Operating Instructions
VEGASOURCE 82
Source holder
Document ID: 66076

2
Contents
VEGASOURCE 82 • Source holder
66076-EN-230810
Contents
1 About this document ............................................................................................................... 4
1.1 Function ........................................................................................................................... 4
1.2 Target group ..................................................................................................................... 4
1.3 Symbols used................................................................................................................... 4
2 For your safety ......................................................................................................................... 5
2.1 Authorised personnel ....................................................................................................... 5
2.2 Appropriate use................................................................................................................ 6
2.3 Warning about incorrect use............................................................................................. 6
2.4 General safety instructions............................................................................................... 6
2.5 Application reference ....................................................................................................... 7
2.6 Installation and operation in the USA and Canada ........................................................... 7
2.7 Environmental instructions ............................................................................................... 8
3 Product description ................................................................................................................. 9
3.1 Conguration.................................................................................................................... 9
3.2 Principle of operation...................................................................................................... 12
3.3 Packaging, transport and storage................................................................................... 14
3.4 Shipment........................................................................................................................ 17
3.5 Accessories.................................................................................................................... 18
4 Mounting................................................................................................................................. 20
4.1 General instructions ....................................................................................................... 20
4.2 Mounting instructions ..................................................................................................... 21
5 Installation - Special equipment........................................................................................... 29
5.1 Version B: Connection - Pneumatic switching ON/OFF.................................................. 29
5.2 Version X, C, B: Connection - Manual switching ON/OFF............................................... 31
6 Setup ....................................................................................................................................... 33
6.1 Adjustment - Version X, C - Manual switching ON/OFF.................................................. 33
6.2 Adjustment - Version B - Pneumatic switching ON/OFF ................................................. 35
7 Maintenanceandfaultrectication...................................................................................... 38
7.1 Cleaning......................................................................................................................... 38
7.2 Maintenance .................................................................................................................. 38
7.3 Test of the switching ON/OFF......................................................................................... 39
7.4 Leakage/contamination test ........................................................................................... 40
7.5 Rectify faults................................................................................................................... 42
7.6 What to do in case of emergency ................................................................................... 42
8 Dismount................................................................................................................................. 44
8.1 Dismounting steps.......................................................................................................... 44
8.2 Return, transport ............................................................................................................ 44
9 Checklist type A packging .................................................................................................... 47
10 Supplement ............................................................................................................................ 49
10.1 Technical data ................................................................................................................ 49
10.2 Dimensions .................................................................................................................... 56
10.3 Manufacturer declaration................................................................................................ 67
10.4 Industrial property rights................................................................................................. 68
10.5 Trademark ...................................................................................................................... 68

3
Contents
VEGASOURCE 82 • Source holder
66076-EN-230810
Editing status: 2023-08-10

4
1 About this document
VEGASOURCE 82 • Source holder
66076-EN-230810
1 About this document
1.1 Function
This instruction provides all the information you need for mounting,
connection and setup as well as important instructions for mainte-
nance,faultrectication,safetyandtheexchangeofparts.Please
read this information before putting the instrument into operation and
keep this manual accessible in the immediate vicinity of the device.
1.2 Target group
This operating instructions manual is directed to trained personnel.
Thecontentsofthismanualmustbemadeavailabletothequalied
personnel and implemented.
1.3 Symbols used
Document ID
This symbol on the front page of this instruction refers to the Docu-
ment ID. By entering the Document ID on www.vega.com you will
reach the document download.
Information, note, tip: This symbol indicates helpful additional infor-
mation and tips for successful work.
Note: This symbol indicates notes to prevent failures, malfunctions,
damage to devices or plants.
Caution: Non-observance of the information marked with this symbol
may result in personal injury.
Warning: Non-observance of the information marked with this symbol
may result in serious or fatal personal injury.
Danger: Non-observance of the information marked with this symbol
results in serious or fatal personal injury.
Ex applications
ThissymbolindicatesspecialinstructionsforExapplications.
• List
The dot set in front indicates a list with no implied sequence.
1 Sequence of actions
Numbers set in front indicate successive steps in a procedure.
Disposal
This symbol indicates special instructions for disposal.

