VelectriX Rear hub Series User manual

MY23 VelectriX Instruction Manual
(rear hub series)
•Stray

Page 1
Contents
Safe Riding Recommendations
Page 2
Pre-Ride Checklist
Page 3
Display and Controls
Pages 4-6
Battery Instructions
Page 7-11
Maintenance
Pages 12
Warranty
Page 13-15
Model Specification
Pages 16

Page 2
Safe Riding Recommendations
1. Please ensure you are familiar with and follow all traffic laws
and regulations for your state. Please remember you may need
to review these when travelling interstate.
2. Always wear a helmet when riding your bike.
3. Don’t lend your bike to anyone who is unfamiliar with it.
4. As with all bikes it is important that you stay within safe limits
and speeds.
5. Please read and become familiar with the “Pre-Ride Checklist”
in this manual before riding your bike.
6. Switch the lights on your bike on when riding at all times of the
day or night. If your bike doesn’t have lights fitted as standard,
it is recommended that you purchase them and fit before riding.

Page 3
Pre-Ride Checklist
1. Check over the bike for any loose nuts, bolts, or fixings.
2. Check the tyre pressure. Please always refer to the tyre
manufactures suggested levels on the side of the tyre.
3. Check the tyres for any visible damage, wear and tear or bald
spots.
4. Check that the brake levers have been installed correctly on
your bike. The left-hand brake lever should operate the rear
brake and the right-hand brake lever should operate the front
brakes.
5. Check that the brakes are working effectively.
6. Check that the bike is fitted with a working bell and reflectors.
7. Check that the wheel nuts or quick release skewers on the bike
are correctly fitted and sufficiently tight.
8. Check that the electronic functions on the bike are working.
9. Check that the handlebars and stem are correctly fitted and
sufficiently tight.
10. Check all accessories and luggage are securely fastened.
11. Check that the battery has sufficient charge for your ride.

Page 4
Display and Controls
The bike is operated by an integrated control button, fitted into the top tube,
with 5 main functions:
•Switching the bike ON/OFF
•Selecting the level of support (power)
•Switching the lights ON/OFF (if bike is equipped with lights)
•Battery capacity indication
•Error code detection
Switching The Bike ON/OFF
Press the button on the display for 2 seconds. The green circle will
illuminate. Repeat to switch the bike off.

Page 5
Select The Level Of Support (Power)
When the display is turned on, press button for 1 second to switch the level
of support to increase/decrease the output of the motor. The lowest level is 1
(Cyan colour), medium is 2 (blue colour) and the highest level is 3 (purple colour)
Battery Capacity Indication
The current battery capacity is displayed when the bike is first switched ON and
will also be displayed during riding as below.

Page 6
Switching The Lights ON/OFF
Turn ON: When the display is turned on, double click the button to turn
the lights on.
Turn OFF: When the display is turned on and the lights are turned on, double
click the button to turn the lights off
Error Code Detection
In the event that the bike develops an error/fault, the display will flash with a
series of blue and cyan colours. Please contact the VelectriX dealer where you
purchased the bike, so they can resolve the issue.

Page 7
Battery Instructions
To check how much charge the battery has, press the button on the battery
top. The battery charge light will illuminate. The colour of the LED indicates
the level of battery charge:
oBlue = More than 90% charge
oGreen = 40 –90% charge
oRed = 20 –40% charge
oFlashing Red = Less than 20% charge
Locking & Unlocking the Battery
The bike is supplied with a set of keys, that are required to remove the
battery from the bike. The lock is located at the top of the battery, in the
frame of the bike.
Removing the Battery from the Bike
To remove the battery, insert the key and turn fully clockwise. Pull the
battery straight up & out from the bike. When reinserting the battery,
place the base in first and push down gently on the top to engage the
lock. You will hear the lock “click” into place.
Always make sure the battery is securely locked in place before riding

Page 8
Battery Care
Rechargeable Lithium-Ion batteries have a limited life and will gradually
lose their capacity to hold a charge. This loss of capacity (ageing) is
irreversible. As the battery loses capacity, the length of time it will power
the bike (ride time) decreases. The typical estimated “healthy life” of a
Lithium-Ion battery is about three years or 500 charge cycles, whichever
occurs first. One charge cycle is a period of use from fully charged, to fully
discharged, and fully recharged again.
Battery Charging
Simply charge your battery any time you feel you need to use it.
The batteries should be charged at room temperature in a dry location
where a smoke detector is installed. Batteries must not be charged in the
vicinity of heat sources or flammable materials. After charging, batteries
and chargers should be disconnected from the power supply.
Factors That Shorten Battery Life
Factors That Lengthen Battery Life
•Heavy-load use
•Low-load use
•Storage at over 30°C temperature
•Storage at a temperature between
10° and 20°
•Parking the ebike in direct sunlight
•Parking the ebike in the shade or
a cool location
•Prolonged storage (more than 30
days without use) in a fully
charged or discharged state
•Storage (more than 30 days
without use) at approx. 30-60%
battery capacity

Page 9
If you are charging your battery on the bike, with the bike turned off, insert
the charging plug into the charging port on the bike. Connect the battery
charger power plug to the mains power outlet and switch the mains power
on. You will then see 2 red lights to show that it is successfully charging.
One of the lights will then turn green, once the battery is fully charged. Turn
off the power outlet and remove the battery charger from the bike.
If you are charging the battery off the bike, firstly ensure that the power on
the bike is switched off and carefully remove the battery from the bike.
Insert the charging plug into the charging port on the battery. Connect the
battery charger power plug, to the mains power outlet and switch the mains
power on. You will then see 2 red lights to show that it is successfully
charging. One of the lights will then turn green, once the battery is fully
charged. Turn off the power outlet and remove the charger from the battery.
Battery Charger
You should only use the battery charger that is supplied, as new, with the
bike
Battery Maintenance
•On the first ride of your new bike, observe and note the ride time
that a new fully-charged battery provides for powering your bike,
measured in distance travelled, not time. Use this distance as a basis
to compare future ride times.
•Routinely check the battery’s charge status.
•Carefully monitor batteries that are approaching the end of their
estimated life. Consider replacing the battery with a new one if you
note either of the following conditions:
oThe battery run time drops below about 60-70% of the
original run time.
oThe battery charge time increases significantly.
