Vacon 500X User manual

vacon 500x
ac drives
users manual

Tel. [phone] • Fax [phone]
1 zvacon summary of vacon 500x
SUMMARY OF VACON 500X PARAMETERS
No. Parameter Name Options Default User Setting See Page
001 Model Number Model dependent Read-only 61
002 Software Rev 0.00-99.99 Read-only 61
003 Rated Current 0.0-200.0 A Read-only 62
005 Serial No. 1 0-65535 Read-only 62
006 Serial No. 2 0-65535 Read-only 62
007 USB Soft. Rev 0.00 - 99.99 Read-only 62
008 Option Installed text string Read-only 62
009 Fbus Soft. Rev 0.00 - 99.99 Read-only 62
030 Pwr Down Date dd/mm/yy Read-only 62
031 Pwr Down Time Dd/hh/mm (Dd = Tu, Th, etc.) Read-only 62
102 Output Freq 0.0-400.0 Hz Read-only 62
103 Output Voltage 0-600 V Read-only 62
104 Output Current 0.0-200.0 A Read-only 62
105 Drive Load -200.0-200.0% Read-only 63
106 Load Torque -200.0-200.0% Read-only 63
107 Drive Temp -20.0-200.0 °C Read-only 63
108 Total Run Time 0.0-6553.5 h Read-only 63
109 Power On Hours 0-65535 h Read-only 63
110 Stator Freq 0.0-400.0 Hz Read-only 63
111 DC Bus Voltage 0 - 1000 Vdc Read-only 63
115 Drive Power Out 0.0-200.0% Read-only 63
116 Out Power (kW) 0.0 - 327.67 Read-only 63
117 MWh Meter 0 - 32767 Read-only 63
118 kWh Meter 0.0 - 999.9 Read-only 63
120 Today’s Date MM/dd/YY Read-only 63
121 Today’s Time hh:mm Read-only 63
150
Show Clock
Parameters
(Parameters 151-
179)
text string 0 (No) 64
151 Tiime Zone Setup text string 12 (-5 East. US) 64
152 TOD Run Enable 0-23 hours, 0-59 min 12:00 64
154 TOD Run Disable 0-23 hours, 0-59 min 12:00 64
156 TOD Run En 2 0-23 hours, 0-59 min 12:00 64
158 TOD Run Dis 2 0-23 hours, 0-59 min 12:00 64
160 Weekend TOD En 0-23 hours, 0-59 min 12:00 64
162 Weekend TOD Dis 0-23 hours, 0-59 min 12:00 64
171 Reminder 1 Conf. text string 0 (disabled) 65
172 Reminder 1 Time 1-32000 hours 1 65
173 Reminder 1 ETA +/- 32000 hours Read-only 65
174 Reminder 2 Conf. text string 0 (disabled) 65
175 Reminder 2 Time 1-32000 hours 1 65
176 Reminder 2 ETA +/- 32000 hours Read-only 65
177 Reminder 3 Conf. text string 0 (disabled) 65

