VALBERG 14S42 D WAD929C User manual

MADE IN PRC
ELECTRO DEPOT
1 route de Vendeville
59155 FACHES-THUMESNIL
FRANCE
EN
WARRANTY CONDITION
This product has a 2-year warranty as of the date of purchase*, covering any fault resulting from
a manufacturing or material defect. This warranty does not cover defects or damage resulting
from incorrect installation, improper use or abnormal wear of the appliance.
*upon presentation of the sales receipt.
FR
CONDITION DE GARANTIE
Ce produit est garanti pour une période de 2 ans à partir de la date d’achat*, contre toute
défaillance résultant d’un vice de fabrication ou de matériau. Cette garantie ne couvre pas les
vices ou les dommages résultant d’une mauvaise installation, d’une utilisation incorrecte ou
de l’usure anormale du produit.
*sur présentation du ticket de caisse.
NL
GARANTIEVOORWAARDEN
Dit product wordt gegarandeerd voor een periode van 2 jaar vanaf de aankoopdatum*, voor
elke storing die het gevolg is van een fabricagefout of het materiaal. Gebreken of schade door
slechte installatie, onjuist gebruik of abnormale slijtage van het product worden niet gedekt
door deze garantie.
*op vertoon van kassabon.
ES
CONDICIONES DE GARANTÍA
El certificado de garantía de este producto tiene una duración de 2 años a partir de la fecha de
compra* que se limita a los defectos de fabricación y averías del material. Se excluyen de la
garantía deficiencias o daños originados por una mala instalación, errores en la manipulación
o por un uso inadecuado.
*previa presentación del comprobante de compra.

976711 - 14S44 D WAD929C
01/2023-V2
Dishwasher
Lave-vaisselle
Vaatwasser
Lavavajillas
INSTRUCTIONS FOR USE .....................02
CONSIGNES D'UTILISATION .....................48
GEBRUIKSAANWIJZINGEN .....................98
INSTRUCCIONES DE USO ...................148
2/2

1
2
3
4
5
6
C
7 8
A B

2 FR
A
2
Thanks!
Thank you for choosing this VALBERG product.
Chosen, tested and recommended by ELECTRO DEPOT,
VALBERG branded products are easy to use, reliable,
and of an impeccable standard.
With every use of this appliance, you can be sure of
complete satisfaction.
Welcome to ELECTRO DEPOT.
Visit our website: www.electrodepot.fr
EN

3 FR
Aperçu de l’appareil
A
3
Table of contents
APreview of the
appliance
CUseful information
BUsing the appliance Using your dishwasher
Installation instruction
Loading the baskets
Quick user guide
Using your dishwasher
Programming the dishwasher
Maintenance and cleaning
Troubleshooting tips
Error codes
Product overview
EN

4EN
Preview of the appliance
A
Product overview
IMPORTANT
To get the best performance from your dishwasher, read
all operating instructions before using it for the first time.
1Inner pipe
2Salt container
3Dispenser
4Lower spray arm
5Filter assembly
6Cutlery basket
7Upper basket
ACutlery rack
BUpper spray arm
CCup rack
8Lower basket
NOTE
Pictures are only for reference, different models may be
different.

5EN
Using the appliance
B
Using your dishwasher
• Before using your dishwasher :
OutsideInside
SALT
1. Set the water softener
2. Loading the salt Into the softener
3. Loading the basket
4. Fill the detergent dispenser
NOTE
Please check the section «Water Softener», if you need to
set the water softener.
Loading the salt into the softener
• If your model does not have any water softener, you may skip this section.
• Always use salt intended for dishwasher use.
• The salt container is located beneath the lower basket and should be filled as explained in
the following:
WARNING
Only use salt specifically designed for dishwashers use!
Every other type of salt not specifically designed for
dishwasher use, especially table salt, will damage the water
softener. In case of damages caused by the use of unsuitable
salt the manufacturer does not give any warranty nor is
liable for any damages caused.

6EN
Using the appliance
B
WARNING
Only fill with salt before running a cycle.
This will prevent any grains of salt or salty water, which may
have been spilled, remaining on the bottom of the machine
for any period of time, which may cause corrosion
• Please follow the steps below for adding dishwasher salt:
SALT
1. Remove the lower basket and unscrew the reservoir cap.
2. Place the end of the funnel (if supplied) into the hole and pour in about 1.5 kg of
dishwasher salt.
3. Fill the salt container to its maximum limit with water, It is normal for a small amount of
water to come out of the salt container.
4. After filling the container, screw back the cap tightly.
5. The salt warning light will turn off after the salt container has been filled with salt.
6. Immediately after filling the salt into the salt container, a washing program should be
started (We suggest to use a short program). Otherwise the filter system, pump or other
important parts of the machine may be damaged by salty water. This is out of warranty.