5
2 For your safety
VEGASOURCE 82 • Source holder
66076-EN-230810
2 For your safety
2.1 Authorised personnel
All operations described in this documentation must be carried out
only by trained and authorized personnel.
During work on and with the device, the required personal protective
equipment must always be worn.
The handling of radioactive substances is regulated by law. The radia-
tion protection rules of the country in which the system is operated
applyrstandforemost.
In Germany the current radiation protection ordinance (StrlSchV)
based on the Atomic Energy Law (AtG) is applicable.
The following points are important for measurement with radiometric
methods:
A handling permit is required for operation of a system using gamma
rays.This permit is issued by the respective state government or
theresponsibleauthority(ocesforenvironmentalprotection,trade
supervisory boards, etc.)
We would be pleased to assist you in applying for the permit.
Whenhandlingradioactivesources,unnecessaryradiationexposure
mustbeavoided.Anunavoidableradiationexposuremustbekeptas
low as possible.Take note of the following three important measures:
1 2 3
Fig. 1: Measures for protection against radioactive radiation
1 Shielding
2 Time
3 Distance
Shielding: Provide good shielding between the source and yourself
as well as all other persons. Special source containers as well as all
materials with high density (e.g. lead, iron, concrete, etc.) provide
eectiveshielding.
Time:Stayasshortatimeaspossibleinradiationexposedareas.
Distance:Your distance to the source should be as large as possible.
The local dose rate of the radiation decreases in proportion to the
square of the distance to the radiation source.
Handling permit
General instructions for
radiation protection

6
2 For your safety
VEGASOURCE 82 • Source holder
66076-EN-230810
Theoperatingcompanymustappointaradiationsafetyocerwith
thenecessaryexpertknowledge.Heisresponsibleforensuringthat
the radiation protection ordinance is complied with and for implement-
ing all radiation protection measures.
Youcanalsondcertiedcourseprovidersonthehomepageofthe
FederalOceforRadiationProtection:www.bfs.de.
Controlareasareareasinwhichthelocaldoserateexceedsacertain
value.Onlypersonswhoundergoocialdosemonitoringareallowed
intothesecontrolareas.Youcanndtherespectivelyvalidlimitvalues
for control areas in the radiation protection ordinance.
We are at your disposal for further information concerning radiation
protection and regulations in other countries.
2.2 Appropriate use
When in operating mode, the source container VEGASOURCE 82 de-
scribed in this document contains a radiactive source for radiometric
level, interface, switching and density measurement as well as mass
owdetection.Thesourcecontainershieldstheradiationofromthe
surroundingsandonlyallowsittoexit,practicallyunhindered,inthe
direction of measurement.
Toensuretheshieldingeectandexcludedamagetotheradioactive
source, all instructions in this operating instructions manual and the
legal radiation protection regulations must be observed during instal-
lation and operation.
Operational reliability is ensured only if the instrument is used prop-
erly. We are not liable for damages caused by improper use.
Youcannddetailedinformationabouttheareaofapplicationin
chapter " Product description".
2.3 Warning about incorrect use
Inappropriate or incorrect use of this instrument can give rise to
hazards,e.g.risktopersonsthroughexposuretogammaradiation.
Damage to property and persons or environmental contamination can
result. Also, the protective characteristics of the instrument can be
impaired.
Take note of the respective safety instructions.
2.4 General safety instructions
This is a state-of-the-art instrument complying with all prevailing
regulations and directives.The instrument must only be operated in
atechnicallyawlessandreliablecondition.Theoperatingcompany
is responsible for the trouble-free operation of the instrument. When
measuring aggressive or corrosive media that can cause a danger-
ous situation if the instrument malfunctions, the operating company
has to implement suitable measures to make sure the instrument is
functioning properly.
During the entire duration of use, the operating company is obliged
to determine the compliance of the necessary occupational safety
Radiationsafetyocer
Control area

