Screen and Headlight Washer Systems V. 5.1

The Company
Alongside our many specialised solutions for auto-
motive manufacturers, we also offer comprehensive
solutions and services for the aftermarket. Spare parts
of matching quality, supplied with the experience and
proven expertise of an OEM supplier are a particular
strength. Our comprehensive range of spare parts of
matching quality is readily available and is synonymous
with a perfect fit, simple installation and consistently
reliable quality, offering significant advantages for distri-
butors, workshops and consumers alike.
Das Unternehmen
Neben unseren speziellen und vielfältigen Lösungen für
Automobilhersteller bieten wir umfassende Lösungen
und Serviceaktivitäten für den Aftermarket.
Hierzu zählen insbesondere qualitativ gleichwertige
Ersatzteile, die wir mit dem Wissen und der langjähri-
gen Kompetenz eines Erstausrüsters anbieten.
Das umfassende und zeitnah verfügbare Leistungs-
spektrum an Ersatzteilen steht für Passgenauigkeit,
einen einfachen Einbau sowie gleichbleibende Qualität.
So bieten qualitativ gleichwertige Ersatzteile Groß-
händlern, Werkstätten und Endkunden gleichermaßen
deutliche Vorteile.
L‘entreprise
Parallèlement à nos solutions particulières et multip-
les pour les constructeurs automobile nous offrons
des solutions et des activités de service étendues
pour l‘Aftermarket (marché de pièces de rechange et
d‘accessoires). En font partie en particulier les pièces
détachées qualitativement équivalentes que nous
proposons avec le savoir et la compétence de longue
durée d‘un premier équipementier de série. La gamme
étendue de fournitures, disponibles à brève échéan-
ce, de pièces détachées représente la précision de
l‘assemblage, un montage simple ainsi qu‘une qualité
constante. Ainsi les pièces détachées qualitativement
équivalentes offrent des avantages nets de la même
manière aux grossistes, aux garages et aux clients
finaux.
Nuestra empresa
Además de las soluciones especiales y variadas que
producimos para fabricantes de automóviles, ofrece-
mos numerosas soluciones y actividades de servicio
para el mercado postventa. Entre éstas destacan en
particular los recambios de calidad equivalente, que
ofrecemos al mercado con los conocimientos y el nivel
de competencia, forjados durante muchos años, de
un fabricante de primeros equipos. Nuestro amplísimo
espectro de recambios, disponibles al poco tiempo de
aparecer en cada modelo de automóvil, se caracterizan
por su precisión de ajuste, su montaje sencillo y su
calidad constante. Por ello, los recambios de calidad
equivalente suponen por igual claras ventajas para
mayoristas, talleres y clientes finales.
The Company
2
The Company

La società
Oltre a numerose soluzioni specializzate per i produt-
tori di automobili offriamo soluzioni e servizi ad ampio
spettro per il settore aftermarket (pezzi di ricambio e
accessori). Tra questi rientrano in particolare pezzi di
ricambio qualitativamente equivalenti che offriamo con
il know-how e l’esperienza pluriennale di un fornitore
OEM. La vasta gamma di pezzi di ricambio rapida-
mente disponibili rappresenta una soluzione ottimale,
facilmente installabile e di qualità costante. I pezzi di
ricambio qualitativamente equivalenti offrono pertan-
to ai distributori, alle officine e ai clienti finali notevoli
vantaggi.
čðîñáïêā
Ēðîêîð õéìðóñæøêáíþïý÷ ê úêòðìðñòðöêíþïý÷
òæúæïêë åíā áãôðñòðêéãðåêôæíæë îý
äðôðãý ñòæåíðèêôþ ìðîñíæìóïýæ òæúæïêā,
ãìíĀùáā ïáâðò óæòãêóïý÷ ðñæòáøêë,åíā
ñðóíæñòðåáèïðäð ðâóíõèêãáïêā áãôðîðâêíæë.
Ą ùáóôïðóôê,ñð ìáùæóôãõ òáãïðøæïïýæ
ðòêäêïáíþïýî éáñáóïýæ ùáóôê,ìðôðòýæ îý,
ìáì ñòæåñòêāôêæ-êéäðôðãêôæíþ,ñòæåíáäáæî
ñáòôïæòáî ïá âáéæ ïáúê÷ éïáïêë ê îïðäðíæôïæäð
ðñýôá.Ĕ õùæôðî úêòðìðäð óñæìôòá õóíõä ê
ãðéîðèïðóôê ñðóôáãðì ã ìòáôùáëúêæ óòðìê
äáòáïôêòðãáïá ôðùïðóôþ êéäðôðãíæïêā êéåæíêë,
ñòðóôðë îðïôáè ê óôáâêíþïðæ ìáùæóôãð
ñòðêéãðåóôãá.Ēðÿôðîõ ñòêðâòæôáā ñð ìáùæóôãõ
òáãïðøæïïýæ ðòêäêïáíþïýî éáñáóïýæ ùáóôê
õ ïáó,ðñôðãýæ ñðìõñáôæíê,ñòðîýúíæïïýæ
ñòæåñòêāôêā ê ìðïæùïýæ ñðíþéðãáôæíê ã
ðåêïáìðãðë óôæñæïê ñðíõùáĀô ðùæãêåïýæ
ñòæêîõûæóôãá.
3
The Company

