Vega PLICSMOBILE Series User manual

Operating Instructions
External radio unit for connection to
HART sensors, optionally with battery
housing/solar module
PLICSMOBILE
Mobile network unit PLICSMOBILE T81
Battery housing PLICSMOBILE B81
Solar panel PLICSMOBILE S81
Document ID: 55234

2
Contents
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
Contents
1 About this document ............................................................................................................... 4
1.1 Function ........................................................................................................................... 4
1.2 Target group ..................................................................................................................... 4
1.3 Symbols used................................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 5
2.3 Warning about incorrect use............................................................................................. 5
2.4 General safety instructions............................................................................................... 5
2.5 EU conformity................................................................................................................... 6
3 Product description ................................................................................................................. 7
3.1 Conguration.................................................................................................................... 7
3.2 Principle of operation........................................................................................................ 8
3.3 Adjustment ....................................................................................................................... 8
3.4 Packaging, transport and storage..................................................................................... 9
4 Mounting................................................................................................................................. 10
4.1 General instructions ....................................................................................................... 10
4.2 Installation procedure..................................................................................................... 11
5 Connecting to power supply................................................................................................. 13
5.1 Preparing the connection ............................................................................................... 13
5.2 Connection options ........................................................................................................ 13
5.3 HART communication .................................................................................................... 14
5.4 Connection steps sensor connection cable.................................................................... 14
5.5 Connection steps voltage supply.................................................................................... 15
5.6 Wiring diagram PLISCMOBILE T81 with power supply .................................................. 16
5.7 Wiring diagram PLISCMOBILE T81 with external power supply..................................... 19
5.8 Wiring plan PLICSMOBILE B81/S81.............................................................................. 21
6 Battery operation and power saving mode......................................................................... 22
6.1 Battery/accumulator operation ....................................................................................... 22
6.2 External battery PLICSMOBILE B81 .............................................................................. 22
6.3 Solar panel PLICSMOBILE S81 ..................................................................................... 23
6.4 Battery - Sizing and operating time ................................................................................ 25
6.5 Power options................................................................................................................. 26
7 Setup ....................................................................................................................................... 28
7.1 Adjustment system......................................................................................................... 28
7.2 Communication via Bluetooth......................................................................................... 28
7.3 Access protection........................................................................................................... 29
7.4 Parameter adjustment with PC and PACTware............................................................... 30
7.5 Parameter adjustment with the VEGA Tools app ............................................................ 31
7.6 Mobile network and SIM card......................................................................................... 33
7.7 Internet connection and measured value transmission................................................... 35
8 Maintenanceandfaultrectication...................................................................................... 38
8.1 Maintenance .................................................................................................................. 38
8.2 Rectify faults................................................................................................................... 38
8.3 How to proceed if a repair is necessary.......................................................................... 39

3
Contents
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
9 Dismount................................................................................................................................. 40
9.1 Dismounting steps.......................................................................................................... 40
9.2 Disposal ......................................................................................................................... 40
10 Certicatesandapprovals.................................................................................................... 41
10.1 Radio license for Europe ................................................................................................ 41
10.2 Radio license for USA .................................................................................................... 41
10.3 Radio license for Canada ............................................................................................... 42
10.4 Installation and operation in the USA and Canada ......................................................... 42
10.5 Environmental instructions ............................................................................................. 42
11 Supplement ............................................................................................................................ 44
11.1 Technical data PLICSMOBILE T81................................................................................. 44
11.2 Technical data PLICSMOBILE B81 ................................................................................ 46
11.3 Technical data PLICSMOBILE S81 ................................................................................ 48
11.4 Dimensions .................................................................................................................... 49
11.5 Industrial property rights................................................................................................. 52
11.6 Hash function acc. to mbed TLS..................................................................................... 52
11.7 Trademark ...................................................................................................................... 52
Editing status: 2019-12-13

4
1 About this document
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,theexchangeofpartsandthesafetyofthe
user. Please read this information before putting the instrument into
operation and keep this manual accessible in the immediate vicinity
of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
This symbol indicates special instructions for Ex applications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Battery disposal
This symbol indicates special information about the disposal of bat-
teries and accumulators.