7
2 For your safety
VEGASOURCE 82 • Source holder
66076-EN-230810
measures with the current valid rules and regulations and also take
note of new regulations.
The safety instructions in this operating instructions manual, the
national installation standards as well as the valid safety regulations
and accident prevention rules must be observed.
For safety and warranty reasons, any invasive work on the device
beyond that described in the operating instructions manual may be
carried out only by personnel authorised by us. Arbitrary conversions
ormodicationsareexplicitlyforbidden.Forsafetyreasons,onlythe
accessoryspeciedbyusmustbeused.
To avoid any danger, the safety approval markings and safety tips on
the device must also be observed.
2.5 Application reference
• Take note of the applicable regulations and national/international
standards.
• Take note of the radiation protection ordinance when using, storing
and working with the radiometric measuring system.
• Take note of the warning instructions and safety zones.
• Install and operate the instrument according to the documentation
andtherespectiveocialregulations.
• The instrument must not be operated and stored outside the
speciedparameters.
• Protecttheinstrumentagainstextremeinuences(e.g.chemi-
cal products, weather, mechanical shock, vibration, etc.) during
operation and storage. Especially when loaded with a source, the
instrument may not be destroyed for any reason (e.g. for scrap-
ping).
• Before switching on the radiation, make sure that no persons are
in the radiation area (also not outside the vessel). The radiation
must only be switched on by trained personnel.
• Do not use a corroded or damaged instrument. Inform the respon-
sibleradiationsafetyocerassoonasdamageorcorrosion
appears and follow his instructions.
• Carry out the necessary tightness test according to the applicable
rules and instructions.
• If there are doubts about the proper condition of the measuring
system, check if there is radiation in the environment of the instru-
mentandinformtheresponsibleradiationsafetyocer.
• Always secure the switch position " OFF" with a lock.
The combination lock can be opened with the number combination
000 on delivery.
We recommend changing the number combination to a personal
number sequence. Make a note of the number combination and keep
it in a safe place.
2.6 Installation and operation in the USA and
Canada
ThisinformationisonlyvalidforUSAandCanada.Hencethefollow-
ingtextisonlyavailableintheEnglishlanguage.

8
2 For your safety
VEGASOURCE 82 • Source holder
66076-EN-230810
Installations in the US shall comply with the relevant requirements of
the National Electrical Code (NEC - NFPA 70) (USA).
Installations in Canada shall comply with the relevant requirements of
the Canadian Electrical Code (CEC Part) (Canada).
2.7 Environmental instructions
Protection of the environment is one of our most important duties.
That is why we have introduced an environment management system
with the goal of continuously improving company environmental pro-
tection.Theenvironmentmanagementsystemiscertiedaccording
to DIN EN ISO 14001.
Pleasehelpusfullthisobligationbyobservingtheenvironmental
instructions in this manual:
• Chapter " Packaging, transport and storage"
• Chapter " Disposal"

9
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
3 Product description
3.1 Conguration
Thetypelabelscontainthemostimportantdataforidenticationand
use of the source holder and the source:
• Source holder
• Order code
• Serial number - Source holder
• Exitangle
• QR code
• Article number - Documentation
• Source
• Isotope contained
• Activity
• Country of origin
• Serial number - Source
• Loading date
The serial number allows you to access the delivery data of the instru-
ment via " www.vega.com", " Instrument search (serial number)".
Thereareseveralversionsavailablewithdierentoptionsforopening
orblockingthebeamexit.Apartfromthemanualversions,thereare
also a version with pneumatic switching ON/OFF.
Type label
Versions

10
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
X
C
B
Fig. 2: Versions VEGASOURCE 82 (Overview)
Version X: Standard version with manual changeover ON/OFF switching (lock for position: " OFF")
Version C: Standard version with manual changeover ON/OFF switching (lock for position: " ON/OFF")
Version B: with pneumatic switching ON/OFF
Features of the versions
X
Manually
C
Manually
B
Pneumatics
Manual switching ON/OFF ● ● –
Cover (optional) ● ● –
Padlock for position " ON/OFF" – ●–
Padlock for position " OFF" ●●●
Pneumatic switching ON/OFF – – ●
With electrical ON/OFF position switch (optionally) ●●●
With Interlock switch (optionally) ● ● –
Tab. 1: Features of the instrument versions

