VDO TPMS Go User manual

VDO TPMS Go
User manual
24/2018 – EN

REVISION OF THE VDO TPMS GO MANUAL
Due to continuing improvements, the information contained in this user manual, the features and design
of this device are subject to be changed without prior notice.
Edition/
Revision Reference Date (week/year) Chapters updated
First edition 24/2018 Firmware version HV1-13-11

UM-UV1-13-11 Table of contents
Page 1/32
TABLE OF CONTENTS
User guide 2
VDO TPMS GO TOOL ....................................................................................................2
1. SPECIFICATIONS..........................................................................................................................2
2. IMPORTANT SAFETY INSTRUCTIONS.........................................................................................3
3. CAUTION .......................................................................................................................................4
4. FUNCTION KEYS...........................................................................................................................5
5. POWER ON....................................................................................................................................6
6. OPERATING INSTRUCTIONS........................................................................................................7
VDO TPMS GO USE.......................................................................................................8
1. CHECK SENSOR...........................................................................................................................8
2. PROGRAM BLANK SENSOR ......................................................................................................11
3. PART LOOKUP............................................................................................................................17
SETTINGS.....................................................................................................................19
1. SETTINGS MENU.........................................................................................................................19
ABOUT..........................................................................................................................23
1. THE ABOUT MENU......................................................................................................................23
LANGUAGE..................................................................................................................24
1. LANGUAGE MENU......................................................................................................................24
RECENT SENSOR DATA.............................................................................................25
1. RECENT SENSOR DATA.............................................................................................................25
MISCELLANEOUS........................................................................................................26
1. CHARGE......................................................................................................................................26
2. TROUBLESHOOTING..................................................................................................................27
3. TOOL UPDATE............................................................................................................................27
4. LIMITED HARDWARE WARRANTY ............................................................................................29
5. SAFETY BATTERY AND CHARGE INFORMATION....................................................................29
6. CE STATEMENTS........................................................................................................................31
7. FCC STATEMENTS......................................................................................................................31
8. RCM STATEMENTS.....................................................................................................................31
9. RECYCLING.................................................................................................................................31
Index 32

UM-HV1-13-11 VDO TPMS GO user guide
Page 2/32
User guide
VDO TPMS GO TOOL
1. SPECIFICATIONS
Battery Type: Rechargeable Li-Po (Lithium-Polymer).
Battery Life: Approximately 400 activations per full charge.
Dimensions (Max. L,W,D): 16.5 cm x 9.5 cm x 3.8 cm (6.5" x 3.7" x 1.5")
Housing Material: High Impact ABS.
Response Frequency:Main frequencies: 315 MHz and 433.92 MHz.
(supporting most specific frequencies).
Low Battery Indication: LCD bar graph display.
Weight: 0,35 Kg (0,7 lbs.)
Temperature: Operating: -4° F to 131° F (-20° C to +55° C).
Storage: -40°F to 140° F (-40° C to +60° C).
Operating Altitude: Up to 2 000 m (6 560 ft).
Device accessories: USB cable
Power supply
USB stick with WebTPM PC software, driver program
and user manual

UM-HV1-13-11 VDO TPMS GO user guide
Page 3/32
2. IMPORTANT SAFETY INSTRUCTIONS
Do not discard. Retain for future reference.
This device complies with:
- CE standards
- FCC rules
- RCM standards
- ROHS standards
Operation is subject to the following two conditions:
(1) This device will not cause harmful interference, and
(2) This device will accept any interference received, including interference that may
cause undesired or improper operation.
WARNING: This product emits electromagnetic and electronically
generated waves that may interfere with the safe operation of
pacemakers.
Individuals that have pacemakers should never use this product.
WARNING:
Do not use on live electrical circuits.
Must read instructions before use.
Wear safety goggles. (User and bystanders).
Risk of entanglement.
Read the Warranty, Safety and Recycling information at the end of this user guide.

