VALBERG FBI 16S43 A XAD929C User manual

978526 - FBI 16S43 A XAD929C
INSTRUCTIONS FOR USE .....................02
CONSIGNES D'UTILISATION .....................54
GEBRUIKSAANWIJZINGEN ...................108
INSTRUCCIONES DE USO ...................160
10/2023 - V4
Dishwasher
Lave-vaisselle
Vaatwasser
Lavavajillas
EN
WARRANTY CONDITION
This product has a 2-year warranty as of the date of purchase*, covering any fault resulting from
a manufacturing or material defect. This warranty does not cover defects or damage resulting
from incorrect installation, improper use or abnormal wear of the appliance.
*upon presentation of the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute
défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les
vices ou les dommages résultant d’une mauvaise installation, d’une utilisation incorrecte ou
de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor
elke storing die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door
slechte installatie, onjuist gebruik of abnormale slijtage van het product worden niet gedekt
door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
El certificado de garantía de este producto tiene una duración de 2 años a partir de la fecha de
compra* que se limita a los defectos de fabricación y averías del material. Se excluyen de la
garantía deficiencias o daños originados por una mala instalación, errores en la manipulación
o por un uso inadecuado.
*previa presentación del comprobante de compra.
Made in PRC
ELECTRO DEPOT
1 route de Vendeville
59155 FACHES-THUMESNIL
FRANCE

1
2
3
4
5
6
7
8
AB
910

2 3FR FR
Aperçu de l’appareil
A A
3
Table of contents
AOverview of the
appliance
CUseful information
BUsing the appliance Using your dishwasher
Installation instruction
Loading the baskets
Quick user guide
Using your dishwasher
Program selection
Usage counter
Maintenance and cleaning
Troubleshooting tips
Availability of spare parts
Error codes
Product overview
2
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
VALBERG branded products are easy to use, reliable,
and of an impeccable standard.
With every use of this appliance, you can be sure of
complete satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr
EN EN

5EN
Using the appliance
B
4EN
Preview of the appliance
A
Product overview
IMPORTANT
To get the best performance from your dishwasher, read
all operating instructions before using it for the first time.
1Inner pipe
2Salt container
3Dispenser
4Top spray arm
5Inner lighting
6Lower spray arm
7Filter assembly
8Cutlery rack
9Upper basket
AUpper spray arm
BCup rack
10 Lower basket
NOTE
Pictures are only for reference, different models may be
different.
Using your dishwasher
• Before using your dishwasher :
SALT
1. Set the water softener
2. Loading the salt Into the softener
3. Loading the basket
4. Fill the detergent dispenser
NOTE
Please check the section «Water Softener», if you need to
set the water softener.
Loading the salt into the softener
• If your model does not have any water softener, you may skip this section.
• It must use salt intended for dishwasher.
• The salt container is located beneath the lower basket and should be filled as explained in
the following:
WARNING
Only use salt specifically designed for dishwashers use!
Every other type of salt not specifically designed for
dishwasher use, especially table salt, will damage the water
softener. In case of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is
liable for any damages caused.

6 7EN EN
Using the appliance Using the appliance
B B
WARNING
Only fill with salt before running a cycle.
This will prevent any grains of salt or salty water, which may
have been spilled, remaining on the bottom of the machine
for any period of time, which may cause corrosion
• Please follow the steps below for adding dishwasher salt:
SALT
1. Remove the lower basket and unscrew the reservoir cap.
2. Place the end of the funnel (if supplied) into the hole and pour in about 0.6 kg of
dishwasher salt.
3. Fill the salt container to its maximum limit with water, It is normal for a small amount of
water to come out of the salt container.
4. After filling the container, screw back the cap tightly.
5. The salt warning light will turn off after the salt container has been filled with salt.
6. Immediately after filling the salt into the salt container, a washing program should be
started (We suggest to use a short program). Otherwise the filter system, pump or other
important parts of the machine may be damaged by salty water. This is out of warranty.
NOTE
• The salt container must only be refilled when the salt
warning light in the control panel comes on. Depending
on how well the salt dissolves, the salt warning light may
still be on even though the salt container is filled. If there is
no salt warning light in the control panel (for some models),
you can estimate when to fill the salt into the softener by
the cycles that the dishwasher has run.
• If salt has spilled, run a soak or quick program to remove
it.
Basket Loading Tips
Adjusting the upper basket
1. To raise the upper basket, just lift the upper basket at the center of each side until the
basket locks into place in the upper position. It is not necessary to lift the adjuster handle.
2. To lower the upper basket, lift the adjust handles on each side to release the basket and
lower it to the lower position.