4

Content
Content
The Company 2
ProductOverview 6
ProductApplications(Passenger Cars) 34
ProductApplications(Commercial Vehicles)415
Reference List 445
Legend 500
55
5

7
Screen and Headlight Washer Systems
Headlight Washer Pumps
Headlight washer pumps are used for
headlight lens cleaning. They supply
the headlight lens washer nozzles with
a corresponding amount of water and
provide the high water pressure needed
for this application (12 V).
Screen Washer Pumps, Mono –
Centrifugal Pumps
Mono pumps have one outlet and sup-
ply the front or rear screen with water.
Two pumps are needed to supply both
screens (12 V or 24 V).
Screen Washer Pumps, Mono –
Gear-type Pumps
Self-priming mono pumps
(12 V or 24 V).
Screen Washer Pumps, Dual –
Centrifugal Pumps
Dual pumps can output fluid in two
directions. By using just one pump,
washer fluid is pumped through one
(or both) of the outlets to the front or
rear screen (12 V or 24 V).
Accessories
Fluid-level Switches
Fluid-level switches are used to warn of
low fluid levels. When the fluid falls
below a defined level, activation of a
reed contact causes a warning light to
come on.
Connectors
Angle, T, I and Y pieces are used to join
different segments of the washer hose
system.
Valves
Anti-drain back valves prevent any
return flow of the washer fluid, sub-
stantially improving the response time
of the washer system. Anti-drain back
valves can also be integrated into the
nozzle assembly.
Gaskets
Gaskets are fitted between pump
intake ports and reservoirs. Combined
with a filter they protect the pumps
against impurities, thereby preventing
damage.
Nozzle Needle
Nozzle needles are used to adjust ball-
type nozzles.
Adapters
Adapters are required for the 1:1 con-
nection of certain pumps in some
vehicles (see chapter entitled “Product
Application”)
Washer Fluid Reservoirs
The reservoirs hold the cleaning fluid.
Washer Nozzles
Washer nozzles deliver water for clean-
ing front and rear windshields, and
headlights. A heatable version of the
nozzles (12 V) is available in some
cases. Some nozzles are fitted with an
anti-drain valve to prevent a return
flow of fluid.
Ball-type Nozzles
There are two types of ball-type noz-
zles: single-jet nozzles (1) and multi-jet
nozzles (2/4). The water is sprayed
onto the screen as a corresponding
number of individual jets.
Product Overview
6

6
Screen and Headlight Washer Systems
Headlight Washer Pumps
Headlight washer pumps are used for
headlight lens cleaning. They supply
the headlight lens washer nozzles with
a corresponding amount of water and
provide the high water pressure needed
for this application (12 V).
Screen Washer Pumps, Mono –
Centrifugal Pumps
Mono pumps have one outlet and sup-
ply the front or rear screen with water.
Two pumps are needed to supply both
screens (12 V or 24 V).
Screen Washer Pumps, Mono –
Gear-type Pumps
Self-priming mono pumps
(12 V or 24 V).
Screen Washer Pumps, Dual –
Centrifugal Pumps
Dual pumps can output fluid in two
directions. By using just one pump,
washer fluid is pumped through one
(or both) of the outlets to the front or
rear screen (12 V or 24 V).
Accessories
Fluid-level Switches
Fluid-level switches are used to warn of
low fluid levels. When the fluid falls
below a defined level, activation of a
reed contact causes a warning light to
come on.
Connectors
Angle, T, I and Y pieces are used to join
different segments of the washer hose
system.
Valves
Anti-drain back valves prevent any
return flow of the washer fluid, sub-
stantially improving the response time
of the washer system. Anti-drain back
valves can also be integrated into the
nozzle assembly.
Gaskets
Gaskets are fitted between pump
intake ports and reservoirs. Combined
with a filter they protect the pumps
against impurities, thereby preventing
damage.
Product Range
Nozzle Needle
Nozzle needles are used to adjust ball-
type nozzles.
Adapters
Adapters are required for the 1:1 con-
nection of certain pumps in some
vehicles (see chapter entitled “Product
Application”)
Washer Fluid Reservoirs
The reservoirs hold the cleaning fluid.
Washer Nozzles
Washer nozzles deliver water for clean-
ing front and rear windshields, and
headlights. A heatable version of the
nozzles (12 V) is available in some
cases. Some nozzles are fitted with an
anti-drain valve to prevent a return
flow of fluid.
Ball-type Nozzles
There are two types of ball-type noz-
zles: single-jet nozzles (1) and multi-jet
nozzles (2/4). The water is sprayed
onto the screen as a corresponding
number of individual jets.
Product Overview
7

