VDO VIEWLINE LEVEL GAUGES User manual

VDO – A trademark of the Continental Corporation
Product Information
www.vdo.com
Viewline Level gauges
Description
Indication of Fuel- Freshwater- and Wastewater Tank levels.
Features
_ Integrated Warning LED.
_ Changeable Frontbezels.
_ LED Illumination Picture: Fuel level gauge
_ Flush mount possibility
_ High reliability
Concept
Housing PC; flame retarding (UL94)
Bezel PC or ABS; several colors and shapes (see table)
Lens PMMA; double lens
Dial backlit; different colors (see table)
Pointer backlit, white on black dials; red on white dials
Illumination Dial: LED amber (605nm)
Pointer: LED red (632nm)
Warning LED red (632nm)
Mounting spinlock Nut; locking height 0,5mm – 20mm,
optional Studs and Bracket; locking height 2 – 15mm
Connection 8 pin MQS connector system

Viewline Level gauges
Technische Änderungen vorbehalten 12/09 Technical details subject to change 2 - 4
The reproduction, distribution and utilization of this document as well as the communication of its contents to others without express
authorization is prohibited. Offenders will be held liable for the payment of damages. All right reserved in the event of the grant of a patent,
utility model or design.
Technical Data
Installation depth 50mm
Installation diameter 52mm
Deflection angle 90°
Operating Voltage 10 – 16 Volt
Accuracy < 3,6 angular degrees
Current consumption < 140 mA, including Warning LED
Operating temperature -30°C to +80°C; plated bezels (chrome) -30°C to +70°C
Storage temperature -40°C to +80°C for 48h; plated bezels (chrome) -40°C to +70°C
+90°C for 1h
Temperature shock Range -40°C to +85°C; plated bezels (chrome) -40°C to +70°C
Transformation time 10 seconds
Retention time 2h
Climatic test Range +25°C to +55°C
Rel. Humidity 95%
EMC in conformity with DIN_EN 61000-6-3
DIN_EN 61000-6-1
DIN_EN 61000-6-4
DIN_EN 61000-6-2
Standards EN 60945
GL, Category C, F (under preparation)
Vibration Sinus 2g; 10-500Hz; duration 16h
Noise 3g; 10-1000Hz, duration 8h
Mechanical shock continuous 25g; 6ms; 1Hz
Single shock 100g; 11ms
Free fall 1m; 3 times
Chemical resistance against- preservative agent
- preservative agent remover
- cold cleaner
- methylated spirit
- interior cleaner
- drinks containing caffeine and tannin
Nominal position NL 0 to NL 85 (DIN16257)
Protection class according to IEC 60529
Front: IP67 (in Nominal position)
Rear: IP52 (in Nominal position)
Reverse polarity protection yes, 5 minute
Over voltage protection yes, 24V for1 minute

Viewline Level gauges
available Gauges:
No. packed No.
unpacked color Function Double Scale Measureme nt range ISO Symbol Sensor
type * Voltage Double
lens
A2C59510034 A2C53210954 black Freshwater no 1/1 20mA 12+24 yes
A2C59510035 A2C53210953 white Freshwater no 1/1 20mA 12+24 yes
A2C59510036 A2C53210834 black Blackwater no 1/1 WASTE 20mA 12+24 yes
A2C59510037 A2C53210833 white Blackwater no 1/1 WASTE 20mA 12+24 yes
A2C60100126 A2C53191462 black Fuel no 1/1 LT EU 12V no
A2C60100127 A2C53191463 black Fuel no 1/1 DT A 12V no
A2C60100128 A2C53191464 black Fuel no F LT EU 12V no
A2C60100129 A2C53191465 black Fuel no F LT US 12V no
A2C60100130 A2C53191466 black Fuel no F 090 12V no
A2C60100131 A2C53191467 black Fuel no F DT A 12V no
A2C60100132 A2C53191468 white Fuel no 1/1 LT EU 12V no
A2C60100133 A2C53191469 white Fuel no 1/1 DT A 12V no
A2C60100134 A2C53191470 white Fuel no F LT US 12V no
A2C60100135 A2C53191472 white Fuel no F 090 12V no
A2C60100136 A2C53191473 white Fuel no F DT A 12V no
A2C60100137 A2C53191755 black Fuel no 1/1 LT EU 12V yes
A2C60100138 A2C53191756 black Fuel no 1/1 DT A 12V yes
A2C60100139 A2C53191757 black Fuel no F LT EU 12V yes
A2C60100140 A2C53191758 black Fuel no F LT US 12V yes
A2C60100141 A2C53191759 black Fuel no F 090 12V yes
A2C60100142 A2C53191760 black Fuel no F DT A 12V yes
A2C60100143 A2C53191761 white Fuel no 1/1 LT EU 12V yes
Technische Änderungen vorbehalten 12/09 Technical details subject to change 3 - 4
The reproduction, distribution and utilization of this document as well as the communication of its contents to others without express
authorization is prohibited. Offenders will be held liable for the payment of damages. All right reserved in the event of the grant of a patent,
utility model or design.

Viewline Level gauges
A2C60100144 A2C53191762 white Fuel no 1/1 DT A 12V yes
A2C60100145 A2C53191763 white Fuel no F LT US 12V yes
A2C60100146 A2C53191764 white Fuel no F 090 12V yes
A2C60100147 A2C53191765 white Fuel no F DT A 12V yes
A2C60100148 A2C53192573 black Freshwater no 1/1 WATER LT EU 12V yes
A2C60100149 A2C53192574 black Freshwater no F WATER LT EU 12V yes
A2C60100150 A2C53192575 white Freshwater no 1/1 WATER LT EU 12V yes
A2C60100326 A2C53192576 white Freshwater no F WATER LT EU 12V yes
*
LT EU Lever type european ohmic values
LT US Lever type US ohmic values
DT A Dip type, adjustable
Accessories:
A2C59510221 VL Dropping resistor 24V without connector
A2C59510886 VL Make point switch 12V
A2C59510854 VL Mounting Kit (studs and brackets) 52, 85, 110mm
A2C59510864 VL Mounting bracket flush mount
A2C53215640 VL Sealing Ring 52mm flush mount
A2C59510847 Bush housing, 8-pin
A2C53324664 Protective connector cap, 8-pin
Tyco No. 539635-1 Hand pliers
Tyco No. 539682-2 Tool for hand pliers.
Tyco No. 1355718-1 Single contacts 0.14 – 0.22 mm² tin plated
Tyco No. 963729-1 Single contacts 0.5 – 0.75 mm² tin plated
Tyco No. 1355717-1 Strip 0.14 – 0.22 mm² tin plated
Tyco No. 928999-1 Strip 0.25 – 0.5 mm² tin plated
Tyco No. 963715-1 Strip 0.5 – 0.75 mm² tin plated
Bezels 52mm
black black nickel* brush aluminum* chrome gold* white
flat A2C53186040 A2C53293468 A2C53293480 A2C53186023 A2C53293482 A2C53186022
round A2C53186027 A2C53293494 A2C53293495 A2C53186029 A2C53293496 A2C53186028
triangle A2C53186024 A2C53293545 A2C53293546 A2C53186026 A2C53293548 A2C53186025
* Only on request, no part off standard portfolio