8 9EN EN
Using the appliance Using the appliance
B B
Folding back the cup shelves
To make room for taller items in the upper basket, raise the cup rack upwards. You can then
lean the tall glasses against it. You can also remove it when it is not required for use.
NOTE
When the upper basket locks in the upper position, It can’t
fold back the cup shelves.
CRASH
Folding back the rack shelves
The spikes of the lower basket are used for holding plates and a platter. They can be lowered
to make more room for large items.
raise upwards fold backwards
Using the cutlery rack
To create more space for the glass basket, the cutlery rack can be removed. Steps :
• Lift the right hand side of the rack, while keeping both parts of the rack flat
• Slide the right hand side of the rack towards the left. Both sections overlap.
• Pull on the right hand side of the rack to remove it completely.
• Do this in reverse order to put the right hand rack back in position.

10 11EN EN
Using the appliance Using the appliance
B B
Installation instruction
WARNING
Electrical shock hazard
Disconnect electrical power before installing dishwasher.
Failure to do so could result in death or electrical shock.
WARNING
The installation of the pipes and electrical equipments
should be done by professionals.
About power connection
WARNING
For personal safety:
• Do not use an extension cord or an adapter plug with this
appliance.
• Do not, under any circumstances, cut or remove the
earthing connection from the power cord.
Electrical requirements
Please look at the rating label to know the rating voltage and connect the dishwasher to
the appropriate power supply. Use the required fuse 10A/13A/16A, time delay fuse or circuit
breaker recommended and provide separate circuit serving only this appliance.
Electrical connection
Ensure the voltage and frequency of the power being corresponds to those on the rating
plate. Only insert the plug into an electrical socket which is earthed properly. If the electrical
socket to which the appliance must be connected is not appropriate for the plug, replace the
socket, rather than using a adaptors or the like as they could cause overheating and burns.
WARNING
Ensure that proper earthing exists before use
This product contains a light source exempt from energy
class for indoor lighting.
The light source of this product can only be qualified by
professionals. Please contact the after-sales service if the
light source fails.
The light source should be removed at the end of the
useful life of the product, sorting and recycling being
carried out separately.
Water supply and drain
Cold water connection
• Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that
it is fastened tightly in place.
• If the water pipes are new or have not been used for an extended period of time, let the
water run to make sure that the water is clear.
• This precaution is needed to avoid the risk of the water inlet to be blocked and damage the
appliance.
ordinary supply hose
safety supply hose
About the safety supply hose
• The safety supply hose consists of the double walls. The system guarantees its intervention
by blocking the flow of water in case of the supply hose breaking and when the air space
between the supply hose itself and the outer corrugated hose is full of water.

12 13EN EN
Using the appliance Using the appliance
B B
WARNING
A hose that attaches to a tap can burst if it is installed on
the same water line as the dishwasher. If your sink has
one, it is recommended that the hose be disconnected and
the hole plugged.
How to connect the safety supply hose
1. Pull the safety supply hoses out from storage compartment located at rear of dishwasher.
2. Tighten the screws of the safety supply hose to the faucet with thread 3/4inch.
3. Turn the water fully on before starting the dishwasher.
How to disconnect the safety supply hose
1. Turn off the water.
2. Unscrew the safety supply hose from the faucet.
Connection of drain hoses
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into
the sink, making sure to avoid bending or crimping it. The height of drain pipe must be less
than 300-1000 mm. The free end of the hose must not be immersed in water to avoid the
back flow of it.
WARNING
Please securely fix the drain hose in either position
A
or
position B
A
B
Water Inlet
Mains Cable
Back of dishwasher
Drain Pipe
Drain hose
40 mm
300-1000 mm
Drain Pipe Counter
How to drain excess water from hoses
If the connection to the drain pipe is positioned higher than 1000 mm, excess water may
remain in the drain hose. It will be necessary to drain excess water from the hose into a bowl
or suitable container that is held outside and lower than the sink.
Water outlet
• Connect the water drain hose. The drain hose must be correctly fitted to avoid water leaks.
• Ensure that the water drain hose is not kinked or squashed.

