Vega D4A User manual

These installation instructions apply to the VEGA D4A Retrofit Kit models designated below.
D4A 480VAC LED RETROFIT KITS
INSTALLATION GUIDE
Vega Light Control Systems ●Holland, Michigan 49423 20211001
Model
-
Watts
-
CCT
-
Type
-
Acc. Cap
-
Mount
Down/Up
-
Control
-
Custom
Applications
D4A
-
20G
-
22K
-
T5M
-
NA
-
F63 D
-
STD
-
480V Retrofit Kits for Post Top and Pendant
D4A
-
30G
-
30K
-
T3M
-
F65 U
-
DIM
-
Style Luminaires With 19” Globes and
D4A
-
40G
-
40K
F70 Vertical Lamps
D4A
-
50G
-
50K
F80
D4A
-
60G
-
C####
#### - Custom Fitter Specific Mounts
480VAC Fixed Plate D4A
5024806 REV C
AVERTISSEMENT
CAUTION
•WARNING - RISK OF FIRE OR ELECTRIC SHOCK. LUMINAIRES WIRING, POWER SUPPLY, OR OTHER
ELECTRICAL PARTS MAY BE DAMAGED WHEN DRILLING FOR INSTALLATION OF RETROFIT KIT HARDWARE.
INSPECT WIRING AND COMPONENTS FOR DAMAGE.
•WARNING - RISK OF FIRE OR ELECTRIC SHOCK. LED RETROFIT KIT INSTALLATION REQUIRES KNOWLEDGE
OF LUMINAIRES ELECTRICAL SYSTEMS. IF NOT QUALIFIED, DO NOT ATTEMPT INSTALLATION. CONTACT A
QUALIFIED ELECTRICIAN.
•WARNING - RISK OF FIRE OR ELECTRIC SHOCK. INSTALL THIS KIT ONLY IN LUMINAIRES THAT HAVE THE
CONSTRUCTION FEATURES AND DIMENSIONS SHOWN IN THE PHOTOGRAPHS AND/OR DRAWINGS AND
WHERE THE INPUT RATING OF THE RETROFIT KIT DOES NOT EXCEED THE INPUT RATING OF THE
LUMINAIRE.
•WARNING - TO PREVENT WIRING DAMAGE OR ABRASION, DO NOT EXPOSE WIRING TO EDGES OF SHEET
METAL OR OTHER SHARP OBJECTS.
•DO NOT MAKE OR ALTER ANY OPEN HOLES IN AN ENCLOSURE OF WIRING OR ELECTRICAL COMPONENTS
DURING KIT INSTALLATION.
•ONLY THOSE OPEN HOLES INDICATED IN THE PHOTOGRAPHS AND/OR DRAWINGS MAY BE MADE OR
ALTERED AS A RESULT OF KIT INSTALLATION. DO NOT LEAVE ANY OTHER OPEN HOLES IN AN ENCLOSURE
OF WIRINGOR ELECTRICAL COMPONENTS.
•THE RETROFIT KIT IS ACCEPTED AS A COMPONENT OF A LUMINAIRE WHERE THE SUITABILITY OF THE
COMBINATION SHALL BE DETERMINED BY AUTHORITIES HAVING JURISDICTION. PRODUCT MUST BE
INSTALLED BY A QUALIFIED ELECTRICIAN IN ACCORDANCE WITH THE APPLICABLE AND APPROPRIATE
ELECTRICAL CODES. THE INSTALLATION GUIDE DOES NOT SUPERSEDE LOCAL OR NATIONAL
REGULATIONSFOR ELECTRICAL INSTALLATIONS.
•AVERTISSEMENT - RISQUE D’INCENDIE OU DE CHOC ÉLECTRIQUE. LE CÂBLAGE DES LUMINAIRES, LES
BLOCS D’ALIMENTATION OU LES AUTRES COMPOSANTS ÉLECTRIQUES PEUVENT SUBIR DES DOMMAGES
LORS DU PERÇAGE EN VUE D’INSTALLER LA QUINCAILLERIE D’UN NÉCESSAIRE DE MODERNISATION.
VÉRIFIER SI LES CÂBLES ET LES COMPOSANTS SONT ENDOMMAGÉS.
•AVERTISSEMENT - RISQUE D’INCENDIE OU DE CHOC ÉLECTRIQUE. L’INSTALLATION DE CE NÉCESSAIRE DE
MODERNISATION EXIGE UNE PERSONNE FAMILIÈRE AVEC LA CONSTRUCTION ET LE FONCTIONNEMENT
DU SYSTÈME ÉLECTRIQUE DU LUMINAIRE ET DES RISQUES ASSOCIÉS. TOUTE PERSONNE QUI N’EST PAS
QUALIFIÉE NE DOIT FAIRE AUCUNE TENTATIVE D’INSTALLATION ET DOIT CONTACTER UN ÉLECTRICIEN
QUALIFIÉ.
•THIS IS A LINE DRIVEN 480VAC LAMP. DO NOT INSTALLABOVE 480VAC.
•THIS LAMP IS NOT RATED FOR USE WITH HID BALLAST OR EXTERNAL LED DRIVER.
•DO NOT USE WITH STANDARD DIMMERS.
•SUITABLE FOR DAMP LOCATIONS–DO NOT USE WHERE DIRECTLY EXPOSED TO WATER.
•THIS DEVICE IS NOT INTENDED FOR EMERGENCY LIGHTING OR FOR USE WITH
EMERGENCY EXITS.
•PLEASE READ ALL INSTRUCTIONS BEFORE ATTEMPTINGINSTALLATION.
Key: NA –No Up Light
D –Base Down, U –Base Up
Universal Mounting Plates to replace socket mounts: F63 – 6.25”, F65 – 6.5”, F70 – 6.95”. F80 – 7.92”
DIM –Bluetooth control for ON/OFF and setting lamp dim level.
480V –Operates with 480VAC supply voltage

