS test a small area before cleaning a large area on any type of surface to make sure no
damage will occur
ØThe steam cleaner should be the only appliance plugged into an outlet
ØUse only a 12 gauge / 15 AMP rated or higher rated extension cord with max length of 25ft
ØAny alteration of electrical cord supply on this steam cleaner will void all warranties
32
Pos.(3)
Entkalkungsanleitung B
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functionality of the
appliance. Te connections on the extension pipes and the safety handle can be sprayed with a
suitable lubricant or silicone spray as required. This will make it easier to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the extension
pipes must be checked regularly for damage. The O-rings will last longer if they are coated regularly
with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for damage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for damage:
Pos(3): 2 O-rings on the brass spout
Checking O-rings on the extension pipes
Check the O-rings on all extension pipes for damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Cleaning, care and maintenance of accessories
Pos.(1) Pos.(2)
Pos.(4) Pos.(5)
You can order a suitable set of O-rings from our online shop at
www.beam.de or by telephone on [phone].
Item no.: 96300
Pos.(3)
Entkalkungsanleitung B
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functionality of the
appliance. Te connections on the extension pipes and the safety handle can be sprayed with a
suitable lubricant or silicone spray as required. This will make it easier to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the extension
pipes must be checked regularly for damage. The O-rings will last longer if they are coated regularly
with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for damage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for damage:
Pos(3): 2 O-rings on the brass spout
Checking O-rings on the extension pipes
Check the O-rings on all extension pipes for damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Cleaning, care and maintenance of accessories
Pos.(1) Pos.(2)
Pos.(4) Pos.(5)
You can order a suitable set of O-rings from our online shop at
www.beam.de or by telephone on [phone].
Item no.: 96300
Check the O-rings on the safety handle for da-
mage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for da-
mage:
Pos(3): 2 O-rings on the brass spout
Check the O-rings on all extension pipes for
damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functio-
nality of the appliance. Te connections on the extension pipes and the safety handle can
be sprayed with a suitable lubricant or silicone spray as required. This will make it easier
to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the
extension pipes must be checked regularly for damage. The O-rings will last longer if they
are coated regularly with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Checking O-rings on the extension pipes
Pos. (1) Pos. (2)
Pos. (3)
Pos. (4) Pos. (5)

4
3
Industry
From carpets to upholstery
The BlueEvolution cleans almost
any surface – streak-free and deep.
Retail
Gleaming sales areas
Tough dirt and odours vanish in no time
at all. Health
Hygienic surfaces
The hot steam thoroughly cleans your practice
rooms with little effort and a big impact for your
patients.
Restaurants
No scrubbing, no chemicals
The BlueEvolution also dissolves fat
in hard-to-reach places – with no strong
cleaning products.
Clean desks
Door handles, conference tables, floors, kitchen
areas – the BlueEvolution guarantees
a clean, germ-free work environment.
Offices
Gyms, saunas and spas
It's good for people to sweat. And thanks to the
BlueEvolution it's no longer a problem
for others. All equipment and contact
surfaces can be cleaned perfectly.
Wellness
für alle Branchen
Putzrevolution
And many more possibilities for use ...
The revolution in commercial cleaning
The BlueEvolution is more flexible than any other professional steam cleaner. Both
the steam and suction power have 3 settings. You can also regulate the hot water
inflow continuously using a control valve, which allows you to set the soaking effect
on the device individually.
Full power for a greater clean.
Kind to the environment.
The BlueEvolution is kinder to the environment than almost any other cleaning system. It is only
filled with clear water and minimises water consumption thanks to the steam pressure. There is no
need for any harmful or really aggressive chemicals.
The applications of the BlueEvolution are practically limitless. The BlueEvolution really comes into
its own in areas of high public traffic. Even large areas can be cleaned efficiently and quickly with
little effort. Pathogens don't stand a chance!
Make steam
Cleaning revolution for all industries
HACCP qualification certifies the highest cleaning power