11
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
Version X, C
1
2
3
4
Fig. 3: Position of the type labels, e.g. version X, C - Manual switching ON/OFF
1 Type label - Source holder
2 Type label - Source
3 Position indication " OFF"
4 Position indication " ON"
B
A
1
6
5
12
11
10
2
3
4
7
8
9
2
2
Fig. 4: Type label, e.g. version X, C - Manual switching ON/OFF
A Type label - Source
B Type label - Source holder
1 Warning - Radioactivity
2 Source: Cs-137 or Co-60
3 Activity of the sources in MBq and mCi or GBq and mCi
4 Country of origin of the source
5 Loading date of the sources (MM/YYYY)
6 Serial number of the source capsule (for traceability of the source)
7 Order code - Source container
8 Serial number - Source holder
9 Beam exit angle
10 Manufacturer
11 QR code
12 Number of the corresponding operating instructions

12
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
General License
1
Fig. 5: Position of the additional type label "General License" (only for USA)
1 General License
The type label contains the serial number of the instrument. With it
youcanndthefollowinginstrumentdataonourhomepage:
• Productcode(HTML)
• Deliverydate(HTML)
• Order-specicinstrumentfeatures(HTML)
• Operating instructions and quick setup guide at the time of ship-
ment (PDF)
• Testcerticate(PDF)-optional
Move to " www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Alternatively, you can access the data via your smartphone:
• Download the VEGA Tools app from the " Apple App Store" or the
" Google Play Store"
• Scan the QR-code on the type label of the device or
• Enter the serial number manually in the app
The scope of delivery typically consists of the following components.
• Source holder
• Documentation
– This operating instructions manual
– Certicateofthesource(sourcecapsule)
– Ifnecessary,furthercerticates
3.2 Principle of operation
The VEGASOURCE 82 is a source holder for shielding radioactive
sources Cs-137 or Co-60.
Serial number - Instru-
ment search
Scope of delivery
Application area

13
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
The radioactive source in the source container emits gamma rays.
The VEGASOURCE 82 is mounted on the vessel or the pipeline
directly opposite the sensor.
The source holder shields the environment against gamma radia-
tion and protects the radioactive source from mechanical damage or
chemicalinuences.Incaseoflargemeasuringranges(e.g.withhigh
vessels) two or more source holders are used.
The VEGASOURCE 82 consists of the components:
1
2
3
4
Fig. 6: Source holder VEGASOURCE 82
1 Source holder
2 Cover (optional)
3 Transport lug
4 Mounting surface
The rays emitted by the gamma source are damped when penetrat-
ing the medium. The sensor detecting the attenuated radiation on the
opposite side of the vessel calculates the measured value from the
intensity of the radiation.
Max. activity of the sources
Thefollowingtablestatesthemax.activityofthesources.Production-
relateductuationsoftheradiationactivityandtolerancesofthe
measuring instruments are not taken into account.
Local dose rate
Country USA Europe II Europe
Distance m (in) 0.3 m (1 ft) 1 m (3.3 ft) 0.3 m (1 ft)
Field (µSv/h) 50 3 3
Max.activity 300 mCi
11.1 GBc
200 mCi
7.4 GBc
20 mCi
0.74 GBc
Tab. 2: Local dose rate at standard distance
Functional principle
Source

