UVPLUS ULTIMATE UVP101R User manual

IP20 245x155x121mm
1.2kg
3-4h
UVC LED 120°
Type C
MAX 11W
275nm UVC 5mg/min
Hand-held
Irradiance:
5000μW/cm²
REV-ODS
Reverse Obstacle
Detection System
2cm
Sensor distance 7.4V/2600 mAh Li-ion UV: 3-3.5h O3: 15-16h
Input Output
5V 2A Work light specifications
Center box
Irradiance:
240μW/cm²
Intelligent UV & OZONE Disinfection Box ULTIMATE
UVP101R
UVC Light germicidal system intends for use in general purpose

• Double-effect disinfection combination, fully reflect the high efficiency of ULTRAVIOLET disinfection and 360° no
blind angle of OZONE disinfection.
• A multi-purpose box can meet the using demands of whole family along with realizing the classified disinfection and
mobile disinfection.
• The metal deposition in the disinfection box can strengthen the reflection efficiency and realize 360° all-round
disinfection without blind angle.
• The inside of disinfection box is equipped with the interlayer, which can increase the disinfection area to the backside
of articles after the ultraviolet is reflected from the inner bottom of box.
• The design of Hall Switch for the disinfection box, opening the box will automatically stop the disinfection work,
which can effectively avoid the damage of ultraviolet or ozone to human body.
• During the hand-held using, REV-ODS intelligent Reverse Obstacle Detection System will start automatically. If
detecting the distance between the light source of disinfection light head and the surface of articles to be disinfected
exceeds 2cm, it will automatically stop the disinfection work, and reach the safe energy-efficient effects.
• In case of disinfecting the surface of articles by independently hand-held using, it is usually able to kill 99.9%
bacteria and virus on the surface or articles within 3 to 5 seconds.
• With the intelligent button operation interface, it is able to independently select and adjust the disinfection mode and
disinfection time.
• Color LCD screen can display the information e.g. disinfection mode, disinfection time and state of charge etc. in real
time.
• UVP101R has the memory function. After starting the machine each time, the screen will display the mode and time
of disinfection work for the last time.
• Type-C charging, portable and durable.
Schematic Diagram of Product:
Color LCD screen
Button of Ozone disinfection
Master switch
Button of UVC disinfection
Type C charging port
Disinfection lamp cap
Upper cover
Lower box
REV-ODS sensor
Ozone generator
UVC LED
Product Features:

• After starting the machine, please select language: short press “ ”to select English
• Long press both of “ ” and “ ” for more than 5 seconds, the unit will automatically switch
off and reset the language selection, you can reselect language in the next use
I. Disinfection lamp cap is fixed with upper cover of box and lower Box (Mode 1). (ULTRAVIOLET mode or
OZONE mode are optional for disinfection)
1. Long press “ ” for 1.5 seconds to start the machine，the screen displays “Double-click start / stop
disinfection” for 5 seconds. If not performing any operation after starting the machine, it will
automatically switch off after 30 seconds for the energy conservation and environment protection.
2. The screen displays “Fixed use” to indicate the installation for disinfection lamp, upper and lower box
of box is completed; If there is any separation between disinfection lamp cap, upper cover of box and
lower box of box, and then the screen will display “Handheld use”.
3. Short or long press “ ” to select “O3 60 min” or “O3 120 min”mode.
4. Short or long press “ ” to select “UVC 5 min”, “UVC 10 min” or “UVC 30 min” mode.
5. After selecting the disinfection mode, double-click “ ” to start disinfection, the screen displays
“Disinfecting…”.
6. In case of any separation between disinfection lamp cap, upper cover of box and lower cover of box in
the course of disinfection, it will automatically stop the disinfection work, and the time will return to the
preset time.
7. In the progress of disinfection, double-click “ ” to stop working, and time will return to the preset
time.
8. Long press “ ” during the disinfection to switch off the machine.
9. Short press any button during the disinfection will not be effective.
10. It will automatically stop the ozone work in the last 10 minutes of preset time in the course of ozone
disinfection, and activate the ultraviolet automatically to perform 10-minute ozonolysis.
11. If the battery level is lower than 20% and the battery level displays in red “ ” ，it is required to
charge as soon as possible to avoid that the remaining battery power is insufficient to finish one
complete disinfection.
12. If the screen displays “Disinfection finished” and time displays the green number 0, it indicates the
disinfection work is completed.
13. After the disinfection work is completed, it will automatically switch off after 30 seconds if not
performing any operation for the energy conservation and environment protection.
14. The disinfection lamp cap has the memory function: After starting the machine each time, the screen
will display the mode and preset time of disinfection work for the last time.
II. Separate hand-held operation for disinfection lamp cap (Mode 2). (Only ULTRAVIOLET disinfection
mode)
1. Long press “ ” for 1.5 seconds to start the machine，the screen displays “Double-click start / stop
disinfection” for 5 seconds. If not performing any operation after starting the machine, it will
automatically switch off after 2 minutes for the energy conservation and environment protection.
2. The preset mode is “UVC 60 min”, double-click “ ” to start disinfection.
3. The intelligent REV-ODS system will start automatically during the disinfection
• If REV-ODS system doesn’t detect the articles to be disinfected, the screen will display “Please move
closer”, and unit will automatically stop the disinfection work, It will automatically switch off after 2
minutes for the energy conservation and environment protection
UVC
UVC
Operation Instruction:

• If REV-ODS system detects the articles to be disinfected, unit will automatically resume the disinfection
work, and screen will display “Disinfecting…”, and unit will continue the previous work for time
countdown
4. In the progress of disinfection, double-click “ ” to stop working, and time will return to the preset
time “60 min”.
5. Long press “ ” during the disinfection to switch off the machine.
6. Short press any button during the disinfection will not be effective.
7. If the screen displays “Disinfection finished” and time displays the green number 0, it indicates the
disinfection work is completed.
8. After the disinfection work is completed, it will automatically switch off after 30 seconds if not
performing any operation for the energy conservation and environment protection.
Suggested Time for Disinfection Articles (Mode-1, disinfection lamp cap is fixed with upper cover of
box and lower box):
1. Time suggestion for ultraviolet disinfection:
• As for the ordinary small-sized articles, such as mobile phone, watch, pen, key chain etc., it is
suggested to disinfect for 5 minutes
• As for the ordinary middle-sized articles, such as mask, milk bottle etc., it is suggested to disinfect for
10 minutes
• As for the professional article disinfection, it is suggested to appropriately extend the disinfection time
2. Time suggestion for ozone disinfection:
• As for the ordinary article disinfection, it is suggested to disinfect for 60 minutes
• As for the professional article disinfection, it is suggested to appropriately extend the disinfection time
SAFETY WARNING:
1. Please read and understand this user manual before use, to ensure that the product is safely and
properly used
2. Our Company shall not be liable for product damage and other injuries caused by improper use or
failure to follow this User Manual.
3. Strictly forbid any children 0-12 years old to use this product. Users should carefully select places
without children before use and ensure that children do not touch the product.
4. Avoid the risk of electric shock during use.
5. The use of this product in gas, flammable and explosive substances, and heat source environments is
prohibited.
6. Don’t use wet hands in operating the product. Please keep the operating environment dry
7. Do not remove, repair and alter the product by oneself. Repairs and battery replacements can only be
carried out by authorized service providers and manufacturers, and repair and replacement of batteries
by authorized service providers and personnel other than manufacturers may result in injury. Replacing
the battery with the wrong model is a risk of explosion
8. Use the product only at specified voltages and frequencies
9. UV Light Hazard. Harmful to bare skin and eyes. Can cause temporary or permanent loss of vision.
Never look at the bulbs while illuminated. Any exposed skin must not be exposed to UV light