5
5
Important Advice for Users
Congratulations on the purchase of this product.
Your choice confirms your strong technical knowledge and your excellent
taste. Ultimately, you have chosen a high-tech product, which has been
manufactured using only materials of the highest quality.
Please take the time to read the User Manual carefully before starting
your new appliance and keep the Manual to hand so that you can refer
to it in the future.
This Manual contains the information you need for proper use, correct
operation, appropriate cleaning, care and maintenance of the appliance.
It is essential that you are familiar with and follow the instructions in the
Manual to ensure risk-free use, as well as your own safety during ope-
ration, cleaning, care and maintenance. This User Manual cannot foresee
every conceivable use of the appliance.
If you would like more information or if specific problems arise that are
not covered in sufficient detail in this User Manual, then please contact
the manufacturer directly to request the necessary information.
1. Description of equipment
The BlueEvolution impresses thanks to its ease of use, sophisticated
technology and diverse range of applications. It sets new standards in
terms of hygiene and cleaning, makes the job much easier and saves
time, drastically reduces the use of harmful cleaning agents that are bad
for the environment, and ensures perfect cleanliness and a healthy feel-
good ambience.
2. Purpose of use
The BlueEvolution can be used for thorough cleaning of surfaces and
objects and to clear unpleasant odours from the air indoors.
This appliance is intented for professional use as a steam generator and
as a liquids/organic materials aspirator in accordance with the descrip-
tions and directions of this user manual.
3. IMPORTANT SAFETY INSTRUCTIONS
3.1 Safety warnings for the UV-C lamp UV
WARNING! This appliance contains a UV emitter. Do not look directly
into the source of light.
WARNING!
Do not switch on the UV light if it is outside the appliance's protective
housing. The appliance may emit harmful UV-C radiation if not used pro-
perly. Even small doses of UV-C radiation may cause damage to eyes and
skin. Users are NOT permitted to replace the UV-C lamp.
READ AND FOLLOW ALL INSTRUCTIONS
When using the Cleaning System, always use basic precaution, including
the following:
WARNING! – To reduce the risk of fire, electrical shock or injury:
1. Do not leave appliance when plugged in. Unplug the Cleaning System
from outlet when not in use, or before servicing. Do not allow to be used
as a toy. Close attention is necessary when the system is being used
around children. Never allow children to use or play with the system.
3. Use only as described in the manual. Only use original manufacturer
attachments.
4. Do not use the Cleaning System with a damaged cord or plug. If
the Cleaning System has been dropped, damaged, left outdoors, or sub-
mersed in water, return the System to the SERVICE .
5. Do not pull or carry the Cleaning System by the cord.
6. Do not use the cord as a handle. Never close a door on the cord. Never
pull it around edges or corners. Never run appliances over the cord. Keep
cord away from heated surfaces.
7. Do not unplug by pulling the cord. To unplug, grasp the plug, not the cord.
8. Do not handle the plug with wet hands.
9. Do not allow objects to get into the output nozzles. Do not try to
operate the Cleaning System with any of the openings blocked. Keep
opening free of dust, lint, hair, or anything that reduce the Steam flow.
10. Keep all parts of the body away from output nozzles and moving parts
of the System.
11. Use extra care when using the Cleaning System on stairs.
12. Use extra care when cleaning around water source (swimming pools,
spas, toilets, etc.)
13. Do not use the Cleaning System to clean animals
14. Never point the steam toward humans or animals.
15. Turn off all controls before unplugging the Vapor System.
16. Do not fill the Cleaning System with anything but clean tap water.
17. To reduce the risk of electric shock – use indoors only
18. Do not use to pick up flammable or combustible liquids, such as
gasoline, or use in areas where they may be present.
19. Connect to a properly grounded outlet only. See Grounding Instruc-
tions
20. Do not pick up anything that is burning or smoking such as cigaret-
tes, matches, or hot ashes.
WARNING – This hose contains electric wires. To reduce risk of elec-
tric shock do not use or repair a damaged hose.
SAVE THESE INSTRUCTIONS
WARNING!
Your Vapor Cleaning System MUST BE PLUGGED INTO A
GROUNDED OUTLET, or electrical shock can occur. Check with a qualified
electrician if you do not know if the outlet is grounded.
Do not modify the plug provided with the Vapor System, if it will not fit
outlet, than have a proper outlet installed by a qualified electrician.
NOTE:
In Canada, the use of a temporary adaptor is not permitted by the Cana-
dian Electrical Code.
THIS UNIT MUST BE GROUNDED
If the unit should malfunction or break down, grounding provides a path
of least resistance of electrical. Current to reduce the risk of electrical
shock. The uniti s equipped with a cord having an equipment grounding
conductor and grounding plug. The plug must be inserted into an appro-
priate outlet that is properly grounded in accordance with all local codes
and ordinaces.
WARNING!
This appliance is for use on a nominal
120-V circuit and has a grounding attach-
ment plug thet looks like the plug illust-
rated in sketch A in figure 20. Make sure
that the appliance is connected to an out-
let having the same configuration as the
plug. No adaptor should be used with this
appliance.
INFO: To minimise the occurrence of condensation (caused when
the steam hose and attachments are not at operating tem-
perature) it is recommended that you allow the steam to flow
for a few seconds on the maximum setting before starting the
cleaning work. This ensures the steam hose and attachments
heat up more quickly.

