Vacon NX series User manual

vacon nx
ac drives
rfi-, du/dt- and sine-filters
user manual
®

vacon • 1
24-hour support [phone] • Email: [email protected]
TABLE OF CONTENTS
Document ID:DPD01805A
Revision release date: 25.05.2016
1. General .......................................................................................................................2
1.1 Intended use.......................................................................................................................... 2
1.2 Safety notice .......................................................................................................................... 2
1.3 General .................................................................................................................................. 3
1.4 Type designation code........................................................................................................... 4
2. Filter types..................................................................................................................5
2.1 RFI-filters .............................................................................................................................. 5
2.1.1 General....................................................................................................................5
2.1.2 RFI filter types......................................................................................................... 6
2.1.3 External RFI filter types.......................................................................................... 9
2.2 dU/dt filters ......................................................................................................................... 12
2.2.1 General.................................................................................................................. 12
2.2.2 dU/dt filter types ................................................................................................... 16
2.2.3 Installation ............................................................................................................ 19
2.3 Sine filters ........................................................................................................................... 25
2.3.1 General.................................................................................................................. 25
2.3.2 Sine filter types ..................................................................................................... 26
2.3.3 Installation ............................................................................................................ 28
3. Drawings and diagrams ............................................................................................ 32
3.1 Dimension drawings............................................................................................................ 32
3.1.1 RFI footprint filters ............................................................................................... 32
3.1.2 External RFI filters................................................................................................ 36
3.1.3 dU/dt- and sine-filters .......................................................................................... 38
3.2 dU/dt-filters in enclosed drive ............................................................................................ 46
3.3 Safe operating area for dU/dt-filters.................................................................................. 52
3.4 Output current for frequency operation ............................................................................. 57
NOTE! You can download the English and French product manuals with applicable safety,
warning and caution information from
http://drives.danfoss.com/knowledge-center/technical-documentation/.
REMARQUE Vous pouvez télécharger les versions anglaise et française des manuels produit
contenant l’ensemble des informations de sécurité, avertissements et mises en garde
applicables sur le site http://drives.danfoss.com/knowledge-center/technical-documentation/
.

1
vacon • 2 General
Tel. [phone] • Fax [phone]
1. GENERAL
1.1 Intended use
This document covers the following filter types:
• RFI - filters on the input side, and
• dU/dt - filters and sine - filters on the output side of the (Vacon NX) AC drive.
1.2 Safety notice
WARNING: All internal components and component boards, with the
exception of the galvanically separated input and output terminals
are connected to high voltage when the AC drive is connected to the
mains. It is extremely dangerous to touch these live parts. Touch may
cause severe injury or death.
NOTE!
The I/O terminals are separated from the high potential of the mains, but the relay
outputs and other I/O terminals may carry high voltages even if the AC drive is not
connected to the mains.
NOTE!
Do not perform any high pot tests (megger) on the filters. The Vacon_RFI_ filters are
intended for use in earthed supplies only. For unearthed (IT) supplies, contact our
representative or us.
13006 emf

General vacon • 3
24-hour support [phone] • Email: [email protected] 1
General safety instructions
Grounding
Screening
1.3 General
AC drives do not supply a smoothly changing AC voltage to the motor, but a pulsed DC voltage. The
sum of the three phase voltage does not sum to zero, as in the case of mains supply, leading to the
presence of a common mode voltage between the motor coils and ground.
The pulses fed to the motor have very steep flanks, and the rate of voltage change (dU/dt) may reach
several kV/us. Unloaded IGBTs will switch at speeds of about 6 - 8 kV/us, when a motor cable and
motor is connected, and the speed will drop to about 2 kV/us. The voltages caused by these steep
pulses may be dangerous to the insulation of the motor.
Warning: Installation and service work only by qualified electricians.
No work on an operating unit. Contact with the electrical parts may
be fatal, even after disconnection from the power network.
To avoid electrical shock hazard:
- Before servicing the unit, wait at least the voltage discharge time
stated in the design guide for the corresponding converter.
- Dangerouse voltage may be on the unit even when the motor is not
rotating.
Never attempt to repair a defective unit.
The unit surface temperature rises during operation. Avoid any
contact.
The unit must be grounded before switching the power on.
Please refer to the data sheet for detailed information.
It is recommended to use shielded cables to reduce noise,
electromagnetic interferences noise and to prevent malfunctions in
the installation.
Preferably:
• Screened and/or twised cable between the converter output and unit
input (U1, V1, W1).
• Shielded cables between the unit output (U2, V2, W2) and the motor.
• In case of unscreened cables it should be ensured that the installa-
tion minimizes the possibility of cross-couplings with other cables
which are carrying sensitive signals. This can be achieved by mea-
sures such as cable segregation and mounting in earthed cable
trays.
9000.emf
9000.emf
9000.emf
9000.emf
9001.emf
13006.emf
13006.emf