5
2 For your safety
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
onlybytrained,qualiedpersonnelauthorisedbytheplantoperator.
During work on and with the device, the required personal protective
equipment must always be worn.
2.2 Appropriate use
The PLICSMOBILE T81 is an external radio unit and is used for the
transmission of measured values and for remote parameterization.
The PLICSMOBILE B81 is a battery housing for voltage supply of
PLICSMOBILE T81.
The PLICSMOBILE S81 is a solar panel for charging the accumula-
tors used in the PLICSMOBILE B81.
Operational reliability is ensured only if the instrument is properly
usedaccordingtothespecicationsintheoperatinginstructions
manual as well as possible supplementary instructions.
2.3 Warning about incorrect use
Inappropriate or incorrect use of this product can give rise to applica-
tion-specichazards,e.g.vesseloverllthroughincorrectmounting
or adjustment. Damage to property and persons or environmental
contamination can result. Also, the protective characteristics of the
instrument can be impaired.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives.The instrument must only be operated in a
technicallyawlessandreliablecondition.Theoperatorisresponsi-
ble for the trouble-free operation of the instrument.When measuring
aggressive or corrosive media that can cause a dangerous situation
if the instrument malfunctions, the operator has to implement suitable
measures to make sure the instrument is functioning properly.
During the entire duration of use, the user is obliged to determine the
compliance of the necessary occupational safety measures with the
current valid rules and regulations and also take note of new regula-
tions.
The safety instructions in this operating instructions manual, the na-
tional installation standards as well as the valid safety regulations and
accident prevention rules must be observed by the user.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by the manufacturer. Arbi-
traryconversionsormodicationsareexplicitlyforbidden.Forsafety
reasons,onlytheaccessoryspeciedbythemanufacturermustbe
used.

6
2 For your safety
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed.
2.5 EU conformity
ThedevicefullsthelegalrequirementsoftheapplicableEUdirec-
tives.ByaxingtheCEmarking,weconrmtheconformityofthe
instrument with these directives.
The EU conformity declaration can be found on our homepage.

7
3 Product description
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
3 Product description
3.1 Conguration
The scope of delivery encompasses:
• Mobile network unit PLICSMOBILE T81
– Label with access codes attached to the instrument
– VEGAidenticationcard(SIMcard)(optional)
– Sensorconnectioncable(optional)
– Remoteantennawith3mcableextension(optional)
• BatteryhousingPLICSMOBILEB81(optional)
– Connectioncable,elddevice(optional)
– Connectioncable,solarpanel(optional)
– Batteriesoraccumulators(optional)
• SolarmodulePLICSMOBILES81(optional)
– Holder for mast mounting
• Documentation
– This operating instructions manual
– Documentation of the access and unlock codes
– Ifnecessary,furthercerticates
The PLICSMOBILE T81 consists of the components:
2
5
3
4
1
Fig. 1: PLICSMOBILE T81
1 Electronics compartment
2 Plug connector (M12) for connection of the HART sensors
3 Multi-functional antenna (mobile network/Bluetooth/GPS)
4 Mounting plate
5 Sensor connection cable
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument:
• Instrument type
• Information about approvals
• Technical data
• Serial number of the instrument
• QR code for device documentation
• Number code for Bluetooth access
• Manufacturer information
Scope of delivery
Constituent parts
Type label