CAUTION:
UVC-Equipment Damage Hazard.
1. Ultraviolet light can cause color shift or structural degradation of plastic materials
2. Ultraviolet light can cause color shift or structural degradation of resin materials
3. Ultraviolet light can cause color shift or structural degradation of leatherwear
4. Ultraviolet light can cause color shift or structural degradation of organic compounds materials
OZONE-Equipment Damage Hazard.
1. OZONE can cause color shift or structural degradation of plastic materials
2. OZONE can cause color shift or structural degradation of resin materials
3. OZONE can cause color shift or structural degradation of leatherwear
4. OZONE can cause color shift or structural degradation of organic compounds materials
5. High concentrations of ozone for a long time can cause electronic products function damage
NOTES:
1. The design of this product based on IEC 62471:2006 Photobiological safety of lamps and lamp
systems and other international standards
2. This product utilizes the ultraviolet rays LED , which emits UV-C rays with peak value wave length at
275nm to disinfect
3. Ultraviolet LED is a relatively tight and fragile electronic component, users should avoid the impact on
the product resulting in product failure.
4. The design of this product is according to Code of Federal Regulations Title 21, Volume 8 by US FDA,
California Code of Regulations Title 17 Public Health, and IEC 62368-1[4] 7.3 and other international
standards
5. According to code of federal Regulations Title 21, Volume 8, ozone is a toxic gas, according to the FDA.
Although ozone has been reported to have adverse physiological effects on the central nervous
system, heart and vision, its main physiological effect is to stimulate the mucous membranes.
Inhalation of ozone causes enough irritation to the lungs, leading to pulmonary edema. The onset of
pulmonary edema is usually delayed by several hours after exposure; As the hazards of ozone are
widely understood, people pay full attention to the use of ozone.
6. At Ozone concentrations of 0.02PPM (0.04mg/m³), ozone can be smelled by people with acute
olfactory senses, at 0.15PPM (0.32mg/m³), ozone can be smelled by the general population, at
1-10PPM (2.14 - 21.4mg/m³) ozone has reached the "stimulus range", and can be clearly smelled, at
10PPM (21.4mg/m³) ozone has reached the "toxic range" or more "poisonous range". The odor of ozone
is not a reliable warning indicator due to the possibility of olfactory fatigue
7. Long term occupied enclosed spaces, such as houses, apartments, hospitals and offices, should have
ozone volumes below 0.1mg/m³ (0.05PPM). The ozone concentration in the workplace, i.e.
occupational exposure limit, is 0.1PPM
8. The amount of space used by the equipment used to place and use this device should not be less than
20m³ to ensure that the ozone remaining in the equipment has sufficient space to be decomposed to a
safe level when the cabinet door is opened
9. When opening the equipment for ozone disinfection, make sure that the equipment is in a well
ventilated environment. If the equipment cannot be ensured to be in a well-ventilated environment,
only open the cabinet door at least 30 minutes after an ozone disinfection session has finished
10. Ozone is unstable, breaks down rapidly at high temperatures, slowly breaks down to (oxygen) at room