24-hour support [phone] • Email: [email protected]
summary of vacon 500x parameters vacon z2
178 Reminder 3 Time 1-32000 hours 1 65
179 Reminder 3 ETA +/- 32000 hours Read-only 65
201 Input Mode text string Local Only 66
202 Rev Enable text string Forward 66
203 Stop Key Remote text string Coast 66
204 Ref Select text string Vin1 67
205 Vin1 Config text string 0-10V 67
206 Vin1 Offset 0.0% to 100.0% 0.00% 67
207 Vin1 Span 10.0% to 200.0% 100.00% 67
208 Cin Config text string 0-20mA 50 67
209 Cin Offset 0.0% to 100.0% 0.0% 68
210 Cin Span 10.0% to 200.0% 100.0% 68
211 Vin2 Config text string 0-10V 68
212 Vin2 Offset 0.0% to 100.0 % 0.00% 68
213 Vin2 Span 10.0% to 200.0% 100.00% 68
214 Vin1 Filter Time 0 to 1000 ms 20 ms 68
215 Cin Filter Time 0 to 1000 ms 20 ms 68
216 Vin2 Filter Time 0 to 1000 ms 20 ms 68
217 Trim Ref Enable
(Set k-Factor) text string 0 69
218 Trim % Factor -100.0 - 100.0% 0.0% 69
301 Min Frequency 0.0 - Max Freq. 0.0 Hz 69
302 Max Frequency 20.0 - 400.0 Hz 60.0 Hz 69
303 Preset Freq 1 Min Freq-Max Freq 5.0 Hz 69
304 Preset Freq 2 Min Freq-Max Freq 10.0 Hz 69
305 Preset Freq 3 Min Freq-Max Freq 20.0 Hz 69
306 Preset Freq 4 Min Freq-Max Freq 30.0 Hz 69
307 Preset Freq 5 Min Freq-Max Freq 40.0 Hz 69
308 Preset Freq 6 Min Freq-Max Freq 50.0 Hz 69
309 Cut-off Freq 0.0 - 5.0 Hz 0.0 Hz 70
310 Preset Freq 7 Min Freq-Max Freq 60.0 Hz 69
311 Preset Freq 8 Min Freq-Max Freq 0.0 Hz 69
312 Preset Freq 9 Min Freq-Max Freq 2.5 Hz 69
313 Preset Freq 10 Min Freq-Max Freq 7.5 Hz 69
314 Preset Freq 11 Min Freq-Max Freq 15.0 Hz 69
315 Preset Freq 12 Min Freq-Max Freq 25.0 Hz 69
316 Preset Freq 13 Min Freq-Max Freq 35.0 Hz 69
317 Preset Freq 14 Min Freq-Max Freq 45.0 Hz 69
318 Preset Freq 15 Min Freq-Max Freq 55.0 Hz 69
380 Keeper Input Cfg text string 4 (disabled) 70
381 Keeper Max Scale 0-32000 1000 70
382 Keeper Save Time 00:00 - 23:59 0:00 70
384 Keeper Save Rate text string 0 (24 hour) 70
385 Keeper Input
Value 0-32000 Read-only 70
No. Parameter Name Options Default User Setting See Page

Tel. [phone] • Fax [phone]
3 zvacon summary of vacon 500x
386 Keeper Time Rate text string 1 (minute) 70
387 Keeper Rec. Num 0-255 Read-only 70
388 Active Kpr. Record 0-255 Read-only 71
389 Keeper Units text string 1 (GPM) 71
401 Ramp Select text string ART-DI 71
402 Accel Time 1 0.1-3200.0 sec 5.0 sec 71
403 Decel Time 1 0.1-3200.0 sec 5.0 sec 72
404 Accel Time 2 0.1-3200.0 sec 3.0 sec 72
405 Decel Time 2 0.1-3200.0 sec 3.0 sec 72
406 DC Inject Config text string DC at Stop 72
407 DC Inject Time 0.0-5.0 sec 0.2 sec 72
408 DC Inject Level 0.0% to 100.0% 50.0% 72
409 DC Inj Freq 0.0 to 20.0 Hz 0.0 Hz 72
410 DB Config text string Internal 73
414 S Ramp Rounding 1 - 100% 25% 73
415 Accel Time 3 0.1-3200.0 sec 10.0 sec 73
416 Decel Time 3 0.1-3200.0 sec 10.0 sec 74
417 Accel Time 4 0.1-3200.0 sec 15.0 sec 74
418 Decel Time 4 0.1-3200.0 sec 15.0 sec 74
490 App Macro text string Factory 74
491 Seq Appl text string Disabled 74
492 SIO Visible text string No 74
501 V/Hz Select text string Linear Fixed 75
502 Voltage Boost 0.0-50% 1.0% 75
503 V/Hz Knee Freq 25.0-400.0 Hz 60.0 Hz 75
504 Skip Freq Band 0.2-20.0 Hz 0.2 Hz 76
505 Skip Freq 1 Min Freq-Max Freq 0.0 Hz 76
506 Skip Freq 2 Min Freq-Max Freq 0.0 Hz 76
507 Skip Freq 3 Min Freq-Max Freq 0.0 Hz 76
508 Skip Freq 4 Min Freq-Max Freq 0.0 Hz 76
509 Rated Mtr Volt 100V-690V Model
dependent 76
510 Rated Mtr FLA 50% - 200% of ND Rating ND Rating 76
511 Rated Mtr RPM 0-24000 rpm 1750 rpm 76
512 Midpoint Freq 0.0 Hz-V/Hz Knee Freq 60.0 Hz 76
513 Midpoint Volt 0.0-100.0% 100.0% 76
514 Motor RS 0.0-655.35 Ohms Model
dependent 76
515 Power Factor 0.50-1.00 0.80 76
516 Slip Comp Enable text string No 77
517 Single Phase text string No 77
519 Find Mtr Data Not active / Motor RS Not active 77
520 Filter FStator 1 - 100 ms 8 ms 77
521 Start Field En text string No 77
522 Filter Time Slip 10 - 1000 ms 100 ms 77
No. Parameter Name Options Default User Setting See Page