1
vacon • 4 General
Tel. [phone] • Fax [phone]
The high switching speeds give rise to EMC effects, both as radiated disturbances as well as
disturbance currents in galvanically connected cables. The radiated interference is usually
grounded by the metallic enclosure of the drive as well as through the use of shielded cable, and
does not cause any problems in the environment. The galvanically coupled interference may have to
be filtered in order to achieve EMC compliance. The Vacon NX range of AC drives contain an internal
filter for bringing the drives into compliance with the standard (specifically IEC 61800-3:2004). In
some cases, an additional filtering is required. Both input and output filters are available for the
Vacon NX range of drives. The drive may also have to be protected against various overvoltages
occurring in the supply. On the input side RFI filters and additional chokes can be installed, on the
output side dU/dt filters or sine filters.
1.4 Type designation code
Figure 1. Type designation code for Vacon NX filters
DUT-0012-6-0-P-UL
UL = UL listed accessories
P = Manufacturer identification
0 = Enclosure class
5 = nominal voltage:
0012 = Maximum current [A]
0 = IP00
2 = IP20
5 = IP54
2 = 200 V
5 = 520 V
6 = 690 V
DUT = filter type
RFI = radio frequency filter
DUT= du/dt-filter
SIN = sinusoidal filter
7118_uk

Filter types vacon • 5
24-hour support [phone] • Email: [email protected] 2
2. FILTER TYPES
2.1 RFI-filters
2.1.1 General
The Table 1 shows the filters used to make the Vacon NX range of AC drives comply with EN/IEC
61800-3 for the domestic and industrial environment, in case the basic drive does not comply. All
frame sizes 4 - 9 comply with the requirements of EN/IEC 61800-3, ed 2 for the categories 1 and 2,
the 690 V versions for category 3. The common DC bus system components and drives which have
rated current higher than 400 A are designed to category 4. Therefore the basic modules do not have
any specific compliance, but the whole installation has to be designed to comply with the
requirements.
The stand - alone and NXC solutions comply with category 3 requirements.
Definitions:
First environment
Environment that includes domestic premises and establishments directly connected without
intermediate transformers to a low-voltage power supply network, which supplies buildings used
for domestic purposes
NOTE! Houses, apartments, commercial premises or offices in a residential building are typical
examples of the first environment location.
Second environment
Environment that includes all establishments other than those directly connected to a low voltage
power supply network, which supplies buildings used for domestic purposes
NOTE! Industrial areas, technical areas of any building fed from a dedicated transformer are typical
examples of the second environment locations (IEC 923/04).
EMC designation C => fulfils the requirements of category 1: PDS (power drive system (AC drive plus
motor)) of rated voltage less than 1000 V, intended for use in the first environment
EMC designation H => fulfils the requirements of category 2: PDS of rated voltage less than 1000 V,
which is neither a plug in device nor a movable device and, when used in the first environment, is
intended to be installed and commissioned only by a professional
NOTE! A professional is a person or an organisation having necessary skills in installing and/or
commissioning power drive systems, including their EMC aspects.
EMC designation L => fulfils the requirements of category 3: PDS of rated voltage less than 1000 V,
intended for use in the second environment and not intended for use in the first environment
EMC designation N => fulfils the requirements of category 4: PDS of rated voltage equal to or above
1000 V, or rated current equal to or above 400 A, or intended for use in complex systems in the
second environment
NOTE! In this case the compliance has to be verified case by case.
The filters must be correctly installed and grounded.
There are no standards at present for IT supplies (floating supplies) - the EMC code T shows that
the drives and drive modules have very small earth capacitance making them suitable for use on IT
supplies. The small capacitance is required as larger values would cause the installed earth circuit
monitoring circuits to fail. We recommend the use of monitors manufactured by Bender.

