Valor 802 Installation guide

INSTALLATION AND OPERATING GUIDE
For
Electric Heaters
Model 801
With
Adorn, Icon, Visage, Elegant or Ultimate Fireslide fronts
&
Model 802
Ultimate, Cosyflame, Fyrside, Nebula & Pizzazz versions
600B599/06
This guide is intended to help you install and care for
your Valor electric heater. Please read carefully before
installing and using your heater.
Important
Please keep your Guide in a safe place for future
reference

2
CUSTOMER CARE
Thank you for choosing Valor
All Valor heaters are designed to meet the most stringent quality, performance and safety requirements to provide our
customers with many years of trouble free service. This guide aims to improve your understanding and appreciation of
your new Valor heater, by providing simple and informative instructions to enable you to install it and to ensure that you
benefit from the excellent performance and features it has to offer.
If you require further assistance, the Valor AdviceLine will be pleased to help.
Please telephone [phone] (local rates apply in the United Kingdom)
FOR OTHER USEFUL TELEPHONE NUMBERS SEE THE BACK COVER
IMPORTANT SAFETY INSTRUCTIONS
It is important that the following safety instructions are followed
Always
Always install the heater in accordance with the instructions. If in doubt obtain expert
advice.
Always make sure the electrical socket is accessible and located adjacent to, but not above
the heater.
Always disconnect the heater from the electrical supply before carrying out cleaning,
maintenance or replacing lamps.
Always make sure the heater is firmly secured to the fireplace opening to prevent the fire
from being tipped over.
Always use a fireguard when young children and infirm persons can come into contact
with the heater.
Always use genuine Valor spares.
Never
Never leave children unsupervised in a room where the heater in ON and unguarded.
Never obstruct or cover the fan outlet or force items into heater openings.
Never install or use the heater anywhere where water is in use, i.e. Bathrooms, Shower
Rooms etc.
Never use aerosols on or around the heater.
Never route the mains supply cable under carpet etc.
Never install the heater close to curtains or combustible materials.
Never use the heater to dry clothes etc.

3
General
Appliance dimensions
Model Projection into
cavity (mm)
Projection into
room (mm)
Overall depth
(mm)
Width (mm) Height (mm)
801 Adorn 68 153 221 545 768
801 Icon 68 59 127 631 622
801 Visage 68 89 157 529 611
801 Elegant 68 89 157 529 611
801 Ultimate
Fireslide
68 89 157 475 600
802 Ultimate 68 89 157 475 600
802 Cosyflame 68 89 157 475 600
802 Fyreside 68 79 147 475 600
802 Pizzazz 68 79 147 475 600
802 Nebula 68 89 157 475 600
Fireplace opening
This heater is intended for use in a fireplace opening generally conforming to British Standard 1251 for a nominal 400mm
(16 inch) or 450mm (18 inch) Fireplace. It may also be located in other fireplace openings or in a wooden surround,
where the following dimensions are available.
Width 390 – 450mm
Height 555 – 590mm
Depth At least 75mm
Clearance for servicing
There should be a clearance of at least 30mm between the top of the appliance and any mantle or shelf so that the outer
surround can be lifted off for servicing access.
Spacers and Wall Kits:
The heater is of a slim design and should suit most fireplace openings and fire surrounds, however there may be some
applications that require the need for either a spacer or flat wall kit. The following table identifies which spacer or wall kit
is available for each heater. The Model 802 Fyreside version is supplied with a 75mm wall kit. For all other appliances the
kits are optional extras obtainable either from the your heater supplier or direct from Valor Sales.
Model 60mm (2.1/2”) Surround Rebate Flat Wall (no recess)
20mm Spacer Kit No. 75mm Wall Kit No.
Model 801 Ultimate Fireslide 05801R1 05801T1
Model 801 Visage 05801S1 05801U1
Model 801 Elegant 05801S1 05801U1
Model 801 Adorn Not Available Not Available
Model 801 Icon Not Available Not Available
Model 802 Ultimate,
Nebula, Cosyflame, Fyrside
& Pizzazz
05801R1 05801T1
Unpacking
Model 801 with Visage, Elegant or Ultimate Fireslide front & Model 802
These are packed in a single carton. This contains the main appliance. In a separate box is the cast fascia complete with
coal pack. Model 802 Fyrside also includes a 75mm wall spacer kit.
Model 801 with Adorn front – Twin Pack
Pack 1 - Main Fire Pack
Pack 2 – Contains cast iron face, the fuel effect and coal pack.
Model 801 with Icon front – Twin Pack
Pack 1 - Main Fire Pack
Pack 2 – Contains the face complete with log effect