14 15EN EN
Using the appliance Using the appliance
B B
Extension hose
• If you need a drain hose extension, make sure to use a similar drain hose.
• It must be no longer than 4 meters, otherwise the cleaning effect of the dishwasher could
be reduced.
Syphon connection
The waste connection must be at a height less than 1000 mm (maximum) from the bottom
of the dishwasher.
Positioning the appliance
• Position the appliance in the desired location. The back should rest against the wall behind
it, and the sides, along the adjacent cabinets or walls.
• The dishwasher is equipped with water supply and drain hoses that can be positioned
either to the right or the left sides to facilitate proper installation.
Built-In Installation (for the integrated model)
Step 1. Selecting the best location for the dishwasher
The installation position of dishwasher should be near the existing inlet and drain hose and
power socket.
Illustrations of cabinet dimensions and installation position of the dishwasher.
1. Less than 5 mm between the top of dishwasher and cabinet and the outer door aligned to
cabinet.
90 ° 90 °
820-870
mm
580mm
Electrical, drain and
water supply line
connection
80
100
Space between cabinet
bottom and floor
600 mm
2. If dishwasher is installed at the corner of the cabinet, there should be some space when
the door is opened.
Dishwasher
Door of
dishwasher
Cabinet
Minimum space
of 50mm
NOTE
Depending on where your electrical outlet is, you may need
to cut a hole in the opposite cabinet side.
Step 2. Aesthetic panel’s dimensions and installation
NOTE
Follow the specific installation instruction for attaching the
aesthetical door panel.
Fully-integrated model
Install the hook on the aesthetic panel and put the hook into the slot of the outer door of
dishwasher (see figure A). After positioning of the panel, fix the panel onto the outer door
by screws and bolts (See figure B).

16 17EN EN
Using the appliance Using the appliance
B B
A
1.Take away the four short screws
2.Pin up the four long screws
B
Step 3. Dishwasher installation steps
NOTE
Please refer to the specific installation steps in the
installation drawings.
1. Install the furniture door to the outer door of the dishwasher. (Step 2 to Step 5)
2. Adjust the tension of the door springs by using an Allen key turning in a clockwise motion
to tighten the left and right door springs. Failure to do this could cause damage to your
dishwasher. (Step 6)
3. Affix the condensation strip under the work surface of cabinet. Please ensure the
condensation strip is flush with edge of work surface. (Step 8)
4. Connect the inlet hose to the cold water supply. (Step 9)
5. Connect the drain hose. (Step 9)
6. Connect the power cord. (Step 9)
7. Place the dishwasher into the cabinet. (Step 10)
8. Level the dishwasher. The rear foot can be adjusted from the front of the dishwasher by
turning the Philips screw in the middle of the base of dishwasher use a Philips screw driver.
To adjust the front feet, use a flat screw driver and turn the front feet until the dishwasher
is level. (Step 11)
9. The dishwasher must be secured in place. The fixed operation is as follows:
4 8
4 8
Step 4. Levelling the dishwasher
Dishwasher must be level for proper dish rack operation and wash performance.
1. Place a spirit level on door and rack track inside the tub as shown to check that the
dishwasher is level.
2. Level the dishwasher by adjusting the three levelling feet individually.
3. When level the dishwasher, please pay attention not to let the dishwasher tip over.
NOTE
The maximum adjustment height of the feet is 50 mm.