temperature, has a half-life of about 16 minutes in 1% of ozone solution and about 25 minutes in the air.
11. Pure ozone, if receives impact or friction, will explode and decompose. High concentrations of ozone
when heated is also prone to explosion. But as long as care is taken, such accidents are rather rare.
Ozone should not have high concentrations of flammable and explosive gases at the disinfection site
when it is used for air disinfection.
12. The user use 3M8514 welding protection mask (or equal grade protection masks) when use ozone to
disinfect, and can process ozone protection which at 10 times occupation touch limit potency under
1PPM
13. This product set enough safety device to guarantee the safety of users. The daily item to item check is
the necessary condition to guarantee that safety use the equipment. Please process item to item check
according to the requirements in the specification, need stop use the equipment immediately once
found the problem.
14. Because of the instability of ozone, ultraviolet light accelerates the decomposition of ozone and
converts it back to oxygen. After the ozone work is completed, the equipment switches to UV mode to
quickly reduce the ozone concentration in the equipment. The user must never open the cabinet doors
before the device has completed the ozone disinfection operation (before the end of the timer
countdown in the monitor)
15. Users are advised to equip users with ozone concentration detection instruments to regularly detect
whether the leaked ozone value of the equipment exceeds the safe value: long term populated
enclosed spaces, such as houses, apartments, hospitals and offices, ozone must be less than 0.1PPM in
English. If ozone leakage value is found to have exceeded the above standard, the equipment must be
immediately stopped.
To guarantee the disinfect effect of UVC:
1. Whether UV light can effective disinfect depends on the amount of exposure received by the
disinfection object, which depends on the radiation power of the UV light source, the distance of the
disinfection object from the UV light source, and the duration of the exposure to UV light.
2. When killing common microorganisms, the irradiated dose should reach 10,000 μW/cm²; 100,000 μ
W/cm² is the recommended dose to kill bacterial spores. The radiation dose should not be less than
100,000 μW/cm² when the target microorganism for disinfection is unknown.
3. According to the radiation intensity of the UV light source of this product and the general distance of
the UV light source from the irradiated object, it is recommended that:
• In order to achieve the radiation dose of 10,000 μW/cm² to meet the general needs of daily use, the
exposure time should be at least above 60 seconds
• In order to achieve the radiation dose of 100,000 μW/cm² to meet the needs of the professional
environment, the exposure time should be at least above 500 seconds
To guarantee the ozone disinfect effect:
1. Ozone can kill bacterial reproductions, viruses, fungi, etc., and can destroy botulinum toxin. In order for
ozone to be effective as a disinfectant, its concentration must be much higher than that that can be
safely tolerated by humans and animals. Ozone has a powerful killing effect on microorganisms in the
air, and at the same time has the odor-removal characteristics, 30minutes of 20mg/m³ (9.35PPM)
concentration of ozone in a sealed environments can achieve disinfection effect. Ozone on the surface
of the items of the microorganism also has a killing effect, requiring 60mg/m³ (28.04PPM), relative
humidity of 70%, and exposure of 60 minutes to 120 minutes, to achieve disinfection effect.

2. If the equipment is stopped in the middle of the operation, the disinfection effect cannot be guaranteed,
a new disinfection session from the start will be necessary.
The reminding of damage about the disinfect objects:
1. The effects of ozone on a variety of substances vary considerably. Glass, stainless steel, butyl rubber,
silicone, polycarbonate, and ABS plastics are better at ozone resistance, but nylon, zinc,
glass-fibre-added plastics, and natural materials such as natural rubber and leather, are less resistant to
ozone.
2. In order to ensure the service life, this product is designed with ozone-resistant materials.
3. In order to examine the accelerated aging effect of ozone on substances, the substance was tested for
60 minutes at a time using ozone concentrations of 35PPM.
4. After 10 tests of six different leather material colors samples, the results show color fading and
hardening of the material, especially the brighter samples, whose fading was more pronounced
5. The same conditions were tested on stainless steel, aluminum, gold-plated PIN needles, silicone,
cotton pads, cotton and ABS plastics, and no significant decomposition was found
6. It is recommended to avoid ozone disinfection of brightly colored leather, silk and other items. Some
highly aged items, such as natural rubber, are also recommended to not undergo ozone disinfection.
Since ozone has an oxidative effect on most metals, users should not use ozone disinfection on
electronic products to avoid ozone damage to devices containing metal substances, such as circuit
boards in electronic products.
Equipment maintenance, please contact professional after-sales service stores or professionals

V1/HJ
WARNING HARMFUL OZONE may be created by this product.
Follow installation and operating instructions.
WARNING UV-C emitted from this product.
Avoid eye and skin exposure to unshielded product.
Follow installation instructions and user manual.
www.uvpluss.com
AEC Lighting Solutions Co., Ltd
Add.: 2548 Bao’an Highway, Jiading District, Shanghai 201801, China
Tel.: [phone]
www.aeclight-reel.com