2
vacon • 6 Filter types
Tel. [phone] • Fax [phone]
The Vacon NX AC drives comply with the immunity requirements EN/IEC 61800-3; 2004, second
environment as standard.
Note that the filters RFI-0012-5-IP54 to RFI-0105-5-IP54 are designed to fit mechanically directly to
the corresponding drive. All others are loose and must be connected to the drive separately.
2.1.2 RFI filter types
Table 1. RFI footprint filters for drive for drive frame sizes 4-7
Suitability
Table 2. Drive suitability for 200VAC & 500VAC air cooled drives frame sizes 4-7
Installation
Figure 2. RFI filter installation principal diagram
Filter type code Drawing
number
Manufacturer's
part code
Rated vol-
tage, 3~, 50-
60Hz [VAC]
Nominal
current at
50°C [A]
Dimensions
W x H x D [mm] W[kg] IP class
RFI-0012-5-IP54 70CTC1100857 FS32821-16-99 520 16 128 x 395 x 61.5 2.8 IP54
RFI-0031-5-IP54 70CTC1100865 FS32821-42-99 520 42 144 x 490 x 61.5 4.4 IP54
RFI-0061-5-IP54 70CTC1100869 FS32821-75-99 520 75 195 x 625 x 90 8.2 IP54
RFI-0105-5-IP54 70CTC1100887 FS32821-130-99 520 130 230 x 745 x 100 15.5 IP54
200VAC drive Filter 500VAC drive Filter
NX_0003-0012 2 RFI-0012-5-IP54 NX_0003-0012 5 RFI-0012-5-IP54
NX_0017-0031 2 RFI-0031-5-IP54 NX_0016-0031 5 RFI-0031-5-IP54
NX_0048-0061 2 RFI-0061-5-IP54 NX_0038-0061 5 RFI-0061-5-IP54
NX_0075-0088 2 RFI-0105-5-IP54 NX_0072-0105 5 RFI-0105-5-IP54
#Reference #Reference
A Keypad C Power unit
B Control D RFI filter
7119_00
A
B
C
D
L1
L2
L3
U/T1
V/T2
W/T3
DC-
DC+/R-
R-

Filter types vacon • 7
24-hour support [phone] • Email: [email protected] 2
Footprint RFI-filter types can be installed in two ways. Back installation procedure is shown in
Figure 3 and side installation procedure is shown Figure 4.
Figure 3. RFI filter back installation
#Reference #Reference
1ø72
Max screw length for AC drive
mounting; M6x16
7120_00
1
1
2
2
2
1
1
2

2
vacon • 8 Filter types
Tel. [phone] • Fax [phone]
Figure 4. RFI filter side installation
Dimension data
Detailed dimension drawings in Chapter 3.1.
#Reference #Reference
1ø72
Max screw length for AC
drive mounting; M6x16
Amin.20mm
7121_00
1
1
1
2
2
A

