V-TAC VT-1231 User manual

POLE LAMP
INSTRUCTION MANUAL
MODEL VT-1231
SKU 11827
WATTS 60W
INPUT POWER AC:220-240V,50/60Hz
IP RATING IP44
HOLDER E27 [Bulb not included]
UNIT COLOR MATTE BLACK
MATERIAL Aluminium + PLASTIC
DIMENSION 200x200x970mm
TECHNICAL DATA
INTRODUCTION & WARRANTY
WARNING
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
instructions carefully before starting the installation and keep this manual handy for future reference.
If you have any another query, please contact our dealer or local vendor from whom you have
purchased the product. They are trained and ready to serve you at the best. The warranty is valid for
3 years from the date of purchase. The warranty does not apply to damage caused by incorrect
installation or abnormal wear and tear. The company gives no warranty against damage to any
surface due to incorrect removal and installation of the product. The products are suitable for 10-12
Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is
warranted for manufacturing defects only.!
• Ensure Electricity is switched o before installation
• Please read through all following instruction before installing the unit.
• User should prepare necessary accessories and spare parts (Not Provided)
• Installation must be performed by a qualified electrician
• Proper grounding should be ensured throughout the installation.
MULTI-LANGUAGE MANUAL QR CODE
Please scan the QR code to access the manual in
multiple languages.
INSTRUCTION MANUAL
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these
WEEE Number: 80133970

INSTALLATION DIAGRAM
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: [e-mail]
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
This marking indicates that this product
should not be disposed of with other
household wastes. Caution, risk of electric shock.
INSTALLATION INSTRUCTION
1. Turn o the power.
2. Mark drilling area with 135mm gap.
3. Drill the holes in the ground.
4. Dig the plastic into the hole.
5. Fix the screws in the holes.
6. Tighten the stand parts
7. Open the lamp to install the bulb.
8. Install the bulb on the holder.
9. Connect supply leads with terminal brown (L) to brown, blue (N)
to blue and greenish-yellow ( ) to greenish-yellow.
10. Tighten the srews to fix the wires.
11. Tighten the nuts to fix down the stand.
12. Check whole fitting is correct.
13. Turn on the Power