18 19EN EN
Using the appliance Using the appliance
B B
Loading the baskets
According to EN60436:
Loading the dishwasher to its full capacity
will contribute to energy and water savings.
Upper basket:
1
1
6
2
5
3
4
3
3
3
1
2
3
36
5
4
3
13
Lower basket:
10
710
11
12
13
3 3
8
9
14
10
10
10 14
11
13
10
12
9
8
7
3 3
10
10
10
10
Number Item
1D = 7,8 cm
H = 4,3 cm Cups
2D = 14 cm Saucers
3D = 6 cm
H = 12 cm Glasses
4D = 7 cm
H = 10 cm Mugs
5D = 16 cm
H = 4,1 cm Dessert bowls
6D = 16 cm
H = 10,5 cm Glass bowl
Number Item
7D = 19 cm Soup plates
8D = 25 cm Melamine bowls
9D = 23 cm Dessert plates
10 D = 32 cm Melamine
dessert plates
11 D = 19,5 cm Dinner plates
12 D = 21,3 cm Small pot
13 D = 18,6 cm
H = 9,5 cm Oven pot
14 D = 13 cm Oval platter
Cutlery rack:
7
5
2
1
2
3
6
6
8
3
2
1
2
4
1 32 6444 5 7 8
1 2 3 4 5 6 7 8
Information for comparability tests in accordance
with EN60436
Capacity: 16 place settings
Position of the upper basket: lower position
Program: ECO
Rinse aid setting: MAX
Softener setting: H3
Number Item
1Soup spoons
2Forks
3Knives
4Tea spoons
5Dessert spoons
6Serving spoons
7Serving fork
8Gravy ladle
The number of places specified on the energy label is based on 25 cm plates and 12 cm high
glasses.

20 21EN EN
Using the appliance Using the appliance
B B
Please read the corresponding content on the instruction manual for detailed operating
method.
1. Install the dishwasher
(Please check the section “INSTALLATION INSTRUCTION ”.)
2. Remove larger residue from dishes. Avoid pre-rinsing.
3. Load the baskets
Quick user guide
4. Fill the dispenser with detergent and rinse aid.
5. Select a suitable program and start the dishwasher.

22 23EN EN
Using the appliance Using the appliance
B B
Control panel
1 2 3 4 5
98 106 7 7
1Power Press the button to turn on/off your dishwasher, the screen
lights up.
2Program
Press the or button to select a program, and the
corresponding indicator will be lit.
3Delay
-/+
Press the + button to add the delay time or press the - button
to decrease the delay time, maximum 24 hours delay can be
defined.
4Function Press the button to select a function, corresponding indicator
will be lit.
5Alt Press the button to select either upper basket or lower basket
loaded, and the response indicators will be lit.
Using your dishwasher
6Program
indicator
Auto
For lightly, normally or heavily soiled crockery with or without
dried-on food.
Hygiene
With the sanitize option selected, the water temperature is
increased to 72 ˚C for high temperature sanitization.
Universal
For normally soiled loads, such as pots, plates, glasses and
lightly soiled pans.
ECO
This is standard program, it is suitable to clean normally
soiled tableware and it is the most efficient program in terms
of its combined energy and water consumption for that type of
tableware.
Glass
For lightly soiled crockery and glass.
58 min
For normally soiled loads that need 58 min wash.
Rapid
For lightly soiled loads,such as glasses, crystal and fine china.
Self-Clean
This program provides an effective cleaning of the dishwasher
itself.
7Warning
indicator
Rinse Aid
If the “ ” indicator is lit, it means the dishwasher is low on
dishwasher rinse aid and requires a refill.
Salt
If the “ ” indicator is lit, it means the dishwasher is low on
dishwasher salt and needs to be refilled.
Water Faucet
If the “ ” indicator is lit, it means the water faucet closed.
8Screen To show the reminding time and delay time,error codes etc.

