USER’S MANUAL
VSK
Sound-insulated kitchen fan

2
VSK
www.ventilation-system.com
CONTENTS
This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the VSK unit and all its
modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should be able to
work in accordance with workplace safety rules as well as construction norms and standards applicable in the territory of the country.
Purpose................................................................................................................................................................................................ 4
Delivery set........................................................................................................................................................................................ 4
Designation key.............................................................................................................................................................................. 4
Technical data.................................................................................................................................................................................. 5
Design and operating principle ........................................................................................................................................... 9
Mounting and set-up.................................................................................................................................................................. 10
Connection to power mains .................................................................................................................................................. 11
Commissioning............................................................................................................................................................................... 12
Technical maintenance.............................................................................................................................................................. 12
Troubleshooting............................................................................................................................................................................. 13
Storage and transportation regulations.......................................................................................................................... 13
Manufacturer’s warranty........................................................................................................................................................... 14
Certificate of acceptance.......................................................................................................................................................... 15
Seller information.......................................................................................................................................................................... 15
Installation certificate.................................................................................................................................................................. 15
Warranty card................................................................................................................................................................................... 15

3
www.ventilation-system.com
All operations described in this manual must be performed by qualified personnel only, properly
trained and qualified to install, make electrical connections and maintain ventilation units.
Do not attempt to install the product, connect it to the mains, or perform maintenance yourself.
This is unsafe and impossible without special knowledge.
Disconnect the power supply prior to any operations with the unit.
All user’s manual requirements as well as the provisions of all the applicable local and national
construction, electrical, and technical norms and standards must be observed when installing
and operating the unit.
Disconnect the unit from the power supply prior to any connection, servicing, maintenance, and
repair operations.
Only qualied electricians with a work permit for electrical units up to 1000 V are
allowed for installation. The present user’s manual should be carefully read before
beginning works.
Check the unit for any visible damage of the impeller, the casing, and the grille before starting
installation. The casing internals must be free of any foreign objects that can damage the
impeller blades.
While mounting the unit, avoid compression of the casing! Deformation of the casing may result
in motor jam and excessive noise.
Misuse of the unit and any unauthorised modifications are not allowed.
Do not expose the unit to adverse atmospheric agents (rain, sun, etc.).
Transported air must not contain any dust or other solid impurities, sticky substances, or fibrous
materials.
Do not use the unit in a hazardous or explosive environment containing spirits, gasoline,
insecticides, etc.
Do not close or block the intake or extract vents in order to ensure the efficient air flow.
Do not sit on the unit and do not put objects on it.
The information in this user’s manual was correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration
of its products at any time in order to incorporate the latest technological developments.
Never touch the unit with wet or damp hands.
Never touch the unit when barefoot.
BEFORE INSTALLING ADDITIONAL EXTERNAL DEVICES, READ THE RELEVANT USER MANUALS.
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.

4
VSK
www.ventilation-system.com
THE UNIT SHOULD NOT BE OPERATED BY CHILDREN OR PERSONS WITH REDUCED
PHYSICAL, MENTAL, OR SENSORY CAPACITIES, OR THOSE WITHOUT THE APPROPRIATE
TRAINING.
THE UNIT MUST BE INSTALLED AND CONNECTED ONLY BY PROPERLY QUALIFIED
PERSONNEL AFTER THE APPROPRIATE BRIEFING.
THE CHOICE OF UNIT INSTALLATION LOCATION MUST PREVENT UNAUTHORISED
ACCESS BY UNATTENDED CHILDREN.
DESIGNATION KEY
The Sound-insulated kitchen fan is designed for exhaust ventilation of kitchens, industrial bakeries, etc. with high temperature and noise
requirements and limited installation space. The fan extracts contaminated hot air up to 120 °C, containing grease, in high resistance
conditions.
The fan is rated for continuous operation.
The fan is a component part and is not designed for stand-alone operation.
The transported air must not contain flammable or explosive mixtures or chemically active vapours.
NAME NUMBER
Fan 1 pc
User’s manual 1 pc
Packing box 1 pc
PURPOSE
DELIVERY SET
VSK 315 4E
Name
VSK - sound-insulated kitchen fan (120 ˚С)
Diameter
Turbine size [mm]
Poles
Number of poles
Phases
E: single-phase
D: three-phase