24-hour support [phone] • Email: [email protected]
summary of vacon 500x parameters vacon z4
523 Id Percent 0 - 200% Read-only 78
524 Iq Percent 0 - 200% Read-only 78
525 Power Fail Config text string CTS No Msg 78
526 UV Ride-Thru En text string w/ LVT 78
600 Current Lim Sel text string 0 79
601 Cur Lim Mtr Fwd 5%-150% 120% 79
602 Cur Lim Mtr Rev 5%-150% 120% 79
603 Cur Lim Reg Fwd 5%-150% 80% 79
604 Cur Lim Reg Rev 5%-150% 80% 79
605 Cur Lim Freq 0.0 - 400.0 Hz 3.0 Hz 79
606 Ramp Time CL 0.1-3200.0 sec 1.0 sec 79
607 Cur Limit
Minimum 0 - 50% 10% 79
608 Restart Number text string 0 80
609 Restart Delay 0-60 sec 60 sec 80
610 Timed OL Select text string 0 (Std Ind 60s) 80
613 Max Regen Ramp 100 - 1000% 300% 81
700 Vmet Config text string Freq Out 81
701 Vmet Span 0.0-200.0% 100.0% 81
702 Imet Config text string Drive Load 82
703 Imet Span 0.0-200.0% 100.0% 82
704 Imet Offset 0.0-90.0-% 0.0% 82
705 Relay 1 Select text string 1 (Drv Fault) 83
706 Relay 2 Select text string 2 (Drive Run) 83
707 DO1 Select text string 0 (Drv Ready) 83
708 DO2 Select text string 6 (At Speed) 83
720 Active Logic text string 1 (Active High) 83
721 DI1 Configure text string 0 (Preset 1) 84
722 DI2 Configure text string 1 (Preset 2) 84
723 DI3 Configure text string 2 (Preset 3) 84
724 DI4 Configure text string 6 (Alt Ramp) 84
725 DI5 Configure text string 7 (Fault Reset) 84
726 MOL Polarity text string 1 (NO Operate) 85
727 MOL Configure text string 21 (MOL) 84
740 Thres 1 Select text string 9 (Load High) 85
741 Thres 1 High -300.00 to 300.00% 100.00% 85
742 Thres 1 Low -300.00 to 300.00% 0.00% 85
743 Thres 2 Select text string 15 (Current
High) 85
744 Thres 2 High -300.00 to 300.00% 100.00% 86
745 Thres 2 Low -300.00 to 300.00% 0.00% 86
746 Timer 1 Type text string 0 (On Delay) 86
747 Timer 1 Signal text string 1 (Drv Fault) 86
748 Timer 1 Time 0.0 - 320.0 sec 1.0 sec 86
749 Timer 2 Type text string 0 (On Delay) 86
No. Parameter Name Options Default User Setting See Page

Tel. [phone] • Fax [phone]
5 zvacon summary of vacon 500x
750 Timer 2 Signal text string 1 (Drv Fault) 86
751 Timer 2 Time 0.0 - 320.0 sec 1.0 sec 86
794 Drive Name text string serial number 86
799 Config USB Mode text string 0 (Disabled) 87
801 Program Number 0-9999 087
802 Start Options text string 0 (LS Lockout) 87
803 PWM Frequency 0.6-16.0 kHz 3.0 kHz 88
804 Display Mode text string 0 = Std Disply 88
805 Display Units alphanumeric 0 (blank) 88
809 Display Scale 1-65535 18000 88
810 Language text string 0 (English) 88
811 Access Code 0-9999 0 89
812 Freq Ref Output text string 0 (6FS) 89
813 Speed Ratio 0.0-200.0% 100.0% 89
814 Display Status text string 0 (Drive load) 89
816 Fly Catch Mode text string 0 (Sweep FWD) 89
819 Flt Text #1 text string User Flt 1 89
825 Flt Text #2 text string User Flt 2 90
850 PID Configure text string 0 (No PID) 90
851 PID FBk Config text string 0 (Vin1) 90
852 PID Prop Gain 0-2000 0 90
853 PID Int Gain 0-10000 0 90
854 PID Feed Gain 0-2000 1000 90
855 PID Error 1 0.00-100.00% Read-only 90
856 PID Error 2 0.00-100.00% Read-only 90
857 PID High Corr 0.00-100.00% 100.00% 90
858 PID Low Corr 0.00-100.00% 0.00% 90
859 PID Deriv Gain 0-200 0.00% 91
860 PID Sleep Cfg text string 0 (disabled) 91
861 PID Sleep Lvl 0.00-100.00% 0.00% 91
862 PID Wake-up Lvl 0.00-100.00% 100.00% 91
863 Sleep Delay Time 0.0-300.0 sec 0.0 sec 91
864 Wake-up Delay 0.0-300.0 sec 0.0 sec 91
865 PID Feedback 0.00-100.00% Read-only 91
866 PID Reference 0.00-100.00% Read-only 91
867 PID User Units text string 0 (No) 91
880 FBus Read 1 0-65535 103 92
881 FBus Read 2 0-65535 104 92
882 FBus Read 3 0-65535 105 92
883 FBus Read 4 0-65535 107 92
884 FBus Read 5 0-65535 909 92
890 FBus Write 1 0-65535 907 92
891 FBus Write 2 0-65535 402 92
892 FBus Write 3 0-65535 403 92
No. Parameter Name Options Default User Setting See Page