246-061-009-002D
Reservoir
_ Content [L]: 1,0
246-061-022-001C
Reservoir
_ Content [L]: 2,0
246-063-004-001G
Valve
_ Valve Type: Ball Valve
246-063-012-001G
Valve
_ Valve Type: Ball Valve
Vehicle models for general information only. Not to be used as a detailed applications guide. 9
246-063-013-001D
Valve
_ Valve Type: Ball Valve
246-063-016-001G
Valve
_ Valve Type: Ball Valve
246-063-016-003G
Valve
_ Valve Type: Ball Valve
246-068-003-001G
Nozzle
_ Number of Jets: 1
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
8

8
246-061-009-002D
Reservoir
_ Content [L]: 1,0
246-061-022-001C
Reservoir
_ Content [L]: 2,0
246-063-004-001G
Valve
_ Valve Type: Ball Valve
246-063-012-001G
Valve
_ Valve Type: Ball Valve
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
246-063-013-001D
Valve
_ Valve Type: Ball Valve
246-063-016-001G
Valve
_ Valve Type: Ball Valve
246-063-016-003G
Valve
_ Valve Type: Ball Valve
246-068-003-001G
Nozzle
_ Number of Jets: 1
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
9

246-068-013-004D
Nozzle
_ Number of Jets: 1
246-069-026-001G
Nozzle
_ Number of Jets: 2
MERCEDES-BENZ
Saloon (W123); KOMBI Estate (S123); COUPE (C123); S-CLASS (W108, W109);
/8 (W115); /8 (W114)
246-069-029-004G
Nozzle
_ Number of Jets: 2
246-069-050-005D
Nozzle
_ Number of Jets: 4
Vehicle models for general information only. Not to be used as a detailed applications guide. 11
246-069-056-001Z
Nozzle
_ Number of Jets: 2
SEAT
CORDOBA (6K2/C2); CORDOBA Vario (6K5); IBIZA Mk II (6K1); INCA (6K9);
LEON (1M1); TOLEDO Mk II (1M2)
VW
CADDY (14); CADDY Mk II (9K9A); CORRADO (53I); GOLF Convertible (155);
GOLF Mk III (1H1); GOLF Mk III Estate (1H5); GOLF Mk III Convertible (1E7);
GOLF Mk III Convertible (1E7); PASSAT (3A2, 35I); PASSAT Variant (3A5, 35I);
POLO (6N1); POLO Box (6NF); POLO Saloon (6KV2); POLO Variant (6KV5);
POLO (6N2); VENTO (1H2); TRANSPORTER Mk IV Bus (70XB, 70XC, 7DB, 7DW);
TRANSPORTER Mk IV Flatbed / Chassis (70XD)
246-069-059-001Z
Nozzle
_ Number of Jets: 2
BMW
3 (E36); 3 Compact (E36); 3 Convertible (E36); 3 Touring (E36); 5 (E34); 7 (E32)
246-075-010-001C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 1
_ Support No.: A
MAN
G; M 90; M 2000 L
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
10

10
246-068-013-004D
Nozzle
_ Number of Jets: 1
246-069-026-001G
Nozzle
_ Number of Jets: 2
MERCEDES-BENZ
Saloon (W123); KOMBI Estate (S123); COUPE (C123); S-CLASS (W108, W109);
/8 (W115); /8 (W114)
246-069-029-004G
Nozzle
_ Number of Jets: 2
246-069-050-005D
Nozzle
_ Number of Jets: 4
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
246-069-056-001Z
Nozzle
_ Number of Jets: 2
SEAT
CORDOBA (6K2/C2); CORDOBA Vario (6K5); IBIZA Mk II (6K1); INCA (6K9);
LEON (1M1); TOLEDO Mk II (1M2)
VW
CADDY (14); CADDY Mk II (9K9A); CORRADO (53I); GOLF Convertible (155);
GOLF Mk III (1H1); GOLF Mk III Estate (1H5); GOLF Mk III Convertible (1E7);
GOLF Mk III Convertible (1E7); PASSAT (3A2, 35I); PASSAT Variant (3A5, 35I);
POLO (6N1); POLO Box (6NF); POLO Saloon (6KV2); POLO Variant (6KV5);
POLO (6N2); VENTO (1H2); TRANSPORTER Mk IV Bus (70XB, 70XC, 7DB, 7DW);
TRANSPORTER Mk IV Flatbed / Chassis (70XD)
246-069-059-001Z
Nozzle
_ Number of Jets: 2
BMW
3 (E36); 3 Compact (E36); 3 Convertible (E36); 3 Touring (E36); 5 (E34); 7 (E32)
246-075-010-001C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 1
_ Support No.: A
MAN
G; M 90; M 2000 L
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
11