UM-HV1-13-11 VDO TPMS GO user guide
Page 4/32
3. CAUTION
READ THESE INSTRUCTIONS BEFORE USE
Your Tire Pressure Monitoring (TPM) tool has been designed to be durable, safe, and
reliable when properly used.
All VDO TPMS TOOLS are intended to be used only by qualified and trained automotive
technicians or in a light industrial repair shop environment. Please read all instructions
below before using. Always follow these safety instructions. If you have any questions
pertaining to the safe or reliability use of this tool, please call your local dealer.
1. Read All Instructions
All warnings on the tool and in this manual should be adhered to. All operating instructions
should be followed.
2. Retain Instructions
The safety and operating instructions should be retained for future reference.
3. Heed Warnings
User and bystanders must wear safety goggles and must read instructions before use. Do
not use on live electrical circuits, risk of entanglement.
4. Cleaning
Clean with a soft dry cloth, or if necessary, a soft damp cloth. Do not use any harsh
chemical solvents such as acetone, thinner, brake cleaner, alcohol, etc as this may
damage the plastic surface.
5. Water & Moisture
Do not use this tool where contact or immersion in water is a possibility. Never spill liquid
of any kind onto the tool.
6. Storage
Do not use or store the tool in an area where it is exposed to direct sunlight or excessive
moisture.
7. Use
To reduce the risk of fire, do not operate the tool in the vicinity of open containers or
flammable liquids. Do not use if the potential for explosive gas or vapors exists. Keep the
tool away from heat generating sources. Do not operate the tool with the battery cover
removed.

UM-HV1-13-11 VDO TPMS GO user guide
Page 5/32
4. FUNCTION KEYS
Power ON /OFF switch Test or trigger sensor.
Next, continue or confirm. Cancel, previous step.
Navigate to select "up”. Navigate to select “down”.
Navigate to select “left”. Navigate to select “right”.
Battery charge
indicator and
low bat. light
Trigger light
Result lights
Keyboard
Antenna

UM-HV1-13-11 VDO TPMS GO user guide
Page 6/32
5. POWER ON
Press key to turn on the TPMS TOOL
ØDisplays the VDO Logo as Fig. 1.
Fig. 1
ØThe software version as Fig. 2.
VDO TPMS Go
Version HV1-13-11
ZONE:EUROPE
Fig. 2
ØAt first start or after a factory reset, the work
zone is asked as Fig. 3.
ZONE
> AMERICA
EUROPE
COREA
Fig. 3
ØThen reverts to the MAIN MENU as Fig. 4.
MAIN MENU
CHECK SENSOR
Fig. 4

UM-HV1-13-11 VDO TPMS GO user guide
Page 7/32
6. OPERATING INSTRUCTIONS
6.1. TPMSTOOL OVERVIEW
Read and diagnose sensors.
Service Procedure
Read Sensor Test
Before servicing the tires/wheels, using your
TPMS TOOL, trigger each of the vehicle's sensors to
make sure they are working properly.
This will eliminate the liability associated with
replacing previously damaged or defective sensors.
MAIN MENU
CHECK SENSOR
This procedure will not change the vehicle settings because the vehicle has yet to be put
into learn/retraining mode. This procedure allows you to quickly identify damaged or
defective sensors, because some vehicles do not report a damaged or defective sensor
condition on the instrument cluster for up to 20 minutes.
Note: If the sensorsdo not trigger, please refer to the Troubleshooting section of this Guide.
Perform tire/wheel service.
Begin by triggering the driver's left front (LF) wheel sensor.
The same procedure should be followed on all wheel sensors, in a
clockwise rotation.
We recommend you trigger each wheel sensor, one final time, to
make sure they are working correctly prior to releasing the vehicle to
the customer.
1 Start LF
4 End LR
RF 2
RR 3
Fig. 5