24-hour support [phone] • Email: [email protected]
summary of vacon 500x parameters vacon z6
893 FBus Write 4 0-65535 920 92
894 FBus Write 5 0-65535 921 92
900 SIO Protocol text string 0 (RTU N81) 92
901 SIO Baud Rate text string 2 (9600) 92
902 Comm Drop # 1-247 1 92
903 SIO Timer 0.0-60.0 sec 1.0 sec 92
904 SIO Cntl Word Bit 0-15 0x0000 93
905 Ext Ref Freq1 Min-Max Freq 0.0 Hz 93
906 Ext Ref Freq2 Min-Max Freq 0.0 Hz 93
907 Cntl Word 2 Bit 0-15 0x0000 93
908 Status Word Bit 0-15 Read-only 94
909 DI Status Bit 0-14 Read-only 94
910 Vin1 Status 0.00-100.00% Read-only 94
911 Cin Status 0.00-100.00% Read-only 94
912 Vin2 Status 0.00-100.00% Read-only 94
913 Output Status Bit 0-5 Read-only 94
914 Vmet Status 0.00-100.00% Read-only 95
915 Imet Status 0.00-100.00% Read-only 95
916 Infrared Baud text string 2 (9600) 95
917 FBus Port Config text string 1 (485 w/ctl) 95
920 SIO Vmet Level 0.00-100.00% 100.00% 95
921 SIO Imet Level 0.00-100.00% 100.00% 95
926 Status Word 2 Bit 0-2 Read-only 95
930 Seq Cntl 1 Bit 0-15 (hex control) 0x0000 96
931 Seq Cntl 2 Bit 0-15 (hex control) 0x0000 96
932 Seq Cntl 3 Bit 0-15 (hex control) 0x0000 96
933 Seq Cntl 4 Bit 0-15 (hex control) 0x0000 96
934 Seq Cntl 5 Bit 0-15 (hex control) 0x0000 96
935 Seq Cntl 6 Bit 0-15 (hex control) 0x0000 96
936 Seq Cntl 7 Bit 0-15 (hex control) 0x0000 96
937 Seq Cntl 8 Bit 0-15 (hex control) 0x0000 96
938 Seq Cntl 9 Bit 0-15 (hex control) 0x0000 96
939 Seq Cntl 10 Bit 0-15 (hex control) 0x0000 96
940 Seq Cntl 11 Bit 0-15 (hex control) 0x0000 96
941 Seq Cntl 12 Bit 0-15 (hex control) 0x0000 96
942 Seq Cntl 13 Bit 0-15 (hex control) 0x0000 96
943 Seq Cntl 14 Bit 0-15 (hex control) 0x0000 96
944 Seq Cntl 15 Bit 0-15 (hex control) 0x0000 96
945 Seq Cntl 16 Bit 0-15 (hex control) 0x0000 96
946 Seq Cntl 17 Bit 0-15 (hex control) 0x0000 96
947 Seq Cntl 18 Bit 0-15 (hex control) 0x0000 96
948 Seq Cntl 19 Bit 0-15 (hex control) 0x0000 96
949 Seq Cntl 20 Bit 0-15 (hex control) 0x0000 96
950 Seq Cntl 21 Bit 0-15 (hex control) 0x0000 96
No. Parameter Name Options Default User Setting See Page