24 25EN EN
Using the appliance Using the appliance
B B
9Function
indicator
Extra Drying
To dry dishes more completely. ( It can only be used with
Hygiene, Universal, ECO, Glass, 58 min )
Strong wash
To wash very dirty, hard to clean dishes. ( It can only be used
with Hygiene, Universal, ECO, Glass, 58 min )
Turbo speed+
Reduce the program time. ( It can only be used with Hygiene,
Universal, ECO, Glass, 58 min, Self-cleaning )
Auto open
After washing the door will open automatically to achieve
better drying effect (Rapid and self-cleaning programs don’t
have this function.)
When you press the button for 3 seconds, the button will
light on when a certain program is selected. You can cancel
the auto-open function for 3 seconds again, corresponding
indicator will go off.
10 Alt
indicator
Upper
When you select Upper, only the dishes in the upper rack will
be washed. The spray system of the lower basket will not
operate.
Lower
When you select Lower, only the dishes in the lower rack will
be washed. The spray system of the upper basket will not
operate.
Water softener
• The water softener must be set manually, using the water hardness dial.
• The water softener is designed to remove minerals and salts from the water, which would
have a detrimental or adverse effect on the operation of the appliance.
• The more minerals there are, the harder your water is.
• The softener should be adjusted according to the hardness of the water in your area.
• Your local Water Authority can advise you on the hardness of the water in your area.
Adjusting salt consumption
• The dishwasher is designed to allow for adjustment in the amount of salt consumed based
on the hardness of the water used. This is intended to optimise and customise the level of
salt consumption.
• Please follow the steps below for adjustment in salt consumption.
1. Open the door, switch on the appliance;
2. Within 60 seconds after the appliance was switched on, press the Program button “>” for
more than 5 seconds, then enter the water softener setting mode.
3. Press the ‘>’ button again to select the proper set according to your local environment, the
setting will change in the following sequence: H3->H4->H5->H6->H1->H2;
4. Without operation in 5 seconds or press the Power button to complete the setup and exit
the setup mode.
WATER HARDNESS
Water softner
level
Regeneration
occurs every
X program
sequence 1)
Salt
consumption
(gram/cycle)
German
°dH
French
°fH
British
°Clarke Mmol/l
0 - 5 0 - 9 0 - 6 0 - 0,94 H1 No
regeneration 0
6 - 11 10 - 20 7 - 14 1,0 - 2,0 H2 10 9
12 - 17 21 - 30 15 - 21 2,1 - 3,0 H3 5 12
18 - 22 31 - 40 22 - 28 3,1 - 4,0 H4 3 20
23 - 34 41 - 60 29 - 42 4,1 - 6,0 H5 2 30
35 - 55 61 - 98 43 - 69 6,1 - 9,8 H6 1 60
1°dH=1.25 °Clarke=1.78 °fH=0.178mmol/l
The factory setting: H3
1) Every cycle with a regeneration operation consumes additional 4.0 litres of water, the
energy consumption increases by 0.06 kWh and the program extents by 10 minutes.
NOTE
Please check the “Loading The Salt Into The Softener”, if
your dishwasher lacks salt.

26 27EN EN
Using the appliance Using the appliance
B B
NOTE
If your model does not have any water softener, you may
skip this section.
Water Softener
• The hardness of the water varies from place to place. If
hard water is used in the dishwasher, deposits will form
on the dishes and utensils.
• The appliance is equipped with a special softener that
uses a salt container specifically designed to eliminate
lime and minerals from the water.
Preparing and loading dishes
• Consider buying utensils which are identified as dishwasher-proof.
• For particular items, select a program with the lowest possible temperature.
• To prevent damage, do not take glass and cutlery out of the dishwasher immediately after
the program has ended.
For washing the following cutlery/dishes
Are not suitable:
- Cutlery with wooden, horn china or mother-of-pearl handles
- Plastic items that are not heat resistant
- Older cutlery with glued parts that are not temperature resistant
- Bonded cutlery items or dishes
- Pewter or cooper items
- Crystal glass
- Steel items subject to rusting
- Wooden platters
- Items made from synthetic fibres
Are of limited suitability:
- Some types of glasses can become dull after a large number of washes
- Silver and aluminum parts have a tendency to discolour during washing
- Glazed patterns may fade if machine washed frequently
Recommendations for loading the dishwasher
• Scrape off any large amounts of leftover food. Soften remnants of burnt food in pans.
It is not necessary to rinse the dishes under running water. For best performance of the
dishwasher, follow these loading guidelines.
(Features and appearance of baskets and cutlery baskets may vary from your model.)
Place objects in the dishwasher in the following way:
• Items such as cups, glasses, pots/pans, etc. are faced downwards.
• Curved items, or ones with recesses, should be loaded aslant so that water can run off.
• All utensils are stacked securely and can not tip over.
• All utensils are placed in the way that the spray arms can rotate freely during washing.
• Load hollow items such as cups, glasses, pans etc. With the opening facing downwards so
that water cannot collect in the container or a deep base.
• Dishes and items of cutlery must not lie inside one another, or cover each other.
• To avoid damage, glasses should not touch one another.
• The upper basket is designed to hold more delicate and lighter dishware such as glasses,
coffee and tea cups.
• Long bladed knives stored in an upright position are a potential hazard!
• Long and / or sharp items of cutlery such as carving knives must be positioned horizontally
in the upper basket.
• Please do not overload your dishwasher. This is important for good results and for
reasonable consumption of energy.
NOTE
Very small items should not be washed in the dishwasher
as they could easily fall out of the basket.