Filter types vacon • 9
24-hour support [phone] • Email: [email protected] 2
2.1.3 External RFI filter types
The external filters must be mounted close to the input of the drive or drive system. Note that the
cable layout must be such, that the maximum physical separation exists between the filter input and
output cables. Otherwise the effect of the filter could be negated.
Table 3. External RFI filter types
Suitability
Table 4. Drive suitability for 200VAC, 500VAC and 690VAC air cooled drives
Table 5. Drive suitability for 500Vac and 690VAC liquid cooled drives
Filter type code Manufacturer's part
code
Rated voltage,
3~, 50-60Hz
[VAC]
Nominal
current at
50°C [A]
Nominal
current at
40°C [A]
Power loss
[W] IP class
RFI-0130-5-0 FN3258H-130-35 520 130 142,4 43.1 IP20
RFI-0150-5-0 FN3359-150-28 520 150 164 24 IP00
RFI-0250-5-0 FN3359-250-28 520 250 250 49 IP00
RFI-0320-5-0 FN3359-320-99 520 320 350 19 IP00
RFI-0400-5-0 FN3359-400-99 520 400 438 29 IP00
RFI-0600-5-0 FN3359-600-99 520 600 657 44 IP00
RFI-1000-5-0 FN3359-1000-99 520 1000 1095 60 IP00
RFI-0042-6-0 FN258HV-42-33 690 42 46 30 IP20
RFI-0100-6-0 FN258HV-100-35 690 100 109.5 30 IP20
RFI-0180-6-0 FN3359HV-180-28 690 180 197 34 IP00
RFI-0300-6-0 FN3359HV-320-99 690 320 350 19 IP00
RFI-0400-6-0 FN3359HV-400-99 690 400 438 29 IP00
RFI-0600-6-0 FN3359HV-600-99 690 600 657 44 IP00
RFI-1000-6-0 FN3359HV-1000-99 690 1000 1095 60 IP00
200VAC drive Filter 500VAC drive Filter 690VAC drive Filter
NX_ 0075-0114 2 RFI-0130-5-0 NX_ 0072-0105 5 RFI-0130-5-0 NX_0004-0034 6 RFI-0042-6-0
NX_0140 2 RFI-0150-5-0 NX_0140 5 RFI-0150-5-0 NX_0041-0080 6 RFI-0100-6-0
NX_0170-0205 2 RFI-0250-5-0 NX_0168-0205 5 RFI-0250-5-0 NX_0125-0170 6 RFI-0180-6-0
NX_0261-0300 2 RFI-0320-5-0 NX_0261-0300 5 RFI-0320-5-0 NX_0208-0261 6 RFI-0300-6-0
NX_0385 RFI-0400-5-0 NX_0325-0385 6 RFI-0400-6-0
NX_0520-0590 5 RFI-0600-5-0 NX_0416-0590 6 RFI-0600-6-0
NX_0650-0920 5 RFI-1000-5-0 NX_0650-820 6 RFI-1000-6-0
500VAC drive Filter 690VAC drive Filter
NX_0087-0105 5 RFI-0130-5-0 NX_0170 6 RFI-0180-6-0
NX_0140 5 RFI-0150-5-0 NX_0208-0261 6 RFI-0300-6-0
NX_0168-205 5 RFI-0250-5-0 NX_0325-0385 6 RFI-0400-6-0
NX_0261-0300 5 RFI-0320-5-0 NX_0416-0590 6 RFI-0600-6-0
NX_0385 5 RFI-0400-5-0 NX_0650-0920 6 RFI-1000-6-0
NX_0460-0590 5 RFI-0600-5-0
NX_0650-0920 5 RFI-1000-5-0

2
vacon • 10 Filter types
Tel. [phone] • Fax [phone]
Installation recommendations:
The motor cable must be kept as short as possible both inside and outside the enclosure. This
means that the optimum location for the drive is close to the driven motor in wall mounted units or
close to the cable conduit hole in enclosed units.
Separate the supply cable and the motor cable by at least 20 cm (8"). If it isn't possible to achieve
spatial separation, use a separator shield, which must be solidly and multiply grounded. The cable
from the filter to the drive must be shielded. The grounding must be done through a large area.
If several drives are used, check if it is feasible to use one common filter for all drives. In that case,
additional filtering of the drives is unnecessary. The cable between the filter and the drives should
be kept as short as possible. This usually means, that the drives and filter are mounted adjacent to
one another.
Ground the filter over a large surface to the mounting plate or the back of the enclosure. If the plate
is varnished, remove the varnish to ensure a good electrical connection at the screw locations.
All metal parts of the enclosure must be connected to one another with low impedance, large area
cables. The door must be grounded through short flexible leads to the frame of the enclosure
Cross the cables at the right angle (90°)
Connect all unused poles of all cables to the ground

Filter types vacon • 11 24-hour support [phone] • Email: [email protected] 2
Dimension data
Table 6. External RFI filter dimension data
Detailed dimension drawings in Chapter 3.1.
Dimensions Weight
Filter type
code
Drawing
number A B C D E F G H I J K L L2 M N O S T U V W X Y Z X* Y* Z* m [kg]
RFI-0130-5-0 70CMC10375 270 90 150 240 255 65 7 2 45 M10 45 64 4.5
RFI-0150-5-0 70CMC10377 300 210 120 160 120 185 12 233 M10 55 30 420 171 127 50 6.5
RFI-0250-5-0 70CMC10377 300 230 125 180 120 205 12 233 M10 66 35 420 191 132 55 7
RFI-0320-5-0 70CMC10376
70CMC10379 300 260 115 210 120 235 12 2 43 M12 20 20 440 221 122 60 25 6 15 40 11 10.5
RFI-0400-5-0 70CMC10376
70CMC10379 300 260 115 210 120 235 12 2 43 M12 20 20 440 221 122 60 25 6 15 40 11 10.5
RFI-0600-5-0 70CMC10376
70CMC10379 300 260 135 210 120 235 12 2 43 M12 20 20 510 241 177 60 25 8 15 40 11 11
RFI-1000-5-0 70CMC10376
70CMC10379 350 280 170 230 145 255 12 3 53 M12 25 25 510 241 177 60 40 8 20 50 14 18
RFI-0042-6-0 70CMC10378 329 70 185 300 314 45 7 2 25 M6 35 130 AWG8 500±10 12 2.6
RFI-0100-6-0 70CMC10378 379 90 220 350 364 65 7 2 45 M10 45 130 5.6
RFI-0180-6-0 70CMC10377 300 210 120 160 120 185 12 2 33 M10 55 30 420 171 127 50 6.5
RFI-0300-6-0 70CMC10376
70CMC10379 300 260 115 210 120 235 12 243 M12 20 20 440 221 122 60 25 615 40 11 10.5
RFI-0400-6-0 70CMC10376
70CMC10379 300 260 115 210 120 235 12 243 M12 20 20 440 221 122 60 25 615 40 11 10.5
RFI-0600-6-0 70CMC10376
70CMC10379 300 260 135 210 120 235 12 243 M12 20 20 440 221 142 60 25 815 40 11 11
RFI-1000-6-0 70CMC10376
70CMC10379 350 280 170 230 145 255 12 353 M12 25 25 510 241 177 60 25 820 50 14 18