UM-HV1-13-11 VDO TPMS GO user guide
Page 8/32
VDO TPMS GO USE
IMPORTANT:
Vehicle specific information in this manual is used as an example and may not
represent specific instructions each make and model may require. When performing
various functions with the tool, it is important to refer to the on-screen prompts
and/or repair manual information.
1. CHECK SENSOR
MAIN MENU
CHECK SENSOR
VEHICLE SELECTION
SUBARU
SUZUKI
TESLA
> TOYOTA
1.1. SELECT CAR MANUFACTURER
VEHICLE SELECTION
SUBARU
SUZUKI
TESLA
> TOYOTA
TOYOTA
ProAce Combi
> RAV4 III
RAV4 IV
Solara II
1.2. SELECT CAR MODEL
TOYOTA
ProAce Combi
> RAV4 III
RAV4 IV
Solara II
RAV4 III
> 2005-2013

UM-HV1-13-11 VDO TPMS GO user guide
Page 9/32
1.3. SELECT YEAR
RAV4 III
> 2005-2013
RAV4 III
> 4 WHEELS
5 WHEELS
1.4. SELECT WHEEL NUMBER
This option does not appear for all vehicles.
RAV4 III
> 4 WHEELS
5 WHEELS
RAV4 III
▲
◄
►
▼
SELECT TIRE
C: : START
The tool is ready to trigger the
sensors.
1.5. TEST SENSOR
RAV4 III
▲
◄
►
▼
SELECT TIRE
C: : START
Use keypad for tire selection.
RAV4 III
TRIGGER PROCESSING
C: : START

UM-HV1-13-11 VDO TPMS GO user guide
Page 10/32
1.6. TEST RESULTS
RAV4 III
TRIGGER PROCESSING
C: : START
1: PASS: press to go to next
tire.
2/5: FAIL.
1: PASS
RAV4 III
F383834 25°C
2.50 bar BAT:OK
433 MHz
C: : START
2: FAIL
RAV4 III
NO SENSOR DETECTED
C: : START
3: FAIL
RAV4 III
DUPLICATE SENSOR
C: : START
4: FAIL
RAV4 III
REDUCE TIRE PRESSURE
C: : START
5: FAIL
RAV4 III
COM. ERROR
C: : START

UM-HV1-13-11 VDO TPMS GO user guide
Page 11/32
2. PROGRAM BLANK SENSOR
This feature allows to recover a sensor ID in order to enter it in the spare blank sensor. If
the "old" sensor can be read, use the "COPY ORIGINAL SENSOR" function to recover the
ID. If it can't be read, use the "CREATE NEW SENSOR" menu to create a randomized ID.
MAIN MENU
PROG. SENSOR
VEHICLE SELECTION
SUBARU
SUZUKI
TESLA
> TOYOTA
2.1. PROGRAM BY SENSOR OR VEHICLE
This option offers to program a sensor, either by sensor brand or by vehicle.
2.1.1. Sensor selection mode
PROGRAM SENSOR
> SENSOR SELECTION
VEHICLE SELECTION
PROGRAM SENSOR
ALCAR by Schrader
ALLIGATOR Sens.it
> EU-Pro
HUF Intellisens
PROGRAM SENSOR
ALCAR by Schrader
ALLIGATOR Sens.it
> EU-Pro
HUF Intellisens
VEHICLE SELECTION
SUBARU
SUZUKI
TESLA
> TOYOTA
2.1.1. Vehicle selection mode
PROGRAM SENSOR
SENSOR SELECTION
> VEHICLE SELECTION
VEHICLE SELECTION
SUBARU
SUZUKI
TESLA
> TOYOTA

UM-HV1-13-11 VDO TPMS GO user guide
Page 12/32
2.1. SELECT CAR MANUFACTURER
VEHICLE SELECTION
SUBARU
SUZUKI
TESLA
> TOYOTA
TOYOTA
ProAce Combi
> RAV4 III
RAV4 IV
Solara II
2.2. SELECT VEHICLE MODEL
TOYOTA
ProAce Combi
> RAV4 III
RAV4 IV
Solara II
RAV4 III
> 2005-2013
2.3. SELECT YEAR
RAV4 III
> 2005-2013
PROGRAM SENSOR
ALCAR by Schrader
ALLIGATOR Sens.it
> EU-Pro
HUF Intellisens
The list of compatible sensors depend
on the vehicle selected
2.4. SELECT BLANK SENSOR MODEL
PROGRAM SENSOR
ALCAR by Schrader
ALLIGATOR Sens.it
> EU-Pro
HUF Intellisens
TOYOTA
Use EU-Pro1 or EU-Pro
Hybrid
(C) STOP (OK)
NEXT
The device displays the compatible
references of the selected brand
to continue.