246-075-015-001C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: A
PORSCHE
911; 911 Targa; 914; 928
246-075-017-002C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 4
_ Support No.: C
MERCEDES-BENZ
A-CLASS (W168); A-CLASS (W169); S-CLASS (W108, W109); S-CLASS (W116);
G-CLASS Cabrio (W463); HECKFLOSSE (W111); COUPE (W111); CABRIOLET (W111);
/8 (W115); /8 (W114); /8 Coupe (W114); PAGODE (W113); VITO Bus (638);
VITO Box (638); VITO Bus (W639); VITO Box (W639); T1 Bus (602); T1 Box (602);
T1 Flatbed / Chassis (602); SPRINTER 3-t Bus (903); SPRINTER 3-t Box (903); SPRIN-
TER 3-t Flatbed / Chassis (903)
246-075-021-006C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: B
ALPINA
B7 Coupe (E24)
AUDI
50 (86); 80 (80, 82, B1); 100 Avant (43, C2); 100 (44, 44Q, C3);
100 Avant (44, 44Q, C3); 200 (44, 44Q); 200 Avant (44, 44Q); NSU RO 80
PORSCHE
924; 944; 944 Convertible
13
246-075-021-006C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: B
VW
DERBY (86); GOLF (17); JETTA (16); KAEFER; KARMANN GHIA Convertible (14, 34);
K 70 (48); PASSAT (32); PASSAT Variant (33); POLO (86); SCIROCCO (53);
1500,1600 Variant (36); LT28-50 Bus (281-363); LT28-50 Box (281-363);
LT28-50 Flatbed / Chassis (281-363); LT 40-55 I Flatbed / Chassis (293-909);
TRANSPORTER Mk II Bus; TRANSPORTER Mk II Flatbed / Chassis
246-075-021-007C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: C
MERCEDES-BENZ
S-CLASS (W116); G-CLASS (W460); G-CLASS Cabrio (W463); /8 (W115); /8 (W114);
/8 Coupe (W114); VITO Bus (638); VITO Box (638); VITO Bus (W639);
VITO Box (W639); T1 Bus (601); T1 Box (601); T1 Bus (602); T1 Box (602);
T1 Flatbed / Chassis (602); SPRINTER 3-t Bus (903); SPRINTER 3-t Box (903); SPRIN-
TER 3-t Flatbed / Chassis (903)
246-075-023-004C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: D
BMW
5 (E12)
VOLVO
340-360 (343, 345)
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
12

12
246-075-015-001C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: A
PORSCHE
911; 911 Targa; 914; 928
246-075-017-002C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 4
_ Support No.: C
MERCEDES-BENZ
A-CLASS (W168); A-CLASS (W169); S-CLASS (W108, W109); S-CLASS (W116);
G-CLASS Cabrio (W463); HECKFLOSSE (W111); COUPE (W111); CABRIOLET (W111);
/8 (W115); /8 (W114); /8 Coupe (W114); PAGODE (W113); VITO Bus (638);
VITO Box (638); VITO Bus (W639); VITO Box (W639); T1 Bus (602); T1 Box (602);
T1 Flatbed / Chassis (602); SPRINTER 3-t Bus (903); SPRINTER 3-t Box (903); SPRIN-
TER 3-t Flatbed / Chassis (903)
246-075-021-006C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: B
ALPINA
B7 Coupe (E24)
AUDI
50 (86); 80 (80, 82, B1); 100 Avant (43, C2); 100 (44, 44Q, C3);
100 Avant (44, 44Q, C3); 200 (44, 44Q); 200 Avant (44, 44Q); NSU RO 80
PORSCHE
924; 944; 944 Convertible
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
246-075-021-006C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: B
VW
DERBY (86); GOLF (17); JETTA (16); KAEFER; KARMANN GHIA Convertible (14, 34);
K 70 (48); PASSAT (32); PASSAT Variant (33); POLO (86); SCIROCCO (53);
1500,1600 Variant (36); LT28-50 Bus (281-363); LT28-50 Box (281-363);
LT28-50 Flatbed / Chassis (281-363); LT 40-55 I Flatbed / Chassis (293-909);
TRANSPORTER Mk II Bus; TRANSPORTER Mk II Flatbed / Chassis
246-075-021-007C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: C
MERCEDES-BENZ
S-CLASS (W116); G-CLASS (W460); G-CLASS Cabrio (W463); /8 (W115); /8 (W114);
/8 Coupe (W114); VITO Bus (638); VITO Box (638); VITO Bus (W639);
VITO Box (W639); T1 Bus (601); T1 Box (601); T1 Bus (602); T1 Box (602);
T1 Flatbed / Chassis (602); SPRINTER 3-t Bus (903); SPRINTER 3-t Box (903); SPRIN-
TER 3-t Flatbed / Chassis (903)
246-075-023-004C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
_ Support No.: D
BMW
5 (E12)
VOLVO
340-360 (343, 345)
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
13