2
vacon • 12 Filter types
Tel. [phone] • Fax [phone]
2.2 dU/dt filters
2.2.1 General
The Vacon NX drives use IGBT transistors as an output element. These semiconductors create the
correct voltage to the motor switching it at very high speed (4 - 6 kV/s) with an unloaded IGBT. This
high speed will, under certain circumstances, cause extra voltage stress on the main insulation of
the motor.
Usually there are no problems with motors designed for a 400 V supply. Such motors are usually
designed for a voltage level of 1200 V, which exceeds the AC drive induced stress.
In 500 V supplies the motor has to withstand at least 1600 V. A dU/dt filter is often required with
these motors in order not to exceed the allowable voltage stress. In 690 V supplies the motor has to
withstand at least 1800 V, and a dU/dt filter is required in these cases.
NOTE! In uncertain cases, confirm the rating of the motor in AC drive application with the motor
manufacturer.
NOTE! Set the switching frequency parameter to correspond to the value printed on nameplate of
the filter and the output voltage level. Do not increase the switching frequency above the filter rated
value, decreasing it below is allowed.
The high switching speed (about 2 kV/s) with the motor and cable connected, creates a travelling
wave in the cable. The speed of this wave is set by the cable's wave impedance, usually about 50 -
100 ohms. This is less than the motor's wave impedance, which is on the order of 1 kohm. As the
travelling voltage wave hits this discontinuity, it is reflected back, increasing the instantaneous
voltage on the motor winding. The wave is reflected back and forth between motor and drive and
finally the steady state voltage is reached.
Winding voltage stresses
The rapid change in voltage is not distributed equally over all windings, but the first windings show
higher voltage stresses than the inner ones, due to the capacitive coupling between the windings.
Modern motors can withstand a voltage rise times of < 2 kV/us. In case of doubt, use a dU/dt filter
or contact the motor manufacturer.
Figure 5. Change of the voltage shape in winding
#Reference #Reference
A Incoming pulse B Winding voltage
B
A
7122_00

Filter types vacon • 13
24-hour support [phone] • Email: [email protected] 2
Voltage stress
Figure 6. Voltage pulse reflection
The reflected voltage maximum value is 2 x DC link voltage, in practice 1,8...1,9 x UDC. The voltage
is fully developed at cable lengths > 5 m.
Note that the DC link voltage is increased if the supply is high or if an active front end maintains a
high DC link voltage or if the drive is in a regenerative (braking) mode. If this voltage stress is too
high, it is recommended to use the dU/dt filters.
A dU/dt filter is an undammed serial LC filter, with a resonance frequency of about 120 kHz - this
will limit the voltage rise speed to < 1000 V/us. If lower speeds are required, the capacitance can be
increased.
The filter, cable and motor form a complex high frequency circuit, which causes a voltage at the
motor with different rise times and peak values depending on the cable length, type etc.
7123_uk
Incoming pulse Ui
Reflected pulse Ur
Total Voltage = Ui+Ur=Ui(1+r)=2Ui ( )
ZoZi
r= Zi–Zo
Zi+Zo
Zi
Zi+Zo