UM-HV1-13-11 VDO TPMS GO user guide
Page 13/32
2.5. SELECT THE OPTION
TOYOTA
Use EU-Pro1 or EU-Pro
Hybrid
(C) STOP (OK)
NEXT
EU-Pro Hybrid
> COPY ID
CREATE SENSOR
2.6. "COPY ORIGINAL SENSOR"
EU-Pro Hybrid
> COPY ID
CREATE SENSOR
RAV4 III
COPY ID
C: : START
RAV4 III
COPY ID
C: : START
RAV4 III
TRIGGER PROCESSING
C: : START

UM-HV1-13-11 VDO TPMS GO user guide
Page 14/32
2.6.1. Test results
RAV4 III
TRIGGER PROCESSING
C: : START
1: PASS: See
"
Sensor
reprogramming
"
section
.
1: PASS
RAV4 III
F383834 25°C
2.50 bar BAT:OK
433 MHz
C: : START
2: FAIL: press to test again. 2: FAIL
RAV4 III
NO SENSOR DETECTED
C: : START
3: FAIL: reduce the tire pressure and
press to test again. 3: FAIL
RAV4 III
REDUCE TIRE PRESSURE
C: : START
4: FAIL: press to test again. 4: FAIL
RAV4 III
COM. ERROR
C: : START

UM-HV1-13-11 VDO TPMS GO user guide
Page 15/32
2.7. PROGRAMMING SENSOR
RAV4 III
F383834 25°C
2.50 bar BAT:OK
433 MHz
C: : START
Hold the new programmable sensor
near the device antenna.
RAV4 III
PROGRAM SENSOR
433 MHz
C: : START
2.7.1. Results
RAV4 III
PROGRAM SENSOR
433 MHz
C: : START
RAV4 III
UPLOADING…
C: : START
RAV4 III
VERIFYING
433 MHz
C: : START
RAV4 III
F383834 25°C
2.50 bar BAT:OK
433 MHz
C: : START

UM-HV1-13-11 VDO TPMS GO user guide
Page 16/32
2.8. "CREATE NEW SENSOR"
EZ-sensor
COPY ID
> CREATE SENSOR
RAV4 III
CREATE SENSOR
433 MHz
C: : START
Hold the new programmable sensor
near the device antenna.
2.8.1. Results
RAV4 III
CREATE SENSOR
433 MHz
C: : START
Note: in this operation the ID is a
random number.
RAV4 III
UPLOADING…
C: : START
RAV4 III
VERIFYING
433 MHz
C: : START
.
RAV4 III
EE995DD 25°C
2.50 bar BAT:OK
433 MHz
C: : START

UM-HV1-13-11 VDO TPMS GO user guide
Page 17/32
3. PART LOOKUP
This is a spare parts data base for all sensors available for each car.
MAIN MENU
PART # LOOKUP
VEHICLE SELECTION
SUBARU
SUZUKI
TESLA
> TOYOTA
3.1. SELECT CAR MANUFACTURER
VEHICLE SELECTION
SUBARU
SUZUKI
TESLA
> TOYOTA
TOYOTA
ProAce Combi
> RAV4 III
RAV4 IV
Solara II
3.2. SELECT VEHICLE MODEL
TOYOTA
ProAce Combi
> RAV4 III
RAV4 IV
Solara II
RAV4 III
> 2005-2013

UM-HV1-13-11 VDO TPMS GO user guide
Page 18/32
3.1. SELECT YEAR
RAV4 III
> 2005-2013
PART# LOOKUP
> OE
OE Sensor ref
OE SERVICE KIT
OE SERVICE VALVE
3.1. SELECT PART NUMBER
PART# LOOKUP
> OE
OE Sensor ref
OE SERVICE KIT
OE SERVICE VALVE
OE
42607-20010
TOYOTA
RAV4 III
2005-2013