•AVERTISSEMENT - RISQUE D’INCENDIE OU DE CHOC ÉLECTRIQUE. N’INSTALLER CE NÉCESSAIRE QUE
DANS LE LUMINAIRE DONT LES CARACTÉRISTIQUES DE CONSTRUCTION ET LES DIMENSIONS SONT
CONFORME À CELLES ILLUSTRÉES DANS LES PHOTOS ET/OU LES DESSINS ET DONT LA PUISSANCE
D’ENTRÉE NOMINALE DU NÉCESSAIRE DE MODERNISATION NE DÉPASSE PAS CELLE DU LUMINAIRE.
•AVERTISSEMENT - AFIN DE PRÉVENIR L’ENDOMMAGEMENT OU L’ABRASION DES CÂBLES, ÉVITER TOUT
CONTACT ENTRE CES DERNIERS ET LE BORD D’UN OBJET TRANCHANT TEL QU’UNE TÔLE.
•NE PAS FAIRE OU MODIFIER LES TROUS OUVERTS DANS L'ENCEINTE DU CÂBLAGE OU DES COMPOSANTS
ÉLECTRIQUESPENDANT L'INSTALLATIONDU KIT.
•SEULS LES OUVERTURES INDIQUÉES DANS LES PHOTOS ET/OU LES DESSINS PEUVENT ÊTRE FAITS OU
MODIFIÉS À LA SUITE DE L’INSTALLATION DU NÉCESSAIRE. IL EST INTERDIT DE LAISSER D’AUTRES
OUVERTURES DANS UN BOÎTIERDE CÂBLAGE OU DE COMPOSANTSÉLECTRIQUES.
•LE NÉCESSAIRE DE MODERNISATION EST ACCEPTÉ À TITRE DE COMPOSANT D’UN LUMINAIRE LORSQUE
LA PERTINENCE DE LA COMBINAISON DOIT ÊTRE DÉTERMINÉE PAR LES AUTORITÉS COMPÉTENTES. CE
PRODUIT DOIT ÊTRE MIS EN PLACE PAR UN ÉLECTRICIEN QUALIFIÉ CONFORMÉMENT AUX CODES
ÉLECTRIQUES APPROPRIÉS APPLICABLES. LE GUIDE D’INSTALLATION NE SUPPLANTE PAS LES
RÈGLEMENTSLOCAUX OU NATIONAUX EN MATIÈRE D’INSTALLATIONS ÉLECTRIQUES.
Vega Light Control Systems ●Holland, Michigan 49423
FCC:
•NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interferenceat his own expense.
•This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
•Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
•The following two statements apply to Bluetoothunits:
•This transmitter must not be locatedor operating in conjunctionwith any other antenna or transmitter.
•Radio Frequency (RF) Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimumdistance of 20 cm between the radiator and your body.
ISED Canada:
•This device contains license-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s license-exempt RSS(s). Operation is subject to the following two conditions: (1) This device
may not cause interference, and (2) This device must accept any interference, including interference that may cause
undesired operation of the device.
•L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences
et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée
aux deux conditions suivantes : (1) L'appareil ne doit pas produire de brouillage; (2) L'appareil doit accepter tout
brouillage radioélectriquesubi, même si le brouillageest susceptible d'en compromettrele fonctionnement.
•Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
•Attention : Tout changement ou modification non expressément approuvé par la partie responsable de la conformité
pourrait annuler l’autorisation de l’utilisateur d’utiliser l’équipement.
•The following two statements apply to Bluetooth units: / Les deux déclarations suivantes s'appliquent aux unités
Bluetooth:
•This transmitter must not be co-located or operated in conjunctionwith any other antenna or transmitter.
•Cet émetteur ne doit pas être co-implanténi exploité conjointementavec une autre antenne ou un autre émetteur.
•Radio Frequency (RF) Radiation Exposure Statement: / Énoncé d'exposition aux rayonnements des
radiofréquences(RF) :
•This equipment should be installed and operated with minimum distance of 20 cm between the radiator and
your body.
•Cet équipement doit être installé et utilisé avec une distance minimale de 20 cm entre le radiateur et votre
corps.
Link to Supplier’s Declaration of Conformity (SDoC):
•https://vegalightcontrolsystems.com/products/d4a-adaptive-light-source/#tab-id-2
5024806 REV C 20211001