8
3 Product description
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
Move to "www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Thereyoucanndthefollowinginformationabouttheinstrument:
• Order data
• Documentation
• Software
Alternatively,youcanndallviayoursmartphone:
• Scan the QR-code on the type label of the device or
• EnterserialnumbermanuallyintheVEGAToolsapp(available
freeofchargeintherespectivestores)
3.2 Principle of operation
The PLICSMOBILE T81 is a mobile network unit for transmission of
measured values and for remote parameter adjustment of HART sen-
sors, especially of plics®sensors. Due to the large operating voltage
range and the integrated power saving functions, a mains-independ-
ent power supply via battery or accumulator/solar cells is possible,
for example through PLICSMOBILE B81.Typical applications are
measured value transmission from mobile vessels, battery-operated
level measurement and deep well measurement.
The measured value and message transmission can be optionally
carried out via e-mail or SMS. Furthermore, the measured values can
be transmitted via https for visualisation in "VEGA Inventory System".
The use of PLICSMOBILE T81 is particularly suitable for inventory
management,VMI(VendorManagedInventory)andremoteenquiry.
The external mobile network unit PLICSMOBILE T81 can be con-
nected to any 4 … 20 mA HART two-wire sensor of the plics®series.
In HART Multidrop operation up to 15 sensors can be connected to a
PLICSMOBILET81(max.5withExversion).
The transmission of measured values, event messages and diagnos-
tic information to the user is carried out via the GSM/GPRS/UMTS
network.Thank multi band technology, the device can be used virtu-
ally anywhere in the world. There is also the option of accessing the
connected sensor via remote parameter adjustment.
The combined radio antenna enables the GSM/GPRS/UMTS com-
munication as well as the Bluetooth connection. In addition, the
antenna enables the reception of position data via GPS.
Powerissuppliedviaastandardlowvoltagesource(externalpower
supplyunit/battery/accumulator/solarpanel)orviatheoptionally
availablePLICSMOBILEB81.Youcannddetailedspecicationson
the power supply in chapter "Connecting to power supply" as well as
in "Technical data".
3.3 Adjustment
The device is adjusted via a PC with PACTware and the corre-
sponding DTM or via smartphone/tablet with the VEGA Tools app.
The connection is made via the Bluetooth interface integrated in
PLICSMOBILE T81.
Documents and software
Application area
Functional principle
Voltage supply

9
3 Product description
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
3.4 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The packaging of standard instruments consists of environment-
friendly, recyclable cardboard. For special versions, PE foam or PE
foil is also used. Dispose of the packaging material via specialised
recycling companies.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Not exposed to corrosive media
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Storage and transport temperature see chapter "Supplement -
Technical data - Ambient conditions"
• Relative humidity 20 … 85 %
Packaging
Transport
Transport inspection
Storage
Storage and transport
temperature

10
4 Mounting
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
4 Mounting
4.1 General instructions
In the standard version, the PLICSMOBILE T81 is designed for
wallmounting.Mountingadaptersforcarrierrailmounting(tophat
rail35x7.5accordingtoDINEN50022/60715)aswellasfortube
mounting are optionally available.
The instrument is suitable for standard and extended ambient condi-
tions acc. to DIN/EN/IEC/ANSI/ISA/UL/CSA 61010-1. It can be used
indoors as well as outdoors.
Makesurethattheenvironmentalandambientconditionsspeciedin
chapter "Technical data" are maintained.
Checkbeforemountingifasucientnetworkcoverage(signal
strength)ofthemobilenetworkproviderisavailableattheplanned
location. This can be simply tested by means of a mobile phone.
Keep in mind that the SIM cards in the PLICSMOBILE T81 and in the
mobile phone are from the same mobile phone provider or work in
the same mobile phone network.The PLICSMOBILE T81 supports
themobilephonestandards2G(GSM)and3G(UMTS).Themobile
phonestandard4G(LTE)howeverisnotsupported.Thereforeforthis
test of the network coverage, the 4G standard in the mobile phone
shouldbetemporarilyswitchedo.
If the radio reception is too weak, you should search for a better posi-
tion. In closed rooms this would be, for example, close to a window
or at least closer to an outer wall. In addition, an antenna extension
with magnetic base is available which can be placed up to 2.9 m away
from the instrument.
Caution:
During operation, a distance of at least 20 cm should be kept between
the antenna and persons working nearby. Operation of the instrument
with smaller distances is not recommended.
Protect your instrument against moisture ingress through the following
measures:
• Usetherecommendedconnectioncable(seechapter"Connect-
ing to power supply")
• Tighten the cable gland
• When mounting horizontally, turn the housing so that the cable
gland points downward
• Loop the connection cable downward in front of the cable gland
This applies mainly to outdoor installations, in areas where high
humidityisexpected(e.g.throughcleaningprocesses)andoncooled
or heated vessels.
To maintain the housing protection, make sure that the housing lid is
closed during operation and locked, if necessary.
Makesurethatthedegreeofcontaminationspeciedinchapter
"Technical data" meets the existing ambient conditions.
Mounting options
Ambient conditions
Installation position
Protection against mois-
ture