4
Figure 4
Figure 3
Figure 2
Figure 1
Installation
The heater must be fixed into position to prevent it from being tipped over.
The following fixing options are available. The parts required for both fixing options are included with all appliances.
Screw fixing
Wire fixing
The heater must not be located under a fixed electrical socket, the socket must always be accessible in order to disconnect
the heater from the electrical supply for maintenance or when replacing a lamp.
Important! This heater must be earthed. The heater is supplied with a 3 pin 13A fused re-wireable plug with 1mm².
3 core mains cable,
L = Brown N = Blue E= Green/Yellow
The mains supply cable must be safely routed from the heater to an electrical socket. Provision is made for left/right or rear
cable entry. Using one of the three cable guides at the base of the heater. To relocate, open the appropriate latch on the
cable guide and refit the mains cable into the required position. If the mains cable is damaged, to avoid a hazard it must be
replaced by a Valor authorised service agent, or a similarly qualified person.
All external wiring between the appliance and the electrical supply, including the earthing, shall comply with current IEE
regulations.
The heater body should be fixed in position before the front surround is finally fitted.
N.B: Please study the illustrations carefully to avoid damage to the heater.
Front Removal – All Models except those with Adorn or Icon front
Model 801
Detach the control linkage – See figure 1
Models 801 & 802
Carefully remove the front surround by removing the two trim fixing screws and lifting upwards and
forward – See figure 2
Do Not Lift The Front Surround By The Control Knob
Keep the front surround and screws in a safe place when installing the fire.
Offer the heater body to the fireplace opening to ensure that it will fit before continuing with the
installation.
Appliance Fixing
Method A – Screw Fix
There are two slots in the top flange – See figure 3. Mark the fixing position through the slots.
Remove the heater. Drill a hole with a No.12 drill bit at each marked position. Insert the wall
plugs provided. Reposition the heater body and screw through the slots to provide a secure fixing.
Method B – Wire Fix
The fixing kit includes a steel wire and eyebolt to attach the heater to the back of the fireplace
opening.
Mark the position for the eyebolt at the back of the fireplace opening equal to the centre line of the
heater and at a height of 533 – 560mm. Drill, plug and screw in the eyebolt – See figure 4.
Thread one end of the steel wire through the two holes in the top flange, passing the wire
through the eyebolt and out through one of the opposite holes on the top flange – See figure 4.
Locate the heater into the fireplace opening, then by gently pulling the steel wire, gather up the
excess until the heater is firm.
Thread the wire back through the remaining hole to lock the wire and heater in place – See
figure 4.
Method C – With 20mm Wall Spacer (Optional extra)
The spacer should be fixed to the fireplace opening or surround using the screws provided. The
heater must then be fixed to the spacer using the screws provided. (See following section –Wall
spacer kit installation)

5
Figure 5
Method D – With 75mm Wall Spacer Kit (Supplied with Model 802 Fyrside, optional extra
with other appliances)
The wall kit should be securely fixed to the wall using the screws provided. The heater must then
be fixed to the wall kit. (See following section –Wall spacer kit installation)
If fixing through marble, ensure that both rawlplug and screw pass freely through the marble.
Secondary Screw fixing
If felt beneficial, the appliance can be additionally secured by screws through the side flanges – see
figure 5.
Wall Spacer kit installation

6
Figure 9
Figure 6
Figure 7 Figure 8
Figure 10
(Shown with Elegant
Front)
Assembly of Fronts
Icon & Adorn Fronts
Remove the tape securing the control linkage to the front.
Do Not Lift The Front Surround By The Control Knob
All Models
Carefully lift the front surround. Hook the front surround onto the retaining plates
on the heater body and lower the front surround down – See figure 6.
All Model 801 Versions
Check that the switch control spindle is in the OFF position and the slider is in the
OFF position. Swing the control linkage/boss towards the control spindle on the
heater and
push the boss onto the spindle, ensuring the “D” flats are in alignment – See figure 7
Final Assembly
All Models
With the two screws provided, fix the front surround to the heater body – See figure
8
Check the controls to make sure they operate smoothly.
Icon Model
Fix the lower cover to the front surround corner brackets using the two knurled screws provided – See figure 9.
Model 801 Visage, Elegant and Ultimate Fireside and all Model 802 versions
Place the front casting/fuel support in position by passing the screw heads/hooks through the keyhole slots in the surround
and lowering down – See figure 10.