6
4
➊Driving handle
➋Locking screw driving handle
➌Locking lever driving handle
➍Display
➎ Socket steam suction hose
➏ Drain plug water tank
➐Drain plug hot water module
➑Main switch
➒Filler holes
➓ Accessories box
AON/OFF button boiler
BON/OFF button suction
CON/OFF button hot water module
Description of equipment
➓
➒
➐➏
➎
➌
➍
➋
➊
➑
➑Main switch
A B C
STEAM VACUUM
PAUSE
WATER
Status:
MENU STANDBY

7
6
Assembly / preparation
Assembly of the driving handle and
accessories box
Attach the handle using the two fixing knobs. Tighten them
by turning clockwise.
Insert the accessories box
Position the box in its place. Fix the two knob.
Fill the reservoir O
Fill the hot water module P
• Open the cap O and fill the water tank with normal tap
water using the funnel.
• Re-close the tank cap.
• Fill the tank P for the hot water module, likewise with
normal tap water. If your water is particularly hard, you
may also use distilled water mixed with tap water in this
tank.
• Re-close the tank cap.
The following combined functions are
possible depending on the application
area:
• Steam cleaning
• Steam cleaning with hot water
• Suction
• Suction and steam cleaning (steam suction)
• Suction and steam cleaning with hot water function
OP

8
7
Assembly / preparation
Filling the filter bowl
Your appliance is fitted with a hygienic water filter. You must
fill the filter bowl with water before starting, in order to bind
the extracted dirt in the water and to clean the suctioned air
in the water bath as well.
• Loosen the clips on the right and left of the filter bowl and
remove from its slot.
• Open the cover on the filter bowl by pushing off the rele-
vant clips.
• Fill with tap water
up to the
green line
(approx.
0,52 gal).
• Re-insert the filter bowl, ensuring the switch cam on the
cover is in the correct position.
WARNING:
The appliance can suck in up to approx. 0,4 gal of liquid.
If you exceed this amount, the fill level sensor will stop suc-
tion automatically and “E04” error will appear on the display.
INFO:
If you only wish to suction liquid, such as accidental water
spills, it is not necessary to fill the appliance's filter bowl with
water.
When sucking liquids, the MAX. capacity in the container is
approx. 1,06 gal.
Inserting the steam suction hose
• Insert the connector of the steam suction hose into the
socket until you hear the click of the safety hook.
• To remove the hose from the appliance, press release but-
ton A and pull on the connector.
A

9
8
Start-up steam
Insert the mains plug into the wall socket.
Turn the general switch 8to ON,
the display will light up showing the menu and will remain
in stand-by waiting for a function to be selected by the user,
differently, the display will switch to energy saving after 60
seconds (Standby).
If the machine was in Standby status press the start icon.
Press the “STEAM” icon to start the boiler. During the
heating stage, it is possible to display the temperature and
pressure which gradually raise up to the operating condi-
tions.
During this stage, the “STEAM” icon will blink and the dis-
play status will show “HEATING”.
Steam Function End
Press the “STANDBY” icon to stop the appliance.
The display will show the “STANDBY” icon.
Steam function
Hold down steam lever Pon the handle to emit steam.
WARNING:
Water droplets may occur on first use, which may be due to
incomplete heat stabilisation in the housing. For this reason,
we recommend aiming the first steam jet at a cloth until an
even flow of steam is achieved.
INFO:
For sensitive materials carry out a test first on a sample or
on an inconspicuous, concealed area. A
8
P
STEAM VACUUM
HEATING
WATER
Status:
MENU STANDBY