INTENDED APPLICATIONS
1. AType 5 LED Light Engine is best suited to a Refractive Globe. Type 3 Refractive globes will
effectively convert the T5M retrofit kit into a Type 3 distribution in globes such as the Lindy
Type 3 and the Granville Type 3.
2. House side shields are available as needed.
3. The height and light center of the D4A is set at the factory and is not field adjustable. Please
contact Vega customer service for assistance in determining the appropriate height for your
fixture or with any other questions: [e-mail], Phone: [phone]
Vega Light Control Systems ●Holland, Michigan 49423
FIXTURE CONSIDERATIONS AND PLANNING
Base UP
Pendant
style fixtures
Base DOWN
Post Top
style fixtures
If installed in fixture other than intended, contact VEGA customer service to evaluate
applicability to fixture: [e-mail], Phone: [phone]
OR visit www.vegalightcontrolsystems.com for additional reference designs
This D4A Retrofit Kit is designed for vertical use only AND in compatible applications only with
features similar to those pictured here
PRODUCT DESCRIPTION
This D4A Retrofit Kit is designed for direct installation into the intended fixture and will not
require the use of any drills or cutting tools. Do not make or alter any open holes in a wiring
enclosure or electrical components during the kit installation.
Required Toolsand Hardware (Not provided)
•Flat and PhillipsHead Screwdrivers
•Wrenchand/or Hex Keys
•Pliers, Wirestrippers
•Screws retained from fixture
Parts included in kit as needed:
F80
F70
F65
F63
CGVC
CHTL
CSBC
CHSP
Wire Nuts
5024806 REV C 20211001

Vega Light Control Systems ●Holland, Michigan 49423
This is a Line Driven (480VAC) LED Lamp Retrofit Kit
For supplemental installation instructions, see:
https://vegalightcontrolsystems.com/products/d4a-adaptive-light-source/#tab-id-2
A. Disconnect electrical power to the fixture.
B. Follow the Fixture Preparation Steps, above.
C. Bypass the existing HID ballast. Refer also to the wiring diagrams.
Step 1: Remove the lamp socket mounting plate and disconnect the lamp socket wiring at
the ballast. Retain the socket plate screws for installation of the D4A Retrofit Kit.
Step 2: Remove the ballast and disconnect the incoming Line Voltage (Hot) supply wire, the
Neutral supply wire, and the ground wire from the ballast.
Step 3: Connect the Line 1 (480VAC) supply wire to one of the two black lead wires of the
D4A Retrofit Kit and connect the Line 2 (480VAC) supply wire to the 2nd black lead
wire of D4A Retrofit Kit.
Step 4: Connect the D4Aground wire to the existing ground wiring or connect to a chassis
screw in the fixture.
D. Secure the D4A Retrofit Kit to the fixture. Reuse the screws from the fixture to attach the
Retrofit Kit when possible.
E. For Type 3 (T3M) or Bluetooth models, align to street side or house side: Loosen the set screw
in the side of the metal fitting that connects the mast/support tube to the mounting plate. Rotate
the D4A to point in the desired street side or house side direction as indicatedon the part label.
Ensure that the mast/tube remains fully inserted into the fitting. Retighten the set screw.
F. Restore the originallight fixture sealingfor water and insect control. Rainwater must not enter
the wiring compartment.
G. Install Globe. For Type 3 globe, rotate “Street Side” of globe to street.
H. Turn power on to test installation.
INSTALLATION INSTRUCTIONS
5024806 REV C
1. Disconnect electrical power before attempting installation.
2. Remove the fixture globe.
3. Remove internal reflectors or Lite Lid from globe.
4. Clean or replace globe as needed.
5. Remove lamp, original optical components.
6. Inspect the Line Voltage (Hot) supply wire, the Neutral supply wire, and the Ground wire for
damage or deterioration. If damaged or deteriorated, replace prior to installation of retrofit kit.
7. If photocell-controlled, connect unit after external control.
FIXTURE PREPARATION STEPS
Note: Failure to removecomponents
noted, including internal reflectors will
voidproduct warranty
Note: Connect line voltage wires using wire nuts as shown in the wiring diagram
✓Strip wires appropriately for the wire nuts utilized, 3/8” for those included in the kit.
✓The white wire may be either Neutral or Line.
✓The surge protector is integrated in the lamp. Maximum protection is provided when Green
or Green/Yellow wire is tied to the grounding conductor.
Note: For connectingto and configuringmodels that include the Bluetooth Dimming capabilities
go to www.vegalightcontrolsystems.com for information about the VEGA Link IQ D4A smart
phone interface.
20211001

Vega Light Control Systems ●Holland, Michigan 49423
Ballast Bypass
Typical Electrical Configuration Prior to Conversion
Final Configuration –480VAC Fixed Plate
5024806 REV C 20211001