14
246-075-024-002C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Voltage [V]: 24
_ Connector No.: 1; _ Connector No.: 1
_ Support No.: C; _ Support No.: C
MERCEDES-BENZ
S-CLASS (W220); SL (R230); G-CLASS (W460); G-CLASS (W461); G-CLASS (W463);
G-CLASS Cabrio (W463); HECKFLOSSE (W110); VITO Bus (638); VITO Box (638);
T1 Box (602); NG; T2/L
246-075-024-005C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 1
_ Support No.: D
246-075-040-020C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 1
_ Support No.: F
VOLVO
F10
246-075-042-001C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
BMW
7 (E23)
Vehicle models for general information only. Not to be used as a detailed applications guide. 15
246-075-042-001C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
PORSCHE
911 (964); 924; 928; 944
VOLVO
340-360 (343, 345)
246-075-044-001C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 2
VOLVO
740 (744); 740 Kombi (745); 760 (704, 764); 760 Kombi (704, 765); 780;
850 (LS); 850 Estate (LW); 940 (944); 940 Kombi (945); 940 Mk II (944);
940 Mk II Estate (945); 960 (964); 960 Kombi (965); 960 Mk II (964);
960 Mk II Estate (965)
246-075-044-002A
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 2
VOLVO
S70; V70; 740 Kombi (745); 760 Kombi (704, 765); 850 Estate (LW);
940 Kombi (945); 940 Mk II Estate (945); 960 Kombi (965); 960 Mk II Estate (965)
246-075-044-003A
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 2
SCANIA
3 - series; 4 - series
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
14

14
246-075-024-002C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Voltage [V]: 24
_ Connector No.: 1; _ Connector No.: 1
_ Support No.: C; _ Support No.: C
MERCEDES-BENZ
S-CLASS (W220); SL (R230); G-CLASS (W460); G-CLASS (W461); G-CLASS (W463);
G-CLASS Cabrio (W463); HECKFLOSSE (W110); VITO Bus (638); VITO Box (638);
T1 Box (602); NG; T2/L
246-075-024-005C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 1
_ Support No.: D
246-075-040-020C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 1
_ Support No.: F
VOLVO
F10
246-075-042-001C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
BMW
7 (E23)
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
246-075-042-001C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 1
PORSCHE
911 (964); 924; 928; 944
VOLVO
340-360 (343, 345)
246-075-044-001C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 2
VOLVO
740 (744); 740 Kombi (745); 760 (704, 764); 760 Kombi (704, 765); 780;
850 (LS); 850 Estate (LW); 940 (944); 940 Kombi (945); 940 Mk II (944);
940 Mk II Estate (945); 960 (964); 960 Kombi (965); 960 Mk II (964);
960 Mk II Estate (965)
246-075-044-002A
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 2
VOLVO
S70; V70; 740 Kombi (745); 760 Kombi (704, 765); 850 Estate (LW);
940 Kombi (945); 940 Mk II Estate (945); 960 Kombi (965); 960 Mk II Estate (965)
246-075-044-003A
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 2
SCANIA
3 - series; 4 - series
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
15

16
246-075-050-007C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 1
246-075-051-003C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 2
_ Support No.: F
VOLVO
140 (142, 144); 240 (P242, P244); 240 Kombi (P245); 260 (P262, P264);
260 Estate (P265)
246-075-051-007C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 2
_ Support No.: F
VOLVO
F 10; F 12; F 16
246-080-003-006D
Nozzle
_ Voltage [V]: 12
_ Number of Jets: 2
_ Equipment: Heatable
MERCEDES-BENZ
S-CLASS (W126)
Vehicle models for general information only. Not to be used as a detailed applications guide. 17
246-080-010-002Z
Nozzle
_ Voltage [V]: 12
_ Number of Jets: 2
_ Equipment: Heatable
SEAT
CORDOBA (6K2/C2); IBIZA Mk II (6K1); INCA (6K9); LEON (1M1); TOLEDO (1L);
TOLEDO Mk II (1M2)
VW
CADDY (14); CADDY Mk II (9K9A); CORRADO (53I); GOLF Convertible (155);
GOLF Mk III (1H1); GOLF Mk III Estate (1H5); GOLF Mk III Convertible (1E7);
PASSAT (3A2, 35I); PASSAT Variant (3A5, 35I); POLO (6N1); POLO Saloon (6KV2);
VENTO (1H2); TRANSPORTER Mk IV Bus (70XB, 70XC, 7DB, 7DW);
TRANSPORTER Mk IV Box (70XA); TRANSPORTER Mk IV Flatbed / Chassis (70XD)
246-080-013-001Z
Nozzle
_ Voltage [V]: 12
_ Number of Jets: 2
_ Equipment: Heatable
BMW
3 (E30); 3 Touring (E30); 5 (E34); 6 (E24); 7 (E32)
246-080-013-003Z
Nozzle
_ Voltage [V]: 12
_ Number of Jets: 2
_ Equipment: Heatable
BMW
3 (E36); 3 Compact (E36); 3 Touring (E36); 5 (E34); 7 (E32); Z3
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
16