10
9
Start-up steam with hot water module Start-up suction
The soaking effect and, thus, cleaning performance can be
increased for heavy soiling by switching the hot water mo-
dule to steam.
INFO:
Do not use on sensitive surfaces or materials.
Switching on “hot water module”
Pressing button
T4
on the handle for the hot water module
switches the function on and symbol Non the display stays
illuminated.
Always use button
T4
on the handle to switch the hot water
module on and off.
The flow of the “washing-extraction” function may be adjus-
ted, by keeping button Cin three steps.
This is displayed by
notches
markedwith 1-2-3 inside the “WATER” icon.
Suction
Press the “VACUUM” icon on the display or the button
T3
for activating or deactivating the suction.
Keep the “VACUUM” icon pressed to switch between the
three suction flows: MINIMUM-MEDIUM-MAXIMUM (the
flow is displayed by notches marked with 1-2-3 inside the
"MOTOR" icon).
INFO:
As there is liquid in the hose and in the extension pipes du-
ring suction operation, the sucker should not disconnected
immediately after cleaning finishes.
A short delay (approx. 30 seconds) is required.
P
T4
T3
T4
T3
STEAM VACUUM
HEATING
WATER
Status:
MENU STANDBY
STEAM VACUUM
PAUSE
WATER
Status:
MENU STANDBY

11
12
Reports
Maximum fill level in the filter bowl
If the suctioned dirt in the filter bowl reaches the maximum
level, the fill level sensors ensure that suction stops automa-
tically.
To continue with cleaning work:
• Remove the filter bowl, empty and fill with tap water up
to the MAX. level indicated, using the integrated siphon
within the filter bowl (approx. 0,52 gal)
• Re-insert the filter bowl, ensuring it is in the correct posi-
tion.
WARNING:
Regularly remove and clean the installation parts from the
filter bowl in the event of heavy soiling. Return to the correct
position afterwards.
Lack of water in the tank
A lack of water in the tank is indicated by the error E01
shown on the display and by an acoustic signal at the same
time.
To resume work, follow the instructions on the display, by
clicking in the “Tap for other info” area.
Lack of water washing-extraction func-
tion
A lack of water in the tank is indicated by the error E02
shown on the display and by an acoustic signal at the same
time.
To resume work, follow the instructions on the display, by
clicking in the “Tap for other info” area.
Tap f or
other
info
Error:
MENU STANDBY
Refill hot water tank
Tap f or
other
info
Errore:
MENU STANDBY
Refill water tank
Tap f or
other
info
Error:
MENU STANDBY
Empty waste tank

12
13
Shutting down
To ensure the functionality, cleanliness and hygiene of the
appliance and accessories, follow this procedure to shut
down the appliance:
1) Remove the filter bowl, empty out the water and re-insert.
2) Set the suction mode to MIN (one notch within the "MO-
TOR" icon).
3) Clean the suction tube and accessory parts in suction
mode.
Suck approx. 0,52 gal of a solution of water and neutral de-
tergent through the accessory parts used (steam tube, ex-
tension tube, etc.) to clean.
INFO:
Repeat the rinsing process with clear water if there is a lot
of foam.
Alternatively, the steam suction hose can also be cleaned
using a suitably sized sponge soaked in disinfectant.
4) Empty the filter bowl, clean and re-insert without cover.
5) Switch off the functions you have selected by pressing the
relevant buttons on the display. The appliance switches off
after approx. 60 seconds.
6) Disconnect from the mains power by pulling out the plug.
7) Pull the steam suction hose out of the appliance for it to
dry out.
8) Store the appliance with open filter bowl in a well ventila-
ted and frost-free room.
T4
T3

