Veil Echo User manual

1
CoversbyVeil.com
1-833-567-5050
Echo
Baseboard Heater Covers Installation Guide
WARNING
Sharp edges. Watch your ngers.
Made in Canada
WHEN USING ELECTRICAL APPLIANCES, BASIC
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO
REDUCE THE RISK OF FIRE ELECTRIC SHOCK, AND
INJURY TO PERSONS, INCLUDING THE FOLLOWING:
1. Read all instructions before installing or using the
cover.
2. Sharp edges and corners may be present on the
baseboard cover panel. Any sharp edges will be
covered after installation using the proper end cap.
Please use caution during installation to avoid injury.
3. To avoid re do not block air intakes or exhaust
in any manner.
4. Do not insert or allow foreign objects to enter
any ventilation or exhaust opening as this may
cause and electric shock or re, or damage the
heater.
5. This heater cover is hot when in use. To avoid
burns, do not let bare skin touch hot surfaces. Keep
combustible materials such as furniture, pillows,
bedding, papers, and curtains away from heater.

2
1
2
Remove old cover.
If you do not have an existing back plate, see page 4
instructions for installing with mounting brackets.
Install the new panel
a
b

3
CoversbyVeil.com
1-833-567-5050
3Install the end caps
a
b

4
If you do not have an existing back plate, you can use the
mounting bracket add-on:
Done!
1Screw the bracket in to the wall 2Install the panel and proceed
with end cap instructions
(Step 3 on Page 3)

3/4” or more
5
CoversbyVeil.com
1-833-567-5050
Please make sure there is a clearance of at least 3/4 inches
between the heater cover and the oor to insure proper air ow.
Echo covers don’t require couplers to join panels. Here’s
how we recommend you join multiple panels:
Heater
Length
Recommended
Cover Conguration
2ft 2ft
3ft 3ft
4ft 2ft + 2ft
5ft 2ft +3ft
6ft 3ft + 3ft
7ft 2ft + 3ft + 2ft
8ft 3ft + 2ft + 3ft
9ft 3ft + 3ft + 3ft
10ft 2ft + 3ft + 3ft + 2ft
11ft 2ft + 2ft + 3ft + 2ft +2ft
12ft 3ft + 3ft + 3ft + 3ft
13ft 2ft + 3ft + 3ft + 3ft + 2ft
14ft 3ft + 3ft + 2ft +3ft + 3ft
15ft 3ft + 3ft + 3ft + 3ft + 3ft

6
You can join to adjacent panels at an angle using the
corner pieces:
1
a
b
2