16
246-075-050-007C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 1
246-075-051-003C
Mono - Gear-type Pump
_ Voltage [V]: 12
_ Connector No.: 2
_ Support No.: F
VOLVO
140 (142, 144); 240 (P242, P244); 240 Kombi (P245); 260 (P262, P264);
260 Estate (P265)
246-075-051-007C
Mono - Gear-type Pump
_ Voltage [V]: 24
_ Connector No.: 2
_ Support No.: F
VOLVO
F 10; F 12; F 16
246-080-003-006D
Nozzle
_ Voltage [V]: 12
_ Number of Jets: 2
_ Equipment: Heatable
MERCEDES-BENZ
S-CLASS (W126)
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
246-080-010-002Z
Nozzle
_ Voltage [V]: 12
_ Number of Jets: 2
_ Equipment: Heatable
SEAT
CORDOBA (6K2/C2); IBIZA Mk II (6K1); INCA (6K9); LEON (1M1); TOLEDO (1L);
TOLEDO Mk II (1M2)
VW
CADDY (14); CADDY Mk II (9K9A); CORRADO (53I); GOLF Convertible (155);
GOLF Mk III (1H1); GOLF Mk III Estate (1H5); GOLF Mk III Convertible (1E7);
PASSAT (3A2, 35I); PASSAT Variant (3A5, 35I); POLO (6N1); POLO Saloon (6KV2);
VENTO (1H2); TRANSPORTER Mk IV Bus (70XB, 70XC, 7DB, 7DW);
TRANSPORTER Mk IV Box (70XA); TRANSPORTER Mk IV Flatbed / Chassis (70XD)
246-080-013-001Z
Nozzle
_ Voltage [V]: 12
_ Number of Jets: 2
_ Equipment: Heatable
BMW
3 (E30); 3 Touring (E30); 5 (E34); 6 (E24); 7 (E32)
246-080-013-003Z
Nozzle
_ Voltage [V]: 12
_ Number of Jets: 2
_ Equipment: Heatable
BMW
3 (E36); 3 Compact (E36); 3 Touring (E36); 5 (E34); 7 (E32); Z3
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
17

246-082-001-001C
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 2
SAAB
900 Hatchback; 900; 900 Convertible; 9000 Hatchback; 9000
246-082-001-002C
Mono - Centrifugal Pump
_ Voltage [V]: 24
_ Connector No.: 2
246-082-005-002C
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 4
MERCEDES-BENZ
190 (W201); Saloon (W123); KOMBI Estate (S123); Saloon (W124);
KOMBI Estate (S124); COUPE (C124); CABRIOLET (A124); E-CLASS (W124);
E-CLASS Estate (S124); E-CLASS Coupe (C124); E-CLASS Convertible (A124);
S-CLASS (W126); S-CLASS Coupe (C126); S-CLASS (W140); SL (R107)
246-082-008-012C
Mono - Centrifugal Pump
_ Voltage [V]: 24
_ Connector No.: 1
MAN
G
MERCEDES-BENZ
LK/LN2; LP; MK; T2/LN1; VARIO
Vehicle models for general information only. Not to be used as a detailed applications guide. 19
246-082-008-013P
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 4
MERCEDES-BENZ
190 (W201); C-CLASS (W202); C-CLASS Estate (S202); Saloon (W123);
KOMBI Estate (S123); COUPE (C123); Saloon (W124); KOMBI Estate (S124);
COUPE (C124); CABRIOLET (A124); E-CLASS (W124); E-CLASS Estate (S124);
E-CLASS Coupe (C124); E-CLASS Convertible (A124); E-CLASS (W210);
S-CLASS (W126); S-CLASS Coupe (C126); S-CLASS (W140); S-CLASS Coupe (C140);
S-CLASS Coupe (C215); SL Coupe (C107); SL (R107); SL (R129); /8 (W115);
/8 (W114)
246-082-008-014C
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 1
AUDI
A6 (4A, C4); A6 Avant (4A, C4); A6 Avant (4B, C5); V8 (44_, 4C_); 80 (80, 82, B1);
80 (81, 85, B2); COUPE (81, 85); QUATTRO (85); 80 (89, 89Q, 8A, B3);
COUPE (89, 8B); CABRIOLET (8G7, B4); 80 Avant (8C, B4); 90 (81, 85, B2);
90 (89, 89Q, 8A, B3); 100 (C1); 100 (43, C2); 100 Avant (43, C2);
100 (44, 44Q, C3); 100 Avant (44, 44Q, C3); 100 (4A, C4); 100 Avant (4A, C4);
200 (43); 200 (44, 44Q); 200 Avant (44, 44Q)
FORD
TRANSIT Bus (T_ _); TRANSIT Box (T_ _); TRANSIT Box (E_ _)
LADA
NIVA (2121); SAMARA (2108, 2109); SAMARA FORMA (21099)
MERCEDES-BENZ
G-CLASS (W460); V-CLASS (638/2); VITO Bus (638); VITO Box (638); T1 Bus (601);
T1 Box (601); T1 Flatbed / Chassis (601); SPRINTER 2-t Bus (901, 902);
SPRINTER 2-t Box (901, 902); SPRINTER 2-t Flatbed / Chassis (901, 902);
SPRINTER 3-t Bus (903); SPRINTER 3-t Box (903);
SPRINTER 3-t Flatbed / Chassis (903); SPRINTER 4-t Bus (904);
SPRINTER 4-t Box (904); SPRINTER 4-t Flatbed / Chassis (904)
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
18