NO ATTACHMENT
Carpet / Curtains / Furniture
Mattresses / Soft Surfaces
Windows / Mirrors / Walls
All hard surfaces
Squeegee / Brush Insert
Squeegee Insert
Carpet / Curtains / Furniture
Mattresses / Soft Surfaces
NO ATTACHMENT
Squeegee / Brush Insert
Windows / Mirrors / Walls
All hard surfaces
Small Extraction Nozzle
Large Extraction Nozzle
13
___________________________________________________________
Your steam vacuum uses a separate reservoir tank to i nject water into the steam as
it’s released from the extraction nozzle. Use the extraction function in combination
with the vacuum for deeper cleaning on soft and hard surfaces.
ØUse the extraction nozzle for cleaning furniture, curtains, mattress, windows, walls,
and floors
ØAfter cleaning, use the vacuum to remove excess water for faster drying.
32
Pos.(3)
Entkalkungsanleitung B
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functionality of the
appliance. Te connections on the extension pipes and the safety handle can be sprayed with a
suitable lubricant or silicone spray as required. This will make it easier to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the extension
pipes must be checked regularly for damage. The O-rings will last longer if they are coated regularly
with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for damage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for damage:
Pos(3): 2 O-rings on the brass spout
Checking O-rings on the extension pipes
Check the O-rings on all extension pipes for damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Cleaning, care and maintenance of accessories
Pos.(1) Pos.(2)
Pos.(4) Pos.(5)
You can order a suitable set of O-rings from our online shop at
www.beam.de or by telephone on [phone].
Item no.: 96300
Pos.(3)
Entkalkungsanleitung B
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functionality of the
appliance. Te connections on the extension pipes and the safety handle can be sprayed with a
suitable lubricant or silicone spray as required. This will make it easier to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the extension
pipes must be checked regularly for damage. The O-rings will last longer if they are coated regularly
with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for damage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for damage:
Pos(3): 2 O-rings on the brass spout
Checking O-rings on the extension pipes
Check the O-rings on all extension pipes for damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Cleaning, care and maintenance of accessories
Pos.(1) Pos.(2)
Pos.(4) Pos.(5)
You can order a suitable set of O-rings from our online shop at
www.beam.de or by telephone on [phone].
Item no.: 96300
Check the O-rings on the safety handle for da-
mage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for da-
mage:
Pos(3): 2 O-rings on the brass spout
Check the O-rings on all extension pipes for
damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functio-
nality of the appliance. Te connections on the extension pipes and the safety handle can
be sprayed with a suitable lubricant or silicone spray as required. This will make it easier
to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the
extension pipes must be checked regularly for damage. The O-rings will last longer if they
are coated regularly with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Checking O-rings on the extension pipes
Pos. (1) Pos. (2)
Pos. (3)
Pos. (4) Pos. (5)
Extraction
Squeegee Insert

Hose
(Part # SV7778)
Extension Wands –Sold Individually
(Part # SV1594) Floor Brush (# SV5672)
Floor Brush Adaptor (SV#1835)
Squeegee Insert (SV#1530
SET: SVFB-Large
Small Extraction Nozzle
(Part # SV7314) Large Extraction Nozzle
(Part # SV8011)
14
Long Jet Nozzle
(Part # SV5439)
Short Jet Nozzle
(Part # SV5439)
Vacuum Attachment
(Part # SV5645)
Brushes
1” Round Nylon
1” Round Brass
3” Round Nylon
3” Triangle Nylon
3” Round Brass
Squeegee / Brush Insert
(SV#8012)
Squeegee Insert
(SV#8015)
Squeegee Insert
(SV#7329)
Squeegee / Brush Insert
(SV7326)
32
Pos.(3)
Entkalkungsanleitung B
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functionality of the
appliance. Te connections on the extension pipes and the safety handle can be sprayed with a
suitable lubricant or silicone spray as required. This will make it easier to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the extension
pipes must be checked regularly for damage. The O-rings will last longer if they are coated regularly
with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for damage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for damage:
Pos(3): 2 O-rings on the brass spout
Checking O-rings on the extension pipes
Check the O-rings on all extension pipes for damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Cleaning, care and maintenance of accessories
Pos.(1) Pos.(2)
Pos.(4) Pos.(5)
You can order a suitable set of O-rings from our online shop at
www.beam.de or by telephone on [phone].
Item no.: 96300
Pos.(3)
Entkalkungsanleitung B
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functionality of the
appliance. Te connections on the extension pipes and the safety handle can be sprayed with a
suitable lubricant or silicone spray as required. This will make it easier to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the extension
pipes must be checked regularly for damage. The O-rings will last longer if they are coated regularly
with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Check the O-rings on the safety handle for damage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for damage:
Pos(3): 2 O-rings on the brass spout
Checking O-rings on the extension pipes
Check the O-rings on all extension pipes for damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Cleaning, care and maintenance of accessories
Pos.(1) Pos.(2)
Pos.(4) Pos.(5)
You can order a suitable set of O-rings from our online shop at
www.beam.de or by telephone on [phone].
Item no.: 96300
Check the O-rings on the safety handle for da-
mage:
Pos.(1): 1 O-ring on the suction pipe
Pos.(2): 2 O-rings on the steam spout
Check the O-rings on the connector for da-
mage:
Pos(3): 2 O-rings on the brass spout
Check the O-rings on all extension pipes for
damage:
Pos.(4): 1: O-ring on the suction pipe
Pos.(5): 2 O-rings on the steam spout
Care of accessories
It is essential to clean accessory parts after use to maintain the performance and functio-
nality of the appliance. Te connections on the extension pipes and the safety handle can
be sprayed with a suitable lubricant or silicone spray as required. This will make it easier
to change accessory parts.
Checking the O-rings
To avoid damage to the appliance or accessories, the O-rings on the safety handle and the
extension pipes must be checked regularly for damage. The O-rings will last longer if they
are coated regularly with a lubricant/ silicone spray or a non-acidic grease.
Checking the O-rings
Checking O-rings on the extension pipes
Pos. (1) Pos. (2)
Pos. (3)
Pos. (4) Pos. (5)
Accessories (order at www.ussteam.net)