28 29EN EN
Using the appliance Using the appliance
B B
Removing the dishes
To prevent water dripping from the upper basket into the lower basket, we recommend that
you empty the lower basket first, followed by the upper basket.
WARNING
Items will be hot! To prevent damage, do not take glass
and cutlery out of the dishwasher for around 15 minutes
after the program has ended.
Loading the upper basket
The upper basket is designed to hold more delicate and lighter dishware such as glasses,
coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long
as they are not too dirty). Position the dishes and cookware so that they will not get moved
by the spray of water.
Loading the lower basket
• We suggest that you place large and difficult to clean items into the lower basket: such as
pots, pans, lids, serving dishes and bowls, as shown in the figure below. It is preferable to
place serving dishes and lids on the side of the racks in order to avoid blocking the rotation
of the upper spray arm.
Loading the cutlery rack
Cutlery should be placed in the cutlery rack separate from each other in the appropriate
positions. Avoid nesting of the cutlery to prevent insufficient cleaning performance.
WARNING
For optimal cleaning and drying results, please refer to the
standard loading options in the last section
Function of the detergent and rinse aid
Function of detergent
• The chemical ingredients of dishwasher detergents are necessary to remove, crush and
dispense all dirt out of the dishwasher.
• Most of the commercial quality detergents are suitable for this purpose.
WARNING
• Use only detergent specifically made for dishwashers
use. Keep your detergent fresh and dry.
• Do not fill detergent into the dispenser until you are ready
to start the dishwasher
Dishwasher detergent is corrosive! Keep dishwasher
detergent out of the reach of children.
Function of rinse aid
The rinse aid is released during the final rinse to prevent water from forming droplets on
your dishes, which can leave spots and streaks. It also improves drying by allowing water to
run off the dishes. Your dishwasher is designed to use liquid rinse aids.
WARNING
Never fill the rinse aid dispenser with any other substances
(e.g. Dishwasher cleaning agent, liquid detergent). This
would damage the appliance.
When to refill the rinse aid dispenser
Almost every program uses rinse aid in the final rinse. Depending on the frequency of use
and the rinse aid setting the dispenser needs to be refilled.
• The Rinse Aid indicator ( ) will be lit when a refill is required.
• Do not overfill the rinse aid dispenser.

30 31EN EN
Using the appliance Using the appliance
B B
Filling the detergent dispenser
1. Open the lid by pressing down the release catch.
Press down
2. Add detergent into the detergent cup Afor the main wash phase. For better cleaning
result, especially when you have very dirt items, pour a small amount of detergent onto the
door B. The additional detergent will be activated during the pre-wash phase.
B
A
A
B
3. Close the dispesner lid by sliding the lid down until latched.
NOTE
• Please observe the manufacturer’s recommendations on
the detergent packaging.

32 33EN EN
Using the appliance Using the appliance
B B
Filling the rinse aid reservoir
1. Open the lid of the rinse aid reservoir by lifting up the handle.
2. Pour the rinse aid slowly into the dispenser, avoid overfilling. Any spilled rinse aid should
be removed with a cloth.
3. Properly close the lid after filling the reservoir.
Adjusting the rinse aid setting
To achieve a better drying performance with limited rinse aid, the dishwasher is designed to
adjust the consumption by user. Follow the below steps.
1. Open the door, switch on the appliance.
2. Within 60 seconds after step 1, press the Program button “>”more than 5 seconds, and
then press the “+” button to enter the set model, the rinse aid indication blinks as 1Hz
frequency.
3. Press the Program button “>” to select the proper set according to your using habits,
the sets will change in the following sequence: D3->D4->D5->D1->D2 ->D3. The higher the
number, the more rinse aid the dishwasher uses.
4. Without operation in 5 seconds or press the Power button to complete the setup and exit
the setup mode.