2
vacon • 14 Filter types
Tel. [phone] • Fax [phone]
Typical values as a function of cable length are as follows:
Figure 7. Typical motor voltage p.u. as a function of motor cable length (m)
Due to the inductance in series with the load there is a voltage drop across the dU/dt filter,
decreasing the voltage available for the motor. At full rated current this drop is about 5 V.
Filters are chosen so that their rated current > drive rated current. They will thermally withstand
the same overload specifications as the drive. For Vacon NX there is only one range of filters,
suitable for the voltage range from 380 to 690 V. The filters can also be used at lower voltages, if
required.
NOTE! The dU/dt filters are designed for a switching frequency of 1,5 kHz for 690VAC and 3,6 kHz
for 500 VAC voltage level. DO NOT EXCEED THIS VALUE, as there is a risk of overheating. Using lower
switching frequencies is not a problem.
NOTE! The dU/dt filters are designed for the maximum output frequency of 70 Hz - if this value is
exceeded there is a risk of overheating. If higher output frequency is requested then the drive output
current is needed to decrease. Motor frequency de-rating for different filter types is shown in
Chapter 3.4.
7124_uk
0.5
1
1.5
2.0
2.5
0
0 100 200 300 400 500
Motor cable length [m]
Motor voltage p.u

Filter types vacon • 15
24-hour support [phone] • Email: [email protected] 2
Recommendations:
Figure 8 on page 15, Table 7 and Table 8 show the filter and motor requirements based on the
nominal voltage level and IEC & NEMA motor standards
Figure 8. IEC/TC60034-25: Limiting curves of impulse voltage Upk, measured between two motor phase
terminals, as a function of the peak rise time tr. Typical values achieved with Vacon AC drives.
Table 7. Recommendations of dU/dt usage based on the voltage class and motor insulation system
Table 8. Recommendations of dU/dt usage based on the voltage class and NEMA motor insulation
system, NEMA MG1, Part 31
Nominal voltage Un Filters and motor isolation requirements
Un ≤480 V No filters required if the motor insulation is
according to curve A - IEC/TS60034-25
Un ≤575 V dU/dt filter is needed for motor insulation according
to curve A - IEC/TS60034-25
or
No filters required if the motor insulation is
according to curve B - IEC/TS60034-25
Un ≤690 V dU/dt filter is needed for motor insulation according
to curve B - IEC/TS60034-25
or
No filter if motor is wound with medium voltage
technology - form wound
For motors with Un ≥600 V Upeak = 3,1 * Un
For motors with Un <600 V Upeak = 2,04 * Un
7125_u
k
0.2
0.4
0.6
0.8
1.0
1.2
1.4
1.6
1.8
2.0
2.2
2.4
0
0.01 0.2
1m
5m
20m
50m 100m
A
B
0.4 0.6 0.8 1.0 4.0
A=up to 500Vac
B=up to 690Vac
2.15 kV
1.56 kV
*=zero current
o=nominal current
Upk (kV)
tr(µs)

2
vacon • 16 Filter types
Tel. [phone] • Fax [phone]
2.2.2 dU/dt filter types
The available IP ratings are IP00, IP21 and IP54.
Table 9. dU/dt-filter types
*) IP00 filters DUT-0012-6-0-P - DUT-01500-6-0-P types are also available in UL listed accessories
models. Filter type code syntax is -UL and manufacturer's part code /UL e.g. DUT-0012-6-0-P-UL,
914-961/UL. Filter rated voltage for UL usage is 600VAC.
Filter type code Manufacturer's part
code
Rated voltage,
3~[VAC]
Nominal
current at
40°C [A]
Nominal
current at
50°C [A]
Power loss
at 40°C [W] IP class
DUT-0012-6-0-P* 914-961 200-690 12 10.5 45 IP00
DUT-0025-6-0-P* 918-988 200-690 25 22 85 IP00
DUT-0055-6-0-P* 923-947 200-690 55 48 120 IP00
DUT-0080-6-0-P* 927-936 200-690 80 70 140 IP00
DUT-0130-6-0-P* 942-1062 200-690 130 115 185 IP00
DUT-0210-6-0-P* 945-1017 200-690 210 185 210 IP00
DUT-0280-6-0-P* 957-952 200-690 280 245 350 IP00
DUT-0350-6-0-P* 958-936 200-690 350 310 410 IP00
DUT-0420-6-0-P* 958-934 200-690 420 370 450 IP00
DUT-0600-6-0-P* 959-904 200-690 600 530 580 IP00
DUT-0820-6-0-P* 959-905 200-690 820 720 750 IP00
DUT-1200-6-0-P* 978-925 200-690 1200 1055 980 IP00
DUT-1500-6-0-P* 983-916 200-690 1500 1320 1100 IP00
DUT-2300-6-0-P 998-917 200-690 2300 2020 2900 IP00
DUT-0012-6-2-P 917-964/S1 200-690 12 10.5 65 IP21
DUT-0034-6-2-P 918-1004/S1 200-690 34 30 85 IP21
DUT-0055-6-2-P 923-947/S1 200-690 55 48 120 IP21
DUT-0100-6-2-P 928-956/S1 200-690 100 88 150 IP21
DUT-0210-6-2-P 945-1017/S1 200-690 210 185 210 IP21
DUT-0012-6-5-P 913-940 200-690 12 10.5 45 IP54
DUT-0034-6-5-P 918-1009 200-690 34 30 75 IP54
DUT-0055-6-5-P 927-944 200-690 55 48 80 IP54
DUT-0100-6-5-P 943-1018 200-690 100 88 110 IP54
DUT-0210-6-5-P 958-949 200-690 210 185 180 IP54
DUT-0280-6-0-S FS7203-280-99-03 200-690 280 - - IP00
DUT-0420-6-0-S FS7203-420-99-03 200-690 420 - - IP00
DUT-0590-6-0-S FS7203-590-99-03 200-690 590 - - IP00
DUT-0820-6-0-S FS7203-820-99-03 200-690 820 - - IP00
DUT-1250-6-0-S FS7203-1250-99-03 200-690 1250 - - IP00
DUT-1600-6-0-S FS7203-1600-99-03 200-690 1600 - - IP00