7
Important
Before continuing any further with the installation or using the fire for the first time, please
check that the flame effect drum is correctly positioned, as this can sometimes become dislodged
during transit.
To do this:
•Lift out the fuel bed.
•You will then see the two light bulbs with the drum above them.
•The drum has a spring-loaded plunger at its right hand side. This should fit into the indent
in the black plastic bracket.
•If it is out of position simply push it back into the indent.
Fuel Effects
Icon
Place the log fuel effect in position in front of the glass screen – See figure 11.
Adorn
Fit the coal support – See figure 12.
All Models except Icon Front
Open the polythene bag containing the loose coals and place them on and in front of the coal support to give the most
pleasing effect. It is not necessary to use all the coals supplied.
All Models except Icon, Fyrside & Pizzazz
Place the ash pan into position below the casting.
Operating the Heater
Never cover the heater, there is a risk of fire if covered.
Model 802
The heater is operated by three switches, located below the canopy.
Switch 1 = O Main On – Off
In the On position only the fuel effect light operates
Switch 2 = ❙1 kW fan heat setting and fuel effect
Switch 3 = ❙❙ 2 kW fan heat setting and fuel effect
The switches are mechanically interlocked, so when switch 1 is turned off, all switches turn off.
Model 801
These models have a slider control located on the right side of the surround for operating the main functions of the heater.
Located to the left of the fan outlet grille are a lamp dimmer control and a room thermostat control.
The Lamp Dimmer is used to set the light output of the fuel effect between off and high as required.
The Room Thermostat is used to maintain room temperature, the higher the setting, the higher the room temperature
will be before the heater turns off. When using the fan Coolblow setting, the thermostat should be turned to a high
position.
Figure 11
Figure 12

8
The Slider Control
There are four slider positions
nOff
Fuel effect lighting on
Fan Coolblow on. Fuel effect lighting on (Set thermostat at High).
Fan heater on (2kw). Fuel effect lighting on (Set thermostat to a high setting and allow the room temperature to
settle before re-adjusting).

9
Figure 13
Maintaining Your Fire
Always disconnect the heater from the electricity supply by removing the 3 pin plug and allowing
the heater to cool before undertaking maintenance or replacing lamps.
Lamp Replacement
The lamps fitted to this heater are long life types, but due to the indeterminate life span
and ease of replacement are specifically excluded from the guarantee.
To replace a lamp.
All Models except Adorn and Icon
Remove the accessible loose coals. Unhook the front casting by lifting slightly to
disengage the unit from the keyhole slots in the trim and gently pull forward.
Replace with a 60W (maximum) clear Edison screw lamp. Do not use opaque or
coloured lamp bulbs.
Refit the front castings and relocate the coals.
Adorn and Icon Models
Remove the coals (Adorn). Lift out the coal support/fuel effect. It will also be
necessary to remove the effects drum to access the lamps. To remove, hold the drum
and firmly slide it to the right to disengage it from the motor spindle, withdraw it from
the heater See figure 13.
Replace with a 60W (maximum) clear B22 Edison screw lamp. Do not use opaque
or coloured lamp bulbs.
Refit the drum by sliding onto the motor spindle and pushing the other end into its
location socket – See figure 13. Check that the drum rotates correctly.
Refit the coal support/fuel effect and coals (Adorn).
Automatic Cut Out
A cut out is fitted to the heating element to prevent damage due to over heating. If it
operates due to an obstruction in the airflow, the heater must be turned off and allowed to cool for 15 minutes, obstruction
removed before restarting.
Care and Cleaning
The canopy trims and glass parts need only to be wiped clean with a dry soft cloth, do not use polishes or abrasive
materials.
Fault Finding
No or low light from the fuel effect: Check the lamp dimmer is turned to high, if it is, then it is possibly a lamp failure.
Remove the lamp as detailed above and check it in a table lamp, that is known to work.
No heat or light: Check the wall socket by plugging in a known working appliance. If functional check the 13A fuse in
the heater plug. If either fuse or socket is suspected, have them checked by an electrician.
Light but no heat: The automatic cut out, may have operated, see above.
Disposal
At the end of the products serviceable life it should be disposed of thoughtfully and safely in accordance with local
authority regulations. The plug should be removed from the mains cable and the mains cable cut from the heater.

10
USEFUL TELEPHONE NUMBERS
•Your Post Code
•Type of Fire
•Model / Name
•Serial Number
•The fault, problem or request
General advice about your heater
VALOR ADVICE LINE 08457 626 341
To report faults or arrange for your heater to be serviced
VALOR SERVICE 0121 386 6203
To order spares or for sales information
VALOR SALES 0121 386 6260
Callers in the Republic of Ireland
Call 00 44 121 373 8111
To help us quickly help you, please try to have
the following information available before
y
ou contact us.
