Vacon NX OPTCJ User manual

vacon nx
ac drives
optcj
bacnet option board
user manual

Tel. [phone] • Fax [phone]
INDEX
Document code: DPD00901A
Date edited: 19.01.2012
1. General info........................................................................................................................3
2. BACnet Option Board Technical data ................................................................................. 4
2.1 System Software versions........................................................................................................ 5
3. BACnet FIELDBUS BOARD LAYOUT AND CONNECTIONS................................................... 6
4. Grounding cable shield ...................................................................................................... 7
4.1 Grounding by clamping the cable to the converter frame (recommended)............................. 7
4.2 Grounding only one point on the net ........................................................................................ 8
4.3 Bus terminal resistors ............................................................................................................. 9
4.4 Bus Biasing............................................................................................................................. 10
5. LED indications ................................................................................................................ 11
6. INSTALLATION OF VACON NX BACnet BOARD................................................................. 12
7. COMMISSIONING.............................................................................................................. 14
7.1 Fieldbus board parameters.................................................................................................... 14
7.2 Expander board menu (M7) .................................................................................................... 14
7.3 BACnet parameters................................................................................................................ 14
7.3.1 MS/TP MAC address (P7.x.1.1)....................................................................................... 15
7.3.2 Baud rate (P7.x.1.2) ........................................................................................................ 15
7.3.3 Instance number (P7.x.1.3)............................................................................................. 15
7.3.4 Communication status (V7.x.2.1).................................................................................... 16
7.3.5 Baud Rate (V7.x.2.2)........................................................................................................ 16
7.3.6 Fault (V7.x.2.3) ............................................................................................................... 16
7.3.7 Index Nr. (V7.x.2.4)......................................................................................................... 16
7.4 ANNEX - PROTOCOL IMPLEMENTATION CONFORMANCE STATEMENT (NORMATIVE)...... 17
7.5 Object Map.............................................................................................................................. 19
7.5.1 Binary Value Object ........................................................................................................ 20
7.5.2 Analog Value Object........................................................................................................ 21
8. FAULT TRACKING............................................................................................................. 23

general vacon • 3
24-hour support [phone] • Email: [email protected]
1
1. GENERAL INFO
Instead of sending and receiving information to and from frequency converters through I/O, you can
connect them to a fieldbus.
Vacon NX frequency converters can be connected to the RS-485 bus using a fieldbus board. The
converter can then be controlled, monitored and programmed from the host system.
BACnet is also known by names Direct Digital Control Systems and Building Management Systems.
BACnet technology is used mostly in building automation, lightning control, air conditioning and in
heating automation. The protocol is an upper level net protocol suitable for large building
automation projects.
BACnet stands for Building Automation and Control Network. BACnet is a true non-propriatery open
protocol communication standard conceived by a consortium of building management, system users
and manufacturers.
If you purchase your BACnet option board separately, please note that it shall be installed in slot E
on the control board of the frequency converter.
WARNING!
Internal components and circuit boards are at high potential when the frequency
converter is connected to the power source. This voltage is extremely dangerous
and may cause death or severe injury if you come into contact with it.

4 • vacon technical data
Tel. [phone] • Fax [phone]
2
2. BACNET OPTION BOARD TECHNICAL DATA
Connections
Interface
OPT-CJ
: Pluggable connector (5.08mm)
Data transfer
method
RS-485 MS/TP, half-duplex
Transfer cable Twisted pair (1 pair and shield)
Electrical isolation 500 VDC
Communications
BACnet MS/TP As described in ANSI/ASHRAE Standards 135-2004
Baud rate 9600, 19200, 38400 and 76800 baud (supports autobaud
detection)
MAC Addresses 1 to 127
Environment
Ambient operating
temperature
–10°C…55°C
Storing
temperature
–40°C…60°C
Humidity <95%, no condensation allowed
Altitude Max. 1000 m
Vibration 0.5 G at 9…200 Hz
Safety
Fulfils EN50178 standard
Table 2-1. BACnet technical data

layout and connections vacon • 5
24-hour support [phone] • Email: [email protected]
2
2.1 System Software versions
OPT-CJ BACnet option board is supported from system software versions:
•NXL NXL00005V149.VCN
•NXS NXS00001V161.VCN
•NXP NXP00002V160.VCN
Autobaud detection and BACnet specific fault codes (readable from panel) are added from system
software versions:
•NXL NXL00005V248.VCN
•NXS NXS00001V163.VCN
•NXP NXP00002V162.VCN
Communication timeout is available from system SW versions. When not supported, the default is 10
seconds.
•NXL NXL00005V254.VCN
•NXS NXS00001V167.VCN
•NXP NXP00002V168.VCN
OPT-CJ software version OPTCJ_10522V009 and newer:
New baud rate 76800 from software versions:
•NXL: NXL00005V257.VCN
•NXS: NXS00001V170.VCN
•NXP: NXP00002V171.VCN