5
www.ventilation-system.com
The fan is designed for exhaust ventilation of rooms with air temperature from -25 °C to +120 °C.
The unit is rated as a Class I electrical appliance.
The unit design is constantly being improved. thus some models may be different from those described in this manual.
Ingress protection rating of the motor against access to hazardous parts and water ingress is IPX4.
Ingress protection rating of the fan against access to hazardous parts and water ingress is IPX4.
TECHNICAL DATA

6
VSK
www.ventilation-system.com
H1
L1
B1
L
H
B
C
A
Model Dimensions [mm] Weight
[kg]
L L1 H H1 B B1 A C
VSK 315 2D 500 538 500 538 500 538 200 440 41
VSK 315 2E 500 538 500 538 500 538 200 440 40.2
VSK 315 4D 500 538 500 538 500 538 200 440 37.2
VSK 315 4E 500 538 500 538 500 538 200 440 37.2
VSK 355 4D 600 638 600 638 600 638 225 540 48.1
VSK 355 4E 600 638 600 638 600 638 225 540 47.4
VSK 400 4D 670 708 670 708 670 708 252 610 58.1
VSK 400 4E 670 708 670 708 670 708 252 610 60.3
VSK 450 4D 700 738 700 738 700 738 282 640 73.3
VSK 450 4E 700 738 700 738 700 738 282 640 71.8
VSK 500 4D 820 858 820 858 820 858 321 760 101.8
VSK 500 4E 820 858 820 858 820 858 321 760 96.3
VSK 560 4D 900 938 900 938 900 938 365 840 130.3
VSK 630 4D 1000 1038 1000 1038 1000 1038 409 940 173.8
VSK 710 6D 1075 1152 1075 1114 1075 1112 455 1015 210
VSK 710 4D 1075 1152 1075 1114 1075 1112 455 1015 240
VSK 800 6D 1175 1252 1175 1214 1175 1212 505 1115 275

7
www.ventilation-system.com
FAN OPTIONS
VVG VSK
D1
a
a/
2
D
D2
d xn
260
Model Dimensions [mm] Weight
[kg]
D D1 D2 n a d
VVG VSK 315 315 365 405 6 60 8 4.76
VVG VSK 355 355 395 435 8 45 10 4.08
VVG VSK 400 400 450 490 12 30 8 4.76
VVG VSK 450 450 500 540 12 30 8 5.34
VVG VSK 500 500 560 600 12 30 12 6.12
VVG VSK 560 560 620 660 12 30 12 6.83
VVG VSK 630 630 690 730 12 30 12 7.66
VVG VSK 710 710 770 810 16 22.5 12 8.6
VVG VSK 800 800 860 900 16 22.5 12 9.67
MK VSK
A
A
B
11
C
15
M
14
2 x
13
12
27
12
6,4
N
Model Dimensions [mm]
A B C N M
MK VSK 315...450 75 2 100 29 16
MK VSK 500...800 85 3 110 30 18