Filter types vacon • 17
24-hour support [phone] • Email: [email protected] 2
Suitability
Table 10. Drive suitability for 200VAC air cooled drives
Table 11. Drive suitability for 500VAC air cooled drives
200VAC drive Filter, IP00 class 200VAC drive Filter,
IP 21 class
Filter,
IP 54 class
NX_0003-0012 2 DUT-0012-6-0-P - NX_0003-0012 2 DUT-0012-6-2-P DUT-0012-6-5-P
NX_0017-0025 2 DUT-0025-6-0-P - NX_0017-0031 2 DUT-0034-6-2-P DUT-0034-6-5-P
NX_0031-0048 2 DUT-0055-6-0-P - NX_0048 2 DUT-0055-6-2-P DUT-0055-6-5-P
NX_0061-0075 2 DUT-0080-6-0-P - NX_0061-0088 2 DUT-0100-6-2-P DUT-0100-6-5-P
NX_0088-0114 2 DUT-0130-6-0-P - NX_0114-0205 2 DUT-0210-6-2-P DUT-0210-6-5-P
NX_0140-0205 2 DUT-0210-6-0-P - ---
NX_0261 2 DUT-0280-6-0-P DUT-0280-6-0-S ---
NX_0300 2 DUT-0350-6-0-P DUT-0420-6-0-S ---
500VAC drive Filter, IP00 class 500VAC drive Filter,
IP 21 class
Filter,
IP 54 class
NX_0003-0012 5 DUT-0012-6-0-P - NX_0003-0012 5 DUT-0012-6-2-P DUT-0012-6-5-P
NX_0016-0022 5 DUT-0025-6-0-P - NX_0016-0031 5 DUT-0034-6-2-P DUT-0034-6-5-P
NX_0031-0045 5 DUT-0055-6-0-P - NX_0038-0045 5 DUT-0055-6-2-P DUT-0055-6-5-P
NX_0061-0072 5 DUT-0080-6-0-P - NX_0061-0087 5 DUT-0100-6-2-P DUT-0100-6-5-P
NX_0087-0105 5 DUT-0130-6-0-P - NX_0105-0205 5 DUT-0210-6-2-P DUT-0210-6-5-P
NX_0140-0205 5 DUT-0210-6-0-P - - - -
NX_0261 5 DUT-0280-6-0-P DUT-0280-6-0-S - - -
NX_0300 5 DUT-0350-6-0-P DUT-0420-6-0-S - - -
NX_0385 5 DUT-0420-6-0-P DUT-0420-6-0-S - - -
NX_0460-0590 5 DUT-0600-6-0-P DUT-0590-6-0-S - - -
NX_0650-0730 5 DUT-0820-6-0-P DUT-0820-6-0-S - - -
NX_0820 5 2 x DUT-0420-6-0-P 2 x DUT-0420-6-0-S - - -
NX_0920-1030 5 2 x DUT-0600-6-0-P 2 x DUT-0590-6-0-S - - -
NX_1150 5 DUT-1200-6-0-P DUT-1250-6-0-S - - -
NX_1300-1450 5 DUT-1500-6-0-P DUT-1600-6-0-S - - -
NX_1770 - 2150 5 2 x DUT-1200-6-0-P 2 x DUT-1250-6-0-S - - -
NX_2700 5 2 x DUT-1500-6-0-P 2 x DUT-1600-6-0-S - - -