6 • vacon technical data
Tel. [phone] • Fax [phone]
3
3. BACNET FIELDBUS BOARD LAYOUT AND CONNECTIONS
Vacon BACnet option board is connected to the fieldbus through a 5-pin pluggable bus connector.
The communication with the control board of the frequency converter takes place through the
standard Vacon Interface Board Connector.
Figure 3-1. Vacon BACnet option board OPT-CJ
Signal
Connector
Description
NC* 1* No connection
VP
2
Supply voltage – plus (5V)
RxD/TxD –N 3 Receive/Transmit data – A
RxD/TxD –P 4 Receive/Transmit data – B
DGND 5 Data ground (reference potential for VP)
*You can use this pin (1) to bypass the cable shield to the next slave
Table 3-1. OPT-CJ bus connector signals
X4
X1
Bus connector Jumpers Interface board connector
Grounding plate
1
2
3
4
5

grounding cable shield vacon • 7
24-hour support [phone] • Email: [email protected]
4
4. GROUNDING CABLE SHIELD
4.1 Grounding by clamping the cable to the converter frame (recommended)
This manner of grounding is the most effective and especially recommended when the distances
between the devices are relatively short or if the device is the last device on the net.
Note: Normally, the option board has already been installed in slot D or slot E of the control board. It
is not necessary to detach the whole board for the grounding of the bus cable shield. Just detach the
terminal block.
1Strip about 5 cm of the cable and cut off the grey cable shield.
Remember to do this for both bus cables (except for the last device). See pictures below.
2Leave no more than 1 cm of the cable outside the terminal block and strip the data cables
at about 0.5 cm to fit in the terminals. See pictures below.
Note: Do this for both bus cables.
Figure 4-1.
Figure 4-2.
Cut here
Strip this part
1 2 3 4 5
B
A

8 • vacon grounding cable shield
Tel. [phone] • Fax [phone]
4
3Insert the data cables of both cables into terminals #3 (Line B) and #4 (Line A).
4Strip the cable at such a distance from the terminal that you can fix it to the frame with the
grounding clamp. See pictures below:
Figure 4-3.
4.2 Grounding only one point on the net
In this manner of grounding, the shield is connected to ground only at the last device on the net in
the same way as described in chapter 4.1. Other devices of the net just pass the shield.
We recommend you to use an Abico connector to fit the shields into the terminal.
1. Strip about 5 cm of the cable and cut off the grey cable shield. Remember to do this for
both bus cables (except for the last device).
2. Leave no more than 1 cm of the cable outside the terminal block and strip the data cable
at about 0.5 cm to fit in the terminals. See Figure 4-4.
Figure 4-5.
Note! Do this for both cables.
1 2 3 4 5
B
A
Shield

grounding cable shield vacon • 9
24-hour support [phone] • Email: [email protected]
4
3. Fix both the cables on the frame with the clamp. See Figure 4-5.
Figure 4-6.
4.3 Bus terminal resistors
Figure 4-8. Using jumper X4 to set the bus termination.
If Vacon is the last device of the fieldbus line the bus termination must be set. Use jumper X4 (ON
position). See Figure 4-7.
Note: Jumper X1 is only used when D9 type connector is assembled (Not used with BACnet protocol)
Fi 4 7