PROBLEM SOLUTION
The Blue Evolution powers ON
after plugging into the electrical
outlet and then turns OFF
This is normal:
ØPush the ON/OFF Button on the console to power ON the Blue
Evolution
Does not turn power up when the
ON button is pushed:
The Blue Evolution should be the ONLY appliance plugged into the
electrical outlet:
ØCheck the fuse box for tripped circuit breaker
ØExtension Cord must meet the following requirements:
v12 gauge / 15AMP minimum rating
v25 ft. max length
Alarm is activated
during warm-up
The Blue Evolution has pumped all the water from the reservoir tanks into
the boiler:
ØRefill the steam reservoir tank
ØPush the ON/OFF button on the console to restart the pump
Alarm is activated
during use
The Blue Evolution is out of water:
ØRefill tanks
ØPush the ON/OFF button to reset the Blue Evolution
No vacuum suction
alarm will activate
The collection tank is dirty or full of water:
ØEmpty and clean
ØRefill with water to the green fill line
No Vacuum Suction
No alarm
ØCheck hose for foreign objects or dirt
ØCollection tank lid is attached correctly and
vAttach the lid to the tank before installing
vLid must sit flush on the collection tank and in the locked into
position
ØCheck and replace the filter as needed
No steam when squeezing trigger
ØIs the temperature on the console ≥330 ℉?
ØCheck the hose connection
ØIs the trigger safety lock engaged?
No water is released
during extraction
Check the spray nozzle for mineral build up
ØDescale as needed to remove
Error Codes
01 –Refill steam tank
02 –Refill extraction tank
03 –Boiler did not refill
04 –Vacuum collection tank is full
05 -Descale boiler
06 –Replace UVC lamp
07 –Boiler overheated
08 -Replace anti-scaling filter
10 –Service Required
12 –Boiler too hot for de-scaling
15
Troubleshooting
ERROR CAUSE REMEDY
Aspiration is turned off, an acoustic
signal is heard and error E04 is dis-
played.
Filter bowl full Empty the filter bowl and refill with
tap water up to the Max. fill level.
Fluff, fibres or hair in the filter bowl Empty the filter bowl, clean out the
hair and fluff and refill with tap water
up to the Max. fill level
Foam in the filter bowl Empty the filter bowl and refill with
tap water up to the Max. fill level.
Tip: To minimise foam build-up, add
3 drops of non-acidic oil (e.g.: sew-
ing machine or light vegetable oil) to
the filter bowl
There is little or no steam and no
hot water
Limescale in hot water modul Perform “Hot water descaling”
(Service/Maintenance – Part 1)
Steam very wet Limescale in boiler and probe cap Perform “Boiler descaling” (Service/
Maintenance – Part 2)
Hot water is switched on Briefly press button (T4) on the
handle or button (C) on the display
There is no hot water Hot water not switched on Briefly press button (C) on the dis-
play and then button (T4) on the
handle
Reservoir tank (P) is empty Fill reservoir tank (P) hot water with
clear tap water
Suction is not working Filter bowl not in position Re-insert filter bowl. Important: the
lug on the cover must sit in the gui-
de on the appliance
Not switched on on the display Press briefly on button (B) on the
display; suction can then be swit-
ched on using button (T3) on the
handle
No suction Polyester filter dirty (optional) Wash with plenty of warm water
and neutral detergent. If damaged
replace it.
Foreign body or dirt in the hose or
accessory
Check hose and accessory and
clean as required
Strange noises while suction Polyester filter (optional) dirty or
not in the right position
Check the filter about dirt and the
position
15