2
vacon • 18 Filter types
Tel. [phone] • Fax [phone]
Table 12. Drive suitability for 690VAC air cooled drives
Table 13. Drive suitability for 500VAC liquid cooled drives
690VAC drive Filter, IP00 class 690VAC drive Filter,
IP 21 class
Filter,
IP 54 class
NX_0005-0010 6 DUT-0012-6-0-P - NX_0004-0010 6 DUT-0012-6-2-P DUT-0012-6-5-P
NX_0013-0022 6 DUT-0025-6-0-P - NX_0013-0034 5 DUT-0034-6-2-P DUT-0034-6-5-P
NX_0027-0052 6 DUT-0055-6-0-P - NX_0027-0052 6 DUT-0055-6-2-P DUT-0055-6-5-P
NX_0062-0080 6 DUT-0080-6-0-P - NX_0062-0080 6 DUT-0100-6-2-P DUT-0100-6-5-P
NX_0100-0125 6 DUT-0130-6-0-P - NX_0100-0208 6 DUT-0210-6-2-P DUT-0210-6-5-P
NX_0144-0208 5 DUT-0210-6-0-P - - - -
NX_0261 6 DUT-0280-6-0-P DUT-0280-6-0-S - - -
NX_0325 5 DUT-0350-6-0-P DUT-0420-6-0-S - - -
NX_0385-0416 6 DUT-0420-6-0-P DUT-0420-6-0-S - - -
NX_0460-0590 6 DUT-0600-6-0-P DUT-0590-6-0-S - - -
NX_0650 6 2 x DUT-0350-6-0-P 2 x DUT-0420-6-0-S - - -
NX_0750-0820 6 2 x DUT-0420-6-0-P 2 x DUT-0420-6-0-S - - -
NX_0920-1080 6 DUT-1200-6-0-P DUT-1250-6-0-S - - -
NX_1500 6 2 x DUT-0820-6-0-P 2 x DUT-0820-6-0-S - - -
NX_1900-2250 6 2 x DUT-1200-6-0-P 2 x DUT-1250-6-0-S - - -
500VAC drive Filter, IP00 class 500VAC drive Filter,
IP 21 class
Filter,
IP 54 class
NX_0016-0022 5 DUT-0025-6-0-P - NX_0016-0031 5 DUT-0034-6-2-P DUT-0034-6-5-P
NX_0031-0045 5 DUT-0055-6-0-P - NX_0038-0045 5 DUT-0055-6-2-P DUT-0055-6-5-P
NX_0061-0072 5 DUT-0080-6-0-P - NX_0061-0087 5 DUT-0100-6-2-P DUT-0100-6-5-P
NX_0087-0105 5 DUT-0130-6-0-P - NX_0105-0205 5 DUT-0210-6-2-P DUT-0210-6-5-P
NX_0140-0205 5 DUT-0210-6-0-P DUT-0280-6-0-S - - -
NX_0261 5 DUT-0280-6-0-P DUT-0280-6-0-S - - -
NX_0300 5 DUT-0350-6-0-P DUT-0420-6-0-S - - -
NX_0385 5 DUT-0420-6-0-P DUT-0420-6-0-S - - -
NX_0460-0590 5 DUT-0600-6-0-P DUT-0590-6-0-S - - -
NX_0650-0820 5 DUT-0820-6-0-P DUT-0820-6-0-S - - -
NX_0920-1150 5 DUT-1200-6-0-P DUT-1250-6-0-S - - -
NX_1370 5 DUT-1500-6-0-P DUT-1600-6-0-S - - -
NX_1640 5 2 x DUT-0820-6-0-P 2 x DUT-0820-6-0-S - - -
NX_2060-2300 5 2 x DUT-1200-6-0-P 2 x DUT-1250-6-0-S - - -
NX_2470-2950 5 2 x DUT-1500-6-0-P 2 x DUT-1600-6-0-S - - -
NX_3710-4140 5 4 x DUT-1200-6-0-P 4 x DUT-1250-6-0-S - - -