18
246-082-001-001C
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 2
SAAB
900 Hatchback; 900; 900 Convertible; 9000 Hatchback; 9000
246-082-001-002C
Mono - Centrifugal Pump
_ Voltage [V]: 24
_ Connector No.: 2
246-082-005-002C
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 4
MERCEDES-BENZ
190 (W201); Saloon (W123); KOMBI Estate (S123); Saloon (W124);
KOMBI Estate (S124); COUPE (C124); CABRIOLET (A124); E-CLASS (W124);
E-CLASS Estate (S124); E-CLASS Coupe (C124); E-CLASS Convertible (A124);
S-CLASS (W126); S-CLASS Coupe (C126); S-CLASS (W140); SL (R107)
246-082-008-012C
Mono - Centrifugal Pump
_ Voltage [V]: 24
_ Connector No.: 1
MAN
G
MERCEDES-BENZ
LK/LN2; LP; MK; T2/LN1; VARIO
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
246-082-008-013P
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 4
MERCEDES-BENZ
190 (W201); C-CLASS (W202); C-CLASS Estate (S202); Saloon (W123);
KOMBI Estate (S123); COUPE (C123); Saloon (W124); KOMBI Estate (S124);
COUPE (C124); CABRIOLET (A124); E-CLASS (W124); E-CLASS Estate (S124);
E-CLASS Coupe (C124); E-CLASS Convertible (A124); E-CLASS (W210);
S-CLASS (W126); S-CLASS Coupe (C126); S-CLASS (W140); S-CLASS Coupe (C140);
S-CLASS Coupe (C215); SL Coupe (C107); SL (R107); SL (R129); /8 (W115);
/8 (W114)
246-082-008-014C
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 1
AUDI
A6 (4A, C4); A6 Avant (4A, C4); A6 Avant (4B, C5); V8 (44_, 4C_); 80 (80, 82, B1);
80 (81, 85, B2); COUPE (81, 85); QUATTRO (85); 80 (89, 89Q, 8A, B3);
COUPE (89, 8B); CABRIOLET (8G7, B4); 80 Avant (8C, B4); 90 (81, 85, B2);
90 (89, 89Q, 8A, B3); 100 (C1); 100 (43, C2); 100 Avant (43, C2);
100 (44, 44Q, C3); 100 Avant (44, 44Q, C3); 100 (4A, C4); 100 Avant (4A, C4);
200 (43); 200 (44, 44Q); 200 Avant (44, 44Q)
FORD
TRANSIT Bus (T_ _); TRANSIT Box (T_ _); TRANSIT Box (E_ _)
LADA
NIVA (2121); SAMARA (2108, 2109); SAMARA FORMA (21099)
MERCEDES-BENZ
G-CLASS (W460); V-CLASS (638/2); VITO Bus (638); VITO Box (638); T1 Bus (601);
T1 Box (601); T1 Flatbed / Chassis (601); SPRINTER 2-t Bus (901, 902);
SPRINTER 2-t Box (901, 902); SPRINTER 2-t Flatbed / Chassis (901, 902);
SPRINTER 3-t Bus (903); SPRINTER 3-t Box (903);
SPRINTER 3-t Flatbed / Chassis (903); SPRINTER 4-t Bus (904);
SPRINTER 4-t Box (904); SPRINTER 4-t Flatbed / Chassis (904)
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
19

