VABCHES J3L211BS01 User manual

1/26
J3L211BS01
As this item contains many parts, please read the installation
instruction carefully before installation . Please use tools
properly and carefully. If you have any questions about the
product and installation, please contact us.
Our professional after-sales team will serve you online all
[e-mail]
day.
J3L211GR01
WhatsApp community↑

2/26
Before You Start
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware of to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw. （Assembly
speed can be increased by using electric screw driver）
Helpful Hints
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-03.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-04.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-05.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-010.bmp
.\Ameriwood Home Manual Template\Ameriwood Home Manual Template 3-012.bmp
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with an R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- If there is a back panel in the package, please install it to make sure your unit is
complete and sturdy.
-Please fix all the screws provided for the back panel which can enhance product
stability. If it is difficult to fix it when tightening, it can be fixed with the help of a
hammer and then tightened.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
PEOPLE NEEDED FOR ASSEMBLY: 1-2

3/26
TOP
Qty:1 Qty:1 Qty:1
D
Qty:1
E
Qty:1
F
Qty:1
PARTITION
G
Qty:1
H
Qty:2
I
Qty:1
Board Identification
Not actual size
J
Qty:1
K
Qty:1
L
Qty:1
FIXED SHELF BOTTOM BOARD
ABC
LEFT SIDE PANEL
RIGHT SIDE PANEL
PARTITION REAR PULL BAR LEFT FRONT LEG
RIGHT FRONT LEG LEFT HIND LEG RIGHT HIND LEG

4/26
M
Qty:1
R
Qty:2
Board Identification
Not actual size
DRAWER BOTTOM
MIDDLE FOOT
N
Qty:2
O
Qty:2
P
Qty:2
Q
Qty:2
DRAWER FRONT DRAWER LEFT SIDE
DRAWER RIGHT SIDE
DRAWER BACK PANEL

5/26
1X42 2X42 3X26
5X17 6X24
12"
7CL X2 X2
X2 X2
12"
7CR
12"
7DL
12"
7DR 9 X2
10 11 12
X20 13
Part List
Ø15X9.5mm Ø6X35mm Ø8X30mm
Ø4X35mm 300mm 300mm
300mm 300mm
Ø21mm
CAM LOCK
spare:3
CAM BOLT
spare:3
WOOD DOWEL
spare:3
SCREW
spare:2
SCREW
spare:2
LEFT CABINET MEMBER RIGHT CABINET MEMBER
LEFT DRAWER RUNNER RIGHT DRAWER RUNNER HANDLE
PERFECT STICKER
spare:2
4X8
Ø6X30mm
WOOD DOWEL
spare:1
Ø3.5X14mm
8X2
M4X8mm
SCREW
spare:1
X1set
STRIP OF LIGHTS
X3
SNAP
spare:1
SCREW
X1
M6X25mm

6/26
Cam Lock
Fastening
System
12
34
The opening must point toward the
edge of the board
Insert the cam bolt into the
hole first, then insert the cam
lock and lock it.
Part List
14 X1
CRIMPING BUCKLE
23*7*5mm
15 X5
Ø3X12mm
SCREW
spare:1
16 X1
TOOL
Ø4X65mm(25mm)
17 X2
GLUE

7/26
Board Identification
Not actual size
N
O
P
Q
R
A
B
C
D
E
F
G
H
H
I
J
K
L
M
N
O
P
Q
R

STEP1
8/26
L
J
K
I
2X16
Ø6X35mm
2

STEP2
9/26
D
E
2X4 3X12
Ø6X35mm Ø8X30mm
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue
17 X1
2
3

STEP3
10/26
I
D
K
J
E
L
1X8
Ø15X9.5mm
Proper orientation of CAM LOCK
UNLOCK
LOCK
1
17 X1
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue

STEP4
11/26
6X6
12"
7CL X1 X1
12"
7CR
300mm 300mm
Ø3.5X14mm
LEFT CABINET MEMBER
7CL
6
6
6
RIGHT CABINET MEMBER
7CR
6
6
6
D
E
UP
UP

STEP5
12/26
6X6
12"
7CL X1 X1
12"
7CR
300mm 300mm
Ø3.5X14mm
Flip
LEFT CABINET MEMBER
7CL
6
6
6
RIGHT CABINET MEMBER
7CR
6
6
6
G
G
UP
UP

STEP6
13/26
G
F
3X6
Ø8X30mm
4X8
Ø6X30mm
HX2
3
Ø8X30mm
4
Ø6X30mm
17 X1
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue

STEP7
14/26
C
B
2X6 3X8
Ø6X35mm Ø8X30mm
3
2
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue
17 X1

STEP8
15/26
B
F
5X3
Ø4X35mm
5
17 X1
B
90°
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue

STEP9
16/26
BG
1X2
Ø15X9.5mm
1
Proper orientation of CAM LOCK
UNLOCK
LOCK
17 X1
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue

STEP10
17/26
B
G
H
H
1X4
Ø15X9.5mm
Proper orientation of CAM LOCK
UNLOCK
LOCK
1
17 X1
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue

STEP11
18/26
C
M
12 X1
M6X25mm
16 X1
Ø4X65mm(25mm)
16
12

STEP12
19/26
5X6
Ø4X35mm
B
H
H
G
C
5
17 X1
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue

STEP13
20/26
C
D
E
1X12
Ø15X9.5mm
B
1
16 X1
Ø4X65mm(25mm)
17 X1
16
Use one drop of glue before
the wooden dowel
Hole for wooden dowel
Wooden Dowel
Glue
Proper orientation of CAM LOCK
UNLOCK
LOCK
The space here is relatively small,
and tool 16 is recommended