14
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
Caution:
Themax.permissibleactivityofthesourcecanbefurtherlimitedbya
country-specicapproval.
3.3 Packaging, transport and storage
Your instrument was protected by packaging during transport. Its
capacity to handle normal loads during transport is assured by a test
based on ISO 4180.
The device packaging consists of wood. This material is environment-
friendly and recyclable. Dispose of the packaging material via special-
ised recycling companies.
Fortransport,thesourceholderisxedtothebottomplateofa
woodentransportbox.
The delivery must be checked for completeness and possible transit
damage immediately at receipt. Ascertained transit damage or con-
cealed defects must be appropriately dealt with.
A seal is located on the outside of the transport packaging indicating
that the packaging was not opened. Check the condition of this seal
and record the intactness.
Transport must be carried out in due consideration of the notes on the
transport packaging. Nonobservance of these instructions can cause
damage to the device.
According to the IAEA regulations, the source container serves ade-
quately as type A packaging for the sources. For transport, the source
holderisxedonatransportboardandprotectedbyawoodenbox.
Dimensions of the transport packaging in mm (in):
• Withoutpneumaticswitchingfacility:380x380x450mm
(15x15x18in)
• Withpneumaticswitchingfacility:380x380x600mm
(15x15x24in)
Warning:
Checkthehoistingequipmentforsucientliftingcapacity,approx.
110 kg (244 lbs)
Persons must never stand beneath the loads.
When transporting, proceed according to the following illustrations.
We recommend using a lift truck or a fork truck for transport to the
place of use.
Packaging
Transport inspection
Transport

15
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
1
3
B
A
2
1
a
b
Fig. 7: Pallet transport of the type A packaging
A Transport with lift truck
B Transport with fork truck
1 Source holder in wooden box
2 Safety latches
3 Fork truck or other lifting vehicle
a Insert slotted screwdriver into the recess
b Lever the slotted screwdriver forward to release the tension lock
For the removal of the source holder, we recommend the use of suit-
able lifting equipment such as lifting bands, crane hooks, etc.
Note:
Additional equipment such as the ON/OFF position switches or a
pneumatic switching ON/OFF change the centre of gravity of the
source holder.
Whenliftingthesourceholderfromthetransportbox,secureit
against tipping with a strap loop on the side.
See the following illustration.

16
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
Fig. 8: Lifting of a source holder with pneumatic ON/OFF switching
• Openthetensionlocksoftheboxlidwithalargeslottedscrew-
driver as shown in the illustration.
• Removetheboxlidandtakelooseaccessoriesoutofthebox.
• Openthetensionlocksonthesidewallsoftheboxwithalarge
slotted screwdriver
• Removethesidewallsoftheboxdowntothebaseplate
• Guide the lifting bands through the ring eyelets on the side of the
source holder
• Remove the transport screw connections to the base plate
• Slowly lift the source holder upwards from the bottom plate using
the lifting bands.
Use the lug of the source holder for transport on a crane hook.Crane transport

17
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
1
Fig. 9: Crane transport of the source holder
1 Lug
Up to the time of installation, the packages must be left closed and
stored according to the orientation and storage markings on the
outside.
Unless otherwise indicated, the packages must be stored only under
the following conditions:
• Not in the open
• Dry and dust free
• Notexposedtocorrosivemedia
• Protected against solar radiation
• Avoiding mechanical shock and vibration
• Ambient temperature for storage and transport see chapter " Sup-
plement - Technical data - Ambient conditions"
• Relative moisture 20 … 85 %
With instrument weights of more than 18 kg (39.68 lbs) suitable and
approved equipment must be used for lifting and carrying.
3.4 Shipment
Radioactive sources are subject to strict regulations. Therefore, when
shipping the sources, we are bound to the respective regulations of
the country where they will be used.
Storage
Storage and transport
temperature
Lifting and carrying
Transport regulations