246-082-008-014C
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 1
OPEL
ASCONA A (81_, 86_, 87_, 88_); ASCONA B (81_, 86_, 87_, 88_);
ASCONA C Hatchback (84_, 89_); ASCONA C (81_, 86_, 87_, 88_);
ASTRA F (56_, 57_); COMMODORE C (14_, 19_); COMMODORE C Estate (61);
CORSA A Hatchback (93_, 94_, 98_, 99_); CORSA A TR (91_, 92_, 96_, 97_);
CORSA A Box; KADETT C City; KADETT C; KADETT C Estate; KADETT C Coupe;
KADETT D (31_-34_, 41_-44_); KADETT D Estate (35_, 36_, 45_, 46_);
KADETT E Hatchback (33_, 34_, 43_, 44_); KADETT E (39_, 49_);
KADETT E Estate (35_, 36_, 45_, 46_); KADETT E Convertible (43B_);
KADETT E Box (37_, 47_); KADETT E Combo (38_, 48_); MANTA B (58_, 59_);
MANTA B CC (53_, 55_); MONZA A (22_); OMEGA A (16_, 17_, 19_);
OMEGA A Estate (66_, 67_); OMEGA B (25_, 26_, 27_); REKORD D;
REKORD D Estate; REKORD E (17_-19_, 11_, 14_, 16_);
REKORD E Estate (61_, 66_, 67_); SENATOR A (29_); SENATOR B (29_);
VECTRA A (86_, 87_)
SAAB
90; 900 Hatchback; 900
SEAT
TOLEDO (1L)
VAUXHALL
ASTRA Mk III; CARLTON Mk III; CARLTON Mk III Estate; CAVALIER Mk II Hatchback;
CAVALIER Mk II; CAVALIER Mk II Estate; CAVALIER Mk II Convertible;
CAVALIER Mk III; NOVA Hatchback; NOVA; OMEGA; SENATOR Mk II
Vehicle models for general information only. Not to be used as a detailed applications guide. 21
246-082-008-014C
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 1
VW
CADDY (14); CORRADO (53I); DERBY (86); DERBY (86C, 80); GOLF (17);
GOLF Convertible (155); GOLF Mk II (19E, 1G1); ILTIS (183); JETTA (16);
JETTA Mk II (19E, 1G2); PASSAT (32); PASSAT Variant (33); PASSAT (32B);
PASSAT Saloon (32B); PASSAT Variant (32B); PASSAT (3A2, 35I); POLO (86);
POLO (86C, 80); POLO CLASSIC (86C, 80); POLO Coupe (86C, 80);
POLO Box (86CF); POLO (6N1); POLO Saloon (6KV2); SANTANA (32B); SCIROC-
CO (53); SCIROCCO (53B); LT28-50 Bus (281-363); LT28-50 Box (281-363);
LT 40-55 I Box (291-512); LT28-50 Flatbed / Chassis (281-363); LT Mk II Bus (2DM);
LT Mk II Box (2DX0AE); LT Mk II Flatbed / Chassis (2DX0FE);
TRANSPORTER Mk III Bus; TRANSPORTER Mk III Box;
TRANSPORTER Mk III Flatbed / Chassis;
TRANSPORTER Mk IV Bus (70XB, 70XC, 7DB, 7DW);
TRANSPORTER Mk IV Box (70XA); TRANSPORTER Mk IV Flatbed / Chassis (70XD)
246-082-008-021G
Mono - Centrifugal Pump
_ Voltage [V]: 12
_ Connector No.: 6
OPEL
ASTRA G Coupe (F07_); CORSA B (73_, 78_, 79_, F35_); CORSA C (F08, F68);
OMEGA B (25_, 26_, 27_); TIGRA (95_); VECTRA B (36_); VECTRA C GTS; VECTRA C;
ZAFIRA (F75_)
SEAT
CORDOBA (6K2/C2); CORDOBA Vario (6K5); IBIZA Mk II (6K1); INCA (6K9)
VAUXHALL
OMEGA; VECTRA Hatchback; VECTRA
VW
CADDY II Estate (9K9B); CADDY Mk II (9K9A); GOLF Mk III Estate (1H5);
GOLF Mk III Convertible (1E7); GOLF Mk IV Estate (1J5);
GOLF Mk III Convertible (1E7); PASSAT (3A2, 35I); PASSAT (3B2);
POLO Saloon (6KV2); VENTO (1H2)
Vehicle models for general information only. Not to be used as a detailed applications guide.
Product Overview
20