10 • vacon grounding cable shield
Tel. [phone] • Fax [phone]
4
4.4 Bus Biasing
Bus biasing is required to ensure faultless communication between devices at RS-485 bus. Bus
biasing makes sure that the bus state is at proper potential when no device is transmitting. Without
biasing, faulty messages can be detected when the bus is in idle state. RS-485 bus state should be
neather +0,200..+7V or –0,200..-7V. Illegal bus state is <200mV..-200mV.
Number of nodes Bias resistance
2-5 1.8 kohm
5-10 2.7 kohm
11-20 12 kohm
21-30 18 kohm
31-40
27 kohm
Table 4-1. Bias resistor size vs number of node
Fail safe
biasing in OPT-CJ option board
Connect resistor biasing resistors between pins #2 and #4 as well as pins #3 and #5 as shown in
picture.
Matters related to this are discussed in the application note
Failsafe Biasing of Differential Buses
(an-847.pdf) published by National Semiconductor (www.national.com).
5
DATA A
DATA B
1
2
3
4
5

led indications vacon • 11
24-hour support [phone] • Email: [email protected]
5
5. LED INDICATIONS
The two LED indications next to the connector show the present statuses of the BACnet board
(yellow) and the Fieldbus Module (green).
Figure 5-1. LED indications on the BACnet board
BACnet board status LED (BS) YELLOW
LED is:
Meaning:
OFF Option board not activated
ON Option board in initialisation state waiting for activation
command from the frequency converter
Blinking fast
(once/sec)
Option board is activated and in RUN state
•
Option board is ready for external communication
Blinking
slow
(once/5 secs)
Option board is activated and in FAULT state
•Internal fault of option board
Fieldbus status LED (FS) GREEN
LED is:
Meaning:
OFF Fieldbus module is waiting for parameters from the
frequency converter
•
No external communication
ON Fieldbus module is activated
•Parameters received and module activated
•
Module is waiting for messages from the bus
Blinking fast
(once/sec)
Module is activated and receiving messages from the bus
Blinking
slow
(once/5 secs)
Module is in FAULT state
•No messages from Master within the watchdog time
•
Bus broken, cable loose or Master off line
X4
X1
1
2
3
4
5
Yellow
Green

12 • vacon installation of bacnet board
Tel. [phone] • Fax [phone]
6
6. INSTALLATION OF VACON NX BACNET BOARD
A
Vacon NX frequency converter
B
Remove the cable cover.
C
Open the cover of the control unit.

installation of bacnet board vacon • 13
24-hour support [phone] • Email: [email protected]
6
D
Install BACnet option board in slot E on the control board of the frequency
converter. Make sure that the grounding plate (see below) fits tightly in the clamp.
E
Make a sufficiently wide opening for
your cable by cutting the grid as wide as
necessary.
F
Close the cover of the control unit and
the cable cover.

14 • vacon commissioning
Tel. [phone] • Fax [phone]
7
7. COMMISSIONING
READ FIRST CHAPTER 8 'COMMISSIONING' IN VACON NX USER'S MANUAL (Document nr. ud00701,
please visit http://www.vacon.com/Default.aspx?id=450403&FileView=462792).
Note! You must select Fieldbus as the active control place, if you wish to control the frequency
converter through fieldbus. See Vacon NX User’s Manual, Chapter 7.3.3.1.
7.1 Fieldbus board parameters
The Vacon BACnet board is commissioned with the control keypad by giving values to appropriate
parameters in menu M7 (for locating the expander board menu see Vacon NX User's Manual,
Chapter 7).
7.2 Expander board menu (M7)
The
Expander board menu makes it possible for the user 1) to see what expander boards are
connected to the control board and 2) to reach and edit the parameters associated with the expander
board.
Enter the following menu level (G#) with the
Menu button right . At this level, you can browse
through slots A to E with the
Browser buttons to see what expander boards are connected. On the
lowermost line of the display you also see the number of parameter groups associated with the
board.
If you still press the
Menu button right once you will reach the parameter group level where there
are two groups: Editable parameters and Monitored values. A further press on the
Menu button right
takes you to either of these groups.
7.3 BACnet parameters
To commission the RS-485 board, enter the level P7.5.1.# from the
Parameters group (G7.5.1). Give
desired values to all RS-485 parameters (see Figure 7-1 and Table 7-1).
Figure 7-1. Changing the BACnet board commissioning parameter values
Expander Board
G
1

G5
R
E
A
D
Y
I
/
O
t
e
r
m
NXOPTCJ
R
E
A
D
Y
I
/
O
t
e
r
m
G
1

G
2
Slave address
R
E
A
D
Y
I
/
O
t
e
r
m
1
2
6
e
n
t
e
r
C
H
A
N
G
E
V
A
L
U
E
C
O
N
F
I
R
M
C
H
A
N
G
E
Parameters
R
E
A
D
Y
I
/
O
t
e
r
m
P
1