11
4 Mounting
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
4.2 Installation procedure
The PLICSMOBILE T81 for wall mounting is supplied with a mounting
base for screw mounting.
→ Fastentheinstrumentwithfourappropriatescrews(notincluded
inthedelivery)accordingtothefollowingillustration.
62 mm (2.44")
12 mm
(0.47")
7 mm (0.28")
85 mm (3.35")
Fig. 2: PLICSMOBILE T81 for wall mounting, bottom view of mounting plate.
The PLICSMOBILE T81 for carrier rail mounting is supplied with an
already assembled adapter for fastening on a 35 x 7.5 carrier rail.
→ Snap the instrument without tools onto the carrier rail. Loosening
from the carrier rail is also carried out without tools. Through the
integrated spring, you just have to apply slight lateral pressure to
the instrument.
1 2
Fig. 3: PLICSMOBILE T81 for carrier rail mounting
1 Adapter plate
2 Carrier rail
The PLICSMOBILE T81 for tube mounting is supplied with a measur-
ing instrument holder and four hexagon socket screws M5 x 12 as
unassembled mounting accessory.
Wall mounting
Carrier rail mounting
Tube mounting

12
4 Mounting
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
→ Mount the measuring instrument holder according to the following
illustration to the socket of PLICSMOBILE T81. Then you can
fasten the instrument with the bent strap to your tube.
1 2
3
Fig. 4: PLICSMOBILE T81 for tube mounting
1 4 screws M5 x 12
2 Measuring instrument holder
3 Tube

13
5 Connecting to power supply
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
5 Connecting to power supply
5.1 Preparing the connection
Always keep in mind the following safety instructions:
• The electrical connection must only be carried out by trained,
qualiedpersonnelauthorisedbytheplantoperator.
• If overvoltage surges are expected, overvoltage arresters should
be installed.
Warning:
Connect only in the complete absence of line voltage.
Power can be supplied optionally via PLICSMOBILE B81 or a sepa-
rate power supply unit.
When using a power supply unit, the secondary circuit must be
separated from the primary circuit by double or reinforced insulation
(accordingtothenationallyvalidsafetystandards).
The air and creeping distances in PLICSMOBILE T81 meet the re-
quirements of EN IEC 61010-1 for secondary circuits with reinforced
insulationunderovervoltagecategoryIII(altitudeupto2000m).
The voltage supply of PLICSMOBILE T81 is connected with standard
cable according to the national installation standards.
If electromagnetic interference is expected which is above the test
values of EN 61326-1 for industrial areas, screened cable should be
used.
Make sure that the cable used has the required temperature resist-
anceandresafetyformax.occurringambienttemperature
We generally recommend the use of shielded cable for HART
multidrop mode.
Use cable with round cross section for instruments with housing and
cable gland. Use a cable gland suitable for the cable diameter to
ensurethesealeectofthecablegland(IPprotectionrating).
Connect the cable screen on the sensor side to ground potential.
In the sensor, the screen must be connected directly to the internal
ground terminal.The ground terminal on the outside of the sensor
housingmustbeconnectedtothepotentialequalisation(lowimped-
ance).
5.2 Connection options
Power can be supplied to the sensors and PLICSMOBILE in two
ways:
This version requires only one power supply for all devices. Up to
15 HART sensors can be connected to the PLICSMOBILE T81. The
power supply is connected to the PLICSMOBILE T81. In addition to
the measured value, the sensor connection cable also transmits the
power supply to all sensors via HART.
Safety instructions
Voltage supply
Connection cable
Cable screening and
grounding
Common voltage sup-
ply of the sensors and
PLICSMOBILE