Tel. [phone] • Fax [phone]
7 zvacon summary of vacon 500x
951 Seq Cntl 22 Bit 0-15 (hex control) 0x0000 96
952 Seq Cntl 23 Bit 0-15 (hex control) 0x0000 96
953 Seq Cntl 24 Bit 0-15 (hex control) 0x0000 96
954 Seq Cntl 25 Bit 0-15 (hex control) 0x0000 96
955 Seq Count 1 0-65535 0 97
956 Seq Count 2 0-65535 0 97
957 Seq Count 3 0-65535 0 97
958 Seq Count 4 0-65535 0 97
959 Seq Count 5 0-65535 0 97
960 Seq Count 6 0-65535 0 97
961 Seq Count 7 0-65535 0 97
962 Seq Count 8 0-65535 0 97
963 Seq Count 9 0-65535 0 97
964 Seq Count 10 0-65535 0 97
965 Seq Count 11 0-65535 0 97
966 Seq Count 12 0-65535 0 97
967 Seq Count 13 0-65535 0 97
968 Seq Count 14 0-65535 0 97
969 Seq Count 15 0-65535 0 97
970 Seq Count 16 0-65535 0 97
971 Seq Count 17 0-65535 0 97
972 Seq Count 18 0-65535 0 97
973 Seq Count 19 0-65535 0 97
974 Seq Count 20 0-65535 0 97
975 Seq Count 21 0-65535 0 97
976 Seq Count 22 0-65535 0 97
977 Seq Count 23 0-65535 0 97
978 Seq Count 24 0-65535 0 97
979 Seq Count 25 0-65535 0 97
980 Seq Decision 1 Bit 0-15 0x0000 97
981 Seq Decision 2 Bit 0-15 0x0000 97
982 Seq Decision 3 Bit 0-15 0x0000 97
983 Seq Decision 4 Bit 0-15 0x0000 97
984 Seq Decision 5 Bit 0-15 0x0000 97
1500 Last Fault All fault options Read-only 97
1527 9th Fault All fault options Read-only 97
1554 8th Fault All fault options Read-only 97
1581 7th Fault All fault options Read-only 97
1608 6th Fault All fault options Read-only 98
1635 5th Fault All fault options Read-only 98
1662 4th Fault All fault options Read-only 98
1689 3rd Fault All fault options Read-only 98
1716 2nd Fault All fault options Read-only 98
1743 1st Fault All fault options Read-only 98
No. Parameter Name Options Default User Setting See Page

24-hour support [phone] • Email: [email protected]
summary of vacon 500x parameters vacon z8

Tel. [phone] • Fax [phone]
9 zvacon
INDEX
SUMMARY OF VACON 500X PARAMETERS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1. INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.2 Overview of This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.3 User’s Manual Publication History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2. TECHNICAL CHARACTERISTICS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.1 Interpreting Model Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.2 Power and Current Ratings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.3 Environmental Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.4 Electrical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
2.5 Control Features Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.6 Dimensions and Weights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3. RECEIVING AND INSTALLATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1 Preliminary Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.2 Installation Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3 Dissipation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.4 Cover Assembly and Torque Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.5 Serial Number Label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.6 Conduit Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.7 Condensation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4. CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2 General Wiring Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2.1 Wiring Practices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.2.2 Considerations for Power Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.2.3 Considerations for Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.3 Input Line Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.3.1 Line Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.3.2 Line Capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3.3 Phase Imbalance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3.4 Single-phase Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3.5 Ground Fault Circuit Interrupters (GFCI) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.3.6 Motor Lead Length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.3.7 Using Output Contactors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.4 Terminals Found on the Vacon 500x Power Board . . . . . . . . . . . . . . . . . . . . . . . 30
4.4.1 Description of the Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
4.4.2 Typical Power Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
4.5 Dynamic Braking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
4.6 Terminals Found on the Vacon 500x Control Board . . . . . . . . . . . . . . . . . . . . . . 34
4.6.1 Description of the Control Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
4.6.2 Typical Connection Diagrams for Digital Inputs . . . . . . . . . . . . . . . . . . . . . . . . . 35
4.6.3 Typical Connection Diagrams for Analog Inputs . . . . . . . . . . . . . . . . . . . . . . . . 37
4.6.4 Typical Connection Diagrams for Analog Outputs . . . . . . . . . . . . . . . . . . . . . . . 38
5. OPERATION AND PROGRAMMING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.2 Keypad Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