P
4
Slave address
R
E
A
D
Y
I
/
O
t
e
r
m
1
2
6

commissioning vacon • 15
24-hour support [phone] • Email: [email protected]
7
#
Name
Default
Range
Description
1 MAC ADDRESS 1 1…127
2 BAUD RATE
1
0 - Auto
1 – 9600 baud
2 – 19200 baud
3 – 38400 baud
4 – 76800 baud
Communication speed
3 INDEX NR. Counting
number 0-65535
Instance Number. Zero means that
unique default device object instance
number is used.
4 Comm. time-out 10 s 0 = OFF
10 – 60 s
Communication time-out
0 = Not in use
Table 7-1. BACnet option board parameters
7.3.1 MS/TP MAC address (P7.x.1.1)
The parameters of every device must be set before connecting to the bus. Especially the
parameters
MAC Address and Baud Rate must be the same as in the master configuration.
The first parameter, MAC (Medium Access Control) address, must be unique on the network
to which it is connected. The same MAC address may be used on a device on another network
within the internetwork.
Addresses 128-254 are reserved for slaves. Addresses 1-127 are valid for both masters
and slaves. The portion of the address space that is actually used for masters in a particular
installation is determined by the value of the Max_Master property of the Device object.
It is recommended that MAC address 0 be reserved for use by the MS/TP router and 255 is
reserved for broadcasts.
7.3.2 Baud rate (P7.x.1.2)
Select the communication speed for the network. Default value is 9600 baud. 0 (– Auto)
means that automatic baud rate detection is used. The used Baudrate is shown in monitor
menu.
7.3.3 Instance number (P7.x.1.3)
The Device Object's Instance number must be unique across the entire BACnet internetwork
because it is used to uniquely identify the BACnet devices. It may be used to conveniently
identify the BACnet device from other devices during installation.
If 0 (default) is selected, the Device Instance number is read from Drive. This unique number
is then shown in Monitor menu. If any other value than zero is selected, the value is used as
Device Object’s Instance number. The actual value is shown in monitor menu.
7.3.4 Communication time-out
BACnet board initiates a communication error if the communication is broken for as long as
defined by the parameter Communication time-out. Communication time-out is disabled
when the parameter is given the value 0. The step for setting the time-out time is 10 seconds.

16 • vacon commissioning
Tel. [phone] • Fax [phone]
7
7.3.5 Communication status (V7.x.2.1)
To see the present status of the RS-485 fieldbus, enter the
Comm.Status page from Monitor
menu (G7.5.2). See Table 7-2 and Table 7-2 below.
Figure 7-2. Communication status
Good messages
0…999 Number of messages received without
communication errors
Bad Frames
0…64
Number of messages received with
CRC or parity errors
Table 7-2. BACnet message indications
7.3.6 Baud Rate (V7.x.2.2)
Shows the actual baud rate.
7.3.7 Fault (V7.x.2.3)
Shows BACnet fault codes. See Table 8-3 from Chapter 8.
7.3.8 Index Nr. (V7.x.2.4)
Shows the Device Object's Instance number.

commissioning vacon • 17
24-hour support [phone] • Email: [email protected]
7
7.4 ANNEX - PROTOCOL IMPLEMENTATION CONFORMANCE STATEMENT (NORMATIVE)
(This annex is part of this Standard and is required for its use.)
BACnet Protocol Implementation Conformance Statement
Date: May 31, 2005
Vendor Name: Vacon
Product Name: Vacon Drive – xxx (xxx = MAC ID)
Product Model Number: OPTCJ
Applications Software Version: 10522 Firmware Revision: 1 BACnet Protocol Revision: 4
Product Description:
BACnet Option board is designed for Vacon NX family devices.
BACnet Standardized Device Profile (Annex L):
BACnet Application Specific Controller (B-ASC)
List all BACnet Interoperability Building Blocks Supported (Annex K): DS-RP-B, DS-WP-B, DM-
DDB-B, DM-DOB-B.
Segmentation Capability:
Segmented requests supported Window Size
Segmented responses supported Window Size
Standard Object Types Supported:
An object type is supported if it may be present in the device. For each standard Object Type
supported provide the following data:
1) Whether objects of this type are dynamically creatable using the CreateObject service
2) Whether objects of this type are dynamically deletable using the DeleteObject service
3) List of the optional properties supported
4) List of all properties that are writable where not otherwise required by this standard
5) List of proprietary properties and for each its property identifier, datatype, and meaning
6) List of any property range restrictions
Data Link Layer Options:
MS/TP master (Clause 9), baud rate(s): 9600, 19200, 34800, 76800 (supports autobaud detection)
Device Address Binding:
Is static device binding supported? (This is currently necessary for two-way communication with
MS/TP slaves and certain other devices.) Yes No