14
5 Connecting to power supply
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
With this version, the PLICSMOBILE T81 and a 4 … 20 mA/HART
sensors are each powered via a separate power supply. Here, the
measured values can be transmitted via radio communication and
the 4 … 20 mA HART signal of the sensor is available in parallel for
processing, e.g. via a PLC.
5.3 HART communication
If the sensors are connected to PLICSMOBILE, HART communica-
tion is ensured and no additional HART resistor must be looped.
If the internal resistance of the connected power supply for the sensor
islessthan230Ω,theHARTsignalisextremelydampedorshort-
circuited. Digital communication with PLICSCOM is then no longer
possible.With low impedance processing systems, a resistance of
approx.230Ωmustbeloopedintothe4…20mA/HARTcable.This
resistance is already integrated in PLICSMOBILE T81 and can be
looped automatically into the circuit by selecting the appropriate wires
(seewiringplanswithorwithoutHARTresistor).
The connection to power supply is carried out as described in the
respective operating instructions manual.
Note:
WhenconnectingmorethanoneHARTsensor,adierentaddress
mustbeassignedtoeachsensor(addressrange1-15).Address0
(mode4…20mA)maynotbeused.Whenassigninganaddress,
only one sensor should be connected to PLICSMOBILE T81. If con-
nectionisalreadycompleted,thewiringmustbebrieyundonefor
addressing. Depending on the installation location of the sensors, it
can be advantageous to carry out this addressing before installing
and connecting the sensors.This can be conveniently carried out
e.g. in the workshop.You only need a 24 Volt power supply as well as
an indicating and adjustment module PLICSCOM or the adjustment
software PACTware with VEGACONNECT.
The HART protocol enables the connection of up to two masters on
thesameline(Primary/SecondaryMaster).ThePLICSMOBILET81
works as Primary Master in the factory setting. If another master is to
be connected, e.g. for parameterization of the sensor, it must work as
a Secondary Master. If this is not possible, the PLICSMOBILE T81
canalternativelybereconguredasaSecondaryMaster.
5.4 Connection steps sensor connection cable
The sensor connection cable is used for transmission of the meas-
ured value from the sensors to the PLICSMOBILE T81. In addition, it
can also transmit the voltage supply for all connected sensors.
ThesensorconnectioncableisavailableinExversion(blue)
aswellasinnon-Exversion(black).Itcanbeorderedinthree
lengths(5/10/25m)andcanbeshortenedafterwardstoindividual
lengths. On one end there is a ready-for-use plug for connection to
PLICSMOBILE T81. On the other end are free cable ends for direct
connection to the sensor.
Separate voltage sup-
ply for sensor and
PLICSMOBILE
HART resistor with com-
mon power supply
HART resistor with sepa-
rate power supply
HART address
HART master mode

15
5 Connecting to power supply
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
To connect, proceed as follows:
1. Connect the colour coded wire ends to the respective sensor
terminals, as described in the wiring plan and the operating
instructions of the sensor.
2. Isolate unused wires, depending on connection type and cable
version
3. Connect the screen to the internal ground terminal, connect the
external ground terminal to the housing with potential equalisation
4. Tighten the compression nut of the cable entry gland. The seal
ring must completely encircle the cable
5. Insert the plug of the sensor connection cable into the plug con-
nection on PLICSMOBILE T81
6. Tighten plug connection
5.5 Connection steps voltage supply
The connection of the voltage supply is made via spring-loaded ter-
minals. A small screwdriver is required to open the terminals. Solid as
wellasexiblecoreswithoutcableendsleevescanbeused.
Proceed as follows:
1. Unscrew the housing lid
2. Loosen compression nut of the cable gland and remove blind
plug
3. Removeapprox.10cm(4in)ofthecablemantle,stripapprox.
1cm(0.4in)ofinsulationfromtheendsoftheindividualwires
4. Insert the cable into the cable gland through the cable entry
Fig. 5: Connection steps 4 and 5
5. Lift the opening levers of the terminals with a screwdriver
6. Insert the wire ends into the open terminals according to the wir-
ing plan
7. Press down the opening levers of the terminals, you will hear the
terminal spring closing
8. Check the hold of the wires in the terminals by lightly pulling on
them
Connection technology
Connection procedure

16
5 Connecting to power supply
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
9. Connect the screen to the internal ground terminal, connect the
external ground terminal to potential equalisation
10. Tighten the compression nut of the cable entry gland. The seal
ring must completely encircle the cable
11. Screw the housing lid back on
Theelectricalconnectionisnished.
5.6 Wiring diagram PLISCMOBILE T81 with
power supply
1
PLICSMOBILE T81
4 5
6
2
7
3
5
12
+
-
678
4...20mA
SIM
Status
Send Off On
123
+-
Fig. 6: Connection voltage supply and plics®sensor
1 Power supply PLICSMOBILE T81 and connected sensors
2 Sensor connection cable
3 HART sensor from the plics®series
4 Brown cable (+) for sensor power supply/HART communication
5 Blue cable (-) for sensor power supply/HART communication
6 Connection of additional HART sensors
7 Unused wires that must be insulated (not present on Ex version)
Note:
If multiple sensors are connected, they are connected in parallel.The
sensorsmustrstbesettoHARTMultidropmodewithindividual
HART addresses and "x current (4 mA)"
Connection plics®sensor

