Ventair SPINIKA Series User manual

1
INSTRUCTION MANUAL
(This photo is for reference only; it does not mean you are purchasing an identical product.
Fan picture is for illustration purposes only. Styles may vary according to the model.)
Ceiling Fan Installation Manual, Rev 1.0
SPINIKA SERIES
Models:
SPN1204WH SPN1204WH-L
SPN1204TI SPN1204WH-L
SPN1204BL SPN1204BL-L
SPN1304WH SPN1304WH-L
SPN1304TI SPN1304TI-L
SPN1304BL SPN1304BL-L
l INSTALLATION
l OPERATION
l MAINTENANCE
l WARRANTY
INFORMATION
CAUTION
Read Instructions Carefully
For Safe Installation and
Fan Operation

2
THANK YOU FOR PURCHASING
Thank you for purchasing this quality Ventair ceiling fan. To ensure correct function and safety, please read all
instructions before using the product and keep all instructions for future reference.
SAFETY PRECAUTIONS
The information contained in the following pages has been prepared to ensure you of trouble-free operation of your
ceiling fan.
1. To en su r e th e su cc e ss o f th e in s t a l l at io n, be sure to read the instruction and study the diagrams thoroughly.
2. All electrical work should only commence after disconnection of the power. Remove fuses or turn off the circuit
breaker to ensure all pole isolation of the electrical supply.
3. Make sure that your installation site will not allow the rotating fan blades to come into contact with any object and
that there is a minimum clearance of 150mm from the blade tip to the wall or ceiling .Please note that the greater
the clearance around the fan, the better the airflow will be.
4. The fixing point for the fan must be able to support the weight of 4 times that of the net weight of the fan.
5. Do not connect the fan motor to a dimmer switch. This may give an unsatisfactory performance (motor hum) and
cause damage to the motor.
6. It is not recommended that ceiling fans and gas appliances be operated in the same room at the same time.
7. The fan must be turned off and stopped completely before reversing the fan direction. This will prevent any damage
to the motor of the unit or controller (if installed).
8. Do not insert anything into the fan blades while the fan is operating. This will damage the blades and upset the
balance of the unit causing the unit to wobble.
9. After the fan is completely installed make sure that all connections are secured and tightened to prevent any
problems.
10. Because of the fan’s natural movement, some connections may loosen. Check the support connections, brackets
and blade attachments twice a year to make sure they are all secured. If they are loose, tighten with a screwdriver.
11. Always have your fan installed by a licensed electrician.
12. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
13. Children should be supervised to ensure that they do not play with the appliance.
14. That the fan is to be installed so that blades are 2.1m or more above the floor.
IMPORTANT:
This fan is suitable for indoor/ fully covered outdoor use only.
An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local wiring rules.

3
SPECIFICATION
MODEL
Light Wattage
(W)
Fan Wattage
(W)
Voltage
(V)
Frequency
(Hz)
Net Weight
(Kg)
SPN1204WH
SPN1204TI
SPN1204BL
No Light
60 watts
220-240 V
50 Hz
7.35 kg
SPN1204WH-L
SPN1204TI-L
SPN1204BL-L
20 watts
60 watts
220-240 V
50 Hz
7.45 kg
SPN1304WH
SPN1304TI
SPN1304BL
No Light
65 watts
220-240 V
50 Hz
7.55 kg
SPN1304WH-L
SPN1304TI-L
SPN1304BL-L
20 watts
65 watts
220-240 V
50 Hz
7.65 kg

4
PARTS LIST
Unpack the fan and carefully identify the parts. Please refer to Fig 1
Note: Part List number 9 and 10 is for fan with light model.
INSTALLATION
Mounting Plate Hanging System
1. Ceiling Joist
2. Canopy
3. Ter m in al B l o c k an d Mo u nt in g Pl a t e
4. Earth Wire
5. Hanger Ball
6. Downrod
Please ensure the fixing tab fits into the
groove of the hanger ball.
Part
Pcs
1.Motor Assembly
1
2.Blade Assembly Set
4
3.Down Rod
1
4.Lower Canopy
1
5.Upper Canopy
1
6.Speed Regulator
1
7.Fascia
1
8.Hang-Sure Set
1
9.LED light drive
1
10.LED light panel
1
Fig. 1

5
INSTALLING THE CANOPY
Fit upper canopy about 5mm off the ceiling. To a vo id u nw a nt ed n oi s e , secure it into position with canopy screw.
CHANGING THE LED LIGHT TEMPERATURE
The LED on the fan with light models have a distinctive switch to
change between three colour temperatures – Warm, Natural
and Cool.
Twist the diffuser anti clockwise to remove, you will see the tri
colour switch button on the LED panel. Press the button once,
the light colour will change, press again and the light color will
change again. It’s circulation changes from Cool white, Natural
and Warm White.
USING A STANDARD WALL CONTROL
1. Turn control know for fan speeds Eco/Med/High
2. Flick switch to ‘On’ Light will be 100%
3. While ‘On’ flick switch ‘Off’ then ‘On’ again within 2 seconds, the light will drop down to be at
75%. Continue the same process to reach 50% and 25% light level.
NOTE: If light switch is ‘Off’ for more than 2 seconds, the light will revert to 100% light setting
when next operated.