18
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
Germany
We are only allowed to ship radioactive sources when we have a copy
of the handling permit in hand. We can assist you with the procure-
ment of the necessary documents. If you need help, contact our
responsible sales organisation.
For safety reasons and to save costs, we always ship the source
holder with the source installed. If the operator needs the source
holder in advance, the source has to be shipped separately at a later
time. In such cases, the source is shipped in a transport drum.
Other countries
We are only allowed to ship radioactive sources when we have a copy
of the import license in hand. We can assist you with the procurement
of the necessary documents. If you need help, contact our responsi-
ble sales organisation.
We can only ship to foreign countries when the radioactive source is
mounted in the source holder.
During shipment, the source holder is in switch position " OFF". This
position is secured by a lock.
Transport of the loaded source holder is carried out by a company
authorizedbyus,withocialapprovalforsuchtransports.
The transport is carried out in a type A packaging (source holder) in
compliance with the European and international convention on the
transport of dangerous goods (ADR and DGR/IATA regulations).
3.5 Accessories
Brackets and special mounting accessories are available for mount-
ing the VEGASOURCE 82.
For mounting on pipelines, there are corresponding clamp brackets.
Contactoursalessta.
To protect the switching mechanism of the VEGASOURCE 82 from
dirt or contamination, a metallic protective cap is available.
This also allows the padlock to be permanently protected from dirt,
moisture and corrosion.
The protective cap can only be used on the devices with manual
switching ON/OFF.
The protective cap is available as an accessory and can also be
retrotted.
Mounting accessories
Protective cap

19
3 Product description
VEGASOURCE 82 • Source holder
66076-EN-230810
Fig. 10: Protective cap (optional) to protect against dirt and corrosion
Inordertoexcludeexternalinterferenceradiation,youcanmounta
gamma modulator in front of the source holder. This allows reliable
measurement even when interference radiation occurs.
Fig. 11: Gamma modulator (optional) for uninterrupted measurement even with
interference radiation
1 Gamma modulator (mounted on the source holder)
For ambient temperatures up to +120 °C (+248 °F) the gamma modu-
lator is optionally available with water cooling.
Any number of devices can be synchronized. To synchronize several
gamma modulators, you need a controller.
There is a special label set for the source holder which can be or-
dered as a spare part.
Gamma modulator
Set of labels

20
4 Mounting
VEGASOURCE 82 • Source holder
66076-EN-230810
4 Mounting
4.1 General instructions
• For mounting of VEGASOURCE 82 you need a special handling
permit.
• Mountingmayonlybecarriedoutbyauthorized,qualiedperson-
nelwhoaremonitoredforradiationexposureaccordingtolocal
lawsorthehandlingpermit.Takenoteofthespecicationsinthe
handling permit. Also take the local conditions into account.
• Carry out all work within the shortest possible time and at the larg-
est possible distance. Provide suitable shielding
• Avoid risk to other persons by taking suitable measures (e.g.
safety fence, etc.)
• All mounting and dismounting work must only carried out with the
switch in position " OFF", secured with a lock.
• When mounting, take the weight of the source holder into account.
The device weight can be found in chapter " Technical data".
• Depending on the version, the centre of gravity of VEGASOURCE
82 can vary. Keep this in mind during crane transport on the lug
Mounting with a crane
Warning:
Checkthehoistingequipmentforsucientliftingcapacity.
Youcanndthedeviceweightinthe"Technical data".
Persons must never stand beneath the loads.
The source holder is screwed onto a transport board. Loosen the
screws and lift the source holder from the transport board. For this
purpose you have to use the lug of the source holder.
Use a suitable lifting tackle (shackle, snap hook, etc.) to fasten the
source holder to the crane hook. Keep in mind that the source holder
will tilt sidewards while lifting.
Versions with manual switching ON/OFF
Protect the source holder against moisture and hence against cor-
rosion.Ifthesourceholderisexposeddirectlytotheelements,you
should cover it with a roof or a suitable protective bonnet.
Ifyouexpectheavysoilingordustonthesourceholder,usethe
optional protective cap.
Version with position switches
Use the recommended cables (see chapter " Connecting to power
supply") and tighten the cable gland.
You can give your instrument additional protection against moisture
penetration by leading the connection cable downward in front of the
cablegland.Rainandcondensationwatercanthusdraino.This
applies mainly to outdoor mounting as well as installation in areas
wherehighhumidityisexpected(e.g.throughcleaningprocesses)or
on cooled or heated vessels.
General information
Moisture