16
19
Service/Maintenance Part 1
Hot water module descaling

17
21
INFO : Up to 0,52 gal of water may flow from the drain plug if the reservoir is full.
Remove the sound-proong casing on the un-
derside of the appliance. To remove, loosen
the middle xing screw by hand, which will en-
able you to fold down, detach and remove the
sound-proong casing.
Place a suitable container under the appliance
and open the drain plug by turning it to the left
with the included Inbus key (label yellow ring
“Hot Water Extraction”). Drain the reservoir and
then screw the drain plug back in and tighten
slightly (Do not screw too tight).
1. Préparation
a)
b)
1. Remove sound-proofing cover

18
22
2. Descaling
Hot water module descaling
WARNING: Descaler residue can be harmful to health and damage surfaces. Wipe
up drops immediately. Read the information on the descaler packaging and follow the
safety instructions.
Mix 0,05 gal of descaler and 0,08 gal of tap
water in a dosing bottle.
Open the washing-extraction cap (P) and pour
the mixture.
Insert the steam-suction tube into the ap-
pliance.
Now, connect the appliance to the mains and
press icon (C) on the display.
The “WATER” icon will be activated.
Press the steam trigger on the handle and pour
the contents onto a basin.
Repeat the descaling procedure two to three
times if you notice any residual limescale.
a)
b)
STEAM VACUUM
PAUSE
WATER
Status:
MENU STANDBY
A B C
23
3. Rinsing
Pour 0,13 gal of clear tap water into the was-
hing-extraction tank. Connect the appliance to
the mains and press (C) icon on the display.
The “WATER” icon will be activated.
Press the steam trigger on the handle.
and pour the contents on a basin.
Repeat the procedure to rinse any residual li-
mestone.
Your appliance is now ready for use again.
a)
23
3. Rinsing
Pour 0,13 gal of clear tap water into the was-
hing-extraction tank. Connect the appliance to
the mains and press (C) icon on the display.
The “WATER” icon will be activated.
Press the steam trigger on the handle.
and pour the contents on a basin.
Repeat the procedure to rinse any residual li-
mestone.
Your appliance is now ready for use again.
a)
Descaling Solution is a mixture of 4 cups of vinegar and 4 cups of tap
water.

19
24
Service/Maintenance Part 2
Boiler descaling

20
25
Descaling instructions boiler / introduction
The boiler must be descaled, at the latest, when the error E05 appears on the display. Be-
cause the hardness of the water varies signicantly depending on the location, scheduled
descaling may need to be brought forward if you notice a signicant drop in steam emission,
or particles of limescale coming out of the steam accessories.
MAKE SURE THE APPLIANCE HAS COOLED DOWN COMPLETELY
Warning! Descalers can be harmful. Read the information on the descaler packaging and
follow the safety instructions.
Descalers or vinegar may cause damage to surfaces. Wipe up drops immediately. Only use
suitable and recommended descalers.
Only perform descaling on a cooled appliance.
Recommended descaler:
Entkalkungsanleitung B
You must perform descaling at the latest when the “Probe cap with Clean” symbol appears on the
display. As water quality varies hugely by region, descaling may also be required before this. Check
the probe cap for limescale accordingly. Heavy limescale build-up indicates that descaling is required.
Warning: Only perform probe check on a cooled appliance.
Fig.01
Warning! Descalers can be harmful. Read the information on the descaler packaging and follow the
safety instructions.
Descalers or vinegar may cause damage to surfaces. Wipe up drops immediately. Only use suitable
and recommended descalers.
Only perform descaling on a cooled appliance.
Recommended descaler:
beam descaler item no.: 8050
Descaling instructions boiler / introduction
Fig. 1
\n\nThe procedure must be
completed completely.
To start the descaling procedure
press the OK button.
ATTENTION!
Descaling procedure
BACK OK
26
1. Preparation
Boiler descaling / step 1
a)
b)
- Warning: Before starting, disconnect from the main power by pulling out oft he
plug.
Remove the sound-proong casing on the un-
derside of the appliance. To remove, loosen
the middle xing screw by hand, which will en-
able you to fold down, detach and remove the
sound-proong casing.
Place a suitable container under the appliance
and open the drain plug by turning it to the
left with the included Inbus key (label blue ring
“Water Only”).
Drain the reservoir and then screw the drain
plug back in and tighten slightly (Do not screw
too tight).