34 35EN EN
Using the appliance Using the appliance
B B
Program Table
• The table shows various information about the programs.
• Consumption values and program duration are only indicative except for ECO program.
( ) indicates that the program uses rinse aid in the last rinse.
Program Description of cycle
Detergent
pre/main
wash
Running
time(min)
Energy
(kWh)
Water
(L)
Rinse
aid
Auto
Pre-wash (45 °C)
Wash (55-65 °C)
Rinse
Rinse
Rinse (50-60 °C)
Drying
5/19g 105-179 0.930-1.470 10.3-17.0
Hygiene
Pre-wash (45 °C)
Wash (72 °C)
Rinse
Rinse (50 °C)
Rinse (60~65 °C)
Drying
5/19g 165 1.650~1.720 16.0
Universal
Pre-wash (45 °C)
Wash (55 °C)
Rinse
Rinse (60~65 °C)
Drying
5/19g 130 1.175~1.250 13.5
(*EN60436)
Wash (45 °C)
Rinse
Rinse (43 °C)
Drying
24g 280 0.559 9.0
Glass
Pre-wash (40 °C)
Wash (50 °C)
Rinse
Rinse
Rinse (55~60 °C)
Drying
5/19g 99 0.825~0.900 11.5
58 min
Wash (50 °C)
Rinse
Rinse (55 °C)
Drying
20g 58 0.740~0.795 11.5
Rapid
Wash (45°C)
Rinse
Rinse (50°C) 15g 45 0.650~0.710 9.0
Program selection
Program Description of cycle
Detergent
pre/main
wash
Running
time(min)
Energy
(kWh)
Water
(L)
Rinse
aid
Self-
cleaning
Wash (70 °C)
Rinse
Rinse (65~72 °C)
Drying
20g 130 1.245~1.320 12.0
NOTE
The ECO program is suitable to clean normally soiled
tableware, that for this use, it is the most efficient program
in terms of its combined energy and water consumption,
and it is used to assess compliance with the EU ecodesign
legislation.
Saving energy
1. Pre-rinsing of tableware items leads to increased water and energy consumption and is
not recommended.
2. Washing tableware in a household dishwasher usually consumes less energy and water
in the use phase than hand dishwashing when the household dishwasher is used according
to the instructions.
Starting a program
1. Pull out the lower and upper basket, load the dishes and push them back.
2. Add the detergent in the dispenser.
3. Insert the plug into the socket. For the power supply specification please refer to last page
”Product information sheet”. Make sure that the water supply is turned on within specified
range of pressure.
4. Open the door, Press the Power button.
5. Choose a program then close the door, the dishwasher will start the program.

36 37EN EN
Using the appliance Using the appliance
B B
Changing the program mid-cycle
• A program can only be changed if it has been running only for a short period of time,
otherwise the detergent may have already been released or the the wash water with
detergent has already been drained. If this is the case, the dishwasher needs to be reset and
the detergent dispenser must be refilled.
To reset the dishwasher, follow the instructions below:
1. Open the door a little to pause the cycle, after the spray arms stopped working you can
open the door completely.
2. Press Program > button for more than three seconds, the dishwasher will be in program
selection mode.
3. You can change the program to the desired cycle setting.
4. Close the door, the dishwasher will restart to run.
3 sec
Forget to add a dish
A forgotten dish can be added any time before the detergent dispenser opens. If this is the
case, follow the instructions below:
1. Open the door a little to stop the washing.
2. After the spray arms stopped working, you can open the door completely.
3. Add the forgotten dishes.
4. Close the door.
5. The dishwasher will start running again.
WARNING
It is dangerous to open the door mid-cycle, as hot steam
may scald you.
Auto Open
At the end of a program the door will open automatically to achieve better drying effect and
reduce energy use during the drying phase. Rapid and self-cleaning programs don’t have
this function.
NOTE
The dishwasher door must not be blocked when set to open
automatically. This can disrupt door lock functionality.
Activ’Door is a technology that opens doors at the end of a cycle. This means that residual
steam in the tank can escape, rather than being deposited on the dishes. This system
optimizes drying while limiting energy consumption. At the same time, this will reduce the
amount of residue on your dishes.
There’s a button to deactivate the Activ’Door. Automatic door opening can operate on all
programs except the short programs (i.e. the quick program and the soaking program, if
present on your appliance). The automatic opening function can be activated or deactivated
by pressing the door opener button.