6
WITH REMOTE CONTROL
Model: SPNRFR
1. Use Eco/Med/High buttons to alter the fan speed.
2. “OFF” button will turn the fan off only
3. Turn Light “ON/OFF” for light.
4. Press the “STEP DIM” button to transition through 75%, 50%, 25% then
back to 100% of light output.
WIRING DIAGRAM FOR WALL CONTROLER
WARNING: FOR YOUR SAFETY, ENSURE THE MAINS SUPPLY IS SWITCHED OFF TO THE WIRING
CIRCUIT BEFORE PERFORMING ANY ELECTRICAL TASKS.
PLEASE ENSURE YOU CHOOSE THE CORRECT WIRING DIAGRAM IN ACCORDANCE TO YOUR
APPLICATION.
HIGH
E C O
MED
Fan Speed
Switch
Light Switch
FOR LIGHT-L
Black
TO 240V/50Hz
Brown
FOR FAN-L
Brown
To Light Circuit
220-240V AC
supply input
TO Fan Circuit(L)
(ACTIVE)

7
WIRING DIAGRAM FOR MOUNTING BRACKET TERMINAL & WALL CONTROL
All pole disconnection switch must be included in the fixed wiring.
WIRING DIAGRAM FOR ISOLATION SWITCH WITH REMOTE CONTROL
All pole disconnection switch must be included in the fixed wiring.
Step 1. Connect EARTH wire to the terminal port marked“ ” on the terminal block mounting bracket.
Step 2. Connect the supply LIVE wire to the wall controller terminal port labeled “TO 240V/50Hz”.
Step 3. Connect a wire from the Fan Live “L” from the terminal block mounting bracket, to the terminal port
labeled “FOR FAN-L” on the wall controller.
Step 4. Connect a wire from the Light Live “ ” from the terminal mounting bracket, to the terminal port labeled
“FOR LIGHT-L” on the wall controller. Note: The fan light wiring is only applicable to fan models with a light
kit.
Step 5. Connect the supply Neutral wire to the terminal port marked “N” on the terminal block mounting bracket.
Once all the above steps have been followed, you are now ready to restore the mains power supply. Make sure
there is nobody near or under the fan, then turn on (and light switch if included in your model) to test.

8
REPLACING THE LED PANEL
ATTACHING REMOTE RECEIVER
SPNRFR Available as optional Extra.
WARNING: FOR YOUR SAFETY, ENSURE THE MAINS SUPPLY IS SWITCHED OFF TO THE WIRING
CIRCUIT BEFORE PERFORMING ANY ELECTRICAL TASK.

9
INSTALLATION TIPS
• Only use the included wall control plate - using other wall control plate will void warranty and may
damage the fan.
• Do not use a solid-state dimmer control.
• Do not use the light switch (if included) to control the fan motor;
• The wall control shall fit into existing gang block or wall plate. If you do not flush mount
• the control use a standard single gang mounting block.
• Be careful not to mix the supply live and the fan live connection. Reverse connection of the speed
control will affect the correct operation of the fan.
• After the wiring connections are completed, ensure that all wires are arranged in a tidy manner and
make sure the ball sits well into the bracket, this is important to reduce your fan from wobbling.
OPERATION
To tu rn the fan on, simply tur the switch knob to the (1,2,3) position.
To turn the fan off, turn the switch knob the (OFF) position.
Troubleshooting
Check and inspect the motor, the down rod and other components for shaking, abnormal sound and vibration when
operating.
Please check position of the blade.
• Change position of the blade.
• Check and make even height of three blades.
• (The difference of blades to be within 5mm)
• Check looseness of screws, bolts and nuts.
Change blade
Check height

10
Maintenace
• Use this in a dry place, free of excessive humidity and water.
• Keep the fan clean. Wipe away dirt with a clean soft cloth, ordinary soap and water, wipe dry. Do not use
solvents, etc. (gasoline or petroleum.)
• Make sure to disconnect the power supply before cleaning and maintenance is carried out.
• Ensure that the fan is switched off from the supply mains before removing the guard.
The points described below should be checked, and corrected if necessary, once each year:
Do the motor, piping or other components shake or vibrate abnormally?
Shaking and abnormal vibration can be caused if the blade holding screw or screws for the suspended part
are loose, or if a blade is deformed, if a blade is deformed, all 3 blades should be replaced as a set.
Is there any unusual noise?
Are the blade holding screw or screw for the suspended part loose? Is the canopy in contact with ceiling
surface?
WARNING:
If at any stage the fan develops excessive wobbling, contact the manufacturer its service agent or suitably qualified
persons.
NIGHT NOISE
This is the biggest cause for service calls, which are outside the manufacturer’s warranty. If a fan has a fault, it will
be noticeable at all times. Naturally when everything is quite at night, you will be more inclined to hear small noises,
which may not be noticeable at other times. Even slight power fluctuations and/or mains frequency control signals
superimposed in your electricity supply for off-peak hot water control may cause a change in fan motor noise. This
is normal.
Do not dispose of electrical products with household waste. Please check with your local council
for advice on disposal or recycling. If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the groundwater and get into the food chain, damaging
your health and well-being.
4 CAPITAL PLACE
CARRUM DOWNS VIC 3201
PHONE: [phone]
FAX: [phone]