7EN
Using the appliance
B
NOTE
• The salt container must only be refilled when the salt
warning light in the control panel comes on. Depending
on how well the salt dissolves, the salt warning light may
still be on even though the salt container is filled. If there is
no salt warning light in the control panel (for some models),
you can estimate when to fill the salt into the softener by
the cycles that the dishwasher has run.
• If salt has spilled, run a soak or quick program to remove
it.

8EN
Using the appliance
B
Basket Loading Tips
Adjusting the upper basket
• Type 1:
The height of the upper basket can be easily adjusted to accommodate taller dishes in either
the upper or lower basket.
To adjust the height of the upper rack, follow these steps:
1. Pull out the upper basket.
lower position
2. Remove the upper basket.
3. Re-attach the upper basket to upper or lower rollers.

9EN
Using the appliance
B
4. Push in the upper basket.
upper position
• Type 2:
1. To raise the upper basket, just lift the upper basket at the center of each side until the
basket locks into place in the upper position. It is not necessary to lift the adjuster handle.
2. To lower the lift the adjust handles on each side to release the basket and lower it to the
lower position.

10 EN
Using the appliance
B
Folding back the cup shelves
To make room for taller items in the upper basket, raise the cup rack upwards. You can then
lean the tall glasses against it.
Folding back the rack shelves
The spikes of the lower basket are used for holding plates and a platter. They can be lowered
to make more room for large items.
raise upwards fold backwards

11 EN
Using the appliance
B
Installation instruction
WARNING
Electrical shock hazard
Disconnect electrical power before installing dishwasher.
Failure to do so could result in death or electrical shock.
WARNING
The installation of the pipes and electrical equipments
should be done by professionals.
About power connection
WARNING
For personal safety:
• Do not use an extension cord or an adapter plug with this
appliance.
• Do not, under any circumstances, cut or remove the
earthing connection from the power cord.
Electrical requirements
Please look at the rating label to know the rating voltage and connect the dishwasher to
the appropriate power supply. Use the required fuse 10A/13A/16A, time delay fuse or circuit
breaker recommended and provide separate circuit serving only this appliance.
Electrical connection
Ensure the voltage and frequency of the power being corresponds to those on the rating
plate. Only insert the plug into an electrical socket which is earthed properly. If the electrical
socket to which the appliance must be connected is not appropriate for the plug, replace the
socket, rather than using a adaptors or the like as they could cause overheating and burns.
WARNING
Ensure that proper earthing exists before use

12 EN
Using the appliance
B
Water supply and drain
Cold water connection
• Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that
it is fastened tightly in place.
• If the water pipes are new or have not been used for an extended period of time, let the
water run to make sure that the water is clear.
• This precaution is needed to avoid the risk of the water inlet to be blocked and damage the
appliance.
ordinary supply hose
safety supply hose
About the safety supply hose
• The safety supply hose consists of the double walls. The system guarantees its intervention
by blocking the flow of water in case of the supply hose breaking and when the air space
between the supply hose itself and the outer corrugated hose is full of water.
WARNING
A hose that attaches to a tap can burst if it is installed on
the same water line as the dishwasher. If your sink has
one, it is recommended that the hose be disconnected and
the hole plugged.

13 EN
Using the appliance
B
How to connect the safety supply hose
1. Pull the safety supply hoses out from storage compartment located at rear of dishwasher.
2. Tighten the screws of the safety supply hose to the faucet with thread 3/4inch.
3. Turn the water fully on before starting the dishwasher.
How to disconnect the safety supply hose
1. Turn off the water.
2. Unscrew the safety supply hose from the faucet.
Connection of drain hoses
Insert the drain hose into a drain pipe with a minimum diameter of 4 cm, or let it run into
the sink, making sure to avoid bending or crimping it. The height of drain pipe must be less
than 1000 mm. The free end of the hose must not be immersed in water to avoid the back
flow of it.
WARNING
Please securely fix the drain hose in either position
A
or
position B
A
B
Water Inlet
Mains Cable
Back of dishwasher
Drain Pipe
Drain hose
40 mm
MAX 1000 mm
Drain Pipe Counter