18 • vacon commissioning
Tel. [phone] • Fax [phone]
7
Networking Options:
Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
Annex H, BACnet Tunneling Router over IP
BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD support registrations by Foreign Devices? Yes No
Character Sets Supported:
Indicating support for multiple character sets does not imply that they can all be supported
simultaneously.
ANSI X3.4 IBM/MicrosoftDBCS ISO 8859-1
ISO 10646 (UCS-2) ISO 10646 (UCS-4) JIS C 6226
If this product is a communication gateway, describe the types of non-BACnet
equipment/networks(s) that the gateway supports.

commissioning vacon • 19
24-hour support [phone] • Email: [email protected]
7
7.5 Object Map
Object types and properties supported:
Figure 7-3. Object types and properties supported:
*Only with commandable values
Property
Object Type
Device
Binary
Value
Analog Value
Object Identifier
X
X X
Object Name X X X
Object Type X X X
System Status X
Vendor Name X
Vendor Identifier X
Model Name X
Firmware Revision X
Appl Software revision X
Protocol Version X
Protocol Revision X
Services Supported
X
Object Types supported X
Object List X
Max APDU Length X
Segmentation Support X
APDU Timeout X
Number ADPU Retries X
Max Master X
Max Info Frames X
Device Address Binding X
Database Revision X
Preset Value
X
X
Status Flags X X
Event State X X
Out-of-Service X X
Units X
Priority Array X*)X*)
Relinquish Default X*)X*)
Polarity
Active Text X
Inactive Text X

20 • vacon commissioning
Tel. [phone] • Fax [phone]
7
7.5.1 Binary Value Object
Instance ID
Object Name
Description
Inactive / Active
Present Value
Access Type
BV0
Ready State Indicates whether the
drive is ready or not
Not Ready / Ready R
BV1
Run/Stop State Indicates whether the
drive is running or
stopped
Stop / Run R
BV2
Fwd/Rev State
Indicates the rotation
direction of the motor
Fwd / Rev
R
BV3
Fault State Indicates if a fault is
active
OK / Fault R
BV4
Warning State Indicates if a warning is
active
OK / Warning R
BV5
At Setpoint
Ref. Frequency reached
False / True
R
BV6
At Zero Speed Motor Running at zero
speed
False / True R
BV7
General 0
Application specific bit
from drives General
Status Word
0 / 1
R
BV8
General 1 Application specific bit
from drives General
Status Word
0 / 1 R
BV9
General 2 Application specific bit
from drives General
Status Word
0 / 1 R
BV10
General 3 Application specific bit
from drives General
Status Word
0 / 1 R
BV11
General 4 Application specific bit
from drives General
Status Word
0 / 1 R
BV12
General 5
Application specific bit
from drives General
Status Word
0 / 1
R
BV13
General 6 Application specific bit
from drives General
Status Word
0 / 1 R
BV14
General 7 Application specific bit
from drives General
Status Word
0 / 1 R
BV15
Run/Stop CMD Command to start drive
(FB control is active)
Stop / Run C
BV16
Fwd/Rev CMD Command to change
rotational direction (FB
control is active)
Fwd / Rev C
BV17
Reset Fault Command to reset
Active Fault from dirve
0 / Reset C
BV18
FBFixedControlWord
Bit_3
Application Specific bit
From the Fixed Control
Word
0 / 1 C
BV19
FBFixedControlWord
Bit_4
Application Specific bit
From the Fixed Control
Word
0 / 1 C
BV20
FBFixedControlWord
Bit_5
Application Specific bit
From the Fixed Control
Word
0 / 1 C
BV21
FBFixedControlWord
Bit_6
Application Specific bit
From the Fixed Control
Word
0 / 1
C