8
VSK
www.ventilation-system.com
VPR VSK
101
16
74
25
L
L1
Model Dimensions [mm] Weight
[kg]
L L1
VPR VSK 315 503 522 2.42
VPR VSK 355 603 622 3.25
VPR VSK 400 673 692 3.91
VPR VSK 450 703 722 4.21
VPR VSK 500 823 842 6.57
VPR VSK 560 903 922 7.71
VPR VSK 630 1003 1022 9.27
VPR VSK 710 1078 1097 10.53
VPR VSK 800 1178 1197 12.3
PK VSK
b°
D1
a
°
100
D
d xn
D2
Model Dimensions [mm] a0b0Weight
[kg]
D D1 D2 d n
PK VSK 315 315 365 405 8 6 15 60 1.7
PK VSK 355 355 405 445 8 6 15 60 1.9
PK VSK 400 400 450 490 8 12 15 30 2.13
PK VSK 450 450 500 540 8 12 15 30 2.39
PK VSK 500 500 560 600 12 12 15 30 2.75
PK VSK 560 560 620 660 12 12 15 30 3.06
PK VSK 630 630 690 730 12 12 15 30 3.44
PK VSK 710 710 770 810 12 16 11.25 22.5 3.86
PK VSK 800 800 860 900 12 16 11.25 22.5 4.34

9
www.ventilation-system.com
The fan casing is made of an aluminium frame fastened with aluminium corners and removable heat- and sound-insulated double-layer
panels made of aluzinc.
Thanks to its corrosion-resistant aluzinc casing and heat-insulation material, the fan is suitable for outdoor installation.
The VSK fan is equipped with an asynchronous motor with an external rotor and a centrifugal impeller with backward curved blades.
The fan has a special design that allows you to change the position of the side panels for air supply in directions at an angle of 90°.
Motor
Frame
Panel Terminal box
When connecting the fan to the air duct system, it is recommended to use the accessories specified in the User’s manual.
Connecting spigots, which also serve as vibration damping inserts, can be of square or round cross-section.
Spigots of round cross-section are equipped with rubber seals.
Connecting spigots are not included in the delivery set, they are ordered separately.
DESIGN AND OPERATING PRINCIPLE

10
VSK
www.ventilation-system.com
Before installing the fan, make sure that there is no visible damage to the impeller and check the integrity of the insulation of the power
supply wires.
The impeller must rotate freely without touching the flange and casing.
The fan must be installed in an air duct of similar diameter.
The fan must be mounted in such a way that the direction of the air flow arrow on the fan casing coincides with the direction of air in the
system. The fans are installed between the air ducts.
The connection to the air ducts is carried out using an appropriately sized flexible adapter.
In case of mounting the fan on flexible joints, attach the fan to a structural unit by means of brackets.
The fan can be mounted in any position according to the direction of air flow (indicated by the arrow on the fan casing).
To attain the best performance of the fan and to minimize turbulence-induced air pressure losses while mounting, connect the straight
air duct section to the fan spigots on both sides of the fan. The minimum straight air duct length is equal to 1 air duct diameter on the
intake side and 3 air duct diameters on the exhaust side.
No filters or other devices must be installed in these sections.
The fan is not a ready to use unit and requires connection to the air ducts.
Install the fan securely while ensuring free access for maintenance operations, the required distance to the walls of the room is at
least 1 m.
The VSK fan is equipped with a drain fitting for connection to the drainage system.
Fan installation sequence:
• Before installation, route the wires and cables necessary to connect the fan to the mains.
• Make sure that the motor is not energized.
• Fasten the MK VSK brackets in accordance with the supporting plane (structure).
• Fix the fan to the MK VSK mounting brackets using suitable fasteners (e.g. dowels).
• Connect the air ducts to the fan.
Mounting of MK VSK brackets The fan can be mounted on a
horizontal plane
If installed outdoors, the
fan can be equipped with a
protective hood - VPR VSK
Installation of the drain fitting
The MK VSK brackets and the VPR VSK protective hood are not included in the delivery set and must be ordered separately.
WHILE INSTALLING THE UNIT ENSURE CONVENIENT ACCESS FOR SUBSEQUENT
MAINTENANCE AND REPAIR.
BEFORE MOUNTING MAKE SURE THE CASING DOES NOT CONTAIN ANY FOREIGN
OBJECTS E.G. FOIL, PAPER.
MOUNTING AND SETUP