17
5 Connecting to power supply
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
1
PLICSMOBILE T81
5 4
2
3
6
7
SIM
Status
Send Off On
123
+-
1
2
3
4
5
6
Fig. 7: Connection of the voltage supply and VEGABOX 03
1 Power supply PLICSMOBILE T81 and connected sensors
2 Sensor connection cable
3 Connection terminal VEGABOX 03
4 Brown cable (+) for sensor power supply/HART communication
5 Blue cable (-) for sensor power supply/HART communication
6 To the HART sensors
7 Unused wires that must be insulated (not present on Ex version)
Note:
If multiple sensors are connected, they are connected in parallel.The
sensorsmustrstbesettoHARTMultidropmodewithindividual
HART addresses and "x current (4 mA)"
1
PLICSMOBILE T81
SIM
Status
Send Off On
123
+-
Sensor
12
+
( ) (-)
power supply
34
+
( ) (-)
R
o on
HART
2
6
7
3
45
Fig. 8: Connection of the voltage supply and VEGADIS 82 HART
1 Power supply PLICSMOBILE T81 and connected sensors
2 Sensor connection cable
3 VEGADIS 82 in HART version
4 Brown cable (+) for sensor power supply/HART communication
5 Blue cable (-) for sensor power supply/HART communication
6 To the HART sensors
7 Unused wires that must be insulated (not present on Ex version)
Connection of sensor via
VEGABOX 03
Connection of sensor via
VEGADIS 82 HART

18
5 Connecting to power supply
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
Note:
If multiple sensors are connected, they are connected in parallel.The
sensorsmustrstbesettoHARTMultidropmodewithindividual
HART addresses and "x current (4 mA)"
If you want to assemble the optionally available sensor connection
cablebyyourself,youcanndheretheconnectionassignment.A
5-pole M12 cable connector with A coding is used as plug connec-
tion.The max. cable length is 500 m.
In Ex application, the max. cable length depends from the cable used
andfurtherfactors.Youcanndadditionalinformationinthesafety
instructions attached to each instrument.
5
4
3
2
1
5
1
2
3
4
Fig. 9: Connection assignment, sensor connection cable
1 Brown cable
2 White cable
3 Blue cable
4 Black cable
5 Cable screen (grey)
Connection assignment,
sensor connection cable

19
5 Connecting to power supply
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
5.7 Wiring diagram PLISCMOBILE T81 with
external power supply
1
PLICSMOBILE T81
45
2
7
63
5
12
+
+
-
-
678
4...20mA
SIM
Status
Send Off On
123
+
-
Fig. 10: Connection of the voltage supply
1 Power supply PLICSMOBILE
2 Sensor connection cable
3 HART sensor from the plics®series
4 Black cable
5 Blue cable
6 Voltage supply, sensor (e.g. PLC)
7 Unused cores to be insulated
Note:
The unused cores of the sensor connection cable must be insulated.
With a PLICSMOBILE in Ex version, an external voltage supply is not
possible/permitted.
Information:
When connecting a 4 … 20 mA/HART sensors, a VEGADIS 82 can
be looped optionally into the circuit for measured value indication.
Connection plics®-Sensor
with HART resistor

20
5 Connecting to power supply
PLICSMOBILE • Mobile network unit PLICSMOBILE T81
55234-EN-191217
1
PLICSMOBILE T81
45
2
7
63
5
12
+
+
-
-
678
4...20mA
SIM
Status
Send Off On
123
+
-
Fig. 11: Connection of the voltage supply
1 Power supply PLICSMOBILE
2 Sensor connection cable
3 HART sensor from the plics®series
4 White cable
5 Black cable
6 Voltage supply, sensor (e.g. PLC)
7 Unused cores to be insulated
Note:
The unused cores of the sensor connection cable must be insulated.
With a PLICSMOBILE in Ex version, an external voltage supply is not
possible/permitted.
Information:
When connecting a 4 … 20 mA/HART sensors, a VEGADIS 82 can
be looped optionally into the circuit for measured value indication.
Connection plics®-Sensor
without HART resistor
